Most Dependable Fountains 485 EZ WM User manual

Most
Dependable
Fountains, Inc.
MODELS:
485 EZ WM
& 485 EZ WMSS
OPERATIONS MANUAL
Most Dependable Fountains, Inc™
5705 Commander Drive
Arlington, TN 38002
800-552-6331
www.mostdependable.com

MODEL 485 EZ WM
DUAL WALL MOUNT WITH CARRIER PLATE
3354-8.16
CADdetails.com
www.mostdependable.com
FOUNTAINS,
PROTECTED BY COPYRIGHT ©2016 CADDETAILS.COM LTD.
REVISION DATE 06/13/2016
MOST DEPENDABLE FOUNTAINS, INC.
5705 COMMANDER DR. P.O. BOX 587
ARLINGTON, TN 38002-0587
TOLL FREE: 1-800-552-6331
PHONE: [phone]
FAX: [phone]
1 1/2"
1 1/2"
SIDE VIEW FRONT VIEW
26 5/8"
36 1/2" 28 1/2"
28 1/2"
18"
27" 5"
8"32"
WASTE ARM BY
OTHERS
PROPER BACKING MUST BE
PROVIDED, BY OTHERS.
WALL CARRIER PLATE TO BE
ANCHORED TO FINISHED WALL
29"
5 1/2"18"5 1/2"
C/L OF WASTE
& WATER
NOTES:
1. MEETS ADA REGULATIONS.
2. PROVIDED WITH CARRIER PLATE.
3. INSTALLATION TO BE COMPLETED IN ACCORDANCE WITH MANUFACTURER'S SPECIFICATIONS.
4. DO NOT SCALE DRAWING.
5. THIS DRAWING IS INTENDED FOR USE BY ARCHITECTS, ENGINEERS, CONTRACTORS, CONSULTANTS AND DESIGN PROFESSIONALS
FOR PLANNING PURPOSES ONLY. THIS DRAWING MAY NOT BE USED FOR CONSTRUCTION.
6. ALL INFORMATION CONTAINED HEREIN WAS CURRENT AT THE TIME OF DEVELOPMENT BUT MUST BE REVIEWED AND APPROVED BY
THE PRODUCT MANUFACTURER TO BE CONSIDERED ACCURATE.
7. CONTRACTOR'S NOTE: FOR PRODUCT AND COMPANY INFORMATION VISIT www.CADdetails.com/info AND ENTER
REFERENCE NUMBER 3354-8.16.

480 and 485 EZ WALL MOUNTED DRINKING FOUNTAIN SPECIFICATIONS
Section 9, California Proposition 6 and the Federal Safe Drinking Water Act.
One piece weld construction with MDF standard 3/16”wall thickness
18 gauge electro-polished stainless steel bowl. Bowl overlaps pedestal, preventing buildup
of residue in visual drinking area. Optional stainless steel Bowl Strainer recommended for
areas with sand.
Stainless steel anti-squirt head (weighing a pound and a half) mounted with a lock nut and
washer to prevent tampering. Lock nut pin holds bubbler in locked position to prevent
twisting or turning. The MDF bubbler head has a unique design that features a steady
stream trajectory and a built in natural shield from contamination. (Most Dependable
Fountains, Inc.™ encourages bubbler comparison.)
304 stainless steel with circumference exceeding 8.6”. Mushroom style push bar overlaps
and prevents sand and other objects from sticking push bar in the ON position. Stainless
steel bubbler housing standard.
Requires less than 5 lbs to operate. Non-cartridge O-ring valve delivers steady stream of
water through an adjustable valve. This valve design is to operate and function at 30 to 80
PSI. Ideal operating pressure is 60 PSI.
Y DRAIN
Maintenance free reinforced nylobraid tubing and ttings, NSF-61 certied. This tubing is
not plastic. It is supplied with a 1/2” MIP threaded inlet with stainless steel strainer. Union
ttings at every connection.
The sixteen powder coat colors are at no additional charge. The colors are: green,
blue, brown, black, red, yellow, orange, white, and textured
emerald, saphire, pyrite, black, burgandy, gold vein, copper and
sandstone. Stainless steel fountains are powder coated for added protection and all
colors listed are available. The color chrome is available for stainless steel models only.
STANDARD WALL MOUNT
The EZ Wall Mounted drinking fountain is furnished with a wall carrier plate to be anchored
to a nished wall.
Shut o water and drain down.
One year warranty, labor not included.
Model 480 EZWM........... 40 lbs Model 480 EZWMSS...... 40 lbs
Model 485 EZWM........... 95 lbs Model 485 EZWMSS....... 95lbs
One piece weld constuction with MDF standard 304 schedule 10 stainless steel
Working parts accessible through bowl of fountain for easy service.
WATER QUALITY (LEAD FREE)
RECEPTOR BOWL
BUBBLER HEAD
PUSH BAR
CONTROL VALVE
WASTE
WATER SUPPLY (LEAD FREE)
FINISH
ACCESS
WINTERIZATION
WARRANTY
SHIPPING WEIGHT
STAINLESS STEEL WALL MOUNT
INSTALLATION
Lead Free by all known denitions
including ANSI/NSF standard 61
OR
MOST DEPENDABLE FOUNTAINS, INC.™
[phone] • [phone] • Fax [phone]
5705 COMMANDER DR. • ARLINGTON, TN 38002-0587
www.mostdependable.com
LEAD FREE

LIMITED PRODUCT WARRANTY
Most Dependable Fountains, Inc.™ warrants that all of its products are
guaranteed against defective material or poor workmanship for a period of
one year from date of shipment. Most Dependable Fountains, Inc.™
liability under this warranty shall be discharged by furnishing without charge
any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of rst class workmanship. Most
Dependable Fountains, Inc.™ will not be liable for the cost of repairs,
alterations or replacements, or for any expense connected therewith made by
the owner or his agents. Most Dependable Fountains, Inc.™ will not be liable
for any damages caused by defective materials or poor workmanship, except
for replacements, as provided above. Buyer agrees that Most Dependable
Fountains, Inc.™ has made no other warranties either expressed or implied in
addition to those above stated. e products manufactured by Most
Dependable Fountains, Inc.™ is warranted to function if installation and
maintenance instructions provided are adhered to. e units also must be
used for the purpose for which they were intended.
Most Dependable Fountains, Inc.™
