Monster MINI ORB User manual

MODEL MLB7-1043
V2.0 1020
Operation Manual
INDOOR/OUTDOOR
RECHARGEABLE
MULTI-COLOR LED MINI ORB
with IR Remote Control

Features
What’s Included
Introduction
• Water-resistant LED Mini Orb is great for both indoor
and outdoor and use
• Integrated rechargeable battery provides over 4hrs of
light (time varies by lighting color/mode)
• Sleek, stylish design accents any décor
• Multi-color and dimmable LED lighting effects with
Flashing and Fading color-changing modes
• Remote control works up to 26ft/8m away
• Charge from any USB power source (not included)
This Indoor/Outdoor Rechargeable Multi-Color LED Mini
Orb is portable, easy to use, and is ideal for adding
controllable ambient lighting to any space indoors or out.
• Indoor/Outdoor Rechargeable Multi-Color LED Mini Orb
• IR Remote Control with battery
• USB Charging Cable
• User Manual x1 pc

Safety
Instructions
Please read and understand all instructions before using
this product. If damage is caused by failure to follow the
instructions, this warranty is null and void.
• Keep these instructions.
• Do not drop, puncture, or disassemble this product.
• For water-resistance, keep the silicon USB cover tightly
sealed.
• Avoid long exposure to direct sunlight, which may cause
damage.
• Do not expose this product to open flames.
• Do not use the product in a strong magnetic field.
• Use a clean, soft cloth to clean. Do not use any corrosive
cleaners/oils to clean.
• Do not attempt to repair the device or open the unit as this
will void the warranty.

1
2
Get Started/
Charging
The LED Mini Orb has a built-in rechargeable battery that can be
charged using the included micro USB to USB Type-A cable and
any 5v USB power source (not included).
For best results, charge before use.
3
NOTE: Under normal operation, the Orb will provide over 4.5hrs
of light. Solid colors, lower brightness, and fewer adjustments
can extend the battery life considerably.
Open the USB cover and insert the charging cable
While charging, the LED will glow Red
When charging is complete, the LED will turn OFF
To keep water-resistant, keep the USB cover closed
securely when not charging

Folding Handle/Hanging Loop
The LED Mini Orb features a fold-out ring on the bottom that
can be used to carry or hang the product, allowing you to use
it in more ways and more locations.
• Do not hang the Mini Orb by the USB charging cable.
• Fold away the handle/hanging loop when not in use.
• Do not drop this product.
Specifications
• LED Mini Orb Input (USB): 5V 0.5A
• Battery Life: 4.5hrs
• Charge Time: 2.5hrs
• Standby Time: 400hrs
• USB Charging Cable Length: 3ft
• Remote Control: 3V
(1 x 3V battery, type CR2025)

MODEL MLB7-1043
V2.0 1020
Operation Manual

①
②
③
④
⑤
⑥
⑦
⑧
Controls, at a Glance
ON
OFF
COLOR SELECTORS
WHITE
FADE
FLASH
RESET
DIMMER BUTTONS
Turn the product on
Turn the product off
Change the color to match your mood
Change the color to white
Fade color-changing mode
Flash color-changing mode
Reset to default settings
Adjust the brightness/intensity
⑧
⑤
①
③
④
⑦
IR Remote LED Mini Orb (bottom)
Power/Mode button
hanging loop
USB charging cover/port
②
⑥

Button
Operation
1
2
3
FLASH
FADE
RED
GREEN
BLUE
WHITE
STANDBY
quickly flashes through the color spectrum
smoothly flows through the color spectrum
solid color
solid color
solid color
solid color
LEDs are off, IR sensor remains active
In STANDBY mode the LEDs will be off but the IR sensor will
remain active so that the Mini Orb can respond to the IR remote.
If the Mini Orb is turned OFF it must first be reactivated
manually before the remote will work.
Note: If left in Standby Mode for an extended period of time,
the battery may become depleted and you may need to
charge the device.
Standby Mode
Turn on the LED Mini Orb by pressing the Power/Mode
button on the bottom of the device (it will turn on into the
last used lighting mode)
Continuously pressing the Mode button will cycle through
the following lighting modes:
At any time, press and hold the Power/Mode button to turn
OFF the LED Mini Orb

IR Remote
Operation
1
2
3
4
1
2
3
Changing the remote control battery:
Note: The Mini Orb can only respond to the remote control if
it is ON or in STANDBY mode.
The battery for the remote control has already been installed.
Remove the battery pull tab to operate.
Turn on the LED Light by pushing the ON button on the
remote control
Select the desired color of the desired effect by pushing
the corresponding button on the remote control
Set the desired brightness using the buttons to
increase/decrease the intensity of color
Push the OFF button to turn off the LED Light
The battery compartment is located on the narrow side of
the remote control
Remove the empty battery and insert a 3V battery, type
CR2025, with the positive terminal pointing upwards
Place the battery compartment back in the remote control
so it locks in place

The illustrated products and specifications may dier slightly from those supplied.
The M Monster logo is a registered trademark of Monster, Inc. or its subsidiaries in the
U.S. and other countries and are used under license. All other brand names are
trademarks of their respective owners. Neither Jem Accessories, Inc. nor Monster, Inc.
is aliated with the respective owners of their trademarks. Licensed and
Manufactured by Jem Accessories, Inc. South Plainfield, NJ 07080. Made in China.
Customer
Service
1 Year Limited Warranty
[email protected]
866-246-2008
Warning
FCC Statement
FCC Radio Frequency Exposure Statement
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s warranty or authority
to operate the equipment.
In the event this product becomes defective,
please do not return this product to your retailer.
This device complies with Part 15 of the FCC Rules. Operation is
subject to following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure
requirements. The device can be used in fixed or mobile condition.
The minimum separation distance is 20cm.
