Hercules PASERO Quick guide

TRANSLATION OF THE ORIGINAL
OPERATING INSTRUCTIONS EN
ELECTRIC BICYCLES
Pasero, Alassio
18-R-0001 | 18-R-0002 | 18-R-0003 | 18-R-0005
034-11421 • 1.0 • 11.10.2017
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP SAFE FOR LATER REFERENCE
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_COVER.book Page 1 Wednesday, October 11, 2017 9:53 AM

Copyright
© HERCULES GMBH
Distribution or reproduction of these operating instructions
and utilisation or communication of their content is prohibited
unless expressly approved. Any infringement will render the
offender liable for compensation. All rights reserved in the
event that a patent, utility model or industrial design is
registered.
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_COVER.book Page 135 Wednesday, October 11, 2017 9:53 AM

1
Data sheet
Surname, first name of the purchaser:
Date of purchase:
Model:
Frame number:
Type number:
Unladen weight (kg):
Tyre size:
Recommended tyre pressure (bar)*: front: rear:
Wheel circumference (mm):
Company stamp and signature:
*After a tyre change, refer to the tyre markings for the permitted tyre
pressures and make sure that they are observed. The recommended tyre
pressure must not be exceeded.
034-11421_1.0_11.10.2017
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 1 Wednesday, October 11, 2017 9:53 AM

Technical data
034-11421_0.1_10.10.2017
2
1 Technical data
Bicycle
Battery
Transportation temperature 5°C-25°C
Ideal transportation temperature 10 °C - 15 °C
Storage temperature 5°C-25°C
Ideal storage temperature 10 °C - 15 °C
Operation temperature 5°C-35°C
Working environment temperature 15 °C - 25 °C
Charging temperature 10 °C - 30 °C
Power output/system 250 W (0.25 W)
Shut-off speed 25 km/h
Table 1: Bicycle technical data
Transportation temperature 5°C-25°C
Ideal transportation temperature 10 °C - 15 °C
Storage temperature 5°C-25°C
Ideal storage temperature 10 °C - 15 °C
Charging ambient temperature 10 °C - 30 °C
Table 2: Battery technical data
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 2 Wednesday, October 11, 2017 9:53 AM

034-11421_0.1_10.10.2017 3
Technical data
Display
Emissions
USB port
Tightening torque
Internal lithium ion battery 3.7 V, 240 mAh
Storage temperature 5°C-25°C
Charging ambient temperature 10 °C - 30 °C
Table 3: Display technical data
A-weighted emission sound pressure level <70dB(A)
Total vibration level for the hands and arms <2.5m/s²
Highest effective value of weighted
acceleration for the entire body <0.5m/s²
Table 4: Emissions from the bicycle*
*The safety requirements as per Electromagnetic Compatibility
Directive 2014/30/EU have been met. The bicycle and the
charger can be used in residential areas without restriction.
Charge voltage 5V
Charging current max. 500 mA
Table 5: USB port technical data
Axle nut tightening torque 35 Nm - 40 Nm
Handlebars clamping screw maximum
tightening torque* 5Nm-7Nm
Table 6: Tightening torque values
*if there is no other data on the component
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 3 Wednesday, October 11, 2017 9:53 AM

Table of contents
034-11421_0.1_10.10.2017
4
1 Technical data 2
2 About these instructions 8
2.1 Manufacturer 8
2.2 Laws, standards and directives 9
2.3 Other valid documents 10
2.4 Subject to change 10
2.5 Language 10
2.6 Identifying 11
2.6.1 Operating instructions 11
2.6.2 Bicycle 11
2.7 For your safety 12
2.7.1 Instruction, training and customer service 12
2.7.2 Basic safety notes 13
2.7.3 Warnings 13
2.7.4 Safety markings 14
2.8 For your information 14
2.8.1 Instructions for actions 14
2.8.2 Information on the type plate 14
2.8.3 Language conventions 17
2.9 Type plate 19
3 Safety 20
3.1 Requirements for the rider 20
3.2 Proper use 20
3.2.1 City and trekking bicycle 21
3.3 Improper use 21
3.4 Personal protective equipment 21
3.5 Hazards for vulnerable groups 21
3.6 Duty of care 22
3.6.1 Rider 22
3.6.2 User 23
4 Description 24
4.1 Overview 24
4.2 Handlebars 25
4.3 Wheel and fork 26
4.3.1 Valve 26
4.3.2 Suspension 27
4.4 Brake system 28
4.5 Electric drive system 29
4.6 Drive system 29
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 4 Wednesday, October 11, 2017 9:53 AM

034-11421_0.1_10.10.2017 5
Table of contents
4.6.1 Battery 31
4.6.1.1 Operating and charge status indicator 34
4.6.2 Running light 34
4.6.3 Display 34
4.6.3.1 USB port 35
4.6.3.2 Displays 36
4.6.4 Command console 40
5 Transportation, storage and assembly 41
5.1 Transportation 41
5.2 Storing 43
5.2.1 Break in operation 43
5.2.1.1 Preparing a break in operation 44
5.2.1.2 Carrying out break in operation 44
5.3 Assembly 45
5.3.1 Unpacking 45
5.3.2 Scope of delivery 46
5.3.3 Commissioning 46
5.3.3.1 Checking the battery 48
5.4 Installing the wheels with quick release 49
6 Adjusting the bicycle to the rider 50
6.1 Adjusting the saddle 50
6.1.1 Determining the seat height 50
6.1.2 Clamp the seat post with the quick release 51
6.1.3 Adjusting the sitting position and saddle tilt 52
6.2 Setting the handlebars 52
6.3 Basic suspension setting 53
6.3.1 Adjusting the hardness of the spring elements 53
6.3.1.1 Adjusting the hardness of the steel suspension fork 53
6.3.1.2 Adjusting the hardness of the air suspension elements 54
6.3.1.3 Front wheel 54
6.4 Setting the grip distance of the brake lever 55
7 Operation 56
7.1 Before each ride 58
7.2 Using the kickstand 60
7.3 Using the pannier rack 61
7.4 Battery 63
7.4.1 Integrated battery 65
7.4.1.1 Removing the integrated battery 65
7.4.1.2 Inserting the integrated battery 66
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 5 Wednesday, October 11, 2017 9:53 AM

Table of contents
034-11421_0.1_10.10.2017
6
7.4.2 Down tube battery 66
7.4.2.1 Removing the down tube battery 66
7.4.2.2 Inserting the down tube battery 67
7.4.3 Saddle tube battery 67
7.4.3.1 Removing the saddle tube battery 67
7.4.3.2 Inserting the saddle tube battery 67
7.4.4 Charging the battery 68
7.4.5 Waking the battery 70
7.5 Electric drive system 71
7.5.1 Switching on the drive system 71
7.5.2 Switching off the drive system 71
7.6 Command console with display 72
7.6.1 Using the USB port 72
7.6.2 Removing and attaching the display 72
7.6.3 Using the pushing aid 74
7.6.4 Using the running light 75
7.6.5 Selecting the level of assistance 75
7.6.6 Switching journey information 75
7.6.7 Changing the system information 75
7.7 Gear shift 76
7.8 Brakes 77
7.8.1 Using the brake 78
7.9 Locking the front wheel suspension 79
8 Maintenance 80
8.1 Cleaning and servicing 81
8.1.1 Battery 81
8.1.2 Display 81
8.1.3 Basic cleaning and preservation 82
8.1.4 Chain 82
8.2 Maintenance 83
8.2.1 Wheel 83
8.2.2 Brake system 84
8.2.3 Electrical cables and brake cables 84
8.2.4 Gear shift 84
8.2.5 USB port 84
8.2.6 Chain tension 85
8.3 Service 86
8.4 Correcting and repairing 87
8.4.1 Using original parts only 87
8.4.2 Wheel quick release 88
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 6 Wednesday, October 11, 2017 9:53 AM

034-11421_0.1_10.10.2017 7
Table of contents
8.4.2.1 Clamping the quick release 89
8.4.3 Adjusting the tyre pressure 91
8.4.3.1 Dunlop valve 91
8.4.3.2 Presta valve 92
8.4.3.3 Schrader valve 93
8.4.4 Setting the gear shift 94
8.4.4.1 Cable-operated gear shift, single-cable 94
8.4.5 Offsetting brake lining wear 95
8.4.6 Replacing the lighting 95
8.4.7 Setting the lamp 95
8.4.8 Repair by the specialist dealer 95
8.4.9 The electric drive system of drive system does not start up 96
8.4.10 First aid for system messages 97
8.4.10.1 First aid 97
8.4.10.2 Specific error eradication 98
8.5 Accessories 99
8.5.1 Child seat 100
8.5.2 Bicycle trailer 102
9 Recycling and disposal 103
10 EC declaration of conformity 105
12 Table of figures 106
13 Index 107
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 7 Wednesday, October 11, 2017 9:53 AM

About these instructions
034-11421_0.1_10.10.2017
8
2 About these instructions
Read these operating instructions before
commissioning the bicycle in order to use all the
functions correctly and safely. They are not a
substitute for personal training by the supplying
HERCULES specialist dealer. The operating
instructions are a component part of the bicycle.
Therefore, if it is re-sold at a later time, they must be
handed over to the subsequent owner.
These operating instructions are mainly directed at the
rider and user of the cycle. In general, they are
technical laypersons.
Staff at all HERCULES specialist dealers have
specialist training and qualifications, and are therefore
capable of identifying risks and preventing hazards
which may arise during maintenance, servicing and
repairs on the bicycle. Information for specialist staff
does not require technical laypersons to take any
action.
2.1 Manufacturer
The manufacturer of the bicycle is:
HERCULES GMBH
Longericher Straße 2
50739 Köln, Germany
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Internet: www.hercules-bikes.de
Text passages which are directed expressly at
specialist staff (e.g. bicycle mechanics), are clearly
marked with a blue tool symbol.
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 8 Wednesday, October 11, 2017 9:53 AM

034-11421_0.1_10.10.2017 9
About these instructions
2.2 Laws, standards and directives
These operating instructions comply with the essential
requirements from:
• the Machinery Directive 2006/42/EC,
• EN ISO 12100:2010 Safety of machinery – General
principles of design – Risk assessment and reduction,
• EN ISO 4210-2:2015, Cycles – Safety requirements
for bicycles – Part 2: Requirements for city and
trekking, young adult, mountain and racing bicycles,
• EN 15194:2009+A1:2011 Cycles – Electrically power
assisted cycles – EPAC bicycles,
• EN 11243:2016, Cycles – Luggage carriers for
bicycles – Requirements and test methods,
• the Electromagnetic Compatibility Directive
2014/30/EU,
• EN 82079-1:2012, Preparation of instructions for use
– Structuring, content and presentation – Part 1:
General principles and detailed requirements,
• EN ISO 17100:2016-05, Translation Services –
Requirements for translation service.
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 9 Wednesday, October 11, 2017 9:53 AM

About these instructions
034-11421_0.1_10.10.2017
10
2.3 Other valid documents
These operating instructions are only complete in
conjunction with the other valid documents.
The following document applies for this product:
• Charger operating instructions.
No other information is also applicable.
The constantly updated lists of approved accessories
and parts are available to HERCULES specialist
dealers.
2.4 Subject to change
The information contained in these operating
instructions are the approved technical specifications
at the time of printing. Any significant changes are
included in a new issue of the operating instructions.
2.5 Language
The original operating instructions are written in
German. A translation is not valid without the original
operating instructions.
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 10 Wednesday, October 11, 2017 9:53 AM

034-11421_0.1_10.10.2017 11
About these instructions
2.6 Identifying
2.6.1 Operating instructions
These operating instructions are printed in colour and
glued (PUR glue) in an outer cover made of thin
paper. HERCULES GMBH assumes no liability for
copies of any kind, for example, black and white
copies, loose pages or electronic copies.
The identification number of these operating
instructions is made up of the document number, the
version number and the release date. It can be found
on the cover page and in the footer.
2.6.2 Bicycle
These HERCULES operating instructions refer to the
model year 2018. The production period is from August
2017 to June 2018. They are issued in August 2017.
The operating instructions are a component part of the
following bicycles:
Identification number 034-11421_0.1_10.10.2017
Table 7: Identification number of the operating instructions
Type no. Model Bicycle type
18-Q-0029 PASERO City and trekking bicycle
18-Q-0030 PASERO City and trekking bicycle
18-Q-0098 PASERO City and trekking bicycle
18-Q-0031 ALASSIO PRO 10 City and trekking bicycle
18-Q-0032 ALASSIO PRO 10 City and trekking bicycle
18-Q-0033 ALASSIO SPORT 9 City and trekking bicycle
18-Q-0034 ALASSIO SPORT 9 City and trekking bicycle
18-Q-0035 ALASSIO SPORT 9 City and trekking bicycle
Table 8: Type number, model and bicycle type categorisation
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 11 Wednesday, October 11, 2017 9:53 AM

About these instructions
034-11421_0.1_10.10.2017
12
2.7 For your safety
The safety concept of the bicycle comprises four
elements:
• the instruction of the rider and/or user, and
maintenance and repair of the bicycle by the
HERCULES specialist dealer,
• the chapter on general safety,
• the warnings in these instructions and
• the safety marking on the type plates.
2.7.1 Instruction, training and customer service
The HERCULES specialist dealer and supplier
provides customer service. Contact details can be
found on the back page of these operating instructions
and in the data sheet. If you are unable to contact your
specialist dealer, you will find further HERCULES
specialist dealers on www.hercules-bikes.de. They will
also be able to attend to your customer service needs.
The rider or the user of the bicycle will be instructed in
person on the functions of the bicycle, in particular its
electrical functions and correct use of the charger, at
the latest when the bicycle is handed over by the
supplying HERCULES specialist dealer.
Each rider to whom this bicycle is made available,
must receive instruction on the functions of the
bicycle. The operating instructions must be submitted
to each rider in printed form and must be
acknowledged and adhered to.
The HERCULES specialist dealer commissioned to
perform repairs and maintenance work receives
regular training.
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 12 Wednesday, October 11, 2017 9:53 AM

034-11421_0.1_10.10.2017 13
About these instructions
2.7.2 Basic safety notes
2.7.3 Warnings
Hazardous situations and actions are marked with
warnings. The warnings in these operating instructions
are shown as follows:
The following pictograms and signal words are used in
the operating instructions for warnings and information
notices:
These operating instructions have a chapter with
general safety notes [Chapter 3, page 20]. The
chapter stands out because of its grey background.
Type and source of the danger
Description of the danger and the consequences.
Measures
SIGNAL WORD
Will lead to serious or even fatal injuries if ignored.
High-risk hazard.
May lead to serious or even fatal injuries if ignored.
Medium-risk hazard.
May lead to minor or moderate injuries. Low-risk
hazard.
May lead to material damage if ignored.
Table 9: Meanings of the signal words
DANGER
!
WARNING
!
CAUTION
!
NOTICE
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 13 Wednesday, October 11, 2017 9:53 AM

About these instructions
034-11421_0.1_10.10.2017
14
2.7.4 Safety markings
The following safety markings are used on the type
plates of the bicycle:
2.8 For your information
2.8.1 Instructions for actions
Instructions for actions are structured in accordance
with the following pattern:
Requirements (optional)
Instruction for action
Result of the action (optional)
2.8.2 Information on the type plate
Alongside the warnings, the type plates of the
products also contain other important information on
the bicycle:
General warning
Adhere to the instructions for use
Table 10: Safety markings on the product
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 14 Wednesday, October 11, 2017 9:53 AM

034-11421_0.1_10.10.2017 15
About these instructions
only suitable for the road, no off-road riding or jumps
suitable for roads, off-road riding and jumps of up to
15 cm
suitable for rough off-road riding and jumps of up to
61 cm
suitable for rough off-road riding and jumps of up to
122 cm
suitable for the most difficult terrain
Table 11: Area of use
City and trekking bicycle
Child's bicycle / bicycle for young adults
BMX bicycle
Mountain bike
Racing bicycle
Carrier bicycle
Folding bicycle
Table 12: Bicycle type
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 15 Wednesday, October 11, 2017 9:53 AM

About these instructions
034-11421_0.1_10.10.2017
16
Read the instructions
Separate collection of electrical and electronic
devices
Separate collection of batteries
Must not be thrown into fire (burning prohibited)
Must not be thrown into water (immersed)
Device of protection class II
Only suitable for use indoors
Fuse (device fuse)
EU conformity
Recyclable material
Table 13: Information on the type plate
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 16 Wednesday, October 11, 2017 9:53 AM

034-11421_0.1_10.10.2017 17
About these instructions
2.8.3 Language conventions
The bicycle described in these operating instructions
may be equipped with alternative components. The
equipment of the bicycle is defined by the respective
type number. If applicable, the notes alternative
equipment and alternative version make reference to
the use of alternative components.
Alternative equipment describes additional components
which are not necessarily an integral part of every
bicycle in these instructions.
Alternative version explains the various variants of
components if they differ in use.
The following terms are used for better legibility:
Term Meaning
Operating
instructions
Original operating instructions
or translation of the original
operating instructions
Bicycle Electric motor driven cycle
Motor Drive motor
Table 14: Simplified terms
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 17 Wednesday, October 11, 2017 9:53 AM

About these instructions
034-11421_0.1_10.10.2017
18
The following conventions are used in these operating
instructions:
Convention Use
Italics Entry in the index
SPACED Displays on the display
screen
[Example, page
numbering]
Cross references
• Bulleted lists
Table 15: Conventions
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 18 Wednesday, October 11, 2017 9:53 AM
