Moomba HV700 User manual

2022-09-07 2200700
Moomba® Boats
HV700
Color Displays
2023 Owner’s Manual

2022-09-07 - 2 - 2200700
We continually strive to bring you the highest quality,
full-featured products. As a result, you may find that
your actual display screens may be slightly different
than what was represented in this manual at the time
of printing.
This product can expose you to chemicals including
lead, which is known to the State of California to
cause cancer. For more information, go to
www.P65Warnings.ca.gov.
Trademarks & Patents
Moomba® is a federally registered trademark owned by Skier’s Choice, Inc. Skier’s Choice™, the Skier’s Choice logo,
the Moomba logo, Helix™, Mondo™, Mojo™, Craz™, Smart Plate™ and AutoWake™ are trademarks owned by
Skier’s Choice, Inc. All other trademarks are the property of their respective owners.
AutoWake™ : U.S. Patent Nos. 8,798,825; 9,499,242; 9,689,395; 9,828,075; 9,873,491; 10,093,398; 10,414,470;
10,640,182; 10,717,502; 10,759,507; 10,858,080; 10,926,848, 10,676,166, 11,130,551, 11,358,68 and other patents
pending.
Flow 3: U.S. Patent Nos. 10,040,522; 10,112,688; 10,202,177; 10,239,591; 10,370,071; 10,479,461.
Amplitude Display: U.S. Patent No. 9,950,771; 10,577,054.
See www.skierschoice.com/patents-trademarks/ for virtual patent marking.
Skier’s Choice, Inc. reserves the right to change product specification at any time without incurring obligation.
© 2022 Skier’s Choice, Inc. All rights reserved.

2022-09-07 - 3 - 2200700
Table of Contents
HV700 Product Information....................................................................................................................................................5
Care and Maintenance........................................................................................................................................................ 5
Basic Navigation Features...................................................................................................................................................6
Quick Access Buttons......................................................................................................................................................6
Touch Point Commands..................................................................................................................................................6
Home Screen.......................................................................................................................................................................7
Ballast............................................................................................................................................................................11
AutoWake®........................................................................................................................................................................12
Displacement ................................................................................................................................................................14
Surf System ...................................................................................................................................................................23
Maps..............................................................................................................................................................................25
Settings Menu ...................................................................................................................................................................28
User Settings.................................................................................................................................................................29
Vessel Settings ..............................................................................................................................................................31
Smart Tech Settings ......................................................................................................................................................36
Maps Settings................................................................................................................................................................38
Engine Diagnostics ........................................................................................................................................................44

2022-09-07 - 4 - 2200700
RGB Lights .....................................................................................................................................................................45
System Information.......................................................................................................................................................46
General Troubleshooting Guide........................................................................................................................................47

2022-09-07 - 5 - 2200700
HV700 Product Information The Moomba7” Touch Screen 2023 display
is designed for instrumentation and control
on electronically controlled engines
communicating via SAE J1939 and NMEA
2000. The display is a multi-functional tool
that provides GPS tracking, AutoWake/Surf
controls and ZeroOff®GPS Cruise control
settings while enabling boat operators to
view vital engine, ballast settings and service
codes. Included with this solution is the
HV700 Touch unit.
Care and Maintenance
General maintenance is not required; however, a soft cloth can be used for cleaning the units.
Window cleaner or alcohol can also be used to clean the glass portion of the display. Do not use
harsh or abrasive cleaners on the unit.

2022-09-07 - 6 - 2200700
Basic Navigation Features
All product features are easily accessed through two Quick Access Keys, Touch Point commands
and Menus.
Quick Access Buttons
A new screen can be accessed quickly by pressing one of the following Quick Access Buttons:
Touch Point Commands
Navigation within the screens is controlled by touching the screen’s active areas. These areas are
illustrated within the following sections.

2022-09-07 - 7 - 2200700
Home Screen

2022-09-07 - 8 - 2200700
Touch
Point
Description
Surf Left
When Surf Left is selected, and the speed is below 15 mph, then the starboard tab is active
and deployed to its surf setting. At this point, the surf setting can be adjusted for the
starboard tab on the AutoWake screen (when AutoWake is turned off).
Surf
On/Off
Turns off the Surf system*
Flow 3: U.S. Patent Nos. 10,040,522; 10,112,688; 10,202,177; 10,239,591; 10,370,071; 10,479,461.
See www.skierschoice.com/patents-trademarks/ for virtual patent marking.
Surf Right
When Surf Right is selected, and the speed is below 15 mph, then the port tab is active and
deployed to its surf setting. At this point, the surf setting can be adjusted for the port tab on
the AutoWake screen (when AutoWake is turned off).
Home
Displays the Home screen.
AutoWake
Settings
Pressing this area provides three levels of AutoWake settings: Beginner, Intermediate and
Advanced.
Maps/GPS
Displays the Maps function.

2022-09-07 - 9 - 2200700
Touch Point
Description
AutoWake
On/Off
Turns on and off AutoWake, a patented system that will manipulate the ballast levels in
order to achieve and maintain the best possible wake for surfing and wakeboarding.
Using an inclinometer (a device that measures angle of pitch and roll) the boat will orient
itself for the best boating experience.
Wakeplate
Setting
Displays the current position of the Wakeplate.
Next Screen
Touching this right arrow (or sliding your finger on it from right to left) will display one of
three screens: Home, Ballast/Tabs (when AutoWake is off), AutoWake (when
AutoWake is on), and Maps.
ZeroOff On/Off
Turns on and off the ZeroOff®GPS Speed Control system.
ZeroOff Set
Speed
Adjusts the set speed for the ZeroOff®GPS Speed Control system.

2022-09-07 - 10 - 2200700
Touch Point
Description
Programmable
(2)
Touching these two areas repeatedly will allow you to display two of your desired
display parameters from these choices: coolant temperature, water depth, battery
voltage, water temperature, oil pressure, clock and engine hours.
Water Depth
Displays the depth from the bottom of the boat’s hull to the floor of the water source.
Amplitude
Presets
The Amplitude Presets are used in conjunction with the AutoWake system to achieve
the optimal surf number and wave size. Select between 0%, 50% or 100% Amplitude.
Ballast
When AutoWake is turned off, touching this area will display the ballast screen where
you can adjust each ballast individually or drain/stop/fill all ballasts at the same time.

2022-09-07 - 11 - 2200700
Ballast
Ballast is used to add displacement to the craft
to make the waves or wakes larger for specific
watersports. This Moomba model is outfitted
with one ballast bag located in the front, and two
ballast bags located in the port and starboard
sides of the rear. Touch the graphical level
representation of one of the ballast settings on
the main screen, and this screen will appear:
The highlighted ballast bag will display controls
at the bottom of the screen to increase or
decrease the ballast percentage. Use the –and
+ buttons to achieve the desired level. Touch an
alternate ballast to adjust if necessary.
Touch Drain All, Stop All or Fill All when it is desirable to have all ballasts with the same levels.

2022-09-07 - 12 - 2200700
AutoWake®
AutoWake* is a patented system that will manipulate the ballast levels to achieve and maintain the
best possible wake for surfing and wakeboarding. Using an inclinometer (a device that measures
angle of pitch and roll) the boat will orient itself for the ultimate boating experience.
To activate AutoWake, touch the AutoWake slider bar and slide to the right:
To view the AutoWake screen, touch the Next Screen arrow and slide to the left, or the symbol
at the top middle of the screen. The following Beginning AutoWake page will appear:
*AutoWake™ : U.S. Patent Nos. 8,798,825; 9,499,242; 9,689,395; 9,828,075; 9,873,491; 10,093,398; 10,414,470; 10,640,182; 10,717,502;
10,759,507; 10,858,080; 10,926,848, 10,676,166, 11,130,551, 11,358,68 and other patents pending.

2022-09-07 - 13 - 2200700

2022-09-07 - 14 - 2200700
Adjust the Ballast in increments of 5 by touching the + or –button.
Displacement
Displacement represents the amount of water displaced by the boat
when manipulating ballast and passenger weight for the optimal
waves. At 100% displacement, the total capacity of the boat has
been reached.

2022-09-07 - 15 - 2200700
Changing the Displacement Set Points
The Displacement Set Points can be changed via three different methods:
(1) Touch in the lower left corner and the following will appear:
If Go Home Leveling is selected, autoleveling will
be activated (if AutoWake is turned on). It doesn’t
change the setpoint but will cause AutoWake to go
inactive.
Select 0% AMP, 50% AMP or 100% AMP.
(2) On the Vessel/AutoWake settings page within the Settings menu, choose Edit Setpoints.

2022-09-07 - 16 - 2200700
(3) On the Intermediate AutoWake page (shown on the next page), adjust the Pitch and Roll
values manually.
Touch INT to view the Intermediate Autowake page:

2022-09-07 - 17 - 2200700
This page allows the manipulation of the pitch and roll values. Touch and adjust via the +
and –buttons:
Touch off the Set field and
watch as the Actual Pitch
number changes to your
desired number.
In the middle of the screen
shown is a visual indication of
your displacement values. The
yellow line is the actual
displacement. The blue lines
are what the potential
displacement could be after
manipulation of the ballast.

2022-09-07 - 18 - 2200700
For advanced wake surfing, aim for a
displacement in the upper third of the
scale.
For intermediate to advanced
wakeboarding, aim for a displacement in
the middle third.
For slalom skiing or general boating,
aim for a displacement in the lower third.
If the ballast is at 100% capacity, the Potential will be same as Actual. Once ballast is full, the only
way to add displacement is to add passengers or additional ballast.
Touch ADV to view the Advanced AutoWake page:

2022-09-07 - 19 - 2200700
This page displays a graphical
representation of where to move
or place passengers or ballast to
optimize the weight to pitch and
roll ratio.
Adjust the Ballast level with the +
and –buttons.
Touch Set to adjust the Pitch and
Roll values.
As the values change, the green
highlighting will move to show the
optimal placement of additional
weight to achieve the desired
pitch and roll without the system
moving ballast.

2022-09-07 - 20 - 2200700
AutoWake States
The text above Displacement will show one of six current states of the system:
This State…
Occurs when…
Notes
AutoWake Inactive
•AutoWake is turned off
•Cruise setpoint is below
7mph or above 26mph, or
•When actual speed is below
3mph and within 0.1mph of
setpoint.
AutoWake
Countdown
•All conditions are met in the
AutoWake Inactive state
A countdown of 10 seconds will begin and
remain if conditions continue to be met ushering
in the AutoWake Active stage. If any of the
conditions change to be outside of the Active
limits, the countdown will stop and the state will
go back to AutoWake Inactive. The countdown
will start over once conditions are met.
Continued
