Mora MRB221N6BSE User manual

Refrigerator Use & Care Guide
For questions about features, operation/performance, parts or service, call:
1-877-465-3566
English
MRB221N6BSE
Model:

....................................................................................................
.....................................................................................................................
.............................................................................................................
...............................................................................................................
.......................................................................................................................
...............................................................................................
................................................................................................
.....................................................................................................................
Table of Contents
Brief introduction
Important safety instructions
Installing your new appliance
Description of the appliance
Display controls
Using Your New Appliance
Cleaning and care
Helpful hints and tips
Troubleshooting
Disposal of the appliance
.................................................................................................
Brief Introduction
Please ensure that everyone using this
appliance is familiar with its operation
and safety features. It is important that
you install the appliance correctly and
pay careful attention to the safety
instructions.
We recommend that you keep this user’s
manual with the appliance for future
reference.
This appliance is intended to be used
in households and similar applications
such as:
are sure you will find your new refrigerator
a pleasure to use. Before you use the
appliance, we recommend that you
carefully read through these instructions,
which provide details about installing and
using the product.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have supervision or been given
instruction concerning use of the appliance.
Children should be supervised to ensure
that they do not play with the appliance.
Do not store explosive substances such as
aerosol cans with a flammable propellant
in this appliance.
Kitchen areas in shops, offices and other
working environments.
Hotels, motels and other residential
environments.
Bed and breakfast environments.
Catering and similar non-commericial
applications.
WARNING
Do not use mechanical devices or other
means to accelerate the defrosting
process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside
the food storage compartments of the
appliance, unless they are of the type
recommended by the manufacturer.
When disposing of the appliance do so
only at an authorized waste disposal
center. Do not expose to flame.
If the power cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in
order to avoid a hazard.
Keep Ventilation openings, in the appliance
enclosure or in the built-in structure, clear of
obsturction.
...................................................................................................
Thank you for your choosing MORA. We
2
2
3
5
15
16
20
22
23
25
27

General safety and daily use
It is important to use your appliance safely.
We recommend that you follow the
guidelines below.
Store any food in accordance with the
storage instructions from the manufacturer.
Important Safety Instructions
Safety for children and other
persons
This appliance is intended to be used in
household and similar applications such
as：
- staff kitchen areas in shops, offices and
other working environments;
- farm houses and by clients in hotels,
motels and other residential type
environments;
- bed and breakfast type environments;
- catering and similar non-retail
applications.
Don’ t try to repair the appliance yourself.
It is dangerous to alter the specifications
or modify this product in any way. Any
damage to the power cord may cause a
short circuit, fire or electric shock.
Don’ t place too much food directly
against the air outlet on the rear wall
of both the refrigerator and freezer
compartment, as it may affect important
air circulation.
Don’ t place hot items near the plastic
components of this appliance.
Frozen food must not be refrozen once it
has been thawed out.
Don’ t store bottled or canned drinks
(especially carbonated drinks) in the
freezer compartment. Bottles and cans
may explode.
Keep all packaging away from children
to avoid risk of suffocation.
Protect children from being scalded by
touching the compressor at the rear
bottom of appliance
Don’ t place items on top of the
appliance as this could cause injury
should they fall off.
Never allow children to play with the
appliance by hanging or standing over
or on the doors, racks, shelves and
drawers etc.
Electrical Safety
To avoid the risks that are always present
when using an electric appliance, we
recommend that you pay attention to
the instructions about electricity belo
w.
Unpack and check through the
appliance. Should any damage be
evident, don’ t plug in the appliance but
contact the shop immediately from
which you purchased it. Keep all
packing materials in this case.
We recommend that you wait for 4 hours
before connecting the appliance to
allow the refrigerant to flow back into
the compressor.
The appliance must be applied with
single phase alternating current of
110~115V/60Hz. If the voltage fluctuates
exceeding the upper limit, A.C.
automatic voltage regulator of more
than 350W should be applied to the
refrigerator for safety use.
Electrical Safety
To avoid the risks that are always present
when using an electric appliance, we
recommend that you pay attention to
the instructions about electricity below.
Use caution consuming popsicles or ice
cubes straight from the freezer as this can
cause freezer burn to the mouth and lips.
3

If the fitted plug is not suitable for your
socket outlets, it should be cut off and
carefully disposed of. To avoid a
possible shock hazard, do not insert the
discarded plug into a socket. If in doubt
contact a qualified, registered
electrician.
Do not use extension cords or multiple
sockets which could cause overloading
of wiring circuits and could cause a fire.
Always plug your appliance into its own
individual electrical socket which has
a voltage rating that matched the
rating plate.
Make sure that the plug is not squashed
or damaged. Otherwise, it may cause
short circuit, electric shock or overheat
and even cause a fire.
Do not insert the power plug if the
socket is loose, there is a risk of electric
shock or fire.
Switch off the appliance and
disconnect it from the main power
before you clean or move it.
Never unplug the appliance by pulling
on the electrical cord. Always grip the
plug firmly and pull straight out from the
socket to prevent damaging the power
cord.
Do not operate the appliance without
the cover of interior lighting.
To avoid eye injury, do not look directly
into the LED light located in the refrigerator
compartment. If it is not functioning
correctly, consult a qualified, registered
electrician or replace it in accordance
with the “Cleaning and Care” chapter.
The refrigerant isobutane (R600a) is
contained within the refrigerant circuit of
the appliance. During transportation and
installation of the appliance, ensure that
none of the components of the refrigerant
circuit become damaged.
The refrigerant (R600a) is flammable.
Don't store products which contain
flammable propellants (e.g. spray cans)
or explosive substances in the appliances.
Avoid open flames (candles, lamps etc.)
and other sources of ignition.
Thoroughly ventilate the room in which
the appliance is situated.
Refrigerant
Caution: Risk of Fire
Should the refrigerant circuit be damaged:
Risk of child entrapment. Before you throw
away your old refrigerator or freezer:
Take off the doors
Leave the shelves in place so that
children may not easily climb inside.
Any electrical component must be
replaced or repaired by a qualified
electrician or authorized service
engineer. Only genuine replacement
parts should be used.
Do not use electrical appliances such
as ice cream makers inside the food
storage compartments of the
appliance unless they are approved by
the manufacturer.
The power plug must be accessible when
the appliance is installed.
This appliance must be grounded.
This appliance is fitted with a plug,
in accordance with local standard. The
plug should be suitable for use in all
houses fitted with sockets in accordance
with current specifications.
WARNING:
4

Installing Your New Appliance
WARNING
Before using the appliance for the first time,
you should be informed of the following tips.
For proper installation, this refrigerator
must be placed on a level surface of
hard material that is the same height
as the rest of the flooring. This surface
should be strong enough to support a
fully loaded refrigerator.
The rollers, which are not casters,
should be only used for forward or
backward movement. Moving the
refrigerator sideways may damage
your floor and the rollers.
Suggestion:
The following figure shows the
minimum installation size of the
appliance, which is different from the
electricity consumption test conditions.
Too small of a distance from adjacent
items may result in lowered freezing
capability and increased electricity
consumption charges. It is advisable
for there to be at least 2" (50mm) of
clearance from the back of the fridge
to the wall, at least 1/2" (12.5mm) of
clearance from its top, at least
1/2" (12.5mm) from its side to the wall
and a clear space in front to allow the
doors to open 130°.
In order to improve efficiency of the
cooling system and save energy, it is
necessary to maintain good ventilation
around the appliance for the dissipation
of heat. For this reason, sufficient clear
space should be available around the
refrigerator.
Ventilation of appliance
This appliance performs well with
ambient temperature between 55°F
(12.8°C) to 110°F (43.3°C). The appliance
may not work properly if left at a
temperature above or below the
indicated range.
Stand your appliance in a dry place to
avoid high moisture.
Keep the appliance out of direct sunlight,
rain or frost. Stand the appliance away
from heat sources such as stoves, fires or
heaters.
Note:
Relevant information (inch)
31.3
WW1 DD1D2D3
20.828.734.253.161.4
1/2"
2"
67.9"
1/2"
W
D
130°
D1
D2
W1
D3
5

Leveling of appliance
0.4" - 0.6"(10 -15mm)
A
A
C
B
C
Adjustable bottom
feet
Front roller
Rear roller
B
For sufficient leveling and air circulating
in the lower rear section of the
appliance, the bottom feet may need to
be adjusted.You can adjust them
manually by hand or by using a suitable
spanner.
To allow the doors to self-close, tilt the
top backwards by 0.4" - 0.6"(10 -15mm).
Note:
If required you may lay the refrigerator
on its back in order to gain access to
the base, you should rest it on soft foam
packaging or similar material to avoid
damaging the backboard of the
refrigerator.
Installing the handles
adjustable bottom feet
Before you use the appliance, you
have to install the handles provided in
the fridge chamber.
Not provided
Wrench (5/16")
Monkey wrench
Upper Hinge-Left
Thin-blade
screwdriver
Cross screwdriver
Allen Wrench (5/32")
Upper Hinge
Cover-left
Screw Hole Cover
right Middle Hinge-left
Left stop Block Left Door Stopper
Tools you will need:
Thin blade(utility knife e.g. )
Additional parts (in
the plastic bag)
The longer one is fridge door handle, the
shorter one is freezer door handle. Please
follow procedures below to install and
reverse the handle.
Take out the screw hole covers on the
doors, install the handle supports 1. Place
the handle 3 and 4 on the doors by fitting
the handle over the handle supports 1,
then fasten the screws 2 with 5/32" Allen
wrench (provided in plastic bag).
6

WARNING!
When reversing the door, the
appliance must not be
connected to the Power, Ensure
that the plug is removed from
the power socket.
NOTE
If required, you may lay the
refrigerator on its back in order
to gain access to the base,
you should rest it on soft foam
packaging or similar material
to avoid damaging the
backboard of the refrigerator.
To reverse the door, the following steps
generally recommended.
1. Take out the screw hole covers on the doors,
install the handle supports 1. Place the handle 3
and 4 on the doors by fitting the handle over
the handle supports 1, then fasten the screws 2
with 5/32" Allen wrench (provided in plastic
bag).
1. Stand the refrigerator upright. Open the door
to take out all door racks (to avoid damage)
and then close the door.
CAUTION!
Please slightly squeeze the
door rack from two sides
toward center and inside of
door rack, and then move it
upward when taking out the
upper rack and lower rack.
When you reverse the door, please move the
handle 3, the screws 2 and the handle supports
1 to the right side. Move the screw hole covers
5 to the left side.
Reversing the door
The side at which the door opens can
be changed, from the right side (as
supplied) to the left side if required.
1
2
3
1
2
1
24
2
1
2
1
5
1
2
3
5
7

2. With the door closed, unscrew 1 and remove
upper hinge cover-right 2 from the right-top
corner of cabinet. Remove the reed switch 4
and the humidity sensor unit 5 from the cabinet
and upper hinge cover-right 2, Install them on
the upper hinge cover-left (provided in the
plastic accessory bag). Unscrew the three
screws 3 which are used for fixing the upper
hinge-right (see the picture below).
1
2
3
4
5
3. Remove the upper hinge-right (please hold
upper door by hand when installing.
4. Remove the upper door from the middle
hinge by carefully lifting the door straight up.
Then place the upper door on a smooth surface
with its panel upwards.
5. Unscrew the two screws 6, then take out the
right door stopper for fridge door 7 and the
right stopper block for fridge door 8, Install the
replacement left door stopper 9 and left
stopper block 10 (provided in the plastic
accessory bag) to the left side with screws 6.
Keep 7 and 8 with the appliance for future
reference.
9
10
6
7
8
6
6. Open the freezer door, use the Allen wrench
(provided in the plastic accessory bag) to
unscrew the screws (11) and the 2 screws (13)
used to fix the middle hinge-right (12) and
remove middle hinge -right (12). Keep the
middle hinge -right (12) for future reference.
8

7. Change screw hole covers and screw on
middle cover plate from left to right (as
shown in figure below).
8. Put out the Middle Hinge-left (14,
provided in the plastic accessory bag),
then screw it with the screws (11) and the 2
screws (13) from right side.
9. Install the screw hole cover-right 11
(provided in the plastic accessory bag) to
the right-top corner of cabinet. Remove
screw hole cover-left 12 from the left-top
corner of cabinet with the thin-blade
screwdriver and Keep the screw hole
cover-left and upper hinge-right for future
reference.
11
12
10. Carefully slot the upper door onto the
middle hinge pin and hold in position. Move
the upper door to an appropriate position,
adjust the upper hinge-left (provided in the
plastic accessory bag) and upper door, then
fit the hinge pin into the hinge hole at the top
of the upper door to secure it in place. Then fix
the upper hinge part with screws (Please
carefully hold the upper door by hand when
installing).
11. Assemble the upper hinge cover-left to
match the hinge. Install the door racks to
original position. Keep the upper hinge cover-
right with the appliance for future reference.
Disassembling the freezer Door
There are two doors in freezer compartment,
and it provide with an upper drawer with a
tray and also a lower drawer with a tray.
You can follow below same steps to
disassemble the drawers, trays and doors.
1. Pull out the freezer door and the upper
drawer(1) to the final position.
13
12
11
13
14
11
9

2. Take out the ice storage box(2)
(if equipped).
3. Remove the 2 screws(3) fixed on the
upper drawer with Phillips(+)
screwdriver.
4. Take out the upper drawer by lifting it
up from the rail system.
1
2
3
1
5. Take out the lower drawer(5) by lifting it
up.
6. Remove the 2 screws(6) holding the
support with Phillips(+) screwdriver.
5
6
6
10

7.Remove the freezer door by lifting it up.
Re-assembling the freezer Door
To reattach the doors after you moved
the appliance to its final location,
assemble the parts in reverse order.
Installing the water lines
In order for the ice maker to operate
properly, a water line is required. You
may need to purchase a water
purifying system to do that. The water
connection must be made by a
qualified plumber. If the refrigerator is
installed in an area with low water
pressure (below 30psi/207KPa), you can
install a booster pump to compensate
for the low pressure.
the maximum inlet water pressure is-
700kPa;
the minimum inlet water pressure is-
207kPa.
The water connection must be
made by a qualified plumber.
Operation outside the water
pressure range may cause
malfunction, severe and
damaging water leaks.
Under normal conditions, a200cc
(5.75 oz.) cup can be filled in
about 10 seconds.
If the refrigerator is installed in an
area with low water pressure
(below30 psi), you can install a
booster pump to compensate
for the low pressure.
Warning
What you need to have before you
start
1. Power drill and 1/4" drill bit.
2. 1/2" or adjustable wrench.
3.Flatblade and Philips-head
screwdrivers.
Saddle-type shut off valve (1/4" outlet)
one 1/4"
compression nut
1 ferrule
(sleeve)
11

You need to purchase several item to4.
complete this connection. You may find
these items sold as a kit at local
hardware store.
Connecting to the water supply
line
1.First,shut off the main water supply.
3.Connect 1/4" extension tubing to
shutoff valve outlet.
2.Using the power drill and a 1/4’’ drill bit
drill into the cold-water line and
connect the saddle-type shutoff valve.
2 clips
1/4"extension
tubing 1 Coupler
Cold water line
Pipe clamp
Shut off valve
Flush the tubing. Turn the main water4.
supply on and flush out the tubing until
the water is clear. Then, shut the water
off at the water valve after about a
quart of water has flushed through the
tubing.
Saddle-type
Packing
nut
Outllet valve
Compression
nut
1/4”Extension
tubing
Ferrule (sleeve)
Connect the extension tubing line5.
with the line on the back of the fridge
with the coupler. Fully insert the
extension tubing into the coupler, and
then insert the clip onto the coupler to
lock up the tubing. Do the same with
the other end. After both of clips are
inserted, check the line to make sure it is
held firmly by the clips.
12

Clip
Water
line
Coupler
Water
line
Ensure that the water line does
not get pinched or bent when
installing. This can result in
improper water flow through the
line and will affect the
functionality of the fridge.
Note
6. Turn the water on and check for
leakage.
Check to see if leaks occur at the
water line connections.
Caution
Connect Water Line to Refrigerator
IMPROTANT: If you turn the refrigerator
on before the water is connected, turn
off the ice maker.
1. You may need to purchase below
items to complete this connection. And
you may find these items sold as a kit at
a local hardware store.
abcaFerrule (Sleeve) -1 pcs
b1/4" Compression nut
- 1 pcs
c1/4" Water line - 1 pcs
Unplug refrigerator or disconnect2.
power.
3. Close shut off value.
4. Thread a 1/4 " compression nut and
ferrule (sleeve) onto the free end and
of 1/4" water line.
5. Insert the free end and of the 1/4"
water line into the brass fitting attached
to the water inlet on the back of the
refrigerator.
6. Slide the 1/4" compression nut over
the ferrule (sleeve) and screw the 1/4"
compression nut onto the brass ftting.
c1/4" Water line
b1/4" Compression
nut
aFerrule (Sleeve)
dBrass fitting
eWater inlet
13

7. Confirm 1/4" water line is secure by
gently pulling on it.
8. Turn on water supply and check for
leaks, and correct any leaks.
Use only the new tubing supplied
with the refrigerator. Old tubing
should not be used.
After connected to the water
supply line, please open the
water valve to flush the filter for 5
minutes before use. The initial
dark discoloration of water is
normal.
When you connect the water line
to the appliance and press the
lever of the dispenser for the first
time, it is normal that there will be
a sound of exhaust coming out
from the appliance.
Note
The water line must be
connected to the cold water
pipe. If it is connected to the hot
water pipe, it may cause the
purifier to malfunction.
Avoid contamination of pipes
during installation.
Connect to potable water
supply only.
Caution
14

Description of the Appliance
Note: Your model may look different from this and other images in this manual,
depending on your model’s features.
Note: To get the best energy ef ciency of this product, please place all shelves, drawers
on their original position as the illustration above.
Refrigerator top LED light
Cabinet
Air Duct
Glass shelves
Refrigerator side LED light
Control panel
Crisper cover
Crisper Drawers
3
2
4
7
8
10
11
12
14
1
2
3
4
5
6
7
Adjustable bottom feet
Fridge door
Half-width Door Bins
Door gasket
Full-width Door Bin
15
13
6
11
12
13
14
15
16
1
5
8
9 10
10
Upper freezer drawer
Lower freezer drawer
9
16
15
Ice maker

Brief introduction
Display Controls
Use your appliance according to the following control regulations, your appliance has
the corresponding functions and modes as the display panels showed in the pictures
below.
Celsius and Fahrenheit Indicator
Temperature Area
Freezer Compartment Icon
Fridge Compartment Icon
Super Freeze Icon
Super Cool Icon
1
2
3
4
5
6
7
9
10
Eco Icon
Confirm Control
Function Selector Control: Left
Control
Function Selector Control:
Right Control
11
8
16
Ice Off Icon

“Switching Celsius and
Fahrenheit”
1. Press “ ” or “ ” repeatedly until the
Celsius/Fahrenheit Indicator “ ” or “ ”
blinks.
2.Press the Confirm Control “ ” for the
first time, and “ ” or “ ” will be always
on. After that, each time you press the
Confirm Control “ ”, the temperature
will be switched between °C and °F, and
the temperature setting value of the
corresponding unit will be displayed in
the temperature area.
“Fridge temperature control”
NOTE
1. Once the appliance is powered on, all icons on the display panel will be lit for 3
seconds with a buzzer sound.
2. All the icons will go off on the condition of all keys untouched and all doors closed
for one minute.
3. The control panel will light up when the door is open or you touch any button.
4. Setting the refrigerator running at high temperature will accelerate food
decomposition. For optimum food preservation, we recommend that when starting
the refrigerator for the first time, the temperature of fridge is set to 39°F (4°C), and
that of the freezer to 0°F (-18°C).
The temperature only means the average temperature of the whole refrigerator
cabinet. Temperatures inside each compartment may vary from those displayed
on the panel, depending on how much food stored and where the refrigerator is
placed. In addition, the actual temperature from higher room and lower room will
be different.
CAUTION
1. Press “ ” or “ ” repeatedly until the
Fridge icon “ ” blinks.
2. Press the Confirm Control “ ” for the
first time, and the Fridge icon “ ” will be
always on. After that, press the Confirm
Control “ ” repeatedly to cycle through
the available temperature settings, from 8°
C to 2°C if you have set temperature type
to Celsius.
8°C- -7C- -6C- -5°C
-- 2°C- - 3°C- - 4°C
If you have set temperature type to
Fahrenheit, the temperature settings cycle
from 46°F to 36°F.
Note: Each press of the button, the
temperature drops one degree.
46°F- - 45°F--44°F--43°F--42°F--41°F
36°F- - 37°F-- 38°F--39°F-- 40°F
“Freezer temperature control”
1.Press “ ” or “ ” repeatedly until the
Freezer icon “ ” blinks.
2.Press the Confirm Control “ ” for thefirst
time, and the Freezer icon “ ” will be always
on . After that, press the Confirm Control “ ”
repeatedly to cycle through the available
temperature settings, from -14°C to -24°C if
you have set temperature type to Celsius.
-14°C- -15°C- -16°C- -17°C- -18°C- - 19°C
- -24°C- -23°C- -22°C- -21°C- -20°C
If you have set temperature type to
Fahrenheit, the temperature settings cycle
from 7°F to -11°F.
7°F- - 6°F- - 5°F- ...
--11°F- -10°F- -9°F
Note: Each press of the button, the
temperature drops one degree.
17

“Super Freeze”
This Super Freeze feature helps to keep
the food stored in the freezer as the
setting temperature during periods of high
usage, large grocery loads, or temporarily
warm room temperatures.
The Super Cool feature helps to keep
food stored in the refrigerator at the
setting temperature during periods of
high usage, large grocery loads, or
temporarily warm room temperatures, The
Super Cool feature lowers the
temperature in the fridge compartment
to 36°F (2°C) to cool food.
1. Press “ ” or “ ” repeatedly until the
Super Cool icon “ ” blinks.
2. Press the Confirm Control “ ” to turn
the Super Cool function on or off. When
the Super Cool function is turned on, the
“ ” icon lights.
3. When setting fridge temperature, the
Super Cool function will turn off and the
temperature setting will revert back to the
previous setting.
NOTE: Super Cool will automatically turn
off after 6 hours.
“Super Cool”
The Super Freeze feature lowers the
temperature in the freezer compartment
to -11°F(-24°C) to freeze the food faster.
1. Press “ ” or “ ” repeatedly until the
Super Freeze icon “ ” blinks.
2. Press the Confirm Control “ ” to turn
the Super Freeze function on or off. When
the Super Freeze function is turned on, the
“ ” icon lights.
3. When setting freezer temperature, the
Super Freeze function will turn off and the
temperature setting will revert back to the
previous setting.
Note: Super Freeze will automatically turn off
after 52 hours.
CAUTION!
When you selecting the Super
Freeze function, ensure there are
no bottled or canned drinks
(especially carbonated drinks) in
the freezer compartment. Bottles
and cans may explode.
“Eco”
The Eco feature makes the refrigerator
worked in an energy saving mode which is
useful for reducing energy consumption
when you are away.
1. Press “ ” or “ ” repeatedly until the Eco
icon “ ” blinks.
2. Press the Confirm Control “  ” to turn the
Eco function on or off. When the Eco
function is turned on, the “ ” icon lights.
3. When setting fridge or freezer
temperature, the Eco function will turn off
and the temperature setting will revert
back to the previous setting.
NOTE: When the Eco function is on, the
temperature of fridge is automatically
switched to 43°F (6°C) and the
temperature of freezer is automatically
switched to 1°F (-17°C).
“Ice Control”
This “”icon shows the condition of
the ice maker function.
1. Press “”or “”repeatedly until the
Ice Control icon “”blinks.
2. Press the Confirm Control “”to turn
the Ice Maker function on or off. When
the Ice Maker function is turned on, the
“”icon is off; When the Ice Maker
function is off , the “”icon is on.
18

“Door Open Alarm”
If the fridge door is opened for longer than
2 minutes, the control panel will
display “dr”, the “ ” icon will blink and
the buzzer will sound 3 times every
minute for 8 minutes.
Pressing and holding “ ” and “ ” keys
at the same time for three seconds
during door alarm, the “ ” icon will be
on and buzzing will stop. Closing the
fridge door, the “ ” icon will go off and
buzzing will stop.
Demo mode
Demo mode is for store display, and it
prevents the refrigerator from generating
cool air. In this of Cooling Off Mode, the
refrigerator may seem like it is working but
it will not make cool air.
If you enter the Demo mode, the
temperature area will show “ ”. To switch
off Demo mode, press and hold “ ” and
“ ” keys at the same time for 5 seconds
and the buzzer gave a long sound.
NOTE: The Demo Mode stays on even if the
refrigerator powers off. If the consumers
enter the mode with unintentional
operation, you should exit as soon as
possible, since the refrigerator will not cool
in this mode, which will cause the food
going bad.
19

Door racks
The refrigerator compartment is provided
with several door racks, which are suitable
for the storage of eggs, canned liquid,
bottled drinks and packed food. They can
be placed at different heights according
to your need. But do not place too many
heavy things in racks. Before you lift up the
door shelf vertically, please take the food
out.
This section tells you how to use most of the
useful features. We recommend that you
read through them carefully before using
the appliance.
1. Using your refrigerator compartment
The refrigerator compartment is suitable for
storage of vegetables and fruit. Food inside
should be packed to store in order to avoid
losing moisture or flavor permeating into
other foods.
To remove the full width shelves, gently pull
them forward until the shelf comes clear of
the shelf guides.
To return the full width shelves, make sure
there is no obstacle behind and gently push
the shelf back into the position.
Using Your New Appliance
CAUTION!
Never close the refrigerator door
while the shelves, crisper and/or
telescopic slides are extended. It
may damage both them and
the refrigerator.
Glass shelves
The refrigerator compartment is provided
with several glass shelves, including two full
width shelves, one half width shelf and one
collapsible glass shelf. They can be placed
at different heights according to your
need.
Refrigerator drawers
The drawers are suitable for storage of fruits
and vegetable. It can be taken out to be
cleaned. To take out the drawer, first pull
the drawer out in level, then tip up it as the
picture below shows. According to the
opposite sequence the drawer can be
positioned rightly.
NOTE
The door racks and shelves can
be taken out to be cleaned.
20
