Montpelier MLF176W User manual

Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING
176cm Tall Low Frost Fridge Freezer
MLF176W - White
MLF176BK - Black
MLF176WWD - White with Water Dispenser
MLF176BKWD - Black with Water Dispenser
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.

Thank you for choosing this Montpellier appliance.
Our appliances have been designed to provide you with the best combination of style, reliability and performance to
give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing
or using your appliance to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future
reference.
Your appliance is covered by a comprehensive two year Parts & Labour
Guarantee. In the unlikely event that you experience a problem with your
appliance, you can rest assured that you are fully protected against the cost of
repairs for the first 24 months . Please note that any claim must be
accompanied by the model reference number, serial number and proof of
purchase.
To activate your guarantee, you will need your product serial number. This can
be found inside your appliance.
NB: Please make sure that you keep a copy of your original sales invoice as this
will be needed if any service call is required.
There are three ways to register your Guarantee:
• Online: Visit the Support page on our website and complete the online
Product Registration form. www.montpellier-appliances.com
•By Post: Simply detach and fill in the form provided, attach a stamp and send
it in the post. Don't forget to include your e-mail address so that we can send
confirmation through to you.
By Phone: Contact our warranty registration department on 0808 1961388
Welcome
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com
•

Contents
I. SAFETY ........................................................................................................................................................... 4
2. Product Features .......................................................................................................................................... 7
3. Preparation for use ...................................................................................................................................... 8
4.Functions........................................................................................................................................................10
5. Instructions for food storage.....................................................................................................................10
6. Important Reminders ...................................................................................................................................15
7. Maintenance and cleaning ..........................................................................................................................16
8.
Simple fault analysis and elimination ..................................................................................................... 20
9.
Product Information Sheet ......................................................................................................................... 22
Here For You .................................................................................................................................................. 23
Reversing the door swing .......................................................................................................................... 19

1. SAFETY
WARNING!
It is hazardous for anyone other than authorized service personnel to carry out servicing
or repairs which involves the removal of covers. To avoid the risk of an electric shock do not
attempt to repair this appliance yourself.
WARNING!
Risk of fire / flammable materials.
Safety tips
Do not use electrical appliances such as a hair dryer or heater to defrost your Freezer.
Containers with flammable gases or liquids can leak at low temperatures.
Do not store any containers with flammable materials, such as spray cans, fire extinguisher
refill cartridges etc. in the Freezer.
Do not place carbonated or fizzy drinks in the Freezer compartment. Ice lollies can
cause “Frost/Freeze burns”. If consumed straight from the Freezer.
Do not remove items from the Freezer compartment if your hands are damp/wet, as this
could cause skin abrasions or “Frost/Freezer burns”. Bottles and cans must not be placed in
the Freezer compartment as they can burst when the contents freeze.
Manufacturer’s recommended storage times should be adhered to. Refer to relevant
instructions.
Do not allow children to tamper with the controls or play with the Freezer. The Freezer is
heavy. Care should be taken when moving it. It is dangerous to alter the specification or
attempt to modify this product in any way.
Do not store inflammable gases or liquids inside your Freezer.
If the power cable is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons inorder to avoid a hazard.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved. Cleaning and user maintenance shall not be made
by children without supervision.
This refrigerating appliance is not intended to be used as a built-in appliance.
This appliance is intended for domestic household use only.
4

WARNING: Keep ventilation openings in the appliance enclosure or in the built-in
structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: Do not use electrical appliances inside the food storage compartments of
the appliance, unless they are of the type recommended by the manufacturer.
WARNING: Refrigerating appliances – in particular a refrigerator-freezer Type I –
might not operate consistently (possibility of defrosting of contents or temperature becoming
too warm in the frozen food compartment) when sited for an extended period of time below
the cold end of the range of temperatures for which the refrigerating appliance is designed;
WARNING: It's necessary that, for doors or lids fitted with locks and keys, the keys be
kept out of the reach of children and not in the vicinity of the refrigerating appliance, in order to
prevent children from being locked inside.
WARNING: The refrigerant used in your appliance and insulation materials require
special disposal procedures.
WARNING: When positioning the appliance, ensure the supply cord is not trapped or
damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power supplies
at the rear of the appliance
To avoid contamination of food, please respect the following
instructions:
–Opening the doorsfor long periods can cause a significant increase of the
temperature in the compartments of the appliance.
–Regularly clean surfaces that can come in contact with food and accessible drainage
systems.
–Clean water tanks if they have not been used for 48 h; flush the water system connected
to a water supply if water has not been drawn for 5 days.
–Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact
with or dripping onto other food.
–Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or
making ice-cream and making ice cubes.
–One-, two- and three-star compartments are not suitable for the freezing of fresh food.
–If the refrigerating appliance is left empty for long periods, switch off, defrost, clean,
dry, and leave the door open to prevent mould developing within the appliance.
5

Electrical Connection
WARNING
This appliance should be properly grounded for your safety. The power cord of this
appliance is equipped with a three-prong plug which mates with the standard three prong wall
outlets to minimize the possibility of electrical shock. Do not, under any circumstances, cut or
remove the third ground prong from the power cord supplied.
This refrigerator appliance requires a standard 220-240VAC 50Hzelectrical outlet with three-
prong ground.
This refrigerator appliance is not designed to be used with an inverter.
The cord should be secured behind the appliance and not left exposed or dangling to prevent
accidental injury.
Never unplug the refrigerator by pulling the power cord. Always grip the plug firmly and pull
straight out from the receptacle.
Do not use an extension cord with this appliance. If the power cord is too short, have a
qualified electrician or service technician install an outlet near the appliance. Use of an extension
cord can negatively affect the performance of the unit. Improper use of the grounded plug can
result in the risk of electrical shock. If the power cord is damaged, have it replaced by an
authorized service center.
Climate Range
The information about the climate range of the appliance is provided on the rating plate. It
indicates at which ambient temperature (that is, room temperature, in which the appliance is
working) the appliance is designed to run at its optimal performance.
Climate range Permissible ambient temperature
SN from +10°C to +32°C
N from +16°C to +32°C
ST from +16°C to +38°C
T from +16°C to +43°C
Note：Given the limit values of the ambient temperature range for the climate classes for
which the refrigerating appliance is designed and the fact that the internal temperatures could be
affected by such factors as location of the refrigerating appliance, ambient temperature and the
frequency of door opening, the setting of any temperature control device might have to be varied
to allow for these factors, if appropriate.
Note:When operating in an environment other than the specified climate type (i.e.,
beyond the rated ambient temperature range), the appliance may not be able to maintain the
desirable compartment temperatures.
Freon-free
The freon-free refrigerant (R600a) and the foaming insulation material (cyclopentane) that is
environmentally friendly are used for the refrigerator, causing no damage to the ozone layer and
having a very small impact on the global warming. R600a is flammable, and sealed in a
refrigeration system, without leakage during normal use. But, in case of refrigerant leakage due
to the refrigerant circuit being damaged, be sure to keep the appliance away from open flames
and open the windows for ventilation as quickly as possible.
6

7
2. Product Features
Electronic temperature control
Reversible door
No Description
1 Thermostat
2 Refrigerator Glass Shelves
3 Crisper Cover
4 Crisper
5 Freezer Drawers
6 Adjusting feet
7 Bottle frames
No Description
1 Thermostat
2 Refrigerator Glass Shelves
3 Crisper Cover
4 Crisper
5 Freezer Drawers
6 Adjusting feet
7 Bottle frames
8 Water Tank
Due to technological innovation, the descriptions of the product in this manual may not be
completely consistent with your refrigerator. Details are in accordance with the material
item.

8
3. Preparation for use
Installation location
1. Ventilation condition
The position you select for the refrigerator installation should be well-
ventilated and has less hot air. Do not locate the refrigerator near a heat
source such as cooker, boiler, and avoid direct sunlight, thus
guaranteeing the refrigeration effect while saving energy consumption. Do
not locate the refrigerator in the damp place, so as to prevent the refrigerator
from rusting and the risk of electric shock. The result of the total space of
the room in which the refrigerator is installed being divided by the by the
refrigerant charge amount of the refrigerator shall not be less than 8 g/ M³
Note: The amount of refrigerant charged for the refrigerator can be found on
the nameplate.
2. Heat dissipation space
When working, the refrigerator gives off heat to surroundings. Therefore, at
least 30mm of free space should be spared at the top side, more than
100mm on both sides, and above 50mm at the back side of the refrigerator.
Dimensions in mm
W D H A B C(°) E F MODEL
540 550 1760 910 1055 130±550 100
Note：Figure 1, Figure 2 only as a product space demand size schematic diagram.
3. Level ground
Place the refrigerator on the solid and flat ground (floor) to keep it stable, or
else, it will give rise to vibration and noise. When the refrigerator is placed on
such flooring materials as carpet, straw mat, polyvinyl chloride, solid backing
plates should be applied underneath the refrigerator, so as to prevent color
change due to heat dissipation.
Unobstructed ventilation shall be maintained around the appliance.

Preparations for use
1. Standing time
Once the refrigerator is in place make sure that you do not switch it on
immediately. If the appliance has been transported in an upright position it will
require 4 hours to stand before being turned on. If the appliance has been
transported in a horizontal position it will require a minimum of 8 hours
standing time before being switched on so as to ensure normal operation.
2. Cleaning
Confirm all of the accessory parts are inside the refrigerator and wipe the
inside with a soft cloth.
3. Power-on
Insert the plug into the solid socket to start the compressor. After 1 hour, open
the freezer door, if the temperature inside the freezer compartment drops
obviously, it indicates the refrigeration system is working normally.
4. Storage of food
After the refrigerator runs for a period of time, the internal temperature of the
refrigerator will be automatically controlled according to the user’s
temperature setting. After the refrigerator is fully cooled, put in foods, which
usually need 2~3 hours to be fully cooled. In summer, when the temperature
is high, it takes more than 4 hours for the foods to be fully cooled (Try to open
the refrigerator door as little as possible before the internal temperature cools
down).
If the refrigerator is installed in a moist place, make sure to check
whether the ground wire and leakage circuit breaker are normal. If vibration
noises are produced due to the refrigerator contacting the wall or if the wall
gets blackened by air convection around the compressor, move the
refrigerator away from the wall. Setting up the refrigerator may cause
jamming noise or image chaos to the mobile phone, fixed-line telephone,
radio receiver, television set surrounding it, so try to keep the refrigerator as
far away as possible in such cases
9

10
4. Functions
Temperature setting:
The temperature of the refrigerator is controlled by the control panel mounted
in the fridge compartment.
The refrigerator temperature setting cycles as following:
5→4→3→2→1→FASTCOOL→5,
The mode " 3" is recommended and mode" 5 "is not recommended for regular
use so as to avoid frozen food
You can set the ‘fast cool’ function to quickly cool or freeze foods. The fast
cool function will exit automatically after 26 hours, ideally it should be turned
off after 2-3 hours manually.
COLDEST
COLD
5 When the user needs a colder temperature.
4
3 When in normal use.
2 When the user does not need a colder temperature.
1
Note: If the indicator light „5‟ or „3‟ or „1‟ start flickering, it indicates that the refrigerator
has broken down. Please contact the after-sales personnel for on-site service as soon as
possible.
5. Instructions for food storage
Precautions for use
The appliance might not operate consistently (there is possibility of defrosting
or temperature becoming too warm in the frozen food compartment) when
sited for an extended period of time below the cold limit of the ambient
temperature range for which the refrigerating appliance is designed
The information of climate type of the appliance is provided on the rating
plate.
The internal temperature could be affected by such factors as the location
of refrigerating appliance, ambient temperature, and frequency of door open,
etc., and if appropriate, a warning that setting of any temperature control
device might have to be varied to allow for these factors should be made.
Effervescent drinks should not be stored in the freezer compartment or the
low-temperature compartment, and some products such as ice lollies should
not be consumed too cold.
