montpellier MON-MCG259 User manual

I
n
s
t
a
ll
a
ti
o
n
a
nd
O
p
era
ti
n
g
I
n
s
t
r
u
c
tio
n
s
MODEL: MON-MCG259
Microwave Oven
Please read these instructions carefully before attempting to install or use this appliance. It
is advisable to keep these instructions in a safe place for future reference.
montpellier
(Picture indicative of model supplied)

2
In
t
roduc
t
ion
Thank you for choosing this montpellier branded appliance. I
t
has been designed to give years of trouble-free use provided
it is installed and maintained correctly.
Please read these instructions carefully before installing or
using your appliance. It is advisable to keep your purchase
and
installation receipts with these instructions in a safe place for
future reference. Included is some important safety information
in addition to guidelines and recommendations that will enab
le
you to take full advantage of all the functions available.
This quality appliance has been tested and certified to meet all
applicable UK electrical and safety standards.
This appliance must be installed and connected in
accordance with current regulations.
After unpacking the appliance ensure that there is no visible
damage. If the appliance has been damaged during transit, do
not use it, contact your retailer immediately.

3
Description
Of
The
Appliance
1. Door & Viewing Window
2. Door Handle
3. LED Display
4. Control Panel
5. Control Knob
(Picture indicative of model supplied)
1. 2.
3.
4.
5.

4
CONTENTS:
Section 1. Installation
Sect
i
o
n 2.
Safety
A
d
v
i
ce
Section 3. Operating the Appliance
Section 4. Maintenance

5
Section 1. Installation
-Remove all packaging, protective film and securing tape from
the appliance.
-Wash the interior of the appliance with warm soapy water.
-Position the appliance in a dry atmosphere.
-Keep the microwave oven away from the TV, Radio or
antenna as picture disturbance or noise may occur.
- Please note that certain parts of this appliance have been
protected with a light film of oil. During initial use you may
see light smoke coming from the oven as the oil is
burnt off. This is quite normal.
-Connect the plug to an adjacent ‘easily accessible’ 13amp
socket outlet and ensure that the appliance is not standing on
the supply cable.
-Never operate this oven without food or liquids inside
-This appliance is fitted with a safety door interlock. Do not
operate the appliance if either of the two interlock levers are
damaged. Please note that the appliance will fail to operate if
the door has not been closed correctly.
-You must never cover or block the air vents on the appliance
cabinet. The air vents ensure good air circulation and allow
the appliance to function correctly. Always ensure that a gap
of 8cm is left between the rear of the appliance and a rear wall
and 8cm between the sides of the appliance and a side wall or
other adjacent appliance. To ensure the correct gap, fit the
supplied plastic spacers as shown below.
Top & Side faces
Plastic Spacers

6
Section 2. Safety Advice
-Please read this booklet thoroughly before installing and
switching on the appliance. The manufacturer accepts no
responsibility for incorrect installation and usage.
-This appliance is guaranteed for Domestic Use Only.
-Do not allow children to play with the appliance.
-This appliance must only be used for cooking/heating foods
and liquids. Do not use it for any other purpose.
-If using an adaptor, this must be used in accordance with the
manufacturers instructions and ensure that the electrical
circuit is not overloaded as this could cause overheating.
-Do not twist or bend the cables, and keep them away from hot
surfaces.
-Do not plug ın or unplug this appliance with wet hands.
-Following installation make sure that the power cable is not
trapped underneath the appliance.
-Remove all twist-ties from food bags before placing them in
the oven.
-Do not heat oil or fat inside the oven.
-Do not over cook food inside the oven.
-Do not heat sealed containers or try to cook eggs (inside their
shells) in this oven – they may explode.
-Potatoes, sausages and items such as chestnuts must be
peeled or pierced before placing them in the oven.
-After liquids have been heated in the oven wait a few
moments before removing the container – handle with care as
the container may be hot – use protective gloves.
-Liquids and foods should be stirred and the temperature
checked prior to consumption.
-If you cover a container with cling film, remove it very carefully
after the cooking process has finished – steam will escape
and may burn your hands.
-Keep the interior surfaces clean. Failure to do this could lead
to the appliance malfunctioning.
-If the power supply cord is damaged, it must be replaced by
the manufacturer, it’s service agent or similarly qualified
persons in order to avoid a hazard.

7
Important Utensil Information
- Do not use metal pans or dishes with metal handles.
- Do not use anything with a metal trim.
- Do not use paper covered wire twist-ties on plastic bags.
- Do not use melamine dishes as they contain a material which
will absorb microwave energy. This may cause the dishes to
crack or burn, and will slow down the cooking speed.
- Use only cookware that is approved to be used in a
microwave oven.
- Do not cook using a container with a restricted opening, such
as bottles, as they may explode.
- Do not heat baby bottles with the teat left on and remove the
teat if replacing the bottle back into the oven.
- Only use thermometers that are approved for microwave
ovens.
- Do not use the microwave oven for heating utensils.

8
Section 3. Operating the Appliance
3.1. Control Panel
LED Display
Panel
Mirowave
Power
Select Button
Pause or
Cancel
Button
Defrost
Select
Button
Auto Menu
Select
Button
Grill/Combi
Selector
Button
Select Steam
& Weight
Input Button
Delay
Start
Button
Start/Reheat
Button

9
3.2. Timer, Power and Cooking Functions
3.2.1. Quick Start
When the door is closed you can start the microwave by pressing
the Start button. The time is automatically set to 1 minute, but
after 5 seconds of operation you can adjust the cook time by
rotating the Control Knob. The power is automatically set to
maximum.
3.2.2. Auto Finish Reminder
At the end of the set cook time an audible signal will be given.
This will be repeated every 2 to 3 minutes until the door is
opened.
3.2.3. Pause/Cancel
At any time during the cook cycle you can pause the program by
simply pressing the Pause button. To restart, press the Start
button. If you want to cancel the program simply press the
Pause/Cancel button twice.
3.2.4. Cooking Power
Press the Micro Power button repeatedly until the required power
level is displayed in the LED Display Panel. Then press the Start
button to commence cooking.
Power Settings:
150W (Min), 300W, 450W (Medium), 600W, 700W, 900W (Max)
3.2.5. Defrost
You can defrost frozen items by weight. For example, if the frozen
food has a weight of 1000g, press the Defrost button and then
turn the control knob until 1000g appears in the LED Display
Panel, then press the Start button.

10
Please note that this program has a built-in pause time to allow
you to check the thawing process. After approximately 1/3 of the
defrost time has elapsed, the oven will pause. If you do not open
the door, the oven will automatically start again after
approximately 3 minutes.
Defrosting Tips:
1. It is better to under estimate defrosting time if you are unsure.
Food will continue to defrost during the standing time.
2. Separate food as soon as possible.
3. Turn large items, e.g. joints, halfway through the defrosting
time, or at pause.
4. Remove any thawed food as soon as possible.
3.2.6. Multi-Function Cooking
You can pre-set the cooking times, power levels and even the
combination of cooking methods. For example, to set the oven to
microwave at 150W for 10 minutes, then 450W for 5 minutes and
finally Grill for 3 minutes, proceed as follows:
1. Press “power” key continuously until the LED display shows
“150”, “microwave”;
2. Turn the control knob until 10.00 appears in the LED display
window and the Start prompt flashes;
3. Press “power” key continuously until the LED display shows
“450”, “microwave”;
4. Turn the control knob until 5.00 appears in the display window.
The Start prompt flashes;
5. Press Grill button once. The grill indicator lights up;
6. Turn the control knob until 3.00 appears in the display window.
The Start prompt flashes;
7. Press the Start/reheat button to start the cooking process.

11
3.2.7. Grill/Combi
Use this function to toast bread etc. Place the food on the grilling
rack and into the oven, then close the door. Press the Grill button
twice to enter the Grill/Combi mode and then turn the Control
Knob to set the required cooking time. Press the Start button to
commence cooking
3.2.8. Steam
To use the steam function, add cold water to the water section of
the steam box and place the food into the food tray. Fit the lid to
the top of the steam box and place the steam box inside the oven.
Press the Steam button and then rotate the Control Knob until the
required cooking time is shown. Press the Start button.
3.2.11 Child lock function
To activate the Child Lock function, press and hold the
Pause/Cancel button until the symbol is shown the LED Display
Panel. The oven will now not operate.
Add water to this section
Add food to this section
Fi
t cover
o
n
top of
the box

12
To cancel the setting, press and hold the Pause/Cancel button
until the symbol disappears from The LED Display Panel.
3.2.12 Utensils guide
You must only use Microwave Safe utensils in this microwave.
Refer to Section 2. Safety Advice (Page 7)
3.2.13 Cooking Tips
a) Place thicker areas of food towards the outer area of the
turntable and thinner food towards the centre
b) Always follow the cooking instructions on the food packaging
c) Turn or stir food during the cooking to ensure even cooking
d) Allow the cooked food to ‘stand’ for a while before consuming
e) If you use a ‘browning’ dish, stand it on a plate in the oven
f) Do not allow plastic ‘cling film’ to come in contact with the food
during the cooking process
3.3. Normal Operating Sounds
You will hear the sound of the motor during operation – this is quite
normal. There will be an audible ‘alarm’ at the end of the cooking
period.

13
Section 4. Maintenance
Before any maintenance or cleaning work is carried out,
DISCONNECT the appliance from the ELECTRICITY supply and
ensure that the appliance is completely cool.
4.1. Internal Cleaning
Clean the interior and accessories with warm soapy water. Rinse
and dry thoroughly. Do not use detergents, abrasive powders, highly
perfumed cleaning products, wax polishes or cleaning products
containing bleach or alcohol.
4.2. External Cleaning
Wash the fascia and door with warm soapy water. Do NOT use
abrasive products.
4.3. What to do if something goes wrong
There is no power to the appliance:
-Check there is not a power cut
-Check there is power to the electric socket/appliance
-Check the fuse in the plug (Must be 13 amp)
The oven will not operate:
-Is the Timer control set to the required time?
-Press the Cancel button twice and try again.
-Has the door been closed correctly?
SERVICE HELP-LINE
Should your appliance develop a fault, please call the
montpellier Service Helpline on:
01527-888133

14
Important Note:
This appliance is marked according to the European directive
2002/96/EC on Waste Electrical and Electronic Equipment
(WEEE). By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences for the
environment and human health, which could otherwise be
caused by inappropriate waste handling of this product.
The symbol on the product, or on the documents
accompanying the product, the Crossed Out Wheelie Bin,
indicates that this appliance may not be treated as household
waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic
equipment.
Disposal must be carried out in accordance with local
environmental
regulations for waste disposal. For more detailed information
about treatment, recovery and recycling of this product, please
contact your local authority, your household waste disposal service
or the retailer where you purchased the product.
We continuously try to improve our products for the benefit of our
customers.
For this reason we reserve the right to make changes to any product
at any time, without notice
Issue: 04/29-08-2013
