Momentum PakYak User manual

V1.0 En / Fr

Table of contents
1 Preface................................................................................................................ 5
1.1 Welcome........................................................................................................................................... 5
1.2 Use of the manual......................................................................................................................... 5
1.3 Illustrations....................................................................................................................................... 5
1.4 Symbols used in the manual......................................................................................................5
1.5 Service & technical support........................................................................................................6
2 Safety.................................................................................................................. 7
2.1 Safe use of the bicycle.................................................................................................................7
2.2 Battery & charger...........................................................................................................................7
2.3 Passengers & cargo...................................................................................................................... 8
2.4 Accessories & attachments.........................................................................................................9
3 Description...................................................................................................... 12
3.1 Part overview................................................................................................................................12
3.2 EnergyPak...................................................................................................................................... 12
3.2.1 EnergyPak Smart Compact 500..................................................................................13
3.3 Charger............................................................................................................................................13
3.3.1 6A Smart Charger............................................................................................................14
3.4 SyncDrive....................................................................................................................................... 14
3.4.1 SyncDrive Pro.................................................................................................................... 14
3.5 RideControl.................................................................................................................................... 15
3.5.1 RideControl Dash..............................................................................................................15
4 Bike usage....................................................................................................... 16
4.1 Carriers............................................................................................................................................16
4.2 Storage Box...................................................................................................................................17
4.3 Keys..................................................................................................................................................18
4.4 Riding range..................................................................................................................................18
4.4.1 Factors that affect range................................................................................................18
4.4.2 Best practices for riding range.....................................................................................19
4.5 EnergyPak...................................................................................................................................... 19
4.5.1 First use............................................................................................................................... 19
4.5.2 EnergyPak power level indicator................................................................................. 20
4.5.3 EnergyPak removal & installation................................................................................20
4.5.3.1 EnergyPak Smart Compact................................................................................ 21
4.6 Charging......................................................................................................................................... 21
4.6.1 Charging a removed EnergyPak.................................................................................. 22
4.6.2 Charging an installed EnergyPak................................................................................ 23
4.6.3 LED Status description................................................................................................... 24
4.6.4 Charging time table......................................................................................................... 24
4.7 Controls...........................................................................................................................................25
4.7.1 RideControl Dash..............................................................................................................25
Table of contents3

5 Transport..........................................................................................................32
5.1 Transporting an e-bike.............................................................................................................. 32
5.2 Travel............................................................................................................................................... 32
6 Storage.............................................................................................................33
6.1 E-bike...............................................................................................................................................33
6.2 EnergyPak...................................................................................................................................... 33
7 Maintenance.................................................................................................... 34
7.1 Cleaning.......................................................................................................................................... 34
7.2 Drivetrain........................................................................................................................................34
8 Legal documentation.................................................................................... 36
8.1 Warranty.........................................................................................................................................36
8.2 Exclusions.......................................................................................................................................37
8.3 Conformity..................................................................................................................................... 37
8.4 Disclaimer.......................................................................................................................................38
8.5 FCC...................................................................................................................................................38
8.6 IC....................................................................................................................................................... 39
4Table of contents

1Preface
1.1Welcome
PACK THE FUN
Bring home the groceries, carry your kid to school, plan a weekend adventure carrying all
the gear you need. The Pakyak E+ electric utility bike combines powerful pedalling support
with thoughtful functionality that makes it fun to simplify your life and ride instead of drive.
Momentum. Go Your Way.
Momentum bikes free you from the constraints of daily life. Empowering you to ride for
clean living, fresh air, plus great stories and adventures along the way. Momentum gives
you choices. Whatever the reason you’re riding for, we’re with you all the way. We create
bikes for every journey, so you can go your own way.
1.2Use of the manual
Safety instructions are very important and should not be overlooked. By reading this e-
bike manual you will have a better understanding of the general operation of the various e-
bike parts.
This manual is a supplement to the general bicycle owners manual. Read all information in
both manuals carefully before you use on your new e-bike.
1.3Illustrations
Illustrations shown in this document may differ in detail from the exact configuration
of your e-bike. The illustrations are a general reference for instruction and description
purposes only.
1.4Symbols used in the manual
WARNING: Warns about a situation that can cause death, serious physical
injury and/or heavy material damage if one does not obey the safety instructions.
CAUTION: Warns about a situation that can cause physical injury or material
damage if one does not follow the safety instructions.
NOTICE: Provides important information to avoid problems.
Preface5

INFO: Provides additional information.
1.5Service & technical support
NOTICE: This manual is not intended to be an extensive reference book about
service, maintenance and/or repairs. Please consult your dealer for service and
technical support. The latest manual versions for our products can be found on
our global website: https://www.momentum-biking.com/global/manuals
6Preface

2Safety
2.1Safe use of the bicycle
Before using the e-bike on the open road, ride the bike in a secure area to get acquainted
with riding a bike with electric pedalling support. Try all settings on the bike and get
familiar with the results.
WARNING:
• Keep both hands on the grips on the handlebar and the brake levers within
reach while riding, to be able to immediately respond to any circumstance.
Failing to do so can cause you to loose control over the bicycle.
• Before every ride, perform a pre-ride check of the technical state of the bike
and all essential bike functions, like steering and braking.
• Make sure the battery is properly placed and locked.
• Ensure that all fasteners are properly tightened.
• Make sure that there are no worn or damaged parts that may fail during the
ride.
2.2Battery & charger
Take all following information into account when handling the battery and the charger.
WARNING:
• Keep the battery away from children and pets.
• Keep the battery & charger away from water and open fire.
• Do not drop or subject the battery & charger to any big shocks.
• Charge the battery only with the charger that was supplied with the e-bike,
or the spare-/replacement charger supplied by an official Momentum dealer.
• Do not use the battery & charger for other purposes.
• Never connect the battery's terminals with each other.
• Do not cover the battery & charger or place objects on top of it during
charging.
• Do not leave the battery & charger unattended while charging.
• Disconnect the charger and the battery immediately if you notice a strange
smell or smoke.
• In the unlikely case that the battery is on fire: NEVER try to put the fire out
with water. Cover the fire with large amounts of sand, and call emergency
services immediately.
Safety7

CAUTION: Avoid contact with battery and charger during charging operation.
The charger can become hot during charging.
NOTICE: When the battery has reached the end of the service life, it should
be treated as hazardous waste material. It should not be disposed of in regular
household trash. Ask your dealer for advice on proper disposal of the battery.
2.3Passengers & cargo
The maximum gross vehicle weight for the Pakyak E+ is 200 kg (440 lbs). This includes
the bike, rider, passenger(s), and any additional cargo or accessories. The maximum total
load limit for the rider, passenger(s), and any additional cargo or accessories is 164 kg
(361 lbs).
WARNING:
• Never exceed the maximum total load limit.
• Always make sure that any cargo, child-seat feature or any other
accessory fitted on the Pakyak E+ is securely fitted in accordance with the
manufacturer’s instructions.
• Always make sure that there are no loose straps or other items that could get
caught in the moving parts of the bicycle.
• Cargo should not obstruct the rider's view, or limit the proper operation of the
e-bike in any way.
CAUTION:
• Cargo can only be safely carried on the carriers. Do not attach cargo to any
other part of the bike.
• The bicycle may behave differently (particularly with regard to steering and
braking) when riding with cargo or passengers.
NOTICE:
• Check and adjust positioning of reflectors and lamps such that these are not
obscured when luggage is attached to the luggage carrier.
8Safety

2.4Accessories & attachments
Original Pakyak E+ accessories
It is recommended to use only original Momentum Pakyak E+ accessories. These are
specifically designed for the Pakyak E+ for optimal fit and function.
WARNING:
• Never exceed the total maximum load limit of the e-bike as stated elsewhere
in this user manual.
• Always follow the instructions for installation, usage and safety included with
each particular accessory.
NOTICE:
• If instructions are unclear or missing, take action to obtain the necessary
information before installing and using the accessory.
Safety9

Child seats
It is recommended to use Thule Yepp child seats on the The Pakyak E+. The rear carrier
of the Pakyak E+ is designed to fit up to 2 Thule Yepp Maxxi child seats with the Easyfit
system.
WARNING:
• Never exceed the carrier maximum load capacity and/or maximum load limit
of the Pakyak E+ as stated elsewhere in this user manual.
• Always follow the child seat manufacturer’s instructions for installation,
usage and safety.
• Some types/models/brands of child seats may not fit the Pakyak E+ properly.
• Never modify any original parts of the e-bike to accommodate a child seat.
• Improper installation or incompatible mounts can cause the child seat to
become detached from the carrier during riding and lead to serious injuries or
death.
• Keep the storage box closed and locked during the use of a child seat.
• When a saddle of a type with exposed coil springs is fitted, a child’s fingers
could get injured by getting trapped in the coil springs. Take appropriate
steps to prevent the trapping of the child’s fingers when using a child seat.
CAUTION:
• The use of a child seat can cause extra load stress and increased wear on the
e-bike’s electric and/or mechanical parts.
10Safety

Carriers
CAUTION:
• Before use, always consult the documentation that came with the carrier and/
or consult your local dealer for installing instructions, maximum load, torque
specifications, parts specifications, maximum compatible wheel size, trailer
and child seat compatibility.
NOTICE:
• For information about the name and address of the manufacturer, importer or
representative, trademark, model and production batch number or reference,
check the carrier's documentation and/or on the carrier itself.
Bicycle trailers & trailer bicycles
WARNING:
• Never exceed the total maximum load limit of the e-bike as stated elsewhere
in this user manual.
• Always follow the trailer manufacturer’s instructions for installation, usage
and safety.
• Never modify any original parts of the e-bike to accommodate a (third party)
trailer.
CAUTION:
• The use of a (third party) bicycle trailer or trailer bicycle will cause extra load
stress and increased wear on the e-bike’s electric and/or mechanical parts.
Safety11

3Description
The Pakyak E+ comes equipped with some unique components and specific features. This
chapter briefly explains several of the important parts and terminology.
3.1Part overview
Ref. Item Description
A. RideControl User controls and display screen
B. EnergyPak Frame integrated removable battery
C. Smart Charge port Connection socket for Smart Charger
D. SyncDrive motor Crank axle driving motor unit
E. Front Carrier Front cargo carrier
F. Rear Carrier Rear cargo & child seat carrier
G. Storage Box Small item storage/ compartment for
Auxiliary battery (optional accessory)
3.2EnergyPak
The EnergyPak is the battery that powers the system. There are several types of
EnergyPak at various energy capacities.
12Description

INFO:
• Not all types may be compatible with your e-bike. Ask your dealer for more
information about the possibilities for replacement, extensions and upgrades.
3.2.1EnergyPak Smart Compact 500
The EnergyPak Smart Compact 500 is a rechargeable battery with 500Wh energy
capacity. Due to the smaller size the battery can fit in the down tube of the frame from the
side.
Parts description
A. EnergyPak
B. Charging socket
C. Energy level indicator & button
NOTICE:
• Technical specifications of the battery and other detailed information can be
found on the printed label on the EnergyPak.
INFO:
• An Auxiliary EnergyPak is also available as an optional accessory to extend
the total capacity and riding range.
3.3Charger
The EnergyPak can be charged with the supplied charger. There are several types of
chargers. The charger can be connected via the charge port on the e-bike, or directly to the
EnergyPak.
INFO:
• The included EnergyPak adapter cable is required to connect the charger
directly to an EnergyPak without a charge port.
Description13

3.3.16A Smart Charger
The 6A Smart Charger is a powerful charger for our high capacity EnergyPaks. The smart
charger continuously monitors the internal state of the battery and adjusts the charging
process accordingly for the fastest charging speed and the maximum battery lifespan.
Parts description
A. AC socket (110V~240 V)
B. Charger
C. 60% charge indicator LED / button
D. 100% charge indicator LED
E. Charge socket
F. Charge adapter
NOTICE: Technical specifications and other details can be found on the printed
label on the charger.
3.4SyncDrive
The SyncDrive is the motor that provides the power assistance to the user. SyncDrive
motors use input from various integrated and/or external sensors to activate and control
the power output. There are several types and variations of SyncDrive motor units for the
bottom bracket, front or rear hub.
3.4.1SyncDrive Pro
The SyncDrive Pro motor is designed for
smooth and reliable operation under high
workloads and is specifically tuned for each
e-bike model and/or type. It has PedalPlus
6 sensor technology, a combination of
several (integrated) sensors and smart
signal processing, to provide very accurate
and responsive pedalling assistance.
14Description

3.5RideControl
The RideControl is the control unit that allows the user to select and control the functions
of the e-bike. It can provide indications on status of the e-bike in various ways depending
on the type and e-bike model, using (integrated) LED indicators, or (external) screen
displays.
3.5.1RideControl Dash
The RideControl Dash is a remote with integrated colour display screen, that shows e-bike
system and ride information.
A. Status bar
1. Wireless connection
2. Light status
3. Phone notification
4. Service
5. Battery status
B. Data field
C. Assist level indicator
D. Light / screen backlight
E. Power on/off
F. Assistance level up/down
G. Info select
H. Walk Assist
I. USB-C port
Description15

4Bike usage
This chapter describes how to use and operate the important parts and systems of the e-
bike.
INFO:
• More general usage information on bike usage can be found in the general
owner's manual.
4.1Carriers
The standard front and rear carrier of the Pakyak E+ provide numerous ways to carry
many sorts of cargo. Additional accessories can offer practical solutions for specific
demands. In addition to the important information in the chapter on safety, take into
account the following general guidelines:
• Distribute the weight evenly between the front and rear, left and right of the bike.
• Place heavier cargo as close to the center and as low on the bike as possible.
• Secure the cargo with straps or binders.
• Ensure you can keep good balance and control, before riding in traffic with passengers
and/or cargo.
• Do not exceed the maximum total load limit of the Pakyak E+.
• Do not exceed the maximum load weight for each carrier, as indicated below:
• Front carrier maximum load weight (A): 15 kg/33 lbs.
• Rear carrier maximum load weight (B): 46 kg/101 lbs.
NOTICE:
• A maximum load weight could also be indicated on a carrier itself. The weight
indicated on the carrier itself should always be considered as correct in the
event it differs from the information in this manual.
16Bike usage

4.2Storage Box
The Pakyak E+ Storage box (A) is intended for carrying smaller items such as a multitool,
minipump, foldable umbrella, lunchbox etc. The lid can be locked and opened with the
included keys that are also used for the battery lock. Push the lock shield to the side to
access the lock's key entry.
NOTICE:
• Although the storage box can be locked, it is not in any way guaranteed to
protect against theft. Do not store any valuable items inside the storage box
and leave the bike unattended.
• The dropper seatpost and saddle might hinder access to the storage box
when they are in the lowest position.
• Even with the dropper seatpost fully extended to the highest position, it
might still be necessary to loosen the seatpost clamp and raise the seatpost
slightly to be able to fully access the storage box.
• The dropper seatpost is operated by a remote via a wire attached to the
bottom of the seatpost. If upward movement of the seatpost is too limited by
this dropper remote wire, ask your dealer for technical assistance.
INFO:
• The storage box will also serve as the holder for the optional Auxiliary
EnergyPak accessory. Additional hardware will need to be installed and
connected to the system by an authorized dealer.
.
Bike usage17

4.3Keys
The Pakyak E+ comes standard with two identical keys that fit the battery lock and the
storage box lock. Keep one of the keys with the key number tag stored as a spare. Write
down the key number and keep that stored together with the bike's frame number and
other documents.
NOTICE:
• Always bring the key when visiting the dealer for maintenance or repairs.
• Without the key, a locked battery and/or storage box cannot be opened/
removed without damage.
• Make sure you always have at least one spare key.
• It is recommended to get an extra spare copy of the key.
• A qualified locksmith can make a duplicate of the original keys.
• Store your key number and spare key(s) in a safe yet accessible place.
4.4Riding range
Riding range can be difficult to predict accurately. A higher capacity EnergyPak will
provide a higher range when all other factors are the same. But in practice there are many
factors that influence energy consumption, and they can vary greatly. An understanding of
how particular factors will affect energy consumption, together with experience, will help
to optimize the riding range and start your trip with confidence.
4.4.1Factors that affect range
The range on one charge strongly depends on several circumstances, such as (but not
limited to):
• The total vehicle weight including the rider, passengers and cargo loaded onto the bike.
• Weather conditions, such as ambient temperature and wind.
• Road conditions, such as elevation and road surface.
• Bike conditions, such as tire pressure and maintenance level.
• Amount of charge and discharge cycles.
• Age and condition of the EnergyPak.
• Bike usage, such as acceleration and shifting.
• Assist level(s) used.
• User assist level settings (by smartphone app).
INFO:
• A new EnergyPak might not yet report the power level very accurately. This
will improve after a few full cycles of discharging (by riding) and recharging.
18Bike usage

4.4.2Best practices for riding range
For optimal riding range and to minimize wear of the moving parts on your e-bike, try to
make a habit out of the following best practices:
•Select an appropriate gear for the riding speed and pedaling speed (cadence).
Shift gears often. Choose a relatively low gear and high, but comfortable pedaling
cadence. This provides an optimal ratio between power output and energy
consumption in almost all riding scenarios.
Don't stay in one (high) gear. Setting off and riding at lower speeds in a high (heavy)
gear will result in higher energy consumption.
Release pressure on the pedals while shifting gears.
•Select the right assist level.
Let the " Smart Assist" function control the assist level automatically (availability may
vary by specification/country).
Choose the lightest manual assist level that you need.
•Ride in harmony with traffic and the environment.
Try to ride at a steady speed and keep the momentum going. Fewer decelerations
require fewer accelerations, which minimizes power consumption.
•Keep the load weight minimal.
Remove any items and/or removable accessories that you don't need.
•Keep the e-bike clean and in optimal technical condition.
Check and maintain tyre pressure regularly.
Check and maintain the drivetrain (chain, chainwheel, sprockets, etc.) regularly.
Always bring your e-bike to your dealer for the scheduled periodic maintenance.
4.5EnergyPak
4.5.1First use
A new EnergyPak is shipped in a protective ‘hibernate’ state. It must be activated before it
can be used. Usually, the dealer will have activated and fully charged the EnergyPak before
delivery. If not, you take the following steps to activate it:
• Push the energy level check button on the EnergyPak (see the topic on EnergyPak
power level indicator for details).
The LED indicator of the EnergyPak will not light up when it is in hibernate state.
• Connect the charger to the EnergyPak (see the topic on charging for details).
• Disconnect the charger from the EnergyPak.
• Push the energy level check button. The LED indicator should now light up.
• The EnergyPak is now activated.
Bike usage19

INFO:
• It is recommended to fully charge the EnergyPak before the first use. This
would automatically activate the battery.
• It is not possible for an EnergyPak to go back to ‘hibernate’ state once it is
activated.
4.5.2EnergyPak power level indicator
Power in the EnergyPak can be checked by
pushing the energy level check button. The
LED indicator on the battery will light up
with a 1 second delay.
NOTICE:
• Pressing the button more than once within 1 second will cause the indicator
to blink in a certain sequence. This is not a user function. To check actual
battery charge level, wait for the LEDs to stop blinking, then push the button
only once and wait a few of seconds for the LEDs to show the charge level.
• When an EnergyPak is connected to the bike, some power will get lost in the
system when the bike is not in use. To prevent this, the EnergyPak can be
disconnected from the bike when not in use for more than a few days.
• After a ride, do not leave a completely empty EnergyPak without charge
for an extended period. Try to make sure that it is at least partially charged
within 1 or 2 days.
• When weather conditions are bad (rain, snow, mud, sand, dust) it is
recommended to take out the EnergyPak after the ride and make sure the
connections are clean and dry before the next ride.
4.5.3EnergyPak removal & installation
The procedure for removal and installation of the EnergyPak can vary by the e-bike type
and model. Read and follow all instructions carefully.
CAUTION:
• An EnergyPak is relatively heavy. Take special care to support the weight of
the EnergyPak when unlocking/releasing the EnergyPak to prevent dropping.
20Bike usage
