MOKENEYE PW01Z User manual

20V CORDLESS PRESSURE WASHER
Model PW01Z
WARNING:To reduce the risk of injury, the user must read and understand the
Owner'sManualbeforeusingthisproduct.Savetheseinstructionsforfuturereference.
For Customer Service [e-mail]
Owner’s Manual
VERSION: PW01Z-EN-01

2
TABLE OF CONTENTS
SPECIFICATIONS ....................................2
GENERAL SAFETY WARNINGS................2
SAFETY WARNINGS FOR PRESSURE
WASHER................................................3
SYMBOLS ..............................................4
GET TO KNOW YOUR TOOL ...................6
OPERATING INSTRUCTIONS.................10
PRESSURE WASHING...........................12
MAINTENANCE....................................13
TROUBLE SHOOTING ...........................13
LIMITED WARRANTY ...........................13
SPECIFICATIONS
Rated Voltage
20V d.c.
Working pressure with diffuser
nozzle
320 Psi
Working pressure with straight
nozzle
350 Psi
Spray angle of diffuser nozzle
40°
Spray angle of straight nozzle
< 3°
Rated Gallons per Minute
1.27
Suction Hose
20 ft (6 m)
Recommended working
temperature
40~104°F
4~40oC
Recommended storage
temperature
40~104°F
4~40oC
GENERAL SAFETY WARNINGS
Read all safety warnings, instructions, illustrations
and specifications provided with
this power tool. Failure to follow
all instructions listed below may result in electric.
SAVE ALL WARNINGS AND
INSTRUCTIONS FOR FUTURE REFERENCE.
The term "power tool" in the warnings refers to
your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
WORK AREA SAFETY
⚫Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
⚫Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
⚫Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
ELECTRICAL SAFETY
⚫Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
⚫Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
⚫Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
⚫Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
⚫When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
⚫If operating a power tool in a damp location is
unavoidable, use a ground fault circuit
interrupter (GFCI) protected supply. Use of a GFCI
reduces the risk of electric shock.
PERSONAL SAFETY
⚫Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power
tools may result in serious personal injury.
⚫Use personal protective equipment. Always wear
eye protection. Protective equipment such as a
dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate
conditions will reduce personal injuries.
⚫Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your
finger on the switch or energizing power tools
that have the switch on invites accidents.
⚫Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.

3
⚫Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
⚫Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving
parts.
⚫If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust- related hazards.
⚫Do not let familiarity gained from frequent use of
tools allow you to become complacent and
ignore tool safety principles. A careless action
can cause severe injury within a fraction of a
second.
POWER TOOL USE AND CARE
⚫Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
⚫Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and
must be repaired.
⚫Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any
adjustments, changing accessories, or storing
power tools. Such preventive safety measures
reduce the risk of starting the power tool
accidentally.
⚫Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
⚫Maintain power tools and accessories. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition that
may affect the power tool's operation. If
damaged, have the power tool repaired before
use. Many accidents are caused by poorly
maintained power tools.
⚫Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
⚫Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed. Use of the power
tool for operations different from those
intended could result in a hazardous situation.
⚫Keep handles and grasping surfaces dry, clean
and free from oil and grease.
⚫Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool
in unexpected situations.
BATTERY TOOL USE AND CARE
⚫Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one
type of battery pack may create a risk of fire
when used with another battery pack.
⚫Use power tools only with specifically designated
battery packs. Use of any other battery packs
may create a risk of injury and fire.
⚫When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another. Shorting the battery terminals together
may cause burns or a fire.
⚫Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause
irritation or burns.
⚫Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
⚫Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or
temperature above 265 °F may cause explosion.
⚫Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the instructions.
Charging improperly or at temperatures outside
the specified range may damage the battery and
increase the risk of fire.
SERVICE
⚫Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the
power tool is maintained.
⚫Never service damaged battery packs. Service of
battery packs should only be performed by the
manufacturer or authorized service providers.
SAFETY WARNINGS FOR PRESSURE
WASHER
IMPORTANT SAFETY INSTRUCTIONS
When using this appliance, basic safety precautions
should always be followed including the following:
-Read all the instructions before using the
product.
-To reduce the risk of injury, close supervision is
necessary when a product is used near children.
-Know how to stop the product and bleed
pressures quickly. Be thoroughly familiar with the
controls.
-Stay alert –watch what you are doing.
-Do not operate the product when fatigued or
under the influence of alcohol or drugs.
-Keep operating area clear of all persons.

4
-Do not overreach or stand on unstable support.
Keep good footing and balance at all times.
-Follow the maintenance instruction specified in
the manual.
Risk of Injection or Injury
-Do Not Direct Discharge Stream at Persons.
Risk of Injection or Severe Injury.
-Keep Clear of Nozzle.
-Do Not Direct Discharge Stream at Persons.
-This Product Is to be Used Only by Trained
Operators.
SAVE THESE INSTRUCTIONS
◼Read this entire manual before attempting to
assemble, operate or install the product.
◼This unit was designed for specific applications.
It should not be modified and/or used for any
application other than that which it was
designed.
NOTICE: Always store your pressure washer in a
location where the temperature will not fall below
40 °F (4 °C). freeze damage is not covered by the
warranty.
-Avoid accidental starts. Move switch on unit to
OFF position before connecting or disconnecting
battery pack.
-Water spray must never be directed towards
any electric wiring or fatal electric shock may
occur.
-The narrow pin point stream is very powerful. It
is not recommended for use on painted
surfaces, wood surfaces or items attached with
an adhesive backing.
-Keep operating area clear of all persons and
animals.
-Always use both hands when operating pressure
washer to maintain complete control of the
wand.
-Do not touch nozzle or water spray while
operating. Never place hands in front of nozzle.
-Wear safety goggles while operating. Wear
protective clothing and footwear to protect
against accidental spraying.
-Disconnect battery pack when not in use and
prior to the detaching of the high-pressure hose.
-Do not operate or store this product in
temperatures below 40 °F (4 °C). Freeze damage
is not covered by the warranty.
-Carefully observe all chemical instructions and
warnings before using. Use only approved
pressure washer cleaners. Do not use bleach,
chlorine, or any cleaners containing acids.
Always follow manufacturer's label
recommendations for proper use of cleaners.
Always protect eyes, skin and respiratory system
from cleaners.
-The pressure washer should not be used in areas
where gas vapors may be present. An electric
spark could cause an explosion or fire.
-To prevent accidental discharge, the spray gun
should be secured by locking the trigger when
not in use.
-Use only hoses and accessories rated for pressure
higher than your pressure washer's psi. Never
use with any other manufacturer's accessories
or components.
-Never defeat the safety features of this product.
-Do not operate machine with missing, broken or
unauthorized parts.
-Never spray flammable liquids or use pressure
washer in areas containing combustible dust,
liquid, or vapors.
SYMBOLS
SAFETY SYMBOLS
The purpose of safety symbols is to attract your
attention to possible dangers. The safety symbols and
the explanations with them deserve your careful
attention and understanding. The symbol warnings
do not, by themselves, eliminate any danger. The
instructions and warnings they give are no substitutes
for proper accident prevention measures.
Be sure to read and understand all
safety instructions in this Owner's
Manual, including all safety alert symbols such as
"DANGER," "WARNING," and "CAUTION" before using
this tool. Failure to following all instructions listed
below may result in electric shock, fire, and/or serious
personal injury.
The definitions below describe the level of severity
for each signal word. Please read the manual and pay
attention to these symbols.
This is the safety alert symbol. It is used
to alert you to potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
DANGER indicates a hazardous
situation which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazardous
situation which, if not avoided,
could result in death or serious injury.
CAUTION, used with the safety
alert symbol, indicates a
hazardous situation which, if not avoided, will result
in minor or moderate injury.
DAMAGE PREVENTION AND
INFORMATION MESSAGES
These inform the user of important information
and/or instructions that could lead to equipment or
other property damage if they are not followed.
Each message is preceded by the word "NOTICE", as
in the example below:

5
NOTICE: Equipment and/or property damage may
result if these instructions are not followed.
The operation of any power tools
can result in foreign objects being
thrown into your eyes, which canresult in severe
eye damage. Before beginning power tool
operation, always wear safety goggles or safety
glasses with side shields and a full-face shield when
needed. We recommend a Wide Vision Safety Mask
for use over eyeglasses or standard safety glasses
with side shields. Always use eye protection which
is marked to comply with ANSI Z87.1
SYMBOLS (CONTINUED)
IMPORTANT: Some of the following symbols may
be used on your tool. Please study them and learn
their meaning. Proper interpretation of these
symbols will allow you to operate the tool better
and more safely.
Symbol
Designation/Explanation
V
Volts
A
Amperes
Hz
Hertz
W
Watt
kg
Kilograms
min
Minutes
s
Seconds
Wh
Watt-hours
Ah
Ampere-Hours
Ø
Diameter
n0
No-load speed
n
Rated speed
…/min
Revolutions or
reciprocations per minute
0
Off position
1,2,3, …
I, II, III,
Selector settings
Infinitely variable selector with
off
Arrow
Direct current
Class II tool
Li-ion RBRC seal
Read manual symbol
Wear eye protection symbol
SYMBOLS (CERTIFICATION
INFORMATION)
IMPORTANT: Some of the following symbols for
certification information may be used on your tool.
Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to
operate the tool better and more safely.
Symbol
Designation/Explanation
This symbol designates
that this tool is listed by
Underwriters
Laboratories.
This symbol designates
that this tool is recognized
by Underwriters
Laboratories.
This symbol designates
that this tool is listed by
Underwriters
Laboratories, to United
States and Canadian
Standards.
This symbol designates
that this tool is listed by
the Canadian Standards
Association.
This symbol designates
that this tool is listed by
the Canadian Standards
Association, to United
States and Canadian
Standards.
This symbol designates
that this tool is listed by
the Intertek Testing
Services, to United States
and Canadian Standards.
This symbol designates
that this tool complies to
NOM Mexican Standards.

6
GET TO KNOW YOUR TOOL
20V CORDLESS PRESSURE WASHER
1) NOZZLE
2) QUICK CONNECT COLLAR
3) QUICK CONNECT COLLAR
4) PRESSURE SPRAY WAND
5) PRESSURE WASHER UNIT
6) WATER INTAKE
7) BATTERY-RELEASE BUTTON
8) ON/OFF TRIGGER
9) MAIN HANDLE
10) BATTERY PACK
11) STRAIGHT NOZZLE (RED)
12) DIFFUSER NOZZLE (WHITE)
13) EXTENSION ROD
14) SUCTION HOSE
15) FILTER
16) QUICK CONNECT HOSE CONNECTOR
17) SOAP BOTTLE
Fig. 1
1
2
3
4
8
9
5
6
7
10
11
12
13
14
15
16
17

7
Quick connect hose
connector
filter
Fig. 3
PRESSURE SPRAY
WAND WITH NOZZLE
EXTENSION ROD
PRESSURE
WASHER UNIT
PRESSURE
SPRAY WAND
WITH NOZZLE
○
1
○
1
○
2
EXTENSION ROD
○
2
PRESSURE
WASHER UNIT
Fig. 4
Fig. 2
PRESSURE
SPRAY WAND
WITH NOZZLE
PRESSURE
WASHER UNIT
LOCKING PIN
○
1
○
2
NOZZLE
PRESSURE
SPRAY WAND
QUICK CONNECT
COLLAR
○
1
○
2

8
PRESSURE SPRAY
WAND
SOAP
BOTTLE
PRESSURE
WASHER UNIT
Fig. 5
Fig. 6
PRESSURE WASHER
UNIT
QUICK CONNECT
HOSE CONNECTOR
○
1
○
2

9
Fig. 8
BATTERY-
RELEASE
BUTTON
ATTACH
DETACH
FUEL GAUGE
Fig. 9
SUCTION HOSE
FILTER
HEAVY OBJECT
Fig. 7

10
OPERATING INSTRUCTIONS
◼To reduce the risk of fire, personal injury, and
product damage due to a short circuit, never
immerse your tool, battery pack or charger in
fluid or allow a fluid to flow inside them.
Corrosive or conductive fluids, such as seawater,
certain industrial chemicals, and bleach or
bleach-containing products, etc. can cause a
short circuit.
◼If any parts are damaged or missing, do not
operate this product until the parts are replaced.
Use of this product with damaged or missing
parts could result in serious personal injury.
◼Do not attempt to modify this tool or create
accessories not recommended for use with this
tool. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possibleserious injury.
◼To prevent accidental starting that could cause
serious personal injury, always remove the
battery pack from the tool when assembling
parts, making adjustments, or cleaning the tool.
This cordless tool must be used only with the
battery packs and charger listed below:
MOKENEYE
Battery Pack
2.0Ah
B202010MZ
3.0Ah
B203005MZ
4.0Ah
B204010MZ
MOKENEYE
Charger
1A
C10MZ1US
2A
C20M1US
2A
C20MK1US
NOTICE: Please refer to the battery and charger
manuals for detailed operating information.
FUEL GAUGE BATTERY PACKS
Some MOKENEYE battery packs include a fuel
gauge which consists of four green LED lights that
indicate the level of charge remaining in the
battery pack.
The fuel gauge is an indication of approximate
levels of charge remaining in the battery pack
according to the following indicators:
To actuate the fuel gauge, press and hold the fuel
gauge button. A combination of the four green LED
lights will illuminate designating the level of charge
left. When the level of charge in the battery is below
the usable limit, the fuel gauge will not illuminate
and the battery will need to be recharged.
NOTICE: The fuel gauge is only an indication of the
charge left on the battery pack. It does not indicate
tool functionality and is subject to variation based
on product components, temperature and end-
user application.
For more information regarding fuel gauge battery
packs, please send e-mail to Mokeneye Customer
Service [email protected].
LED FUNCTIONS OF CHARGER
LED WILL BE ON TO INDICATE STATUS OF CHARGER
AND BATTERY PACK:
Charging with C20M1US/C20MK1US charger
-LED lights up red = Fast charging mode.
-LED lights up green = Fully charged and in
maintenance charge mode.
-LED lights up green = When an under-charged
battery pack is inserted into charger, indicates hot
battery pack or that battery pack is out of normal
temperature range or deeply discharged or
defective battery pack.
-No LED on = Defective charger.
CHARGING THE BATTERY PACK
Battery packs for this tool are shipped in a low
charge condition to prevent possible problems.
Therefore, you should charge it until the green LED
on the front of the charger comes on.
CHARGING A COOL BATTERY PACK
If battery pack is within normal temperature range,
the red LED on charger will come on.
NOTE: If the charger does not charge the battery
pack under normal circumstances, return both the
battery pack and charger to your nearest Mokeneye
Authorized Service Center for electrical check.
-Charge the battery pack only with the charger
provided.
-Make sure the power supply is normal household
voltage, 110~240 volts, 50/60 Hz, AC only.
-Connect the charger to the power supply.
-For C20M1US/C20MK1US charger, place the
battery pack in the charger aligning raised rib on
the battery pack with the groove in the charger.
-Press down on the battery pack to be sure
contacts on the battery pack engage properly
with contacts in the charger.
-Normally the red LED on charger will come on.
This indicates the charger is in fast charging
mode.
-Red LED should remain on for approximately 1 to
2 hours then the green LED will come on. Green
LED on indicates battery pack is fully charged and
charger is in maintenance charge mode.
NOTICE: The green LED will remain on until the
charger is disconnected from the power supply.
80-100% charged
60-79% charged
40-59% charged
Pack needs to be charged

11
-After normal usage, a minimum of 1 hour of
charging time is required to fully recharge battery
pack.
-The battery pack and the charger will become
slightly warm to the touch while charging. This is
normal and does not indicate a problem.
-Do not place the charger and battery pack in an
area of extreme heat or cold. They will work best
at normal room temperature.
NOTICE: The charger and battery pack should be
placed in a location where the temperature is
more than 32°F but less than 100°F.
-When batteries become fully charged, unplug the
charger from power supply and remove the
battery pack.
CHARGING A HOT BATTERY PACK
When using the tool continuously, the batteries in
the battery pack will become hot. You should let a
hot battery pack cool down for approximately 30
minutes before attempting to recharge. When the
battery pack becomes discharged and is hot, this
will cause the green LED to come on instead of the
red LED. After 30 minutes, reinsert the battery pack
in the charger. If the green LED continues to remain
on, return battery pack to your nearest Mokeneye
Authorized Service Center for checking or replacing.
NOTICE: This situation only occurs when continuous
use of the tool causes the batteries to become hot.
It does not occur under normal circumstances. Refer
to "CHARGING A COOL BATTERY PACK" for normal
recharging of batteries. If the charger does not
charge your battery pack under normal
circumstances, return both the battery pack and
charger to your nearest Mokeneye Authorized
Service Center for electrical check.
TO ATTACH NOZZLE
See Fig. 2
Flying objects could cause risk of
serious injury. Do not attempt to
change nozzles while pressure washer is running.
Turn pressure washer off before changing nozzles.
Do not direct discharge stream toward persons,
unprotected skin, eyes or any pets or animals.
Serious injury will occur.
To connect the nozzle to the spray wand, pull the
quick connect collar toward the spray wand and
insert the appropriate nozzle. Release the quick
connect collar to lock the nozzle in place.
To ensure nozzle is locked into place, give the nozzle
a firm tug after the quick connect collar has locked
into place.
NOTICE: Do not attempt to move the nozzle to
adjust pressure. The nozzle is not adjustable.
NOTICE: The high-pressure spray from your
pressure washer is capable of causing damage to
surfaces such as wood, glass, automobile paint,
auto striping and trim, and delicate objects such as
flowers and shrubs. Before spraying, check the item
to be cleaned to assure yourself that it is strong
enough to resist damage from the force of
the spray.
How To Use Spray Wand
Refer to the following chart to choose the correct
nozzle for the job to be performed.
Do not attempt to move the
nozzle to adjust pressure. The
nozzle is NOT adjustable.
Nozzle
Color
Red
White
Spray
Angle
3°
40°
Uses
Delivers the
optimal cleaning
effect for the
toughest
cleaning tasks.
Cleaning of
painted or
delicate surfaces
Surfaces
Grills, driveways,
concrete or brick
walkways,
unpainted brick
or stucco.
Auto/RV, marine,
wood, painted
brick and stucco,
vinyl, painted
siding
TO ATTACH THE SPRAY WAND
See Fig. 3
The spray wand connects to the pressure washer.
To connect the spray wand to the pressure washer.
-Insert the end of the spray wand into the
opening on the pressure washer. Push in and
turn the spray wand clockwise until its secured
into working position as shown.
-To remove the spray wand, push in and turn the
attachment counterclockwise and pull from the
pressure washer.
TO ATTACH THE EXTENSION ROD
See Fig. 4
The extension rod connects to the pressure washer.
To connect the extension rod to the pressure
washer.
-Insert the end of the spray wand into the
opening on the extension rod. Push in and turn
the spray wand clockwise until its secured into
working position as shown.
-Insert the end of the extension rod into the
opening on the pressure washer. Push in and
turn the extension rod clockwise until its secured
into working position as shown.
-To remove the spray wand, push in and turn the
spray wand counterclockwise and pull from the
extension rod.
-To remove the extension rod, push in and turn
the extension rod counterclockwise and pull
from the pressure washer.
TO ATTACH THE SOAP BOTTLE
See Fig. 5
The soap bottle connects to the pressure washer.
To connect the soap bottle to the pressure washer.

12
-Insert the end of the soap bottle into the
opening on the pressure washer. Push in and
turn the soap bottle clockwise until its secured
into working position as shown.
-To remove the attachment, push in and turn the
soap bottle counterclockwise and pull from the
pressure washer.
TO ATTACH THE SUCTION HOSE
See Fig. 6,7 Do not use to suction soap,
chemicals, dirty or corrosive
liquids, such as window cleaner, plant food,
fertilizers or bleach. Do not use salt water.
-To connect the quick connect hose adapter on
the end of the suction hose to the water
intake on the pressure washer, push the quick
connect hose adapter firmly onto the water
intake, otherwise it will result in inability to
absorb water.
NOTICE: Before use, gently tug on the suction
hose to ensure the connection is secured as
shown in the Figure 6 inset.
-Place other end of suction hose with filter on it
into container of fresh water or a fresh water
source. Put a heavy object on the filter to make
sure the filter is covered in the liquid.
-Select the correct nozzle to be used.
-After the job being performed is complete, place
the suction hose into container of clean water
and draw the clean water through the system
to rinse.
TO ATTACH/DETACH BATTERY PACK
See Fig. 8 To reduce the risk of serious
personal injury, turn unit off and
remove the battery pack before making any
adjustments or removing/installing attachments or
accessories. An accidental star-up can cause injury.
To attach the battery pack
Align the raised rib on the battery pack with the
grooves of the tool, and then slide the battery pack
onto the tool.
When placing the battery pack
onto the tool, be sure that the
raised rib on the battery pack aligns with the
groove inside the tool and that the latches snap
into place properly. Improper attachment of the
battery pack can cause damage to internal
components.
To detach the battery pack
To remove the battery, press and hold the red
release button on the front of the battery pack and
pull the battery away from the tool.
PROPER HAND POSITION
See Fig. 9
◼To reduce the risk of serious personal injury,
always use proper hand position as shown.
◼To reduce the risk of serious personal injury,
always hold securely in anticipation of a
sudden reaction.
Proper hand position requires one hand on the
main handle and the other hand on the pressure
washer's body as shown.
PRESSURE WASHING
PREPARING SURFACE FOR CLEANING
-Remove objects from the area which could
create a hazard.
-Ensure that all doors and windows are closed
tight. Protect all plants and trees in the adjacent
area with a drop cloth ensuring that they will
not be harmed by any over-spray.
-Pre-rinse cleaning area with fresh water.
-Use only detergents formulated for
pressure washers.
-Always test detergent in an inconspicuous area
before use.
PREPARING PRESSURE WASHER UNIT
FOR USE
Risk of fluid injection and
laceration. When using the
high ‑ pressure setting, DO NOT allow the
high ‑ pressure spray to come in contact with
unprotected skin, eyes, or with any pets or animals.
Serious injury will occur.
Before operation:
-Connect the water supply to the pressure
washer. For instructions on connecting the
water supply to the pressure washer, please
refer to Attach the Suction Hose.
-Connect the pressure spray wand, soap bottle,
or other attachment. For instructions on
connecting the pressure spray wand, please
refer to Attach the Suction Hose, Attach the
Spray Wand, Attach the Extension Rod, Attach
the Soap Bottle.
PREPARING THE PRESSURE WASHER
IMPORTANT: Squeeze the trigger and hold the
trigger for 10 seconds to purge the system of air. If
air is still found in the water stream, continue to run
water through the spray handle.
CLEANING A SURFACE
Risk of injury from spray. Always
remove the battery when gun is
not in use. Failure to do so could cause
accidental spraying.

13
-To start the pressure washer, squeeze the
trigger.
NOTICE: The best angle for spraying water
against a cleaning surface is 45°. Spraying head
on tends to cause dirt particles to embed in the
surface. When working on vertical surfaces, it is
best to apply detergent starting at the bottom
and working upwards which will prevent the
detergent from sliding down and
causing streaks.
-To stop the pressure washer, release the trigger.
NOTICE: Excessive pump pressure may be the result
of a clogged nozzle or brass coupling. Always turn
off the pressure washer and remove the battery
before attempting to unclog a nozzle or
brass coupler.
Never draw from water that
contains chemicals. Only draw
from fresh water sources.
MAINTENANCE
To avoid serious personal injury, always remove the
battery pack from the tool when cleaning or
performing any maintenance.
SERVICE
Preventive maintenance
performed by unauthorized
personnel may result in misplacing of internal wires
and components which could cause serious hazard.
We recommend that all tool service be performed
by a MOKENEYE Factory Service Center or
Authorized MOKENEYE Service Station.
GENERAL MAINTENANCE
When servicing, use only identical
replacement parts. Use of any
other parts could create a hazard or cause product
damage.
NOTICE: Periodically inspect the entire product for
damaged, missing, or loose parts such as nozzle,
soap bottle, suction hose, etc. Tighten securely all
fasteners and caps and do not operate this product
until all missing or damaged parts are replaced.
Please contact customer service or an authorized
service center for assistance.
CLEANING
◼Blow dirt and dust out of all air vents with clean,
dry air at least once a week. To minimize the risk
of eye injury, always wear ANSI Z87.1 approved
eye protection when performing this procedure.
◼Never use solvents or other harsh chemicals for
cleaning the non-metallic parts of the tool.
These chemicals may weaken the plastic
materials used in these parts. Use a cloth
dampened only with water and mild soap. Never
let any liquid get inside the tool; never immerse
any part of the tool into a liquid.
STORAGE
Store the tool indoors in a place that is inaccessible
to children. Keep away from corrosive agents.
TROUBLE SHOOTING
⚫Problem: Tool does not work.
LIMITED WARRANTY
1 YEAR LIMITED WARRANTY- LEGAL
MOKENEYE warrants to the original purchaser only,
that all MOKENEYE consumer POWER TOOLS will be
free from defects in material or workmanship for a
period of one years from date of purchase.
BATTERIES AND CHARGERS are warranted for 1
years. Original purchasers should also retain their
receipt as proof of purchase.
Notwithstanding the foregoing, if a MOKENEYE
consumer portable power tool is used for industrial,
professional or commercial purposes, the foregoing
warranty will apply for a duration of ninety days.
SELLER'S SOLE OBLIGATION AND YOUR EXCLUSIVE
REMEDY under this Limited Warranty and, to the
extent permitted by law, any warranty or condition
implied by law, shall be the repair or replacement of
parts, without charge, which are defective in
material or workmanship and which have not been
misused, carelessly handled, or repaired by persons
other than Seller or Authorized Service Station. To
make a claim under this Limited Warranty, you
must return the complete product, transportation
prepaid, to any MOKENEYE Factory Service Center
or Authorized Service Station. For Authorized
MOKENEYE Power Tool Service Stations, please
contact Amazon Store Customer Service.
This limited warranty does not apply to accessory
items such as circular saw blades, drill bits, router
bits, jigsaw blades, sanding belts, grinding wheels
and other related items.
In no event shall seller be liable for any incidental or
consequential damages (including but not limited
to liability for loss of profits) arising from the sale or
use of this product. Some states in the u.s. and
some Canadian provinces do not allow the
exclusion or limitation of incidental or
consequential damages, so the above limitation or
exclusion may not apply to you.
Cause
Remedy
Battery pack is
depleted.
Charge the battery.
Tool is over-loaded.
Release the variable-speed trigger
switch and try again.
Battery pack is over
temperature.
Turn off the Tool and cool the
battery pack under air flow.
Battery pack is not
installed properly.
Confirm battery is locked and
secured to the tool.
Burned out switch.
Have the switch replaced by an
Authorized MOKENEYE Service
Center or Service Station.
