Moosoo YT-E-005D User manual

HOUSEHOLD ICE MAKER
Operating Instructions
Model：YT-E-005D
Congratulations on purchasing our equipment.
Please read this manual carefully and use it correctly as described in the
manual
Keep the manual for future reference.。
Contents
Product introduction……………………………
Product feature………………………
Name of each part……………………
General Safety Warnings…………………
Handing and placing……………………
Electrical connection………………………
Use and operating…………………………………
Preparation before use…………………
Operation panel and function description…………
Water injection and drainage……………………
Reminder ………………………
Cleaning and Maintains…………………………
cleaning……………………………
Maintains……………………………
others………………………
Analysis and elimination of non - fault
phenomena……
Analysis and exclusion of special phenomena………
Recycling……………………………
For proper operation, please read the following
instructions carefully before using the device.Improper
use can cause personal injury and electrical damage。

Product introduction
Product feature
■ fast making ice
Adopting compressor refrigerating technology , ice maker produce bullet efficiently。
■Environment protection
R600a refrigerants and cyclopentane vesicants are hydrocarbons that do not destroy
the ozone layer or produce a greenhouse effect.
■Climate type
Suit for SN,N,ST,T
■Status notes
Low water warning and waning for full storage box-remove ice to continue process。
■ transparent window
The ice making process can be viewed through the transparent window。
■Usage occasion
This appliance is intended to be used in house hold and similar applications such as:
-staff kitchen areas in shops,office and other working environments
-farm house:
-by clients in hotels,motels and other residential type environments:
-bed and breakfast type environments:
List of Main Parts
It is only sketch map for this manual,some feature or parts maybe different with your
machine,pls refer to the product .
1cover(lid) 2transparent window
3 temperature sensor 4 ice maker box
5ice storage box 6Operation panel
7shell 8 ice spoon
9.air outlet 10 outfall
11.air inlet 12 power cord
◇ice house
4-1 ice maker box
（water box）
4-2 evaporator
4-3 connecting rod
4-4 ice shovel plate
◇Ice storage
The storeroom is divided into two parts, the upper part is ice storage area
and the lower part is water storage area.
5-1 ice storage basket
5-2 water max mark
5-3 water mix mark
5-4 water outlet
General Safety Warnings
4-1
4-2
4-3
4-4
5-1
5-2
5-3
5-4
1
2
3
4
5
6
7
8
9
10
11
12

■This device can be used by children aged 8 years and over and by persons
with reduced physical, sensory or mental abilities or lack of experience and
knowledge, provided that they have received supervision or guidance on the wise
use of the device and are aware of the risks involved。
■ Children must not play with the apparatus. Children are not allowed to
clean and maintain without supervision. Children between the ages of 3 and 8
are allowed to take ice。
■ Children should be watched carefully to ensure that they do not play and
climb the ice machine, and do not let anyone climb, sit, stand or lean on the
door (cover) of the ice machine, in order to prevent personal injury and damage
to the ice machine。
■Avoid squeezing, folding, knotting or damaging the power cord. If the
power cord is damaged, it must be replaced by a professional from the
manufacturer, its maintenance department or similar department to avoid danger.
The appliance can only be powered on after the power line is replaced, otherwise
it is easy to cause electric shock or even fire。
■ When unplugging the power plug, do not pull the power cord directly to
prevent it from breaking。
■ When repairing or cleaning the ice maker, the power plug must be
unplugged。
■ The ice maker is mainly used for making and storing ice for a short time,
not for cooling or storing other food and drinks。
■ Only drinking water can be injected to make ice, otherwise it will cause
personal injury and product damage。
■ Do not store explosives such as combustion-supporting sprays in the
appliance。
Danger: Do not store or use inflammable articles, such as gas, paint,
gasoline, etc. near the ice maker, and do not put inflammable and explosive
articles, such as alcohol, gasoline, etc. in the ice maker to prevent explosion
and fire。
Danger: Do not place the ice maker in a damp, spattered area。
Warning: this product is only suitable for making and storing ice cubes.
It is not used for other purposes, such as storing blood and products, medicines,
biological products, chemicals and technical data
Warning: Do not use electrical appliances in the pantry of appliances other
than those recommended by the manufacturer。
Warning: The top of the ice maker should not be placed and used microwave
oven, electric plate pot, voltage regulator and other electrical devices, also
should not be placed on the top of the ice maker heavy objects and liquid
containers, in order to prevent people from falling or liquid overflow caused
by leakage of electricity caused by electric shock and fire
Warning: In case of flammable gas leakage, close the valve of the leakage
source and try to drain the indoor air. Do not unplug appliance power sockets
and operate the ice maker in case of fire.。
Warning: Keep vents in the appliance's housing or internal structure free
of obstacles。
Warning: Do not damage refrigerant circuit. In case of fire and inflammable
material danger, pay attention to avoid igniting inflammable material to cause
fire
Warning: Do not use machinery or other means to speed up the defrosting
process except as recommended by the manufacturer。
Handing and placing
■ handing
Do not hold the door (cover) to move the ice maker, lift it from the lift
structure or bottom of the product design。
Do not lift or turn the ice maker upside down。
■ palcing
◇ The ice maker must be placed on a smooth, horizontal surface,
otherwise it will be dangerous to the user。
◇ The ice maker should be placed in a dry, ventilated place with free
flowing air.In order to avoid overheating, affect the ice making machine use effect
and prevent the occurrence of hazards, the ice making machine ventilation grid to
retain more than 20cm around the space, the top to retain more than 30cm space。
！
！
！
！
！
！
！
！

◇Do not cover or block the ice maker's grille, and keep away from curtains and
other flammable materials.Avoid direct exposure to heat or sunlight.
Warning: When placing equipment, make sure the power cord is not clamped or
damaged.Do not place multiple portable sockets or portable power sources at the
back of the device.
Electrical connection
■Power supply: The ice maker is powered by alternating current (see product
nameplate for specific power supply specifications), and the allowable voltage
fluctuation range is ±10%
■To ensure safe use, the socket and its connecting wire must be able to withstand
more than 10A current.
■
Be sure to use a separate three-core power outlet with a reliable grounding wire.
using
Preparation before use
■Clean the machine and its components before use.
■The appliance needs to sit down for 30 minutes after moving, before switching the
power on. Failure to follow this instruction might cause damage to your Ice Maker
■Pour the water into water storage box (Only allow the water conformed to drinking
standard).
■ cleaning inner。
Start using
■Refer to the instructions for electrical connection. Plug in and turn on
the power。
■ Follow the water injection and drainage instructions。
■Refer to the instructions of the operation panel and function Settings for
setting and starting up
If the ice machine has been moved, please stop for 30 minutes before starting
to make ice, otherwise the refrigeration effect will be affected and the
refrigeration system will be seriously damaged
Please make sure the plug is firmly connected.Loose plugs can cause wires
and sockets to heat up, break, and even catch fire。
Please ensure that the product ventilation grille and surrounding obstacles,
ensure that the product ventilation.
Operation panel and function description
■ standby mode
－After power on，LCD working indicator twinkle，then
the machine will go into standby mode.
－Under ice-making mode, short press the ice-making button,
then the ice-making icon will stop shining, and the
machine will go into standby mode.
■Ice-making mode
－In other working modes except flushing and ice filling reminder mode, press the ice
making button once, the ice making icon flashes and the machine enters the ice
！
！
！
Operation panel illustration description
L/M/S ice size icon
Ice full icon
Unrest ice box icon
Make ice
TIMER
Adjust
Select button
On/off/ice make
Add water icon
set
Time off icon
Time on icon
Timing icon
LCD display

making mode.
－Press the Ice selection button to set the ice size. There are three ice types to choose
from. When selected, the corresponding icon is displayed, which defaults to medium
ice
■Washing mode
Under the standby mode, long pressing ice-making button, for 5 seconds, L/M/S icons
start shining, the machine goes into washing mode.
- Under the washing mode, long pressing ice-making button, for 5 seconds, the washing
mode stop.
■Ice-full reminding mode
- Under standby mode or ice-making mode, when the ice cubes covered the temperature
sensor and the sensor detected that the temperature is about 2C, the ice-full icon will be
lighted, and the machine will make the “di-di”sound for 5 seconds, and go into ice-full
reminding mode automatically.
- When the temperature sensor detected that the temperature is about 4C, the machine will
go into the mode which the machine is working before the ice-full reminding.
■Automatic water affusion and water shortage reminding mode
Under ice-making mode, when the float switch is at the minimum lever line, or the water
box is not full of water, the water shortage icon is shining, making “di-di”sound for 5s and
go into water shortage mode.
- Under water shortage mode, short press the ice-making button, the machine will go into
ice-making mode.
■ice-making box not been reset reminding mode
- Under the ice-making or washing mode, if the ice making box is not at the ice making or
washing place, the ice-making box not been reset icon shining, and make the “di-di”sound
for 5s. The machine automatically go into the ice-making box not been reset reminding
mode.
- 20mins later, the machine will go into ice-making mode automatically.
- Under the ice box not reset mode, short pressing the ice-making button will make the
machine into ice-making mode.
■Clock, appointment time Settings
－Short press the "Set" button to set real-time time, ice making time and standby
time.When the first two digits flicker, press the adjustment key to set the hour
value;When the next two Numbers flash, press the adjustment key to set the minute
value.
－ Sets the real-time time when the clock icon is displayed and the clock
number flashes。
－ When the clock on icon and timer on icon are displayed and the clock number
is flashing, set the reservation time for ice making. The default reservation
time for ice making is 8:00。
－ When the clock icon is displayed, the timer shutdown icon is displayed
and the clock number flashes, set the reserved standby time. The default standby
time is 12:00
－ The clock is set to 24 hours。
■ appointment function
－ In addition to the setting state of clock and appointment time, short press
the adjustment button to turn on or off the appointment function。
－ When the timer boot icon is displayed, turn on the ice making reservation
function。
－ When the timer shutdown icon is displayed, the standby function is
enabled。
◇ Every time I press the button, it will make a "di" sound. The LCD screen is
backlit in 60S and goes out, only ICONS and clock are displayed.
Water injection and drainage
■ Water injection
－ Water injection is required when the water volume in the storage area is
lower than the minimum water level mark or water 。
－ Artificial injection of drinking water into the storage area。

－ Each water injection shall keep the water volume between the maximum and
minimum water level marks and shall not exceed the maximum water level marks。
◇ Warning: Only potable water can be filled。
■ drainage
－ When the water in the storage area is polluted or the inner wall of the
storage area needs to be cleaned, drainage shall be carried out。
－ Remove the power plug before draining the water。
－ Move the ice maker so that the water outlet is in a position suitable for
manual operation and drainage
－ Unscrew the drain nut and remove the plug, the water will flow out
automatically。
－ After draining, plug the plug immediately and tighten the drain nut。
◇ When injecting water or draining water, ensure that no water is injected or
splashed onto the live parts of the appliance to avoid danger
◇ When used again after draining, check whether there is leakage at the drain
outlet to ensure that there is no leakage to continue to use.。
Reminder
■ When the ice - making mode is on, avoid reaching into the ice - making area
to prevent danger。
■ When using purified water or distilled water to make ice, there may be a false
alarm of lack of water, as long as a little salt can be added
■ The design of the ice box is not reset reminder mode is a protective function.
In general：
－ When there is ice or foreign body around the outside of the ice box to block
the rotation of the ice box, it is only necessary to manually remove the ice
or foreign body。
－ When the ice on the icicle greatly affects the rotation of the water box,
it is necessary to wait for the ice to melt naturally before using. It is not
allowed to forcibly remove the ice on the icicle。
■To avoid contamination of food, please follow the following instructions：
－ Opening the door (cover) for a long time can cause a significant increase
in the temperature of the ice maker storage room。
－ Regularly clean surfaces that may come in contact with food and accessible
drainage systems;Clean the water tank if it has not been used for 48 hours;If
water is in the tank for more than 5 days, flush the water circulation system
connected to the water supply system。
－ If the ice maker is empty for a long period of time, close, defrost, clean,
dry, and keep the door (cover) open to prevent mold from forming inside the ice
maker。
Cleaning and care
cleaning
■ Precautions for storage room and external cleaning：
－ You must unplug the plug before cleaning。
－When cleaning, ensure that water does not enter the live area。
－ Use a soft towel dipped in warm water or a neutral cleaner to scrub the inside
and outside surfaces of the ice maker。
－ Do not scrub with a cleaner that contains an abrasive (such as toothpaste),
an acid, a chemical solvent (such as alcohol), or a polish。
－ Do not rinse with water。
Inner cleaning
Refer to the “Affusion”, add the water mixed with 50% vinegar.
Open the swill mode.
After the will mode end, drain the water referring to the “Drainage”
Circling with adding the water, and draining the water along with washing, until
the draining water is clear.
Maintains
The ice maker should be put at the place where is dry and ventilative, to prevent
the machine from the heat source and sunshine.
The over-temperature water should be cooled down to indoor temperature for
ice-making.

Reduce the time of keeping the door/cover open.
■Clear the ventilating grill at regular time.
Other attentions
Turn off, stop using
－ Take out the plug if you want to turn off the machine.
－If the machine will stop using for a long time, please work as these steps:
cleaning, turn off the machine, and leave a little gap between the door and the
machine.
ATTERNTION: IF YOU DECIDE NOT TO USE THE ICE MAKER ANY MORE, THE STORAGE COULD
NOT STOGE ANY FOOD
Non - fault phenomenon analysis and elimination
Fog condensation：
The air humidity may be too high. Please rub away the drop of water.
Obvious different size of ice cube
Stop and restart, try several times. The cooling system is not stable at first
several rounds.
The ambient temperature is too low.
Ice cube too small
Ambient temperature is too high or the water temperature is too high.
Strange noise (“si-si” “hu-hu” “di-da” “wu-wu”)
When the cooling system is working, the freezing medium flowing in the tube will
cause the noise of “si-si”;
When the cooling system is working, the wind fan will cause the noise of “hu-hu”.
When the water box arrives at the deice place, it will cause the noise of “di-da”
by turning on/off the solenoid valve.
When it is watering to the inner box, it will cause the noise of “wu-wu”.
All the above situations are normal.
Analysis and exclusion of special phenomena
phenomena
Possible cause
handling method
No DISPLAY on
LCD screen, no
prompt sound
when pressing
keys
The power plug is not
properly plugged in;
Power failure; The
control system is broken
Plug into a power outlet;
Check for power failure;
Professional personnel are
needed to check the
maintenance control system
Leakage water
The drain nut is not
tightened; The drain
plug is not plugged;
Excessive water
injection exceeds the
position of the ice box,
and the internal water
circulation pipe is not
connected properly or
damaged；
Tighten the nut; Plug the plug
and tighten the nut; Remove
excessive water, need
professional personnel to
check and maintain the
internal water circulation
line;
If there is
water in the
storage area,
please add
water
The ice-making mode is
not on; The amount of
water below the minimum
water level; The outlet
of water storage area is
blocked; Pure or
distilled water is
injected; Fault of
internal water
circulation and its
detection system
Turn on ice making mode; Add
water according to the water
injection instructions;
Remove foreign matter from
outlet of water storage area;
Add a little salt to purified
water or distilled water;
Professionals are needed to
inspect and maintain the
internal water circulation
and its detection system;
Ice storage
area free of ice
or small amount
of ice,
indicating full
The ambient temperature
of the place is lower
than 3 ℃ ; Ice on the
temperature sensor; The
temperature sensor
Place in a suitable
environment; Remove ice
shelved or automatically
recover after ice melts
naturally; Professionals are
！

ice
parameters change;
needed to check and replace
the temperature sensor;
Ice full icon
flashes (you
can still make
ice with this
phenomenon)
The temperature sensor
connection wire falls
off, breaks or internal
short circuit
Professionals are needed to
check and replace the
temperature sensor;
There is a
continuous
reminder that
the ice box is
not reset
See tips; Failure of ice
making box and its
internal driving
mechanism and detection
system;
Operate according to warm
prompts; Professionals are
needed to check and maintain;
Ice - making
mode operates
normally, no
ice or a small
amount of ice
The refrigeration
system is not stable in
operation; Ventilation
grille is blocked; Fan
not working or
refrigeration system
failure；
Continuous observation;
Remove objects near the
ventilation grille and dust
accumulation; Professionals
are needed to check and
maintain;
Difficulty or
inability to
shed ice
Low ambient
temperature; The ice
fell into the ice box,
causing the ice to
become too large for
reprocessing; Failure
of refrigeration system
and its control system;
Place in a suitable
environment; Operate
according to warm prompts;
Professionals are needed to
check and maintain;
abnormal noise
Resonance; Internal
motion, control device
noise;
When making ice, the internal
electric components will
vibrate to ensure that no
other items near the ice maker
will be affected by the
vibration, resulting in
product resonance and noise.
Professional personnel are
needed for inspection and
maintenance.
LCD display
cracked or icon
missing
LCD display is broken
Professionals are required to
check and replace the control
board;
Recycling (Disposal of the product at the end of its life)
Waste Electrical Products Should Not Be Disposed Of With Household Waste. Please
Recycle Where Facilities Exist. Check With Your Local Authority For Recycling
Advice
