edge range
wall bay kit 1
60003
Item Code Description Qty
2510D 60055 Wood Shelf 70 x 35cm 1
9612 60018 Wall Plate
With screws M5x10 TB
2
9653A 60022 Hanging Rail 60cm 1
9652 60021 End Connector 2
9600 60014 Upright 2
9615 60019 Square Collar 2
9625D 60032 Wood Base 70 x 40cm 1
You will also need Qty
Phillips Screwdriver 1
Rubber Mallet 1
Self-Tapping Shelf Screws ø4x30mm 4
Wall Plugs 2
Wall Screws 2
notes
• This range is designed with clothing in mind,
therefore your max load is dependant on the
strength and quality of your wall fixings (not
supplied)
146cm
70cm
40cm
SELF
ASSEMBLY
35cm
60cm

3
edge range
wall bay kit 1
assembly guide
6 attach shelf
Screw in the shelf with self-tapping screws (not supplied - we suggest
ø4x30mm 18mm thick).
5 attach to the wall
Screw the wall plates to the wall (screws and wall plugs not supplied) and
then fix the uprights to the wall plates with screws M5x10 TB. Now tighten
all screws and those of the joints.
4 insert wall plates and mark
Insert the wall plates (9612) in the uprights, place against the wall, ensure
they are level and mark references. The wooden base remains detached
from the wall to allow mounting with baseboards or skirting.
3 attach the hanging rails
Insert the hanging rail (9653A) between the uprights. Fasten with screws
M5x10 TB - not tight.
2 insert the connectors
Insert end connectors (9652) in square holes of uprights. End connector
is a single model for right and left, pay particular attention to direction of
the thread.
1 place the base
Place the wooden base (9625D) close to the wall, insert the square
collars (9615) and the uprights (9600 with black finned cap)

4
edge range
wall bay kit 2
60005
146cm
100cm
40cm
notes
• This range is designed with clothing in mind,
therefore your max load is dependant on the
strength and quality of your wall fixings (not
supplied)
You will also need Qty
Phillips Screwdriver 1
Rubber Mallet 1
Self-Tapping Shelf Screws ø4x30mm 4
Wall Plugs 2
Wall Screws 2
Item Code Description Qty
2512D 60057 Wood Shelf 100 x 35cm 1
9612 60018 Wall Plate
With screws M5x10 TB
2
9653B 60023 Hanging Rail 90cm 1
9652 60021 End Connector 2
9600 60014 Upright 2
9615 60019 Square Collar 2
9626D 60034 Wood Base 100 x 40cm 1
SELF
ASSEMBLY
35cm
90cm

5
edge range
wall bay kit 2
assembly guide
6 attach shelf
Screw in the shelf with self-tapping screws (not supplied - we suggest
ø4x30mm 18mm thick).
5 attach to the wall
Screw the wall plates to the wall (screws and wall plugs not supplied) and
then fix the uprights to the wall plates with screws M5x10 TB. Now tighten
all screws and those of the joints.
4 insert wall plates and mark
Insert the wall plates (9612) in the uprights, place against the wall, ensure
they are level and mark references. The wooden base remains detached
from the wall to allow mounting with baseboards or skirting.
3 attach the hanging rails
Insert the hanging rail (9653B) between the uprights. Fasten with screws
M5x10 TB - not tight.
2 insert the connectors
Insert end connectors (9652) in square holes of uprights. End connector
is a single model for right and left, pay particular attention to direction of
the thread.
1 place the base
Place the wooden base (9625D) close to the wall, insert the square
collars (9615) and the uprights (9600 with black finned cap)

6
edge range
wall bay kit 3
60001
146cm
318cm
40cm
notes
• This range is designed with clothing in mind,
therefore your max load is dependant on the
strength and quality of your wall fixings (not
supplied)
You will also need Qty
Phillips Screwdriver 1
Rubber Mallet 1
Self-Tapping Shelf Screws ø4x30mm 12
Wall Plugs 6
Wall Screws 6
SELF
ASSEMBLY
Item Code Description Qty
2510D 60055 Wood Shelf 70 x 35cm 3
9612 60018 Wall Plate
With screws M5x10 TB
6
9653A 60022 Hanging Rail 60cm 5
9651 60020 Centre Connector 4
9652 60021 End Connector 2
9600 60014 Upright 6
9615 60019 Square Collar 6
9625D 60032 Wood Base 70 x 40cm 3
35cm
60cm
60cm
60cm
60cm
70cm
70cm
70cm

7
edge range
wall bay kit 3
assembly guide
6 attach shelves
Lastly, screw in the shelves with self-tapping screws (not supplied - we
suggest ø4x30mm 18mm thick).
4 attach to the wall
Screw the wall plates to the wall (screws and wall plugs not supplied) and
then fix the uprights and shelf supports to the wall plates with screws
M5x10 TB. Now tighten all screws and those of the joints.
2 insert the connectors
Insert end connectors (9652) and centre connectors (9651) in square
holes of uprights. End connector is a single model for right and left, pay
particular attention to direction of the thread.
1 place the base
Place the wooden bases (9625D) close to the wall, insert the square
collars (9615) and the uprights (9600 with black finned cap)
3 insert wall plates and mark
Insert the wall plates (9612) in the uprights, place against the wall, ensure
they are level and mark references. The bases remain detached from the
wall to allow mounting with baseboards or skirting.
2 attach the hanging rails
Insert the 5 hanging rails (9653A) between the uprights.. Fasten with
screws M5x10 TB - not tight.

8
edge range
combination bay kit 1
60007
146cm
224cm
40cm
SELF
ASSEMBLY
notes
• This range is designed with clothing in mind,
therefore your max load is dependant on the
strength and quality of your wall fixings (not
supplied)
• The 70cm and 100cm hanging units can be
attached to either side of the central shelves
Item Code Description Qty
2506D 60051 Wood Shelf 60 x 35cm 4
2510D 60055 Wood Shelf 70 x 35cm 1
2512D 60057 Wood Shelf 100 x 35cm 1
9612 60018 Wall Plate
With screws M5x10 TB
4
9653A 60022 Hanging Rail 60cm 1
9653B 60023 Hanging Rail 90cm 1
9655A 60024 Shelf Support 60cm 4
9651 60020 Centre Connector 2
9652 60021 End Connector 8
9600 60014 Upright 2
9601 60016 Shelf Upright 2
9615 60019 Square Collar 4
9625D 60032 Wood Base 70 x 40cm 1
9626D 60034 Wood Base 100 x 40cm 1
35cm
60cm
90cm
70cm
100cm
60cm
35cm
You will also need Qty
Phillips Screwdriver 1
Rubber Mallet 1
Self-Tapping Shelf Screws ø4x30mm 8
Self-Tapping Shelf Screws ø4x25mm 16
Wall Plugs 4
Wall Screws 4

9
edge range
combination bay kit 1
assembly guide
6 attach shelves
Lastly, screw in the shelves with self-tapping screws (not supplied - we
suggest ø4x30mm 18mm thick, and ø4x25mm 12mm thick).
4 attach to the wall
Screw the wall plates to the wall (screws and wall plugs not supplied) and
then fix the uprights and shelf supports to the wall plates with screws
M5x10 TB. Now tighten all screws and those of the joints.
2 insert the connectors
Insert end connectors (9652) and centre connectors (9651) in square
holes of uprights. End connector is a single model for right and left, pay
particular attention to direction of the thread.
1 place the base
Place the wooden bases (9625D/9626D) close to the wall, insert the
square collars (9615) and the uprights (9600/9601 with black finned cap)
3 insert wall plates and mark
Insert the wall plates (9612) in the uprights and shelf supports, place
against the wall, ensure they are level and mark references. The bases
remain detached from the wall to allow mounting with baseboards or
skirting. The wall plates on the shelf supports allow them to stay straight.
2 attach the hanging rails and shelf supports
Insert the 2 hanging rails (9653A/9653B) between the uprights. Insert
the 4 shelf supports (9655A) between the two bays. Fasten with screws
M5x10 TB - not tight.

10
edge range
combination bay kit 2
60009
180cm
254cm
40cm
notes
• This range is designed with clothing in mind,
therefore your max load is dependant on the
strength and quality of your wall fixings (not
supplied)
• Hanging units are the same size
SELF
ASSEMBLY
Item Code Description Qty
2506D 60051 Wood Shelf 60 x 35cm 5
2512D 60057 Wood Shelf 100 x 35cm 2
9612 60018 Wall Plate
With screws M5x10 TB
4
9653B 60023 Hanging Rail 90cm 2
9655A 60024 Shelf Support 60cm 5
9651 60020 Centre Connector 2
9652 60021 End Connector 10
9600A 60015 Upright 2
9601A 60017 Shelf Upright 2
9615 60019 Square Collar 4
9626D 60034 Wood Base 100 x 40cm 2
35cm
90cm
90cm
100cm
100cm
60cm
35cm
You will also need Qty
Phillips Screwdriver 1
Rubber Mallet 1
Self-Tapping Shelf Screws ø4x30mm 8
Self-Tapping Shelf Screws ø4x25mm 20
Wall Plugs 4
Wall Screws 4

11
edge range
combination bay kit 2
assembly guide
6 attach shelves
Lastly, screw in the shelves with self-tapping screws (not supplied - we
suggest ø4x30mm 18mm thick, and ø4x25mm 12mm thick).
4 attach to the wall
Screw the wall plates to the wall (screws and wall plugs not supplied) and
then fix the uprights and shelf supports to the wall plates with screws
M5x10 TB. Now tighten all screws and those of the joints.
2 insert the connectors
Insert end connectors (9652) and centre connectors (9651) in square
holes of uprights. End connector is a single model for right and left, pay
particular attention to direction of the thread.
1 place the base
Place the wooden bases (9625D) close to the wall, insert the square
collars (9615) and the uprights (9600/9601 with black finned cap)
3 insert wall plates and mark
Insert the wall plates (9612) in the uprights and shelf supports, place
against the wall, ensure they are level and mark references. The bases
remain detached from the wall to allow mounting with baseboards or
skirting. The wall plates on the shelf supports allow them to stay straight.
2 attach the hanging rails and shelf supports
Insert the 2 hanging rails (9653B) between the uprights. Insert the 5 shelf
supports (9655A) between the two bays. Fasten with screws M5x10 TB -
not tight.
