Montgomery Ward WSP-1202 User manual

Instruction Manual
MODEL: WSP-1202
120V~, 60Hz, 1350W
Wards.com 1•888•557•3848
Montgomery Ward Customer Service
3650 Milwaukee Street, Madison, WI 53714
8:00 am to Midnight, Monday through Friday
Wards.com 1•888•557•3848
Steam Press
duces
dry cleaning
costs and
time spent
ironing

Thank you for purchasing your Steam Press by Montgomery
Ward™. We guarantee that it will perform to the highest standard,
time after time, with all the convenience, easy cleanup and durability
you rely on from Wards.
Your new steam press will reduce the amount of time you spend ironing,
and cut down on dry cleaning costs, too. You’ll enjoy the easy to use
controls including fabric temp selector and steam burst, and handy features
like the locking knob, ironing board cover, spray bottle and water container.
3
PLEASE READ THESE INSTRUCTIONS BEFORE USE
Basic safety precautions should always be followed when using your Steam Press,
especially when children are present.
WARNING: TO AVOID THE RISK OF ELECTRICAL SHOCK, ALWAYS MAKE
SURE THE PRODUCT IS UNPLUGGED FROM THE ELECTRICAL OUTLET
BEFORE ASSEMBLING, DISASSEMBLING, RELOCATING, SERVICING OR
CLEANING
1. Do not touch hot surfaces. Use any handles or knobs.
2. To protect against electrical shock, do not place cord, plug or appliance in water
or other liquid.
3. To disconnect, turn control to Off, then remove plug from wall outlet. Do NOT pull
directly on the power cord, or use cord as a carrying handle.
4. Do NOT operate any appliance with a damaged cord or plug, or after the
appliance malfunctions or has been damaged in any manner. Call our toll-free
customer service number for information regarding replacement, or returning
the product.
5. Be sure to unplug the electrical cord from the power outlet when not in use.
6. Do NOT let cord hang over edge of table or counter or touch hot surfaces.
7. Do NOT leave the press unattended when young children or pets are present.
8. Children should be supervised and cautioned that the press is NOT a toy and
should NOT be played with.
9. Place the press on a secure, level heat-resistant surface when in use.
10. Do NOT place on or near a hot gas or electric burner, or in a heated oven.
11. Do NOT immerse the press in water or other liquids.
12. Do NOT handle the press with wet hands.
13. Do NOT use extension cords or outlets with inadequate current carrying
capacity.
14. Do NOT use this appliance for other than its intended use. Operating this unit
in any way other than recommended may result in damage to unit or injury to
operator.
Important Safeguards....................... 3–4
Polarized Plug....................................... 5
Parts & Features................................... 6
Assembly & Use ............................. 7–11
Storage & Maintenance...................... 12
Cleaning & Care ................................. 12
Troubleshooting .................................. 13
Warranty & Return Information..... 14–15
Table of Contents
21•888•557•3848
Wards.com
Important Safeguards
PLEASE SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY
© 2014 Montgomery Ward, Inc. All rights reserved.
ank you
for your
purchase!

41•888•557•3848
Wards.com
45
Polarized Plug
Do not attempt to modify the plug in any way.
SHORT CORD INSTRUCTIONS
1. A short power supply cord is provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord.
2. Longer detachable power-supply cords or extension cords are available and may
be used if care is exercised in their use.
3. If a long detachable power cord or extension cord is used:
 •Themarkedelectricalratingofthedetachablepowersupplycordorexten-
sion cord should be at least as great as the electrical rating of
the appliance.
 •Iftheapplianceisofthegroundedtype,theextensioncordshouldbethe
same type 3-wire.
 •Thelongercordshouldbearrangedsothatitwillnotdrapeover
the countertop or tabletop where it can be pulled on by children or tripped
over.
PLASTICIZER WARNING
CAUTION: To prevent Plasticizers from migrating from the finish of the
countertop or tabletop or other furniture, place NONPLASTIC coaster or placemats
between the appliance and the finish of the countertop or tabletop. Failure to do so
may cause the finish to darken. Permanent blemishes may occur or stains can
appear.
15. Do NOT disassemble unit or attempt to make any repairs yourself. Incorrect
assembly or repair could result in risk of fire, electric shock or injury to persons
when operating.
16. Stop using the steam press if the circuit breaker trips. Unplug the steam press
before turning the circuit breaker back on.
17. Always allow your press to cool down for at least 30 minutes before storing in a
cool, dry place.
18. Close supervision is necessary when any appliance is used by or near children.
19. The use of accessory attachments not recommended by the appliance
manufacturer may cause personal injury or damage to the appliance.
20. Do not use outdoors.
Important Safeguards (cont’d)

76 1•888•557•3848
Wards.com
1. Set the press on a flat, level heat-resistant surface.
2. Turn the Locking Knob dial to “unlock” and lift the Pressing Handle to open the
press. The press will automatically stay in lifted position.
3. Before plugging in the press, fill the Water Tank using the Water Refill Con-
tainer provided. Slide the Water Tank forward and pour the water into the holes
of the tank. When finished, slide the tank back into place. Water is only neces-
sary when using the Steam Burst Button.
NOTE: When filling the Water Tank, distilled water is preferred, but
not mandatory.
NOTE: The Water Tank is not removable. It is designed to store any
water left over from use. Do NOT attempt to force it free.
4. Plug in and press On/Off Button. The red Power Indicator Light will illuminate.
Make sure the Pressing Plate is in the open position when the unit is initially
turned on. Make sure the board cover is on before using.
5. Select the desired temperature and allow the press to heat before use. Use
the Fabric Temperature Selection arrows to choose fabric setting. It may take a
few minutes to reach the chosen temperature when decreasing or increasing
settings.
NOTE: It takes approximately 5 minutes for the press to reach the
Linen temperature.
Fabric Nylon Silk Rayon Wool Cotton Linen
Temp. 212°F 266°F 284°F 320°F 392°F 410°F
Steam No No No Ye s Ye s Ye s
Warning: During initial use or after a long period of time without use, press
the Steam Burst Button continuously for several seconds to clear Pressing
Plate of residual water or calcium buildup in system before use.
CAUTION: Be sure to examine the garment label before selecting a fabric
setting. If you cannot determine a fabric type, select the lowest setting and
increase as needed. It is best to start with the most delicate fabrics first to
avoid damage to your fabric.
Assembly and UseParts & Features
A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
K.
L.
M.
N.
O.
P.
Pressing Plate
Pressing Handle
Steam Burst Button
Locking Knob (use when storing)
Removable Ironing Board Cover
Cord Storage Compartment
Water Tank
Ironing Board
Power Light (red)
Ready Light (green)
Steam Ready Light (yellow)
Power On/Off Button
Fabric Temperature Selection
Pressing Cushion
Spray Bottle
Water Refill Container

89
1•888•557•3848
Wards.com
6. The Green Ready Light will illuminate once the press has reached the desired
temperature and is ready for you to start pressing. Be sure to use the provided
Pressing Cushion to flatten out gathered areas such as sleeves, darts and
yokes. If needed, use Spray Bottle for dampening fabric before pressing.
7. Pull down the Pressing Handle and press the Pressing Plate and the Ironing
Board together. Hold for a few seconds, then lift to separate the Pressing Plate
and Ironing Board.
IMPORTANT: Press On/Off Button to cancel your selected pressing cycle.
8. To use steam, adjust the Fabric Temperature Selection to Wool, Cotton or Linen
settings. The Yellow Steam Ready Light will illuminate to let you know that you
are able to use the Steam Burst Button for steaming your garments.
9. Pull the Pressing Handle down directly above the garment. When the handle is
1–2 inches away, push the Steam Burst Button and press the garment. Do NOT
activate Steam Burst Button when the unit is completely closed, you may dam-
age the press.
CAUTION: Do NOT hold down the press for longer than 5 seconds. If using
Steam Burst Button, do NOT fully close the press down onto the fabric. If you
hold down the press for too long, you may cause your garments to wrinkle
because they have gotten too hot. If this should happen, spray the garment
with water and start over.
CAUTION: When using steam, do NOT hold the Steam Burst Button down for
longer than 3 seconds. If steam is used for too long, you will cause the press
to drop dramatically in temperature and will have to wait for it to heat back
up. The drop in temperature cannot be avoided as the burst of steam cools
down the Pressing Plate instantly. By using steam in short bursts, you will
help to eliminate the dramatic temperature drop and thus be able to press
quicker and more efficiently.
Auto Shutoff and Auto Wake-Up:
E1. A warning beep will signal if the Pressing Plate is left in a closed position
against the Ironing Board for more than 10 seconds. The press will stop heating
and the Auto Shutoff feature will initiate unless the Pressing Plate is restored
to the lifted position. The Auto Wake-up feature will then kick in. In some cases,
you will need to either turn press off and then on again or unplug then re-plug
the unit in to reset function.
CAUTION: Do NOT lock Pressing Plate and Ironing Board together as press
will begin to beep. Only lock when storing.
Assembly and Use (cont’d)
E2. A warning beep will signal if the Pressing Plate is left in a lifted position without
use for approximately 10 minutes. The press will stop heating and Auto Shutoff
feature will engage. In order to restore use, simply press On/Off Button or press
Temperature Control buttons to reset the press.
Important note: If you forget to raise the Pressing Plate or become distracted, the
machine will give a warning beep then the Auto Shutoff feature will initiate. The
steam press will completely shutoff after about 10 minutes of no activity with the
press in the open position.
E3. A warning beep may be caused by a loose thermostat inside the machine.
CAUTION: If the E3 warning occurs, unplug your press and call our toll-free
Customer Service for warranty assistance.
WARNING: During initial use or after a long period of time without use, press
the Steam Burst Button continuously for several seconds to clear Pressing
Plate of residual water or calcium buildup in system before use.
NOTE: Some garments have details such as darts, curved seams and shoulder
pads which should not be pressed flat. Use Pressing Cushion provided for use in
these areas.
WARNING: Do NOT attempt to lower the Pressing Plate to its lowest position
or lock the press with the Pressing Cushion in between.You may damage
your press by doing so.
Basic Ironing:
Tablecloth
1. Fold the length of fabric in either half or thirds and place on the Ironing Board.
2. Accordion pleat the length on the Ironing Board and move the pleated item into
the large open space behind the Ironing Board.
3. Move the tablecloth toward you, then press. Continue moving forward until the
entire item is pressed. To store, fold it, place it on the ironing board and close the
press. Apply mini-pressure. If necessary, refold the tablecloth to press any areas
that were hanging off the sides of the Ironing Board. Repeat the pressing proce-
dure.
HINT: Use the same method for most large items, such as duvet covers, bed
sheets, pillowcases, table runners, towels, blankets, quilts, etc.
Assembly and Use (cont’d)

10 11
1•888•557•3848
Wards.com
Pants:
Waistband
•Placethetopofpantsonthepress.PressthePressingBoarddownoverthe
pants to the Ironing Board. If using the Pressing Cushion, place the waistband of
the pants around the board on top of the cushion. Arrange pleats. Rotate pants to
press entire waistband.
Side Pockets
•SlidepocketsoverthePressingCushionoverthePressingBoardthenpress.
Inseam
•Placetheinsideoftheinseamontheboardfacingup.Alignwiththeslantedleft
side of the board. Press.
Legs
•PlacetopofpantleghalfwayontheIroningBoard.Pressthefrontcrease.Then,
place bottom of pant leg half way on the Ironing Board. Allow the hem or cuff to
hang off the end of the board. Press. Follow the same method for pressing back
crease.
NOTE: The hems of the pants can be pressed by placing them both on the Ironing
Board and applying a small amount of pressure.
Shirts & Blouses:
Yoke
•Arrangetheshouldersaroundtheslantedleftsideoftheboard.Letthecollar
hang off the edge. Press.
Cuffs
•PlacethecuffsandplacketsaroundtheedgesoftheIroningCushion.Arrange
any pleats. Press.
Sleeves
•Placethegarmenttotheleftsideofthepresswiththecollartowardyou.Place
the first sleeve on the Ironing Board with the curve of the garment fitted to the
slanted left side of the board (the second sleeve will lay in front of the press off the
board). Press. Remove first sleeve and place second sleeve on the board. Press.
Body
•Putthesleevestogetherandfoldtheshirtinhalf.PlaceitatthebackoftheIron-
ing Board away from you, extending the sleeves behind the board on the right.
Bring the shirt front with the buttons forward first. With your right hand, hold the
collar so that the curved edge of the neck opening is flat against the Ironing
Board. Do not release the collar until you have lowered the Pressing Plate. Press.
Keep pulling the shirt forward until you have worked all the way around.
Assembly and Use (cont’d) Assembly and Use (cont’d)
Shirts & Blouses (continued):
Collar
•Placethecollarontheboard,sprayandpress.Foldthecollarinhalf,sprayand
press.
Shirttail
•ButtonthegarmentandplaceshirttailsquarelyontheIroningBoard.Press.Hang
the shirt on a hanger, or fold it. It is a good idea to let it cool before folding. Use
the Ironing Cushion to retouch any area.
HINT: Use this same procedure on other fitted garments such as blouses, fitted
shirts, jackets, etc.
T-shirt:
•PlaceT-shirtatontheIroningBoard.Dependingonshape,beginwithsleeves.
NOTE: If your T-shirt has rhinestones or an application on it, press with decorated
side face down on the board or turn the shirt inside out.
Pleated Skirt:
•PlacePressingCushionunderwaistbandandpress.Rotateskirtuntilentirewaist-
band is pressed.
•Sliptheskirtovertheboard.Arrangethepleats.Press.Pleatsmayneedtobe
pinned to the Ironing Board Cover. Do not use plastic head pins when using the
press. Rotate skirt until all pleats are pressed.
Jacket:
Sleeves without creases
•Foldthesleeveontheseamlineandplacetheseamlineatontheboard.Allow
the top edge of the sleeve to hang off the edge of the board. Press.
Lapels
•Placelapelsat,diagonallyontheIroningBoard.Press.UseIroningCushionif
needed.
Ties & Ribbons:
•Placethetielengthwiseontheboard.Press.Youcanalsoplacethemhorizontally
on the board and close the press then pull tie or ribbon through it.
Embroidery Items:
Place the garment face down on Ironing Board to reduce wear and prevent dam-
age. If needed, place a towel over the garment then press. This will protect stitch-
ing, rhinestones, etc.

12 13
1•888•557•3848
Wards.com
CAUTION: Prior to storing or maintaining your steam press, isolate the unit by re-
moving the cord from the electrical outlet and avoid immersing the unit in water.
1. Water may be left in Water Tank reservoir; however, it is recommended that if
the machine will be stored for a long period of time, any leftover water in the unit
should be drained by pressing the Steam Burst Button before the end of use until
the Water Tank is emptied.
2. Wait approximately 30 minutes for press to cool down before storing. Once
cooled, lower the Pressing Plate onto the Ironing Board; pull down the Pressing
Handle completely, then turn the Locking Knob to locked position.
3. Loosely wrap electrical cord and place it in the Cord Storage Compartment lo-
cated at the left of the Water Tank on the base of the Ironing Board.
4. Wipe steamer with a soft cloth if/when necessary.
5. Store in a cool, dry place.
Storage & Maintenance
Cleaning & Care
1. Fill Water Tank using the provided Water Refill Container.
2. Place the Pressing Cushion in the center of the Ironing Board.
3. Place a clean towel over the Pressing Cushion and the Ironing Board.
4. Set the Fabric Temperature Selection control to the highest setting (Linen). When
the Steam Ready Light (yellow) illuminates, gently lower the Pressing Plate onto
the Pressing Cushion.
5. Press the Steam Burst Button 6 to 7 times. Be careful to avoid touching the hot
metal surfaces and avoid leaving hands under Ironing Board or Pressing Plate
when using the Steam Burst Button.
6. Once the Pressing Plate has cooled down, you can clean the surface with a damp
cloth. Do NOT use any abrasives on the Pressing Plate. This Pressing Plate has a
nonstick coating that will assist in cleaning.
7. The Ironing Board Cover is removable and can be rinsed with mild detergent and
warm water.
Troubleshooting
Prior to using or maintaining your steam press, isolate the unit by removing the
cord from the electrical outlet.
Problem Solution
LED is not on •Ensurethepresspowercordiscorrectlypluggedintoa
120V power outlet.
•Ensurecircuitbreakerisoperational.
•Tryoperatingthepressfromanotherpoweroutlet.
No heat •Makesuretemperaturehasbeenselected.
•PressingPlatehasbeenleftinraisedpositionformore
than 10 minutes and Auto Shutoff has engaged.
No steam •Watermaybelow,rellWaterTank.
•Temperaturesettingistoolowtoactivatesteam.Select
a higher temperature and wait for Ready Light (yellow)
to illuminate before steaming.
Buttons are not
working properly
•Unplugtheunitfromthepoweroutletfor5minutesthen
plug back in.
E1 Warning •ThePressingPlateandIroningBoardhavebeenheld
together for too long. Separate the plate from the board
and either unplug your unit then plug back in or turn the
press off then on again to restart the unit.
E2 Warning •Ifthepressisleftunusedfortoolong,abeepand
warning will appear. After 10 minutes of no use, the
press will automatically shut off.
E3 Warning •Thereisaloosewireinthethermostat.Unplugyour
press and call Customer Service.
Steam Burst out-
put is weak
•PressingPlateneedstobecleaned.Referto“Cleaning
& Care” section of the manual for proper procedure.

Wards.com 1•888•557•3848
Montgomery Ward, Inc. warrants this product
to be free from defects in material and workmanship
for one year from provable date of purchase.
Within this warranty period, Montgomery Ward will repair or
replace, at its option, defective parts of this
product at no charge, provided the product is returned,
freight prepaid with proof of purchase to Montgomery Ward.
Allow 2-4 weeks for return shipping.
This warranty does not cover improper installation, misuse,
abuse or neglect on part of the owner. Warranty is also
invalid in any case that the product is taken apart or
serviced by an unauthorized service station.
This warranty gives you specific legal rights and they may
vary from state to state.
THE FOREGOING WARRANTIES ARE IN LIEU OF ALL
OTHER WARRANTIES AND CONDITIONS,
EXPRESS OR IMPLIED, INCLUDING
BUT NOT LIMITED TO THOSE OF MERCHANTIBILITY
OR FITNESS FOR A PARTICULAR PURPOSE.
1 Year Limited Warranty
Montgomery Ward Customer Service
8:00 am to Midnight CST, Monday through Friday
1514
Returns
If any item, for any reason, does not meet your expectations, just return it to us.
We’ll gladly either:
 •Refundyourmerchandiseamount
 •Credityouraccount
 •Sendareplacement
You can return any unused item in its original packaging within 60 days of its
receipt for a full refund of the purchase price (excluding shipping and handling
charges).
Please send returns to:
Montgomery Ward, Inc.
Attn: Customer Returns
2000 Harrison Suite 100
Clinton, IA 52732-6676
When returning an item:
 •Usetheoriginalpackagingandpackitsecurely.
 •Pleaseadequatelyinsureyouritemincaseyouneedtomakeaclaim
with the carrier you choose for returning your item.
 •Includeyourordernumberandreasonforreturn.
 •Werecommendkeepingthereceiptfor4weeks.
