Monitech LL Series User manual

M20B09-ML121LL00
1
12.1-INCH LCD USER MANUAL LL SERIES
One touch and
you are ready to go

M20B09-ML121LL00
2
IMPORTANT
WARRANTY
Before using any MONITECH product please carefully
review this Manual as well as any additional
documentation provided with your shipment.
Attempting any of the following will void
product warranty:
•unauthorized repairs or parts replacement
•inappropriate use or placement: exposing product
to liquids, harmful gases, electrical shock, physical
shock, temperatures beyond the range of -20°C to
60°C (-4°F to 140°F)
•use of electrical voltage other than 12V 4.16A
(power supply and AC cable provided)
•removal or modification of serial, product, or
warranty labels.
WARNING
ELECTRICAL HAZARD
DO NOT OPEN
TO AVOID ELECTRICAL SHOCK DO NOT
OPEN PRODUCT CASING. UNAUTHORIZED
REPAIRS OR PARTS REPLACEMENT ARE
PROHIBITED AND WILL VOID PRODUCT
WARRANTY. PLEASE RETURN TO MONITECH
FOR REPAIRS.

M20B09-ML121LL00
3
1.Mounting Brackets
This line of Monitech Product has Mounting brackets that you will
attach onto the side of our monitor by unscrewing the screws on
the side and placing the brackets on by screwing in the screws that
you just removed. These brackets help you mount the monitor to
the old CRT frame of your application.
Take the set of
brackets out of the
monitor box. The
mounting ears should
be towards the back
of the monitor.
Use a screwdriver to
unscrew the screws
on the side of the
monitor.
Place the brackets
where the slots are.
Use the screws
previously taken off to
fasten the brackets.

M20B09-ML121LL00
4
2. Just press AUTO.
Once you have mounted your new Monitech LCD into
your control panel with the video cable attached, the
indicator light on the back of the monitor may turn
green. This means the video power is on. If the green
light is off, press the I/O button to power it up.
Now press AUTO on the 6-button menu found on the
back of the LCD. After a few seconds, the screen will

M20B09-ML121LL00
5
center the image and automatically adjust the image
size, color, brightness and contrast.
That’s all there is to it! Your LCD is ready to go.
3. Adjust brightness, contrast &
color temp.
Use this menu to adjust the brightness, contrast, and
color. Use “Color adjust” to change the ratios
between red, green, and blue. Use “Color Temp” to
set color saturation. (If you select USER and the color
gets messed up, go to the MISC menu, and select
RESET.) Press MENU and the PICTURE menu will
appear:

M20B09-ML121LL00
6

M20B09-ML121LL00
7
Now press the up  or down  buttons
to select what feature you would like to change.
Press MENU to enter.
Then use the up  or down  to adjust the value of
your selection.
To exit, press AUTO until it goes away.
4. Adjust Picture
Fine-tune the image by adjusting the horizontal (H)
and vertical (V) positions as well as the phase & clock.

M20B09-ML121LL00
8

M20B09-ML121LL00
9
5.Video connector
This picture shows the value for six pins on the video connector at the
back of the monitor. (The other pins
have no application.)

M20B09-ML121LL00
10
Troubleshooting
My screen is black.
Ensure the DC power cable is fully inserted into the
monitor receptacle. Use only 12V 4.16a power supply
(+ on center pin). Ensure the power supply is securely
connected to a 120-240V AC power source and that
the green light indicates it is ON.
I am seeing lines through my video.
Press the AUTO button at the back of the monitor.
How do I increase the brightness on the screen?
Press MENU, then MENU again to open the COLOR
menu. Adjust the brightness from there.
How do I deal with intermittent video issues?
Ensure the video cable does not run close to high-
power devices or cables. Ensure all cables are securely
seated and free of damage.

M20B09-ML121LL00
11
For Technical Support, Call
1-877-493-6105
