Most
Dependable
Fountains, Inc.
MODELS:
545 SM & 545 SMSS
Fun Time Shower
OPERATIONS MANUAL
Most Dependable Fountains, Inc™
5705 Commander Drive
Arlington, TN 38002
800-552-6331
www.mostdependable.com

36"
MODEL 545 SM
8" SS SURFACE CARRIER INCLUDED
METERED
CONTROL
VAVLE
METERED CONTROL
VALVE
3354-11.9
TOP VIEW
1/2" X 12" ZINC
PLATED ROD
8" STAINLESS
STEEL SURFACE
CARRIER
ACCESS
DOOR
8" STEEL PIPE
OPTIONAL: 8" SS PIPE
CADdetails.com
www.mostdependable.com
FOUNTAINS,
PROTECTED BY COPYRIGHT ©2016 CADDETAILS.COM LTD.
REVISION DATE 06/13/2016
MOST DEPENDABLE FOUNTAINS, INC.
5705 COMMANDER DR. P.O. BOX 587
ARLINGTON, TN 38002-0587
TOLL FREE: 1-800-552-6331
PHONE: [phone]
FAX: [phone]
30" 42"
NOTES:
1. OPTIONAL STAINLESS STEEL SURFACE CARRIER INCLUDED.
2. FUNTIME SHOWER HAS 4 SHOWER HEADS WITH 2 METERED VALVES. EACH VALVE CONTROLS 2 HEADS.
3. INSTALLATION TO BE COMPLETED IN ACCORDANCE WITH MANUFACTURER'S SPECIFICATIONS.
4. DO NOT SCALE DRAWING.
5. THIS DRAWING IS INTENDED FOR USE BY ARCHITECTS, ENGINEERS, CONTRACTORS, CONSULTANTS AND DESIGN PROFESSIONALS
FOR PLANNING PURPOSES ONLY. THIS DRAWING MAY NOT BE USED FOR CONSTRUCTION.
6. ALL INFORMATION CONTAINED HEREIN WAS CURRENT AT THE TIME OF DEVELOPMENT BUT MUST BE REVIEWED AND APPROVED BY
THE PRODUCT MANUFACTURER TO BE CONSIDERED ACCURATE.
7. CONTRACTOR'S NOTE: FOR PRODUCT AND COMPANY INFORMATION VISIT www.CADdetails.com/info AND ENTER
REFERENCE NUMBER 3354-11.9.

FUNTIME SHOWER SPECIFICATIONS
PUSH BAR
CONTROL VALVE
FINISH
INSTALLATION
WINTERIZATION
WARRANTY
SHIPPING WEIGHT
STAINLESS STEEL PEDESTAL
OR
SPRAY HEADS
One piece weld construction with MDF standard 3/16”wall thickness.
304 stainless steel with circumference exceeding 8.6”. Mushroom style push bar
overlaps and prevents sand and other objects from sticking push bar in the ON
position. Stainless steel bubbler housing standard.
Requires less than 5 lbs to operate. This valve design is to operate and function at
30 to 80 PSI. Ideal operating pressure is 60 PSI. Two slow closing metered valves
can be set to run from 30 to 45 seconds before shutting o. Once valve controls 2
spray heads that cover a 9’ half radius.
Oven baked powder coat. Choice of colors are: green, blue, black, red,
yellow, orange, brown and white. Textured color choices: emerald,
sapphire, pyrite, text-black, burgundy, gold vein, copper and sand-
stone. Stainless steel models are powder coated for added protection. The color
chrome is available for stainless steel models only.
STANDARD PEDESTAL
Surface Mount installation, is designed to be anchored on top of an existing
surface (concrete, etc.) with anchor bolts through a mounting plate that is
welded to the unit. Surface mount carrier recommended for all surface mount
installations. Access door standard on all pedestal units.
Shut o water and drain down. Remove valve during winter months.
One year warranty, labor not included.
130 lbs.
One piece weld construction with MDF standard 304 schedule 10 stainless steel.
Four upward shower sprayheads.
MOST DEPENDABLE FOUNTAINS, INC.™
[phone] • [phone] • Fax [phone]
5705 COMMANDER DR. • ARLINGTON, TN 38002-0587
www.mostdependable.com

INSTALLATION INSTRUCTIONS
Most Dependable Fountains, Inc.™
All SM (surface mount) products are designed to be installed on the
surface of a new or existing concrete slab. Your contractor needs to provide
a 1 ½” PVC drain line (when applicable) and water line thru nish grade.
Connections are made to our SM products thru our access door, as shown
on detail drawings. e water tubing is provided with a ½” male iron pipe
connection. is is an excellent location for a cuto valve. Surface Mount
units are anchored to the existing concrete by means of ½” concrete shields
with bolts or we recommend ½” quick bolts.
Note: We oer an optional template which is designed to be poured in the
concrete slab. It comes with the necessary vandal resist stainless steel bolts
and washers need to anchor.
All DB (direct bury) products are designed to be installed to a depth of 14”
below grade. MDF provides 1 ½” PVC drain line inside the pedestal
(when applicable) to point of connection by others. MDF also provides
reinforced nylobraid exible tubing with a ½” male iron pipe thread for
connection to water supply by others. MDF recommends an optional valve
box using a PVC conduit to the pedestal. By using this option you have
complete control of your product.
Individual detail drawings available Online or by request.
For more information:
Most Dependable Fountains, Inc.™
www.mostdependable.com
[e-mail]
800-552-6331
901-867-0039

LIMITED PRODUCT WARRANTY
Most Dependable Fountains, Inc.™ warrants that all of its products are
guaranteed against defective material or poor workmanship for a period of
one year from date of shipment. Most Dependable Fountains, Inc.™
liability under this warranty shall be discharged by furnishing without charge
any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of rst class workmanship. Most
Dependable Fountains, Inc.™ will not be liable for the cost of repairs,
alterations or replacements, or for any expense connected therewith made by
the owner or his agents. Most Dependable Fountains, Inc.™ will not be liable
for any damages caused by defective materials or poor workmanship, except
for replacements, as provided above. Buyer agrees that Most Dependable
Fountains, Inc.™ has made no other warranties either expressed or implied in
addition to those above stated. e products manufactured by Most
Dependable Fountains, Inc.™ is warranted to function if installation and
maintenance instructions provided are adhered to. e units also must be
used for the purpose for which they were intended.
