Moray BONLAB Height Adjustable Desk User manual

HEIGHT ADJUSTABLE
DESK
OPERATION
MANUAL
for
CONTACT US
in case of emergency or
for Maintenance
+ 971 6 5771201
www . morayme . com

HEIGHT
ADJUSTABLE DESK
OPERATION MANUAL
page 2 of 6 www . morayme . com
FOUR LEGS HEIGHT
ADJUSTABLE TABLE WITH
TRESPA WORKTOP

HEIGHT
ADJUSTABLE DESK
OPERATION MANUAL
page 3 of 6
INTENDED USE
BONLAB  Height Adjustable Desk with Phenolic Resin TRESPA
TOPLAB worktop is exclusively designed to be used as
Laboratory Table .
www . morayme . com
PROHIBITED USE
This table is prohibited to use for
• Load lifting
• Use as a climbing aid
• Permanent storage of heavy objects 
• Outdoor use .
The unit  will be assembled by our installation staff .
WARNING - To reduce the risk of burns , fire , electric shock ,
injury to persons , or property damage :
• Close supervision is necessary when this furnishing is used
by , or near children , invalids , or disabled persons . Keep
children away from electric height - adjustable desks , control
units , and keypads . There is a risk of injury and electric
shock .
• Use this table only for its intended use as described in these
instructions .
• Do not use attachments
• Keep the table close to the power socket / outlet to be easily
accessible .
• Never operate this table if it has a damaged cord or plug , if
it is not working properly , if it has been dropped or damaged ,
or dropped into water .
• Keep the cords away from heated surfaces .
• Do not open any of the components : legs , control box , or
keypad . There is a danger of electric shock . Do not insert
anything into any seam or opening .
• Keep all electrical components away from liquids .
• Do not operate where aerosol ( spray ) products are being
used or where oxygen is being administered .

HEIGHT
ADJUSTABLE DESK
OPERATION MANUAL
page 4 of 6 www . morayme . com
• Inappropriate use of this product may cause property or
bodily injury .
• Check surroundings on all sides before using the desk . Body
parts and property can be crushed if trapped between an
immobile obstacle and the desk ’ s range of motion .
• Ensure the length of power cords are of appropriate length
for desk travel . Monitors , computers , speakers , anything with
a cord that is not long enough for the desk ’ s range of motion
could be pulled down and cause other items
to fall , and cause damage to property .
• Please provide this manual to any users , installers , or
support personnel operating the product .
• Make sure no obstacles are in the desk ’ s path .
• If casters are not installed , use a two - person lift and lift the
desk so that it can be moved without dragging . Dragging the
desk may cause the frame and screws to pull loose from the
desktop .
• Desk contains pinch points . Keep hands and fingers clear of
moving parts .
This height adjustable desk has an electric motor and is
designed for use in dry work areas only . The desk height is
adjustable so that it can be positioned at the most
ergonomically suitable height .
These desks are designed only for the purposes included
in this manual . They should not be used in environments
with high humidity or dampness . Any other use is at user ’ s
risk .
Do not move around , crawl , or lie under the desk frame .
Do not sit or stand on the desk frame .

HEIGHT
ADJUSTABLE DESK
OPERATION MANUAL
page 5 of 6 www . morayme . com
TECHNICAL SPECIFICATIONS
Height Range : 600mm to 1240mm
Base width : 900mm x 1800mm
Worktop width : 1000mm x 2000mm
Travel speed : 38mm per second
Weight Capacity : 200kgs
Duty cycle : 10 %, Max 2min on , 18mins off
4memory presets
Soft Start / Stop
Adjustable leveling studs
PRESET - HEIGHT INSTRUCTIONS
· Use the up / down buttons to find a desired height
· Press “ S ” button . The LED display shows “ 5 -“ then press
“ 1 ” to save the first preset position . The LED display will
show “ 5 - 1 ”
· Repeat the above steps to save second and third
presets . The LED screen will show “ 5 - 2 ” and “ 5 - 3 ”
· Press “ 1 ”, “ 2 ” , “ 3 ” Or “ 4 ” to automatically reach the
height saved before

HEIGHT
ADJUSTABLE DESK
OPERATION MANUAL
page 6 of 6 www . morayme . com
RESET INSTRUCTIONS
a ) When the LED shows “ A5r ” press the down arrow button until the
desk reaches its lowest height and rebounds to stop . This indicates
the reset has completed .
b ) If this doesn ’ t work and the LED shows “ E01 ” or “ E02 ” ( or “ E03 ” on
return desks ), please check that all wired connections to the legs ,
legs to control box are correct . If so , please try the reset instructions
20 minutes later . If not , cut the power , adjust the cables .
c )  If when trying step a ) the Down arrow doesn ’ t work ,
check the cable connection and then cut off the power for at least 10
seconds . Reconnect the power and press the down button to start the
reset process when it shows the “ A5r ”
If the above steps don ’ t work , please call us on
+ 971 6 5771201
