Montpellier Mcf101w User manual

Chest Freezer

MCF101W - White

MCF151W - White

MCF201W - White

Thank you for choosing this Montpellier appliance.

Our appliances have been designed to provide you with the best combination of style, reliability and performance to

give you years of trouble-free use.

You may be familiar with a similar product, but please take time to read these instructions carefully before installing

or using your appliance to ensure you get the most from your purchase.

We recommend that you keep this manual in a safe place for future

reference.

Your appliance is covered by a comprehensive two year Parts & Labour

Guarantee. In the unlikely event that you experience a problem with your

appliance, you can rest assured that you are fully protected against the cost of

repairs for the first 24 months . Please note that any claim must be

accompanied by the model reference number, serial number and proof of

purchase.

To activate your guarantee, you will need your product serial number. This can

be found inside your appliance.

NB: Please make sure that you keep a copy of your original sales invoice as this

will be needed if any service call is required.

There are three ways to register your Guarantee:

• Online: Visit the Support page on our website and complete the online

Product Registration form. www.montpellier-appliances.com

•By Post: Simply detach and fill in the form provided, attach a stamp and send

it in the post. Don't forget to include your e-mail address so that we can send

confirmation through to you.

By Phone: Contact our warranty registration department on 0808 1961388

Welcome

ACROSS ALL OUR MODELS

YEAR

GUARANTEE

PA R T S & L A B O U R

www.montpellier-appliances.com

•

CONTENTS

Safety Tips ........................................

Climate range ....................................

Locks .................................................

Freon Free ........................................

Names Of The Parts .........................

Transportation Instructions ................

Installation Instructions ......................

Starting ..............................................

Freezer Operation .............................

Storing Frozen food ..........................

Freezing Fresh Food .........................

Defrosting ..........................................

Cleaning And care .............................

Electrical Information .........................

Trouble Shooting ...............................

Here For You .....................................

Changing The Light ............................

SAFETY

WARNING!

It is hazardous for anyone other than authorized service personnel to carry out servicing

or repairs which involves the removal of covers. To avoid the risk of an electric shock do not

attempt to repair this appliance yourself.

WARNING!

Risk offire / flammable materials.

Safety tips

Do not use electrical appliances such as a hair dryer or heater to defrost your Freezer.

Containers with flammable gases or liquids can leak at low temperatures.

Do not store any containers with flammable materials, such as spray cans, fire extinguisher

refill cartridges etc. in the Freezer.

Do not place carbonated or fizzy drinks in the Freezer compartment. Ice lollies can

cause “Frost/Freeze burns”. If consumed straight from the Freezer.

Do not remove items from the Freezer compartment if your hands are damp/wet, as this

could cause skin abrasions or “Frost/Freezer burns”. Bottles and cans must not be placed in

the Freezer compartment as they can burst when the contents freeze.

Manufacturer’s recommended storage times should be adhered to. Refer to relevant

instructions.

Do not allow children to tamper with the controls or play with the Freezer. The Freezer is

heavy. Care should be taken when moving it. It is dangerous to alter the specification or

attempt to modify this product in any way.

Do not store inflammable gases or liquids inside your Freezer.

If the power cable is damaged, it must be replaced by the manufacturer, its service agent or

similarly qualified persons inorder to avoid a hazard.

This appliance can be used by children aged from 8 years and above and persons with

reduced physical, sensory or mental capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use of the appliance in a safe way

and understand the hazards involved. Cleaning and user maintenance shall not be made

by children without supervision.

This refrigerating appliance is not intended to be used as a built-in appliance.

This appliance is intended for domestic household use only.

WARNING: Keep ventilation openings in the appliance enclosure or in the built-in

structure, clear of obstruction.

WARNING: Do not use mechanical devices or other means to accelerate the defrosting

process, other than those recommended by the manufacturer.

WARNING: Do not damage the refrigerant circuit.

WARNING: Do not use electrical appliances inside the food storage compartments of

the appliance, unless they are of the type recommended by the manufacturer.

WARNING: Refrigerating appliances – in particular a refrigerator-freezer Type I –

might not operate consistently (possibility of defrosting of contents or temperature becoming

too warm in the frozen food compartment) when sited for an extended period of time below

the cold end of the range of temperatures for which the refrigerating appliance is designed;

WARNING: It's necessary that, for doors or lids fitted with locks and keys, the keys be

kept out of the reach of children and not in the vicinity of the refrigerating appliance, in order to

prevent children from being locked inside.

WARNING: The refrigerant used in your appliance and insulation materials require

special disposal procedures.

WARNING: When positioning the appliance, ensure the supply cord is not trapped or

damaged.

WARNING: Do not locate multiple portable socket-outlets or portable power supplies

at the rear of the appliance

To avoid contamination of food, please respect the following

instructions:

–Opening the door for long periods can cause a significant increase of the temperature

in the compartments of the appliance.

–Regularly clean surfaces that can come in contact with food and accessible drainage

systems.

–Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact

with or dripping onto other food.

–Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or

making ice-cream and making ice cubes.

–One-, two- and three-star compartments are not suitable for the freezing of fresh food.

–If the refrigerating appliance is left empty for long periods, switch off, defrost, clean,

dry, and leave the door open to prevent mould developing within the appliance.

Climate Range

The information about the climate range of the appliance is provided on the rating

plate. It indicates at which ambient temperature (that is, room temperature, in which

the appliance is working) the appliance will work more efficiently.

Climate range Permissible ambient temperature

SN from +10°C to +32°C

N from +16°C to +32°C

ST from +16°C to +38°C

T from +16°C to +43°C

Note：Given the limit values of the ambient temperature range for the climate classes for

which the refrigerating appliance is designed and the fact that the internal temperatures

could be affected by such factors as location of the refrigerating appliance, ambient

temperature and the frequency of door opening, the setting of any temperature control

device might have to be varied to allow for these factors, if appropriate. If the power cable

is damaged, it must be replaced by the manufacturer, its service agent or similarly

qualified persons in order to avoid a hazard.

Note:When operating in anenvironment other than the specified climate type (i.e., beyond

therated ambient temperature range), the appliance may notbe able to maintain the desirable

compartment temperatures.

Locks

If your Refrigerator is fitted with a lock, keep the key out of reach and not in the vicinity of

the appliance to prevent children being entrapped. When disposing of an old Refrigerator,

break off any old locks or latches as a safeguard.

Freon-free

The freon-free refrigerant (R600a) and the foaming insulation material (cyclopentane) that

is environmentally friendly are used for the refrigerator, causing no damage to the ozone

layer and having a very small impact on the global warming. R600a is flammable, and

sealed in a refrigeration system, without leakage during normal use. But, in case of

refrigerant leakage due to the refrigerant circuit being damaged, be sure to keep the

appliance away from open flames and open the windows for ventilation as quickly as

possible.

NAMES OFTHE PARTS

Due to technological innovation, the product descriptions in this manual may not be

completely consistent with yourfreezer. Details are in accordance withthe real product.

WARNING: Never touch the interior of the Freezer Chamber or frozen foods in

the compartment with wet hands asthis could result in frost bite.

TRANSPORTATION INSTRUCTIONS

The appliance should be transported onlyin a vertical upright position. The packing as

supplied must be intact during transportation.

If during the course of transport the product has been transported horizontally, itmust only

be laid on its left hand side (when facing the door front) and it must notbe operated for at

least 4 hours toallow the system to settle after the appliance is brought back to an upright

position. Failure to comply with the above instructions could result in damage occuring to

the appliance. The manufacturer will not be held responsible if these instructions are

disregarded. The appliance must be protected against rain, moisture and other

atmospheric influences.

IMPORTANT : Care must be taken while cleaning / carrying the appliance to avoid

touching the condenser metal wires at the back of the appliance, as you might injure your

fingers and hands or damage your product.

IMPORTANT :This appliance is not designed for stacking with any other appliance. Do

not attempt to sit or stand on top of your appliance as itisnot designed for such use. You

could injure yourself or damage the appliance.

IMPORTANT : Make sure that mains cable is not caught under the appliance during

and after carrying /moving the appliance, to avoid the mains cable becoming cut or

damaged.”

When positioning your appliance take care not to damage your flooring, pipes, wall coverings

etc. Do not move the appliance by pulling by the lid or handle. Do not allow children to play

with the appliance or tamper with the controls. Our company declines toaccept anyliability

should the instructions not be followed.

light

Handle & Lock

Remove handle and lines

1. If possible avoid placing the appliance near cookers, radiators

or in direct sunlight as this will cause the compressor to run for long

periods. If installed next to a source of heat or refrigerator, maintain

the following minimum side clearances:

4" (100 mm)

12" (300 mm)

From Cookers

From Radiators

From Fridges 4" (100 mm)

2. Make sure that sufficient room is provided around the appliance to ensure free air

circulation. Ideally, A space of no less than 10cm must be left around the freezer,

and ensure you allow gaps as shown in the below diagram.

3. The appliance should be located on a smooth surface.

4. It is forbidden to use the refrigerator outdoors.

5. Protection from moisture. Do not locate the freezer in a moist space to avoid the metal

parts rusting. And do not spray water in to the freezer, otherwise it will weaken the

insulation and causes current leakage.

6. Refer to "Cleaning and Care" section to prepare your appliance for use.

7. If the freezer is installed in unheated areas, garages etc., in cold weather condensation

may form on the outer surfaces. This is quite normal and is not a fault. Remove the

condensation by wiping with a dry cloth.

INSTALLATION INSTRUCTIONS

STARTING

Before you starting to use the freezer, please check that:

1. The interior isdryand air can circulate freely at the rear.

2. Clean the interior asrecommended under "CLEANING AND CARE".

3. Insert the plug into the wall socket and switch on the electricity supply，then the Red light

turns on. Avoid accidental disconnection by taping over the switch. The green light will glow

and the compressor will start running.

4. You will hear a noise as the compressor starts up. The liquid and gases sealed within the

refrigeration system may also give rise to noise, whether the compressor is running or not

which is quite normal.

5. If you going to store already frozen food open the freezer lid and check that the freezer has

reached the correct temperature. Then you can put in your already frozen food.

6. Do not load the appliance immediately after itisswitched on. Wait until the correct storage

temperature has been reached. We recommend that you check the temperature with an

accurate thermometer.

Important Notes:

•If there isa power failure do not open the lid. Frozen food should not be affected ifthe failure

lasts up to 22 hours ( details can be found on the rating plate at the rear of the freezer).Ifthe

failure is longer, then the food should be checked and eaten immediately or cooked and then

refrozen.

•If you find that the lid of the chest freezer isdifficult to open just after you have closed it, don’t

worry. This isdue to the pressure difference which will equalize and allow the lid to be opened

normally after a few minutes.

FREEZER OPERATION

Due to individual factors of the refrigerator, the actual temperature in the box

may have a certain error from the set temperature, which isa normal

phenomenon and does not affect the normal use ofthe product.

The inside temperature of freezer isregulated by the thermostat adjustment knob.

“1,2,3,4,5,6,7”marks onthe knob do not represent the exact temperature, but show that

the smaller number representsthe higher the temperature, conversely, the bigger the

number, the lower the temperature.

The following figure illustrates information as below:

“1（Refrigerator）”:Temperature range（5℃）

“2-4 （Freezer）”:Temperature range（-12~-18℃）

“4-7（Freezer）”:Temperature range（-18~-24℃）

"7（Fast freezer ）": Temperature range（below-24℃）

Thereis a deviation of plus and minus 3℃for eachmode indifferent usage environments

due to the mechanical control mode. Please make adjustments according to actual usage.

Fast freeze ( below -24℃）

When setting the knob to fast freeze this will cause the compressor to run continually. The

low temperature will allow food to freeze quicker and more evenly.

Caution: Do not keep the freezer on fast freeze for more than 2-3 hours. Once you have

finished with fast freeze return the thermostat to your previous setting.

Refrigerating Mode

When changing the status of the freezer to refrigeration you should take the following

steps;

Set the thermostat knob to within the Refrigeration Temperature Range (1-2)

Remove any remaining frozen food from the freezer

Leave the freezer empty for between 1-2 hours

Finally fill with the required food.

When changing from refrigeration status to any other settings you should remove any

food from the freezer to avoid frost damage.

FREEZING FRESH FOOD

Place fresh food to be frozen near the side walls to ensure fast freezing and away from

already frozen food, if possible. Never exceed this maximum capacity. Do not freeze too

large a quantity at any one time.

The quality of the food is best preserved when it is frozen right through to the centre as

quickly as possible.

Take special care not to mix already frozen food and fresh food.

DEFROSTING

Defrost twice a year or when a frost layer of around 7 mm (1/4”) has formed.

Alternatively you may switch off the freezer at the socket outlet and pull out the mains plug.

Extract the water conduit and put in a water container. It is also advisable to place some old

towels on the floor to collect any spills.

6 hours before the defrosting, please set the thermostat knob at "7" position to make

sure the food is at the lowest temperature when you get it out. All food should be

wrapped in several layers of newspaper and stored in a cool place (e.g. fridge or larder).

Remove the freezer basket. Leave the lid open. Containers of warm water may be placed

carefully in the freezer to speed up the defrosting.

Never use hairdryers, electrical heaters or other such electrical appliances for defrosting.

When defrosting has finished drain out the defrost water which collects at the bottom of the

freezer as per the below diagrams and dry the interior thoroughly. After defrosting switch on

the Fast Freeze and leave it on for no more than three hours.

1.A drain outlet is positioned at the bottom of the freezer liner, when defrosting, remove its

rubber cover , then the defrosting water flows out and is discharged from the drain pipe.

2.Extract the water conduit by 20-25mm until the water hole can be seen.

3.Twist the water conduit until the arrow points downward.

4.After defrosting is done, make sure there is no more water coming out before pushing the

conduit back in to place and make sure that the arrow points upward.

STORING FROZEN FOOD

Prepackaged commercially frozen food should be stored in accordance with the frozen food

manufacturer’s instructions for a freezer compartment.

To ensure that the high quality achieved by the frozen food manufacturer and the food

retailer is maintained the following should be remembered:

1. Put packets in the freezer as quickly as possible after purchase.

2. Do not exceed “Use By”, “Best Before” dates on the packaging.

Important Notes:

•Do not use pointed or sharp-edged objects such as knives or forks to remove the frost.

•Never use hairdryers, electrical heaters or other such electrical appliances for defrosting.

•It isnormal that water beads or frosts appear on the freezer collar and door gaskets in wet/

damp weather, this will not affect the normal use. In such cases,please clean it with a dry

cloth !

CLEANING AND CARE

** We recommend that you switch off the freezer at the socket outlet and pull outthe mains

plug before cleaning.

** Never use any sharp abrasive instrument, soap, household cleaner, detergent and wax

polish for cleaning.

** Use lukewarm water to clean the cabinet of the freezer and wipe it dry.

** Use a damp cloth wrung out in a solution of one teaspoon of bicarbonate of soda to one

pint of water to clean the interior and wipe it dry.

** Excess depositsof ice should be removed on a regular basis using a plastic ice scraper

available from your local store. Large accumulation of ice will impair the performance of the

freezer.

** Ifthe freezer isnotgoing to be used for a long period of time switch it off, remove all food,

clean it and leave the lid ajar.

** Check lid seals regularly to ensure they are clean and free from food particles.

Important Notes:

Never use water to wash the compressor, always wipe down the freezer with a dry cloth

thoroughly after cleaning to prevent rust.

DO’S AND DON’TS

Do – Defrost food from the freezer thoroughly in afridge or in amicrowave oven

following defrosting and cooking instructions.

Do – Ensure that chest freezer lid is completely closed after each use.

Do – Defrost frozen meat completely before cooking.

Do – Close the lid gently.

Do – Check contents of the freezer at regular intervals.

Do – Clean and defrost your freezer regularly (See “Defrosting”)

Do – Keep food for as short a time as possible and adhere to “Best Before”, “Use By” dates.

Do – Store commercially frozen food in accordance with the instructions given on the packets

that you buy.

Do – Always choose high quality fresh food and be sure it is thoroughly clean before you

freeze it.

Do – Prepare fresh food for freezing in small portions to ensure rapid freezing.

Do – Wrap all foods in aluminum foil or freezer quality plastic bags and make sure any air is

excluded.

Do – Wrap frozen food when you buy itandput itin to the freezer as soon as possible.

Do – Store small items in the basket provided.

Do – Remove Ice cream from the freezer 5 minutes before serving.

Don’t – Leave the lid open for long periods as this will make the freezer more costly to

run and cause excessive ice formation.

Don’t – Use pointed sharp edged objects such asknives, forks to remove the ice.

Don’t – Put hot food in the freezer. Let itcool down first.

Don’t – Put liquid-filled bottles or sealed cans containing carbonated liquids into the freezer

as they may burst.

Don’t – Store poisonous or dangerous substances in the freezer. Your freezer hasbeen

designed for the storage of edible foodstuffs only.

Don’t – Consume ice-cream and water ices direct from the freezer. The low temperature may

cause ‘freezer burns’ onlips.

Don’t – Freeze fizzy drinks.

Don’t – Try to keep frozen food which has thawed, itshould be eaten within 24 hours or

cooked and refrozen.

Don’t – Remove items from the freezer with wet hands.

Don’t – Shut the lid with force. You will damage the appliance.

Changing the light.

The LED lamp is used by the refrigerator for lighting, this features low energy

consumption and long service life. In case of any abnormality, please contact the after-

sales personnel for service. The LED lamps can only be replaced by the after-sales

personnel.

Lamp type：LED light.

Energy efficiency level：F

ELECTRICAL INFORMATION

THIS APPLIANCE MUST BE EARTHED.

This appliance is fitted with afused three pin plug to BS 1363 which will be suitable for use

in all houses fitted with sockets to current specifications.

If the fitted plug is not suitable for your socket outlets, itshould be cut offand carefully

disposed of. To avoid a possible shock hazard, do not insert the discarded plug into a

socket. This appliance complies with the EEC Directives:

Correct Disposal of this product

This marking indicates that this product should not be disposed with

other household wastes throughout the EU. To prevent possible harm to

the environment or human health from uncontrolled waste disposal,

recycle it responsibly to promote the sustainable reuse of material

resources. To return your used device, please use the return and

collection systems or contact the retailer where the product was purchased.

They can take this product for environmental safe recycling.

War nings for disposal

※Refrigerant and cyclopentane foaming material used for the refrigerator are flammable.

Therefore, when the refrigerator is scrapped, it shall be kept away from any fire source and be

recovered by a special recovering company with corresponding qualification other than be

disposed by combustion, so as to prevent damage to the environment or any other harm.

※When the refrigerator is scrapped, disassemble the doors, and remove gasket of door and

shelves; put the doors and shelves in a proper place, so as to prevent trapping of any child.

Ordered Parted

Printed Circuit board

Light Source

Door Handles

Door Hinges

Trays

Baskets

Door gaskets

Minimum Time Required For provision.

Professional maintenance personnel

Professional repairers and final users

Temperature Sensor

Thermostats

Special for new European standard

The ordered parts in the following table can be acquired from customer

services.

Product Data Sheet concerning (EU) 2019/2019

The product data sheet for your appliance can be found online if you wish to download a

copy.

Go to https://eprel.ec.europe.eu and enter the model identifier for your appliance to

download the data sheet.

Alternatively you can download from https://www.montpellier-appliances.com by going to

the relevant product page.

The model identifier for your appliance can be found on the rating plate at the rear of the

appliance.

Provided By

Professional repairers and final users
