Montgomery Ward MW8000 User manual

Instruction Manual
MODEL: MW8000
115V~, 60Hz, 705W
Wards.com 1•888•557•3848
Montgomery Ward Customer Service
3650 Milwaukee Street, Madison, WI 53714
8:00 am to Midnight, Monday through Friday
Wards.com 1•888•557•3848
Window AC 8000BTU
Energy-
Saving
Mode

Thank you for purchasing your Window Air Conditioner by
Montgomery Ward®. We guarantee that it will perform to the highest
standard, time after time, with all the convenience, easy cleanup and
durability you rely on from Wards.
Your new 8000BTU air conditioner has an easy touch control panel with
digital display. With the convenience of a remote control, you have control of
your environment from anywhere in the room. With just a push of a button,
you can remain cool even while asleep. Cools rooms up to 350 square feet.
3
PLEASE READ THESE INSTRUCTIONS BEFORE USE
Basic safety precautions should always be followed when using your Window Air
Conditioner especially when children are present.
WARNING: TO AVOID THE RISK OF ELECTRICAL SHOCK, ALWAYS MAKE
SURE THE PRODUCT IS UNPLUGGED FROM THE ELECTRICAL OUTLET
BEFORE ASSEMBLING, DISASSEMBLING, RELOCATING, SERVICING OR
CLEANING.
1. Close supervision is necessary when any appliance is used by or near children.
2. Do not allow children or pets to be exposed to direct airflow for long periods of time.
3. To protect against electrical shock, do not place cord, plug or appliance in water or
other liquid.
4. Use a dedicated circuit to avoid a power surge or overloading of the circuit.
5. Do not allow water to get on control panel or into any part of the unit.
6. Discard appliance following local ordinances.
7. Use the plug to disconnect from electrical outlet; never pull out by the cord.
8. Do not modify or alter the plug or power cord.
9. Turn power OFF before removing plug from outlet.
10. Never operate the appliance or remove the plug with wet hands.
11. Do not use an extension cord with this appliance.
12. Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions or has been damaged in any manner. Call our toll-free
customer service number for information regarding replacement, or returning
the product.
13. Do not remove front grill when machine is in use.
14. The back of the unit must be lower than the front of the unit to allow for ad-
equate flow of condensation.
15. Do not block front grill, air inlet or outlet, or in any way restrict airflow.
16. Do not use abrasive cleansers or pads to clean air conditioner.
17. Remove batteries from remote control when not in use for long periods of time.
18. Do not unplug air conditioner when it is operating.
19. Use care when removing the filter. Do not touch metal parts of unit when removing
filter.
Important Safeguards........................3-4
3-Prong Plug......................................... 4
Installation .......................................4-10
AC Removal ....................................... 11
Operating Instructions ...................11-14
Cleaning and Care.........................15-16
Troubleshooting .............................17-18
Warranty & Return Information......20-21
Table of Contents
21•888•557•3848
Wards.com
Important Safeguards
PLEASE SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY
© 2015 Montgomery Ward, Inc. All rights reserved.
ank you
for your
purchase!

41•888•557•3848
Wards.com
45
Installation (cont’d)
3-Prong Plug
This appliance has a 3-prong GFCI (Ground Fault Circuit Interrupter) plug for use in
a 3-prong (grounding) outlet to minimize the possibility of electric shock. This appli-
ance should only be used with a 115V, 60Hz grounded outlet. Failure to follow these
instructions could result in fire, electrical shock, serious injury or death.
If the plug does not fit fully in the outlet, contact a qualified electrician to install a
3-prong (grounding) outlet. Do not attempt to modify the plug in any way. Failure to
follow these instructions could result in fire, electrical shock, serious injury or death.
Important Safeguards (cont’d)
20. Before cleaning, turn power OFF and unplug from electrical outlet.
21. Do not insert body parts or tools into the inlet or outlet grills during operation.
22. Do not ingest water drained from air conditioner.
23. Do not store flammable or combustible liquids by unit.
24. Do not step or sit on air conditioner.
25. Do not store appliance on its side.
26. Do not use appliance for other than intended use.
Installation
Your 8000BTU air conditioner is designed to be installed into standard double hung
windows with an opening width of 24"- 39"and 15.4"vertical height.
1. Cabinet
2. Upper guide
3. Control panel
4. Horizontal louver blades
5. Vertical louver blades
6. Guide panel
7. Front grill
8. Air filter
9. Air inlet
10. Air direction control
1
2
3
6
7
8 & 9
4
5
10

7
61•888•557•3848
Wards.com
Installation (cont’d) Installation (cont’d)
Remove air conditioning unit and accessories from box. Save box to use for storage of
unit during the winter or when not in use for long periods of time.
1. Guide Panel Assembly:
Install the curtain (Item H) into the curtain sash (Item G) with the middle clip on
the inside of the curtain sash. Then slide the curtain clip (Item F) on the end of the
curtain sash to hold curtain in place.
Item Name of Part Qty.
A SCREW (ST4X10FT) 4
BScrew (ST4X16FT) 5
CFoam Strip (adhesive back) 1
DUpper Guide 1
EFoam Strip (non-adhesive back) 1
FCurtain Clip 2
GCurtain Sash 2
HCurtain 2
Tools Required for Installation
• Gloves
• Cross-Tip screwdriver
• Pliers
• 3/8-inch adjustable wrench
• 1/4-inch hex socket and rachet
• Tape measure
• Drill (if pilot holes are needed) with 1/4-inch drill bit
2. Upper Guide:
Secure the Upper Guide (Item D) to the top of the air conditioner using the 4
screws (Item A) provided.

81•888•557•3848
Wards.com
Installation (cont’d) Installation (cont’d)
9
3. Guide Panels:
Extend the curtains in the guide panels and slide them down into the T-shaped
groove on the left and right sides of the unit.
4. Foam Strip:
Cut the adhesive-backed foam strip (Item C) to the width of the window. Remove
backing from foam and attach strip to the underside of the window.
5. Window Center:
With the window open, find and mark the center line of the inner sill.
CAUTION: Hold unit firmly until window sash is lowered to top channel behind the
upper guide. Personal injury or property damage may result if the air conditioner
falls from the window.
6. Install Air Conditioner in Window:
Carefully fit the unit into the open window, lining up the center of the unit with the center
line on the sill.
Firmly hold on to unit while lowering the window sash down behind the upper guide.
Extend side curtains to fill the open window.
When the air conditioner is properly installed it should tilt back and down on the
outside of the window. If it does not, there is a problem with the installation. Cor-
rect installation allows for proper drainage of the condensation.
