Moman Power 99S User manual

Thank you for choosing MOMAN product. Please read this manual
carefully before use and follow all instructions mentioned herein.
User Manual
MOMAN
Power 99S
Adopt imported batteries with high quality and performance.
One D-tap input/output and two USB outputs, widely compatible
with mobile phones, tablet, laptop, photographic equipment and other
devices.
Equipped with OLED screen for real-time displaying information.
Support multiple devices working simultaneously, discharging while
charging.
Pure copper metal contact for stable output.
Features
Package List
Product Appearance Operations
Intelligent Protection System
Power 99S V-Mount
Battery x1
Overcharge
protection
Over power
protection
Overheating
protection
Over voltage
protection
Short circuit
protection
Over current
protection
Overdischarge
protection
Restore
automatically
USB-A Charging
Cable x1
USB-C Charging
Cable x1
①USB-C Input (PD)
②Power On/O
③OLED Display
④V-Mount Plate
⑤D-Tap Input/Output
⑥USB-A Output
⑦USB-C Output (PD)
⑧BP Electrode Interface
⑨ Current Battery Power
⑩ Charging Display
1. Charge
You could charge this V-mount battery through BP electrode interface, D-Tap
port or USB-C input(PD).
※Recommended Power
D-tap input: lower than 16.8V 3A
Adapter with USB-C input(PD): above 45W
2. Power On/O
Power On: Long press the power button for 2 seconds and the OLED screen
is on.
Power O: Long press the power button for 2 seconds and the OLED screen
is o.
3. Discharge
After the battery is on, you could use this V-mount battery to charge cameras,
high-power LED lights, monitors, smartphones, tablets, etc. though BP
electrode interface, D-Tap port, USB-A output or USB-C output(PD).
Specications
Warning
Storage
Warranty
Voltage
Capacity
Output
Input
Temperature
Max. Charging Time
Dimensions
Weight
14.4V
99Wh, 6700mAh
BP
D-TAP
USB-A
USB-C
BP
D-TAP
USB-C
-20℃-+55℃
3.5H
110mmx75mmx56mm
550g
14.4V ⎓ 13A MAX
14.4V ⎓ 13A MAX
5V ⎓ 2.6A 9V ⎓ 2A 12V ⎓ 2A
5V ⎓ 2.6A 9V ⎓ 2A 12V ⎓ 2A 20V ⎓ 2.3A
16.8V ⎓ 3A MAX
16.8V ⎓ 3A MAX
20V ⎓ 2A MAX
Please use the product according to the instructions.
Do not disassemble by yourself, put it into water or re in case of
short circuit and leakage
Do not squeeze & collide to avoid strong impact.
Do not use in severe high temperature, humidity or corrosive
environment to avoid damage to the circuit leakage phenomenon.
Please keep the product out of children’s reach to avoid unnecessary
accidents.
The battery is electro-chemical product with 2-year service life.
Please timely replace the new battery after the expiry.
When the battery is not used for a long time, please charge the
battery to half-full state, and place it in a dry and ventilated place.
Check it per six months.
Warranty rules
Please note the following circumstances are not within the scope of the
maintenance.
Disclaimer
From the date of purchase, the product will be replaced within one
month if quality problems occur, and guaranteed within two years.
Within the warranty period, any defect originating from the quality of
the product, we oer free repair or replacement of spare parts.
Produce malfunction or damage caused by failure to install, use,
maintain or store according to the instructions.
Alteration/ tearing o of product labels, or product damage caused by
disassembly / maintenance without authorization.
The warranty period has expired.
Product damage due to force major factors(such as earthquake, ood,
re, lightning strike, etc.) or articial damage.
Our company does not assume any responsibility for product damage
or any other accidents caused by product overheating or short circuit
caused by failure to follow instructions in this manual.
Unit 25 Basepoint Business Centre, Aviation Park, West Christchurch, United
Kingdom BH23 6NX
www.momanx.com
@MomanGlobal
https://moman.co/youtube
Moman (UK) Limited
The battery should be stored in a clean, dry and ventilated
environment, avoid contact with corrosive substances, also be away
from re and heat sources.
Store temperature: -5℃ -+35℃ . Relative humidity: ≤ 75%RH.
