Montezuma MF301DW3 User manual

OWNER'S MANUAL
1-DRAWER,
3-DOOR
WORKSTATION
MF301DW3
www.montezumastorage.com

2
LIFE ORGANIZED
Montezuma is committed to helping you succeed in both your work
and personal life by being organized, prepared and equipped with
the right tools, gear and home supplies at your finger tips.
We are here to ensure that your life is organized.
Thank you for your purchase of this Montezuma 1-Drawer,
3-Door Workstation.
ATTENTION
TO REDUCE THE RISK OF INJURY, THE USER MUST READ AND
UNDERSTAND THIS INSTRUCTION MANUAL BEFORE USING THIS
PRODUCT FOR THE FIRST TIME. SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
Fill in the following information and retain
this owner's manual for future reference:
MODEL(S):
DATE OF PURCHASE:
PLACE OF PURCHASE:
RECEIPT NO:

3
SPECIFICATIONS
OVERALL DIMENSIONS:
77.6 cm W x 49 cm D x 206.6 cm H
(30-1/2" W x 19-1/4" D x 81-3/8" H)
1 x 1-DOOR WALL CABINET
DIMENSIONS:
77.6 cm W x 30.5 cm D x 51 cm H
(30-1/2" W x 12" D x 20" H)
MAXIMUM SHELF WEIGHT:
23 kg (50 lb)
2 x PEGBOARD PIECES
DIMENSIONS:
77.6 cm W x 32 cm D x 2.2 cm H
(30-1/2" W x 12-5/8" D x 7/8" H)
MAXIMUM WEIGHT CAPACITY: 23 kg (50 lb)
* per each pegboard
2 x POSTS
DIMENSIONS:
5.5 cm W x 3.1 cm D x 166.1 cm H
(2-1/8" W x 1-1/4" D x 65-3/8" H)
1 x 1-DRAWER, 2-DOOR
BASE CABINET
DIMENSIONS:
77.6 cm W x 46 cm D x 87.9 cm H
(30-1/2" W x 18-1/8" D x 34-5/8" H)
MAXIMUM DRAWER WEIGHT:
32 kg (70 lb)
* Dimensions do not include adjustable feet.

4
1
6
8
7
9
12
3
4
5
15
16
17
13
1
10
9
1
8
11
12
3
2
14
5
PARTS LIST
x x x
The keys are
taped inside
the cabinets.

5
To order replacement parts, email [e-mail] or call 1-800-459-4409
(Monday–Friday, 8:00 am–4:30 pm, CST). Have the part number and quantity ready.
Replacement keys may be ordered using the code that appears on the face of the lock.
Not all parts are covered under warranty. Those parts not covered can be purchased.
REF DESCRIPTION PART NUMBER QTY
1M6 x 16 mm Hex Socket Head Screw 320327 43
2Washer 324050 6
3M6 x 65 mm Hex Tapping Screw 320316 6
4Gas Strut 303002 2
5End Cover 314195 4
6Shelf 233955 1
7Shelf Support 226078 4
8Lock and Key [phone] 3
9M6 Hex Flange Nut 323085 2
10 Worktop 571406 1
11 Slide Set 300029–300030 1
12 Adjustable Feet 110 0 6 8 4
13 Drawer Liner 552161 1
14 Magnet 312033 2
15 Post A 226911 4
16 Post B 240368 2
17 Pegboard 226913 2

6
x x x
Lock and Key
For securing
your valuables
M6 Hex Flange Nut
For use with M6 x 16 mm
Hex Socket Head Screw
when attaching unit to other
units
End Cover
For covering holes for
attaching to other units,
if not in use
Shelf Support
For supporting
adjustable shelf
Shelf
For placing at
desired height
M6 x 65 mm Hex
Tapping Screw
For securing unit
to the wall
Gas Strut
Pre-installed
For opening door
Washer
For use with M6 x 65 mm
Hex Tapping Screw
43
6
41
3
26
4
2
M6 x 16 mm Hex Socket Head Screw
8 for attaching top panel of wall cabinet
11 for attaching bottom panel of wall cabinet
4 for attached worktop to base cabinet (pre-installed)
18 for attaching pegboards and wall cabinet to posts
2 for attaching unit to other units
Worktop
Pre-installed
1

7
Magnet
Pre-installed
For keeping doors closed
Adjustable Feet
For attaching
to bottom panel
4
2
Pegboard
For hanging tools
Post A
Top and bottom posts
in each stack
Post B
Middle post in
each stack
2
24
Slide Set
Pre-installed
For installing drawers
1
Drawer Liner
For protecting drawers
1

8
A S S E M B LY
BASE CABINET ASSEMBLY
Carefully lay the cabinet on its back, with a soft mat underneath for protection.
Screw the four adjustable feet into the cabinet bottom. Turn the cabinet upright.
WARNING: DO NOT STACK A 1-DRAWER, 2-DOOR BASE CABINET
ON TOP OF ANOTHER CABINET.
WALL CABINET ASSEMBLY
Carefully separate the front and back panels of the wall cabinet, allowing the side panels
to unfold completely.
Make sure the unit is upside down.

9
Insert the lip of the bottom panel into the slot in the back of the cabinet, then tilt the
bottom panel down. Make sure the holes are aligned.
Attach the bottom panel using eleven M6 x 16 mm hex socket head screws.

10
Turn the cabinet back to the upright position. Attach the top panel using eight
M6 x 16 mm hex socket head screws.
Insert four shelf supports inside the cabinet at the desired height.
Place the shelf on the shelf supports.

11
PEGBOARD BACK WALL ASSEMBLY
Attach two A posts to the back of the base cabinet using three M6 x 16 mm hex socket
head screws per post.
Slide two B posts fully onto the A posts.
Place one pegboard on the front, making sure the grommet hole is on the bottom.
Attach using two M6 x 16 mm hex socket head screws per post.

12
Slide two A posts onto the B posts. Make sure to leave enough room at the top for the
wall cabinet.
Place one pegboard on the front, making sure the grommet hole is on the top.
Attach using two M6 x 16 mm hex socket head screws per post.

13
Insert two M6 x 16 mm hex socket head screws into the top holes of the wall cabinet, but
do not fully tighten. Hang the wall cabinet on the top of the posts, then fully tighten the
screws.
Attach the bottom of the wall cabinet to the posts using two additional M6 x 16 mm hex
socket head screws.

14
INSTALLATION
If you have purchased other units, assemble them now, then put all units together to build
your garage.
For a better appearance, attach the sides of each unit together using M6 x 16 mm hex
socket head screws and M6 hex flange nuts at both top and bottom.

15
Hide holes on the exterior ends of the units with the supplied end covers, if necessary.

16
For safety, secure the tops of the each unit to the wall using M6 x 65 mm hex tapping
screws and washers. Use three M6 x 65 mm hex tapping screws and washers on wall
cabinets and three M6 x 65 mm hex tapping screws and washers on base cabinets.
For best results, mount to studs or other solid surfaces. Do not mount to drywall as it will
not support the required weight and poses a danger if mounted incorrectly.

17
DRAWER REMOVAL
Pull the drawer out so that it’s almost fully extended. Push up on the black release lever
on one side, while pushing down on the black release lever on the other side. While
holding the levers in these positions, pull the drawer outward until it is released from the
drawer slide.
ONE SIDE – PUSH UP OTHER SIDE – PUSH DOWN
DRAWER REPLACEMENT
Extend the drawer slides from the unit. Insert the brackets on each side of the drawer
into the slots in the slides, being careful that they are properly positioned. Once properly
inserted, completely close the drawer to set the slides in position.

18
MAINTENANCE
Periodically clean the drawer and door fronts, trim, and other surfaces with mild detergent
and water.
Grease and oil can be removed with most standard cleaning fluids. For safety, use a
nonflammable cleaning fluid.
SAFETY
Use two people to move the units into place. Failure to do so can result in back or other
injuries.
DO NOT leave children unattended near the garage storage system.
WEAR SAFETY GLASSES when removing or repositioning the slides. The tool could
slip, causing personal injury.
DO NOT alter this product in any manner. For example, do not weld external lock bars or
attach electrical equipment. This may cause product damage or personal injury.
Close and lock the doors and drawers before moving this product. The doors could come
open and make the product unstable and tip, which may cause personal injury or product
damage.
Keep the product on level surfaces. The product could become unstable and tip if stored
or moved on an uneven surface, which may cause personal injury or product damage.

19
This product is warranted to be free from defects in materials
and workmanship for a period of five (5) years from the date
of original purchase.
If this product is defective, email [e-mail]
or call 1-800-459-4409 (Monday–Friday, 8:00 am–4:30 pm, CST). If the
product is defective, we will replace the defective part at no cost to you.
Please do not ship your product back to the store or to us
unless we send you written instructions for return.
In the event it becomes necessary for your product
to be returned, we will notify you how to proceed.
A copy of your original purchase receipt must accompany
the returned product.

MF301DW3-EN/FR-06/19
Manufactured by:
QUALITY CRAFT
Surrey, BC, Canada V3S 5N4
[e-mail]
1-800-459-4409
(Monday to Friday, 8:00 am–4:30 pm, CST)
Made in China
