Moosoo YT-E-005A User manual

HOUSEHOLD ICE MAKER
Instruction Manual
For any questions and malfunctions of the appliance during use, please contact our
customer service email: [email protected]
Model：YT-E-005A/B
110 - 120V 60Hz

CONTENT
PRODUCT INTRODUCTION
OPERATING INSTRUCTIONS
CLEANING AND MAINTENANCE
TROUBLESHOOTING
RECYCLING (DISPOSAL OF THE PRODUCT)
01
04
07
08
09

PRODUCT INTRODUCTION
Overview
■ Fast ice-making
Adopting compressor refrigerating technology, ice maker produce bullet shape ice efficiently.
■ Environment protection
R134a refrigerants and cyclopentane vesicants are hydrocarbons that do not destroy the ozone
layer or increase greenhouse effect.
■ Climate type
Usable for SN,N,ST,T types of climate.
■ Status prompts
Warning the full of prompt tones and indicator lights
■ Viewing window
The ice making process can be viewed through the transparent window.
■ Applicable scene
This machine is intended for household use and similar applications such as:
- Staff kitchen areas in shops,office and other working environments
- Farm house
- By clients in hotels, motels and other residential type environments
- Bed and breakfast type environments
1
1. Cover(lid)
2. Viewing window
3. Temperature sensor
4. Ice maker box
5. Ice storage box
6. Operation panel
7. Housing
8. Ice shovel
9. Air outlet
10. Water outlet
11. Air inlet
12. Power cord
Product feature
1
2
3
4
5
6
7
8
9
10
11
12

General safety warnings
The storeroom is divided into two parts, the upper part is ice storage area and the lower part is
water storage area.
2
4-1 Ice maker box(water box)
4-2 Evaporator
4-3 Connecting rod
4-4 Ice shovel plate
5-1 Ice storage basket
5-2 Water max mark
5-3 Water min mark
5-4 Water outlet
Ice making space
Storage
■ This machine can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of this device in a safe way and understand
the hazards involved.
■ Children must not play with the machine. Children are not allowed to clean and maintain without
supervision. Children between the ages of 3 and 8 are permitted to take out ice under supervision.
■ Children should be watched carefully to ensure that they do not play and climb the ice machine,
and do not let anyone climb, sit, stand or lean on the door (cover) of the ice machine, in order
to prevent personal injury and damage to the ice machine.
■ Avoid squeezing, folding, knotting or damaging the power cord. If the power cord is
damaged, it must be replaced by a professional from the manufacturer, its maintenance
department or similar department to avoid danger. The machine can only be powered on
after the damaged power cord is replaced, otherwise it is easy to cause electric shock or
even fire.
■ When unplugging the power plug, do not yank the power cord directly but grab the plug instead
in case of damaging the cord.
■ When maintaining or cleaning the ice maker, it must be unplugged from the socket.
■ The ice maker is mainly used for making and storing ice for a short time, not for cooling or storing
other food and drinks.
■ Only use drinking water for making ice, otherwise it may cause personal injury and product
damage.
■ Do not store explosives such as combustion-supporting sprays in the machine.
4-1
4-2
4-3
4-4
5-1
5-2
5-3
5-4
5-5
5-5 Water storage

3
Danger: Do not store or use inflammable articles, such as gas, paint, gasoline, etc. near
the ice maker, and do not put inflammable and explosive articles, such as alcohol, gasoline,
etc. in the ice maker to prevent explosion and fire.
Danger: Do not place the ice maker in a damp, spattered area.
Warning: This product is only suitable for making and storing ice cubes. It is not used for
other purposes, such as storing blood, products, medicines, biological products, chemicals
and technical documents.
Warning: Do not place any electric machines or containers containing on the top of the
ice maker in case of falling causes injuries to people or triggering electric shocks by leaking
of liquid.
Warning: In case of flammable gas leakage, close the valve of the leakage source and
try to drain the indoor air. Do not unplug machine power sockets or operate the ice maker
before ventilating the gas in case of triggering fire..
Warning: Keep outlets and inlets in the machine's housing or internal structure free of
obstacles.
Warning: Do not damage refrigerant circuit. In case of causing fire, please pay attention
to avoid igniting inflammable material.
Warning: Do not use machinery or other means to speed up the defrosting process
except for recommendation from the customer service.
Carrying and placement
Carrying
Do not hold the door (cover) to move the ice maker, lift it by the handle or bottom of the
product design.
Do not lay down or turn the ice maker upside down.
Placement
◇The ice maker must be placed on a smooth, horizontal surface.
◇The ice maker should be placed in a dry, ventilated place with free flowing air. In order to avoid
overheating and affecting the ice making machine and prevent the occurrence of hazards, leave
20 cm clear space for each side of the machine and 30 cm of its top.
◇Do not cover or block the inlets and outlets of ice maker, and keep it away from curtains and
other flammable materials. Avoid direct exposure to heat or sunlight.
Warning: When placing equipment, make sure the power cord is not clamped or damaged.
Do not place multiple portable sockets or portable power sources behind the device.

OPERATING INSTRUCTIONS
4
Electrical connection
■ Power supply: The ice maker is powered by alternating current (see product nameplate for
specific power supply specifications), and the allowable voltage fluctuation range is ±10%.
■ To ensure safe use, the socket and its connecting wire must be able to withstand more than
10A current.
■ Be sure to use a separate three-core power outlet with a reliable grounding wire.
Preparation before use
■ Remove all protective materials on the machine.
■ Check if there are accessories missed in the package.
■ Place the machine well according to the Carrying and placement.
■ Clean the machine thoroughly according to the Cleaning and Maintenance.
Start using
Operation panel and function description
■ Refer to the instructions for electrical connection. Plug in and turn on the power.
■ Refer to the water injection and drainage instructions.
■ Refer to the instructions of the operation panel and function Settings for setting and start using
the machine.
If the ice machine has been moved, please stop for 30 minutes before starting to
make ice, otherwise the refrigeration effect will be affected and the refrigeration system
may be damaged.
Please make sure the plug is firmly connected.Loose plugs can cause wires and sockets to
heat up, break, and even catch fire.
Please ensure that the product ventilation grille and surrounding obstacles, ensure that the
product ventilation.
Operaon panel illustraon descripon
Icefull indicator light
Working indicator light
Icemaking buon
Add Water Indicator light

■ Standby mode
－After plugging in the machine, the working indicator light flickers as the machine enters
standby mode.
－ Under ice-making mode, short press the ice-making button, then the working indicator light
will stop flickering, and the machine will go into standby mode.
■ Ice-making mode
－In any working modes except Washing Mode, Add Water Mode and Ice Full mode, press
the ice making button once, the ice making icon flashes and the machine enters the ice
making mode.
■ Washing mode
－Under the standby mode, long pressing ice-making button for 5 seconds, all lights will be
on and the machine enters washing mode.
－When the washing process is over, it automatically returns to standby mode.
－Under the washing mode, long press ice-making button for 5 seconds to stop the washing
mode.
■ Ice Full mode
－Under standby mode or ice-making mode, when the ice cubes cover the temperature
sensor and the sensor detects that the temperature is less than 37°F, the ice-full icon will be
lighted and the machine will beep for 5 seconds before entering ice-full reminding mode
automatically.
－When the temperature sensor detects that the temperature is about 41°F, the machine will
return to ice-making mode. Short press again, the machine will enter standby mode.
■ Water shortage reminding mode
－Under ice-making/ washing mode, when the float switch is at the minimum, or the water
box is not filled with water, the add water icon will be shining, beep for 5 seconds and enter
water shortage mode.
- Under water shortage mode, short press the ice-making button to enter ice-making mode.
■ Ice box incorrect position reminder mode
－In the process of ice making and washing mode, if the ice box fails to reach the water
injection or ice making position within 2 minutes, the Add Water and Ice Full indicator lights
will both flicker, as well as the Working indicator light. The machine will beep for 5 seconds.
－After 20 minutes, the machine automatically returns the ice-making mode.
－Short press the ice making key to enter the ice making mode when the ice making box is
not in correct place.
5

Water injection and drainage
■ Water injection
－Water injection is required when the water volume in the storage area is lower than the
minimum water level mark.
－Add drinking water into the the water storage area.
－Each water injection shall keep the water volume between the maximum and minimum
water level marks and shall not exceed the maximum water level marks.
◇Warning: Add potable water only.
■ Drainage
－Drain the machine when the water in the storage area is polluted or the inner wall of the
storage area needs to be cleaned.
－Unplug the power cord before draining the water.
－Move the machine to a position where is suitable for manual operation and storage.
－Unscrew the drain nut and remove the plug, the water will flow out automatically.
－After draining, put the plug back immediately and tighten the drain nut.
◇When injecting water and draining water, ensure that no water is injected or splashed onto
the live parts of the machine to avoid danger.
◇When used again after draining, check whether there is leakage at the drain outlet for
further use.
Kindly reminder
■ When the ice-making mode is on, avoid reaching into the ice-making area with bare hand.
■ When using purified water or distilled water to make ice, there may be a false alarm of lack of
water. Just add small amount of salt to cancel the alarm.
■ The reminder of the ice box not being placed is a protective function. In general：
－When there is ice or foreign objects blocking the rotation of the ice box, please manually
remove the ice or foreign objects.
－When the ice on the evaporator greatly affects the rotation of the water box, it is necessary
to wait for the ice to melt naturally before using. It is not allowed to forcibly remove the ice
manually.
■ To avoid contamination of food, please follow the following instructions：
－Opening the door (cover) for a long time can cause a significant increase in the tempera-
ture of the ice maker storage room.
－Regularly clean surfaces that may come in contact with food and accessible drainage
systems.Clean the water tank if it has not been used for 48 hours; If water is in the tank for
more than 5 days, flush the water circulation system connected to the water supply system.
－If the ice maker is empty for a long time, close, defrost, clean, dry, and keep the door
(cover) open to prevent mold from forming inside the ice maker.
6

CLEANING AND MAINTENANCE
Water injection and drainage
■ Water injection
－Water injection is required when the water volume in the storage area is lower than the
minimum water level mark.
－Add drinking water into the the water storage area.
－Each water injection shall keep the water volume between the maximum and minimum
water level marks and shall not exceed the maximum water level marks.
◇Warning: Add potable water only.
■ Drainage
－Drain the machine when the water in the storage area is polluted or the inner wall of the
storage area needs to be cleaned.
－Unplug the power cord before draining the water.
－Move the machine to a position where is suitable for manual operation and storage.
－Unscrew the drain nut and remove the plug, the water will flow out automatically.
－After draining, put the plug back immediately and tighten the drain nut.
◇When injecting water and draining water, ensure that no water is injected or splashed onto
the live parts of the machine to avoid danger.
◇When used again after draining, check whether there is leakage at the drain outlet for
further use.
Kindly reminder
■ When the ice-making mode is on, avoid reaching into the ice-making area with bare hand.
■ When using purified water or distilled water to make ice, there may be a false alarm of lack of
water. Just add small amount of salt to cancel the alarm.
■ The reminder of the ice box not being placed is a protective function. In general：
－When there is ice or foreign objects blocking the rotation of the ice box, please manually
remove the ice or foreign objects.
－When the ice on the evaporator greatly affects the rotation of the water box, it is necessary
to wait for the ice to melt naturally before using. It is not allowed to forcibly remove the ice
manually.
■ To avoid contamination of food, please follow the following instructions：
－Opening the door (cover) for a long time can cause a significant increase in the tempera-
ture of the ice maker storage room.
－Regularly clean surfaces that may come in contact with food and accessible drainage
systems.Clean the water tank if it has not been used for 48 hours; If water is in the tank for
more than 5 days, flush the water circulation system connected to the water supply system.
－If the ice maker is empty for a long time, close, defrost, clean, dry, and keep the door
(cover) open to prevent mold from forming inside the ice maker.
Cleaning
■ Precautions for storage room and external cleaning：
－Please unplug the machine before cleaning.
－Make sure water does not touch the circuit.
－Use a soft towel dipped in warm water or a neutral detergent to scrub the inside and
outside surfaces of the ice maker.
－Do not clean with a detergent that contains an abrasive (such as toothpaste), an acid, a
chemical solvent (such as alcohol), or a polish.
－Do not rinse the machine with water.
Inner cleaning
Refer to the “Injection”, add the water mixed with 50% vinegar.
Open the washing mode.
After the washing mode ends, drain the water referring to the “Drainage”
Circling with adding the water, and draining the water along with washing, until the draining
water is clear.
The ice maker should be placed at the place where is dry and ventilative, to prevent the
machine from the heat source and sunshine.
The over-temperature water should be cooled down to ambient temperature for ice-making.
Reduce time of keeping the door/cover open.
■ Clear the ventilating grill at regular time.
Maintenance
Other attentions
7
Turn off
－Unplug the machine if you want to turn off it.
－If the machine won't be used for a long time, please work as these steps: turn off the
machine, cleaning and leave a little gap between the door and the machine.
Attention: The ice maker is not supposed to use for storing food.
Non - fault phenomenon analysis and elimination
Fog condensation appears on the housing:
－The air humidity may be too high. Please rub away the drop of water.
The size of ice tube varies too obviously
－Stop and restart, try several times. The cooling system is not stable at first several rounds.

TROUBLESHOOTING
－The ambient temperature is too low.
Ice cube is too small
Ambient temperature is too high or the water temperature is too high.
Strange noise
When the cooling system is working, the freezing medium flowing in the tube will make noise.
When the cooling system is working, the fan will make noise.
When the water box arrives at the deice place, turning on/off the solenoid valve may make noise.
When the water is injected into the inner box, the pump will make noise.
All these noise are normal.
8
The indicator light is not
on and there is no sound
when pressing the button
keys
The adding water
indicator light is on while
there is still water left in
the storage area
There is no ice in or little
ice in the ice storage area
while the ice full indicator
light is on
1.The ice-making mode is
not on
2. The amount of water
below the minimum
water level
3. The outlet of water
storage area is blocked
4. Pure or distilled water is
injected
1. Turn on ice making mode
2. Add water according to
the water injection
instructions
3. Remove foreign matter
from outlet of water
storage area
4. Add a little salt to purified
water or distilled water
1.Place in a suitable
environment
2.Remove ice shelved or
automatically recover
after ice melts naturally
1.The power plug is not
properly plugged in
2. Power failure
1. The drain nut is not
tightened
2. The drain plug is not
plugged
1. The ambient tempera-
ture of the place is
lower than 37°F
2. Ice on the temperature
sensor
1. Tighten the nut
2. Plug the plug and tighten
the nut
Water leakage
1. Plug into a power outlet
2. Check for power failure
Problem Possible cause Potential solutions

RECYCLING (DISPOSAL OF THE PRODUCT)
Waste electrical products should not be disposed along with household waste.
Please recycle according to local regulations.
If the solutions above could not solve your problems or there are any other queries, please contact
with our customer service at [email protected].
9
1. The refrigeration system is
not stable in operation
2. Ventilation grille is blocked
Ice full indicator light flashes
(while you can still make ice )
Ice-making mode operates
normally, no ice or a small
amount of ice comes into
being
Difficulty or inability to shed
ice
Abnormal noise
There is a continuous reminder
that the ice box is not reset
1. Make sure that the
machine is placed on a
stable surface and it is
able to work continuously
2. Remove objects near the
ventilation grille and dust
accumulation
The temperature sensor
connection wire falls off,
breaks or internal short
circuit
When making ice, the
internal electric compo-
nents will vibrate. Make
sure that no other items
near the ice maker will be
affected by the vibration,
resulting in product
resonance and noise
1. Low ambient temperature
2. The ice fell into the ice
box, causing the ice to
become too large for
reprocessing
Noise comes from resonance
1. Place in a suitable
environment
2. Operate according to
Kindly reminder
Contact customer service for
help
Refer to Kindly Reminder Operate according to Kindly
Reminder
Problem Possible cause Potential solutions
