Motor Scrubber M3 User manual

User Manual
English

MotorScrubber
Contents
02 03
When using electric
products, basic safety
precautions should
always be followed
to reduce the risk
of electric shock
and personal injury,
including the following:
• Consider your work
area environment.
When using the
MotorScrubber be
aware of overhead
electrical wires.
• MotoScrubber is
powered by DC
current only. Do not
attempt to operate
MotorScrubber with
AC current.
• Never pull the
MotorScrubber by
its cord or yank it to
disconnect it from the
battery.
• Keep the cord away
from heat, oil and sharp
edges.
• Keep your
MotorScrubber clean.
(For safer operation,
follow instructions for
attaching accessories.
Keep the upper handle
switch area dry, clean
and free from oil, grease
and water).
• Disconnect the
MotorScrubber when
not in use and when
attaching accessories.
• Inspect for damage
before using
MotorScrubber.
• When servicing, use
only genuine parts and
accessories.
MotorScrubber is a
power tool. As with any
power tool, always use
both hands to ensure
safe operation.
• Ensure you adopt the
correct posture when
using MotorScrubber.
Maintain a straight
back.
• Adjust the position
of the control handle
(see page 12) so your
arm is straight when
holding the handle.
Your back should be
straight at all times.
Save these instructions
for future reference.
Thank you for purchasing
your MotorScrubber
machine.
We hope you enjoy using your MotorScrubber
product, please feel free to leave comments and
feedback at motorscrubberclean.com/support.
PLEASE READ ALL INSTRUCTIONS
Thank You For Purchasing 03
Application Details 04
Know Your Equipment 05
Preparing Your Machines
Important Information 06
Electrical Connection 06
Battery & Charging Information 07
M3
M3 08
Cleaning the M3 10
Changing a MotorScrubber Brush 11
Removing Dirty Slurry 11
The Handle - Brush Switch 12
Handle Position 12
Adjusting the Flip Clip 12
Underwater Use 13
Complete Parts Breakdown 14
Certicate of Conformity 16
Warranty 17
Safety Instructions 18
Troubleshooting 19

04
Application
Details
FLOOR CLEANING
SWIMMING POOLSSTAIR CLEANING
KITCHEN CLEANING
The M3 makes light work of deep cleaning
conned and hard to reach places. Achieving
outstanding cleaning results on any surface.
05
Know Your
Equipment
*For further information about the
Battery & Charging see page 7.
M3
1. Brush Switch
2. Electric Cable and Connector
3. Flip Clip
4. Locking Knob
5. Rotating Disc Hub
6. Handle Screws
7. Control Handle
8. QR Code
BACKPACK
9. Carry Handle
10. Electrical Connector
11. Battery Pack*
12. Charger
5
6
4
1
7
3
2
8
11
9
10
12
2 Step Quick Connect
Simply push together the electrical
connector found on both the
backpack and M3 to begin cleaning.
BACKPACK: The backpack should be
put over your shoulders like a backpack.
There are two adjustable straps, which
can be pulled to tighten the shoulder
supports to a comfortable user level.
Ensure the Velcro belt strap is fastened
across your abdomen.

Before use, the battery
coiled cord needs
connecting to the battery
terminals. It is vitally
important to connect the
cable with the correct
polarity.
If the cable is connected
incorrectly it could cause
damage / re when
plugged into the charger.
Unzip the battery
compartment located on
the backpack.
Important Information
Electrical
Connection
Important: before you
connect the power
cable, check the brush
switch is not on. (see
page 12).
To connect the black SAE
connectors align the two
connectors and push
together until closed.
To release the
connection, grip the two
connected areas and pull
apart.
Connect the red wire from coiled cord to the red
positive battery terminal.
Connect the black wire from the coiled cord to the
black negative battery terminal.
Battery & Charging
Information
• The battery should be
charged before using
your MotorScrubber,
after each use, and if
unused for 4 months.
• When charging the
machine the red light
will show, when the
battery is fully charged
the light will show
green. A full charge
from at will take
approximately 8 hours.
• Connect charger to
the coiled cable on the
backpack then plug the
charger directly into a
120 VAC/60HZ or 240
VAC electrical outlet,
or use an adapter or a
charger made for the
AC source being used.
(Do not use an
extension cord).
After charging,
disconnect the charger
from the AC outlet
and (IMPORTANT)
disconnect the charger
from the battery.
• MotorScrubber uses a
rechargeable sealed
lead-acid battery.
Non-spillable.
• Capacity: 12-volt, 7.0
amp-hour.
• Depending upon the
average depth of
discharge, over a
thousand discharge/
charge cycles can be
expected. CHARGING
CHARGED
0706
Additional Battery
Charge Setup
When you require long
periods of machine
usage, it is always advised
to have an additional
battery on charge so that
you can switch over to
a fully charged battery
quickly. MS3009
MS1580

w
Powerful, Lightweight &
Battery Operated
Say goodbye to
manual scrubbing
with M3.
The M3 makes
light work of deep
cleaning conned
and hard to reach
places. Achieving
outstanding cleaning
results on any
surface.
• 3x faster scrubbing than
manual methods
• 360rpm drastically cuts
exhaustive manual labour
• Plug and go!
• Powerful high torque M10
motor delivers 10,000rpm,
geared to 360rpm
Key Benets:
4 hour runtime gives the freedom
to clean anywhere. Fully adjustable,
lightweight, padded backpack ts
any user.
0908

10
• When using
MotorScrubber make
sure the brush or
pad is at to the
oor, this will ensure
smooth operation of
the machine and an
optimal clean.
• Apply soap/cleaning
solution to the surface
with a sprayer or
directly to the scrub
disc. You may also mix
soap concentrate in
a bucket and dip the
scrub head into the
bucket.
• Scrub with straight,
light strokes. You can
exert light pressure
where needed, let
MotorScrubber do the
hard work for you.
DO NOT USE
MOTORSCRUBBER WITH
FLAMMABLE CLEANING
FLUIDS
FUSED PROTECTION
MotorScrubber is
equipped with 15Amp
replaceable fuse, to
protect against short
circuit. This fuse can be
found inside the battery
compartment.
Cleaning With M3
11
Changing A
Motorscrubber
Brush
1. Turn the
MotorScrubber upside
down and support the
handle with the inside
of your foot.
2. Line-up the tabs on
the disc with the hub
on the MotorScrubber.
3. Hold the hub rmly
to prevent rotation.
Press down while
turning the disc
clockwise until it locks
in place.
4. To remove, press down
on the disc and turn
it counter clockwise
holding hub until tabs
are free. Then lift off
the disc.
There are many ways
to remove dirty slurry
after cleaning, the most
effective ways are:
1. MotorScrubber can
be equipped with a
suction head, which
can be connected to
a wet vac for instant
slurry pickup.
2. Squeegee - Many
hard oor areas have
a drain in the oor.
Dry and remove the
slurry with your BLADE
oor squeegee into
the drain.
3. Attach BLADE A-Fibre
and dry.
Removing
Dirty
Slurry
• Absorbs 500ml/0.13gal of liquid.
• Absorb Spills & Dry Floors.
A-Fibre

13
Underwater
Use
• Because its motor
head can be
fully-immersed in water,
the MotorScrubber
is ideal for many
underwater cleaning
tasks. One of the
more popular uses of
the MotorScrubber is
cleaning the “scum line”
above the water level in
swimming pools, spas,
boats, etc.
• Immersing the head
for long periods of time
could effect its water-
proong seals, due to
the effects of prolonged
heating, cooling and
chlorine. The seals
could contract and
allow water to make
direct contact with the
motor, which would
cause a motor failure.
Guidelines need to be
followed to avoid this.
• If the unit is used
underwater on a regular
basis, an internal
inspection of the head
is also required each
month by a competent
technician, this is to
check for water ingress.
WE RECOMMEND
NOT USING THE
MOTORSCRUBBER
FULLY SUBMERGED
IN WATER FOR MORE
THAN 2 MINUTES
CONTINUOUSLY.
MOTORSCRUBBER
SHOULD THEN BE
REMOVED AND
ALLOWED TO COOL
FOR 5 MINUTES.
• Waterline cleaning,
where MotorScrubber
is half in and half out
of the water there is no
limitations.
• Regular underwater
usage will reduce the
lifetime of the head
unit. MSGREY12V
complete motor head
can be purchased
and replaced when
required. 1 year is the
suggested life of regular
underwater use.
Submerge
up to
25cm
away
from the
switches.
Fully submerged
Use for 2 minutes
then take out to cool
for 5 minutes.
Scum line cleaning
There are no
limitations, you can
clean continuous
using this method.
12
Changing The Control
Handle Position
1. Turn the
MotorScrubber over so
the back of the handle
is facing you.
2. Using a Phillips
screwdriver, remove
the two screws and
take off the handle
base.
3. Move the handle to
your desired position,
replace the handle
base and screws.
BRUSH SWITCH
The red switch operates
the brush. This is a
latching switch, depress
the switch until you
hear a click and let
go, the motor will run
continuously.
Press again and this
will stop the brush.
It is important that this
button is not depressed
before you connect the
electrics.
The
Handle
2
3
Adjusting The
Flip Clip
Release the black clip by
pushing up the release
catch. (1) Adjust the pole
to your desired length,
then push the black
clip back into position.
Do not extend further
than the red stop line
printed on the handle.
If the telescopic pole
is slipping while in use,
you will need to ensure
the clip is tightened
appropriately. To do
this, locate the green
adjustment screw (2)
and ensure the black clip
is in an open position.
Being careful not to over
tighten, turn the screw
clockwise (3) until you
can comfortably push
the black clip back
into its lock position.
If the black clip is too
difcult to push back,
turn the green screw
anti-clockwise until it
is easy to push back
into position. For an
instructional video
please visit: www.
motorscrubberclean.
com/support
1

M3 Complete
Parts Breakdown
14
1. MSS103 Handle Grip
2. MSS402 Switch Housing
3. MSS032 Handle Flip Clip 32mm
4. MSS061 Locking Knob
5. MSS062 Acorn Nut
6. MS7003 Hub Dark Grey
7. MSGREY12V Motorhead Complete
8. MSS172B Thumb Screws
9. MS3003R Aluminium Tube
10. MS3004B Handle
11. MS3114 Back Pack
12. 12V7A Battery
13. MS3009 2 Core Coiled Cable
14. MS1580 Charger
1
8
4
6
7
2
3
5
9
10
11
13
12
14
15

We at MotorScrubber UK
work hard to build the
highest quality cleaning
tools, we strive for
perfection!
As the market leader
in compact scrubbing
machines, we select
the highest grade
components and
continuously develop our
machines, based on the
valuable feedback from
our customers.
Our aim is to build the
world’s most powerful,
compact cleaning tool,
which you can use all
day every day without
failure. We want you to
be 100% satised with
your MotorScrubber, in
the rare event a fault
should occur, we are
here to help and ensure
your machine is back up
and running as soon as
possible.
So that we can cover your
warranty fully, please
follow our terms.
Your Warranty
Every MotorScrubber is
thoroughly inspected
and tested before
leaving the factory.
It is warranted to be
free from defects in
workmanship and
materials, for the period
of one year from the date
of original purchase.
We sell our machines
through a network of
approved distributors
able to support you with
aftercare.
9 out of 10 faults can
be xed over the phone
or by watching our
support videos. Please
chek here: www.
motorscrubberclean.
com/how-to-videos
Should any problem
covered by this warranty
develop during the
one-year period, follow
the instructions in this
booklet and return the
unit, carefully packaged
with freight prepaid to
your original supplier.
Your supplier will inspect
the item and liaise with
us directly. If inspection
shows the problem
was caused by a defect
in workmanship or
materials, your supplier
will repair (or at our joint
option, replace) the unit
without charge, return
freight prepaid.
PLEASE DON’T VOID
YOUR WARRANTY BY:
1. Making alterations to
the product.
2. Repairing or
attempting to
make repairs by
anyone other than
an authorised
MotorScrubber agent.
3. Mistreating, misusing
or improperly
maintaining or
operating the product.
*Terms and conditions
may vary depending on
your country, please
contact your local
supplier for exact terms.
Register your warranty at:
motorscrubberclean.com/warranty
LIMITED ONE-YEAR WARRANTY
MotorScrubber M3 12-VOLT DC TOOL
1716

• To protect against risk
of electrical shock, do
not put battery charger
in water or any other
liquid.
• Do not operate in the
presence of explosives
and/or ammable
fumes or liquids.
• Do not store or carry
battery so that metal
objects can contact
battery terminals – the
battery could short
circuit causing re,
personal injury or
damage to the battery.
• Never attempt to
open battery for any
reason. If the housing
of the battery breaks
or cracks, immediately
discontinue use and
do not recharge.
The battery should be
replaced.
• Do not charge a battery
if it is wet or shows any
evidence of corrosion.
• Do not incinerate the
battery; it can explode
in a re.
• Plug the battery
charger directly into
a 120VAC/60HZ or
240VAC, with the
correct plug adaptor,
electrical outlet (Do not
use an extension cord).
• Charge the battery only
with the MotorScrubber
battery charger.
• Do not use the
charger in wet or
damp conditions. It is
intended for indoor use
only.
• Do not use the charger
near sinks or tubs. Do
not immerse in water.
• Do not allow the cord
to hang over the edge
of a table or counter or
touch hot surfaces.
• Do not use charger for
any other uses other
than MotorScrubber
batteries; other
batteries may explode.
• Do not operate charger
with damaged cord
or plug. Replace the
charger immediately.
• Do not operate charger
if it has received a sharp
blow, been dropped
or otherwise damaged
in any way. Return
the appliance to your
local distributor for
examination, repair or
electrical or mechanical
adjustment. Do not
disassemble charger.
• For best results, do
not charge a battery
when the battery or air
temperature is below
40°F (5°C) or above
105°F (40°C).
• Unplug the charger
when not in use and
before cleaning or
maintenance.
• Do not abuse the cord.
To reduce the risk of
damage to the electric
plug or cord, never
carry the charger by its
cord or yank the cord
to disconnect. Instead,
grasp the charger plug
and pull to disconnect.
Keep charger cord away
from heat, oil and sharp
edges.
• Flush eyes and skin with
water if contact is made
with acid.
•NEVER ATTEMPT
TO OPERATE THE
MOTORSCRUBBER
FROM AN ELECTRICAL
OUTLET. OPERATE THE
MOTORSCRUBBER
ONLY FROM THE
12-VOLT BATTERY.
Important Safety Instructions
Is your machine not
turning on?
• If your MotorScrubber
is not turning on or is
turning slowly, check
the battery terminals
are connected properly
and motor to handle
plugs are connected
securely.
• Next, using a voltmeter,
simply open the battery
pack, disconnect
the two leads at the
battery, and touch the
voltmeter probes to the
terminals accordingly.
A satisfactory reading
would be approximately
11.5 to 13 volts.
• If the battery tests as
satisfactory, the motor
should be tested next.
Disconnect the plug
between the handle
and the motor (wrap
cord from handle with
rubber band, to prevent
cord from retracting
into handle), connect
the battery pack coil
cord directly to the
motor. If the motor
now turns properly,
the on/off switch or
wiring harness within
the handle is not
functioning properly.
If the motor still does
not turn, the M3 is
defective. Consult your
selling distributor.
Troubleshooting
For additional help on using MotorScrubber products,
please visit the support section of our website
www.motorscrubberclean.com/how-to-videos
1918

UK
8 Orgreave Rd, Shefeld,
S13 9LQ, England
0044 (0)114 478 8710
[email protected]
HEAD OFFICE
[email protected]om
www.motorscrubberclean.com
USA
[phone]
[email protected]
Register at:
motorscrubberclean.com/warranty
Don’t forgot to register your warranty.
