MONTAGUE Vectaire SL70 User manual

INSTRUCTION MANUAL
THE MONTAGUE COMPANY
1830 Stearman Avenue P.O. BOX 4954
HAYWARD,CA 94540-4954
TEL: [phone] FAX: [phone]
Gas Convection Ovens
with
Solid State Electronic Controls
MONTAGUE SL
MODELS:
SL70 (AH, AP) and SL2-70 (AH, AP)
This manual is meant as a supplement to the Gas Vectaire manual. The
contents herein describe the function and operation of the Solid Electronic
Controls. For information on the Gas Vectaire oven installation, operation,
maintenance, service and parts, refer to the Gas Vectaire manual part no.
4520-9.
Keep area around appliances free and clear from combustibles.
PLEASE RETAIN THIS MANUAL
FOR FUTURE REFERENCE.
These instructions should be read thoroughly before attempting installation.
Set up and installation should be performed by qualified installation personnel.
addendum

2
CONTENTS
INTRODUCTION, INSTALLATION & CAUTIONS 2
OPERATION (Cooking with Solid State Controls) 3-7
WIRE DIAGRAMS 8
IMPORTANT
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause property damage, injury
or death. Read the operating
and maintenance instructions
thoroughly before installing or
servicing this equipment.
FOR YOUR SAFETY:
Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance.
INSTRUCTIONS TO BE FOLLOWED IN THE EVENT THE USER SMELLS GAS MUST BE
POSTED IN A PROMINENT LOCATION. THIS INFORMATION MAY BE OBTAINED BY
CONSULTING THE LOCAL GAS SUPPLIER.
SHIPPING DAMAGE CLAIM PROCEDURE
For your protection, please note that equipment in this shipment was carefully inspected
and packed by skilled personnel before leaving the factory. The transportation company
assumes full responsibility for safe delivery upon acceptance of this shipment.
If shipment arrives damaged:
1. VISIBLE LOSS OR DAMAGE—Be certain this is noted on freight bill or express receipt,
and signed by person making delivery.
2. FILE CLAIM FOR DAMAGES IMMEDIATELY—Regardless of the extent of damage.
3. CONCEALED LOSS OR DAMAGE—If damage is unnoticed until merchandise is un-
packed, notify transportation company or carrier immediately, and file “concealed dam-
age” claim with them. This should be done within fifteen (15) days of date that delivery
was made to you. Be sure to retain container for inspection.
We cannot assume responsibility for damage incurred in transit. We will, however, be glad
to furnish you with necessary documents to support your claim.

3

4
The SL series Vectaire gas convection ovens are very similar to the Vectaire ovens Montague
has produced for years. The most significant difference is that solid-state electronic controls are
used instead of the elecro-mechanical ones commonly used. The result is the most accurate,
responsive and predictable ovens we have ever offered with the recognized dependability of
solid-state components.
This special manual is meant to be used as a supplement to the main "Vectaire Gas Convection
Ovens" instruction manual, which should be reference first for special instructions.
INSTALLATION
Montague's general installation instructions should be followed. In addition, since solid state
components have a very short life span when exposed to temperatures above 185°F,
(85°C), certain installation precautions are necessary. The SL ovens have been designed to
operate well below this temperature when installed properly, and the following cautions are
observed:
Caution
1. Do not obstruct the air out the vent holes at the top of the oven, or the flow of fresh
room air to the oven bottom or lower front portion of the burner access cover.
2. Do not mount the oven on a solid curb unless it has been modified at the factory for
this type of operation.
3. When stacking ovens, never reverse the top and the bottom ovens.
4. Never stack an SL convection type oven with a standard Vectaire, or any other type
of oven without first consulting the factory. Certain ovens are not compatible, or a
stacking kit may be required.
Special Caution
DO NOT PLACE HIGH HEAT PRODUCING EQUIPMENT ADJACENT TO THE RIGHT SIDE
OF AN "SL" VECTAIRE CONVECTION OVEN. EXCEEDING 185°F, (85°C), SURFACE TEM-
PERATURE CAN CAUSE PREMATURE COMPONENT FAILURE NOT COVERED UNDER
MANUFACTURERS WARRANTY. THE OVENS NEED 6" MINIMUM CLEARANCE ON THE
RIGHT SIDE BETWEEN SIMILAR OVENS OR OTHER COOKING EQUIPMENT. OPTIONAL
INSTALLATION KITS ARE AVAILABLE THAT REDUCE THE MINIMUM CLEARANCE
BETWEEN SIMILAR OVENS TO 1" AND BETWEEN OTHER EQUIPMENT TO 2". CONSULT
FACTORY.
INTRODUCTION

5
Gas Control System - Vectaire SL (all models)
Follow the procedures in the main “Vectaire Gas Convection Ovens” manual to light the
standing safety pilot on standard models.
On models equipped with the optional Electronic Ignition, the procedure in the main manual is to
be followed with one exception. The Fan Control Knob must first be set to either HI or LO before
the electronic ignition system is energized and a temperature can be selected to initiate pre-heat.
On initial start-up or if the oven has not been used for an extended period of time, the pilot may
fail to ignite within 50 seconds, and a complete shut down of the ignition system will occur for
safety purposes. Turn the Fan Control Knob to the SYSTEM OFF position for at least 30
seconds, then back to either HI or LO and repeat the procedure.
If the oven does not ignite after 3 successive attempts, the entire oven gas system should be
checked for possible causes.
Control Panel - Vectaire SL70AH Models (Cook-n-Hold ) See Diagram A.
The FAN CONTROL KNOB is located at the top of the control panel, and when in the “off”
position turns all power off to the oven. The “COOL “ position is used to cool down the oven with
the fan on and the door open. The “HI” and “LO” positions are to select the fan speed. If the
model is not equipped with a two-speed motor, the “LO” position will result in no change in
speed. The fan must be switched on during cooking.
The LIGHT SWITCH is located directly below the fan control. If pressed and held, the oven
lights will come on. When released, the oven lights will turn off.
Below the light switch is the control DISPLAY WINDOW. At the top-left corner of the window
is the “CYCLE INDICATOR” light. When illuminated, the burner is on and applying heat to the
oven. When out, the control is not calling for more heat and the burner is off.
The TEMPERATURE DISPLAY is located at the top of the window and the TIME DISPLAY
is located at the bottom of the window.
Beneath the time display are four indicator lights. “HOUR” is illuminated when the time
displayed is greater than 60 minutes. “COOK/BAKE” is illuminated whenever a timed cooking or
baking cycle has been started, and the time display is showing the time remaining. “FAN DELAY”
is illuminated when this option has been selected, and the fan is either being pulsed or delayed
at the beginning of the cycle. “HOLD” is illuminated whenever this option has been selected, the
cook cycle has ended, and the oven is in the hold phase.
OPERATION
