MotorGuide X5 Series User manual

Operation
Maintenance
Installation
Warranty
Manual
© 2017 Mercury Marine X5-55/X5-70/X5-80/X5-105
8M0121079 1116 eng

eng

EU Compliance Statement
Attwood Corporation hereby declares that the MotorGuide X5 trolling motor is
in compliance with the essential requirements and other relevant provisions of
the 99/5/EC R&TTE directive.
CE Declaration
Manufacturer: Attwood Corporation
Address: 1016 N. Monroe
Lowell, MI 49331 USA
Telephone: 616‑897‑9241
Authorized Representative: Brunswick Marine
Parc Industriel de Petit‑Rechain
B‑4800
Verviers, Belgium
Telephone: [phone]
Product: MotorGuide X5 Series
Model: includes all 12, 24, and 36 volt DC models
Council Directive 2004/108/EC ‑ Electromagnetic Compatibility
•EN 55012:2008; A1:2010 ‑ Vehicles, boats and internal combustion
engines.
Council Directive 98/96/EC ‑ Maritime Equipment Directive
•EN 60945:2002+C1:2008 ‑ Maritime navigation and radiocommunication
equipment and systems (Motor systems)
• CISPR16 ‑ Conducted and Radiated Emissions
• EN61000‑4‑2:2008 ESD
• EN61000‑4‑3:2006 Radiated Immunity
• EN61000‑4‑4:2004 EFT
• EN61000‑4‑5:2005 Surges
• EN61000‑4‑6:2008 Conducted Susceptibility
• EN61000‑4‑8:2001 Magnetic Field Immunity
• EN6100‑4‑11:2004 Voltage Dips and Interrupts
Council Directive 2006/42/EC ‑ Machinery
•EN ISO 12100 ‑ Safety of machinery ‑ General principles for design, risk
assessment and reduction
An official copy of the Declaration of Conformity can be found at http://
www.motorguide.com/support/certifications.
eng i

Thank You
Thank you for choosing MotorGuide, one of the finest trolling motors available.
Years of experience have been committed to the goal of producing the finest
quality products. This led to MotorGuide's reputation for strict quality control,
excellence, durability, long‑lasting performance and being the best at providing
after‑the‑sale service and support.
Please read this manual carefully before operating your motor. This manual
has been prepared to assist you in the operation, safe use, and care of your
trolling motor.
Again, thank you for your confidence in MotorGuide.
Warranty Message
The product you have purchased comes with a Two Year Limited Warranty
from MotorGuide, the terms of the policy are set forth in the Warranty
Information section of this manual. The policy statement contains a description
of the duration of coverage, important disclaimers and limitations of
damages, and other related information. Please review this important
information.
The description and specifications contained herein were in effect at the time
this manual was approved for printing. MotorGuide, whose policy is one of
continued improvement, reserves the right to discontinue models at any time, to
change specifications, designs, methods, or procedures without notice and
without incurring obligation.
MotorGuide, Lowell, Michigan U.S.A.
Copyright and Trademark Information
© MERCURY MARINE. All rights reserved. Reproduction in whole or in
part without permission is prohibited.
Alpha, Axius, Bravo One, Bravo Two, Bravo Three, Circle M with Waves Logo,
K‑planes, Mariner, MerCathode, MerCruiser, Mercury, Mercury with Waves
Logo, Mercury Marine, Mercury Precision Parts, Mercury Propellers, Mercury
Racing, MotorGuide, OptiMax, Quicksilver, SeaCore, Skyhook, SmartCraft,
Sport‑Jet, Verado, VesselView, Zero Effort, Zeus, #1 On the Water and We're
Driven to win are registered trademarks of Brunswick Corporation. Pro XS is a
trademark of Brunswick Corporation. Mercury Product Protection is a registered
service mark of Brunswick Corporation.
ii eng

Warranty Information
MotorGuide Limited Two Year Warranty............................................................ 1
General Information
Boater's Responsibilities..................................................................................... 3
Protecting People in the Water........................................................................... 3
Passenger Safety Message................................................................................ 3
Safe Boating Suggestions.................................................................................. 3
Product Overview
X5‑55/X5‑70/X5‑80/X5‑105 MotorGuide Trolling Motor...................................... 5
Specifications......................................................................................................7
Wiring and Battery Information
Wiring and Battery Information........................................................................... 9
Recommended Practice and Procedures........................................................... 9
Battery Recommendations................................................................................. 9
Battery Precautions.......................................................................................... 10
Wire and Cable Routing....................................................................................10
Wire Color Code Abbreviations........................................................................ 11
Battery Connection........................................................................................... 11
eng iii

Trolling Motor Installation and Operation
Mount Bracket Installation................................................................................ 15
Permanent Foot Pedal Mounting (Optional)..................................................... 17
Installing the Motor into the Bow Mount............................................................18
Removing the Motor from the Bow Mount........................................................ 19
Connecting the Sonar Display to the Trolling Motor......................................... 19
Reducing Sonar Transducer Interference.........................................................20
Stowing the Trolling Motor................................................................................ 20
Deploying the Trolling Motor............................................................................. 22
Adjusting the Trolling Motor Depth................................................................... 23
Adjusting the Steering Tension—Hand‑Operated Models Only....................... 25
Directional Indicator—Cable Steer Models....................................................... 26
Speed Control—Cable Steer Models................................................................27
Speed Control—Hand‑Operated Models.......................................................... 28
Battery Indicator Light....................................................................................... 28
Maintenance
Trolling Motor Care........................................................................................... 29
Inspection and Maintenance Schedule............................................................. 29
Lubrication Points............................................................................................. 30
Battery Inspection............................................................................................. 30
Corrosion Control Anode (Saltwater Models)................................................... 31
Propeller Replacement..................................................................................... 31
Adjusting the Steering Cable Tension.............................................................. 33
Front Locking Pin Replacement........................................................................34
MotorGuide Accessories Inquiries.................................................................... 35
Troubleshooting
Trolling Motor Performance.............................................................................. 36
Reducing Sonar Transducer Interference.........................................................37
Owner Service Assistance
Mercury Marine Service Offices........................................................................ 38
iv eng

MotorGuide Limited Two Year Warranty
KEEP YOUR ORIGINAL PURCHASE RECEIPT
1. To obtain warranty service, the purchaser should deliver or return the unit
(postage prepaid and insured) to any MotorGuide authorized service
center. DO NOT RETURN TO PLACE OF PURCHASE unless they are
an authorized service center. Motors purchased in other countries should
be returned to place of purchase. Products returned by mail should be
carefully packaged and include a note describing the nature of the
problem and/or service requested, customer address, and phone number.
A copy of the receipt, Bill of Sale, registration verification, or other proof of
purchase is required with the return of the product for warranty
consideration. Warranty claims will not be accepted without presentation
of purchase receipt for trolling motor, other verification of registration, or
Bill of Sale for boat package.
2. MotorGuide electric trolling motors are warranted to the original purchaser
to be free from defects in material and/or workmanship for two (2) years.
Warranty is NOT transferable to any subsequent purchaser.
3. MotorGuide, at its discretion, will repair or replace items covered under
the terms of this warranty. Neither MotorGuide nor MotorGuide service
dealers are responsible for damages to MotorGuide products due to
repairs performed by anyone other than the MotorGuide Factory Service
Center. Neither MotorGuide nor Mercury Marine is responsible for failure
or damage caused by improper installation, set‑up, preparation, or
previous service or repair errors.
4. Warranty coverage is available only to customers that purchase from a
dealer authorized by MotorGuide/Mercury Marine to distribute the product
in the country in which the sale occurred. Warranty coverage and duration
varies by the country in which the product resides. This warranty applies
to X5 series MotorGuide trolling motors sold and residing in the United
States. This Limited Warranty begins on the date the product is first sold
to a purchaser or the date on which the product is first put into service,
whichever occurs first. MotorGuide accessories are covered by this
Limited Warranty for a coverage period of one (1) year from the date of
retail sale. The repair or replacement of parts, or the performance of
service under this warranty, does not extend the life of this warranty
beyond its original expiration date. Promotional warranties are not
included in this statement and coverage may vary by promotion. Product
either sold or put into service more than six years from date of
manufacture is excluded from warranty coverage.
5. MotorGuide Composite Shaft Limited Lifetime Warranty. MotorGuide
composite shafts are warranted to the original retail purchaser to be free
of defects in material or workmanship for the lifetime of the original
purchaser. MotorGuide will provide a new composite shaft at no cost for
any composite shaft which contains a defect in material or workmanship.
The installation costs are the sole responsibility of the purchaser.
WARRANTY INFORMATION
eng 1

6. This warranty does not apply to normal worn parts, i.e., worn cables,
adjustments, or product damage due to 1) neglect, lack of maintenance,
accident, abnormal operation or improper installation or service; 2) abuse,
i.e., bent metal columns, bent armature shafts, broken control cables, etc.,
accidents, modifications, misuse, excessive wear or damage caused by
an owner’s failure to provide reasonable and necessary installation or
care; 3) use of an accessory or part not manufactured by MotorGuide/
Mercury; 4) alteration or removal of parts; 5) opening the lower unit
(motor) by anyone other than the Factory Service Center will void this
warranty.
7. This warranty will not apply to haul‑out, launch, towing and storage,
transportation charges and/or travel time, telephone or rental charges of
any type, inconvenience, or loss of time or income, or other consequential
damages.
8. We reserve the right to improve the design of any trolling motor without
assuming any obligation to modify any trolling motor previously
manufactured.
9. Serialized "Service‑Repair" motors have a one (1) year warranty.
Nonserialized "Service‑Repair" electric trolling motors are NOT warranted.
"Service‑Repair" motor denotes a trolling motor sold by MotorGuide that
may be "used," but has been inspected and may have had minor repairs.
Original retail purchaser of a "Service‑Repair" motor is the first purchaser
of the motor after it is denoted as "Service‑Repair." "Service‑Repair"
motors have a blue sticker on the battery cable and box denoting
"Manufacturer Certified Service‑Repair Motor."
10. TERMINATION OF COVERAGE: Warranty coverage may be terminated
for repossessed product, or product purchased at auction, from a salvage
yard, from a liquidator, from an insurance company, from unauthorized
marine dealers or boatbuilders, or other third party entities.
11. ALL INCIDENTAL AND/OR CONSEQUENTIAL DAMAGES ARE
EXCLUDED FROM THIS WARRANTY, WARRANTIES OF
MERCHANTABILITY AND FITNESS ARE EXCLUDED FROM THIS
WARRANTY, IMPLIED WARRANTIES ARE LIMITED TO THE LIFE OF
THIS WARRANTY, SOME STATES DO NOT ALLOW LIMITATIONS ON
HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION
OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,
SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO
YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND
YOU MAY ALSO HAVE OTHER LEGAL RIGHTS WHICH MAY VARY
FROM STATE TO STATE.
WARRANTY INFORMATION
2 eng

Boater's Responsibilities
The operator (driver) is responsible for the correct and safe operation of the
boat and safety of its occupants and general public. It is strongly recommended
that each operator (driver) read and understand this entire manual before
operating the trolling motor.
Be sure at least one additional person on board is instructed in the basic
operation of the trolling motor in case the driver is unable to operate the boat.
Protecting People in the Water
WHILE YOU ARE TROLLING
It is very difficult for a person in the water to take quick action to avoid a boat
heading in their direction, even at slow speeds.
21604
Always slow down and exercise extreme caution any time you are boating in an
area where there might be people in the water.
WHILE THE BOAT IS STATIONARY
! WARNING
A spinning propeller, a moving boat, or any solid device attached to the boat
can cause serious injury or death to swimmers. Stop the trolling motor
immediately whenever anyone in the water is near your boat.
Shut off the trolling motor before allowing people to swim or be in the water
near your boat.
Passenger Safety Message
Whenever the boat is in motion, observe the location of all passengers. A
sudden reduction in boat speed, such as a sharp change of boat direction,
could throw them off the boat.
Safe Boating Suggestions
In order to safely enjoy the waterways, familiarize yourself with local and other
governmental boating regulations and restrictions, and consider the following
suggestions.
Use flotation devices. It is the law to have an approved personal flotation
device of suitable size for each person aboard and have it readily accessible.
GENERAL INFORMATION
eng 3

Do not overload your boat. Most boats are rated and certified for maximum
load (weight) capacities, refer to your boat capacity plate. If in doubt, contact
your dealer or the boat's manufacturer.
Perform safety checks and required maintenance. Follow a regular
schedule and ensure all repairs are made properly.
Never be under the influence of alcohol or drugs while boating (it is the
law). Alcohol or drug use impairs your judgment and greatly reduces your
ability to react quickly.
Passenger boarding. Stop the trolling motor whenever passengers are
boarding or unloading.
Be alert. The operator of the boat is responsible by law to maintain a proper
lookout by sight and hearing. The operator must have an unobstructed view
particularly to the front. No passengers, load, or fishing seats should block the
operators view when operating the boat.
Underwater hazards. Reduce speed and proceed with caution whenever
navigating in shallow water.
Tripping hazards. To avoid a trip hazard, route all cables and wiring neatly
and out of the way.
Report accidents. Boat operators are required by law to file a Boating
Accident Report with their state boating law enforcement agency when their
boat is involved in certain boating accidents. A boating accident must be
reported if 1) there is loss of life or probable loss of life, 2) there is personal
injury requiring medical treatment beyond first aid, 3) there is damage to boats
or other property where the damage value exceeds $500.00 or 4) there is
complete loss of the boat. Seek further assistance from local law enforcement.
GENERAL INFORMATION
4 eng

X5‑55/X5‑70/X5‑80/X5‑105 MotorGuide Trolling Motor
CABLE STEER MODELS
a - Top housing
b - 53.3 cm (21 in.) mount bracket
c - Latch release handle
d - Foot pedal
e - Momentary on button
f - 3‑position switch
g - Speed control knob
h - Battery cables
i - 61 cm (24 in.) mount bracket (optional)
j - Propeller
k - Lower unit
l - Composite column
m - Bracket door knob
a
b
58588
c
d
e
f
g
h
i
j
k
l
m
PRODUCT OVERVIEW
eng 5

HAND-OPERATED MODELS
a - Top housing
b - Extendable speed control tiller handle
c - Serial number decal
d - Battery cables
e - Latch release handle
f - 53.3 cm (21 in.) mount bracket
g - Composite column
h - Propeller
i - Lower unit
j - Bracket door knob
k - Steering tension collar
l - Depth adjustment collar
62253
a
b
c
d
e
f
g
h
j
k
l
i
PRODUCT OVERVIEW
6 eng

Specifications
NOTE: Freshwater models are abbreviated as FW . Saltwater models are
abbreviated as SW .
Model Control Type Volts
Speeds
Forward/
Reverse
Sonar Peak
Thrust
Shaft
Length
X5‑55
FW
Foot pedal/
cable steer FW 12 V Variable No 24.9 kgf (55 lbf)
114.3 cm
(45 in.)
X5‑55
FW
Foot pedal/
cable steer FW 12 V Variable Yes 24.9 kgf (55 lbf)
114.3 cm
(45 in.)
X5‑70
FW
Foot pedal/
cable steer FW 24 V Variable No 31.8 kgf (70 lbf)
114.3 cm
(45 in.)
X5‑70
FW
Foot pedal/
cable steer FW 24 V Variable Yes 31.8 kgf (70 lbf)
114.3 cm
(45 in.)
X5‑80
FW
Foot pedal/
cable steer FW 24 V Variable No 36.3 kgf (80 lbf)
91.4 cm
(36 in.)
X5‑80
FW
Foot pedal/
cable steer FW 24 V Variable No 36.3 kgf (80 lbf)
114.3 cm
(45 in.)
X5‑80
FW
Foot pedal/
cable steer FW 24 V Variable Yes 36.3 kgf (80 lbf)
114.3 cm
(45 in.)
X5‑80
FW
Foot pedal/
cable steer FW 24 V Variable No 36.3 kgf (80 lbf)
127.0 cm
(50 in.)
X5‑80
FW
Foot pedal/
cable steer FW 24 V Variable Yes 36.3 kgf (80 lbf)
127.0 cm
(50 in.)
X5‑80
FW
Foot pedal/
cable steer FW 24 V Variable No 36.3 kgf (80 lbf)
152.4 cm
(60 in.)
X5‑80
FW
Foot pedal/
cable steer FW 24 V Variable Yes 36.3 kgf (80 lbf)
152.4 cm
(60 in.)
X5‑80
FW
Extendable
hand/
twist‑tiller
FW 24V Variable No 36.3 kgf
(80 lbf)
127.0 cm
(50 in.)
X5‑80
SW
Extendable
hand/
twist‑tiller
SW 24V Variable No 36.3 kgf
(80 lbf)
127.0 cm
(50 in.)
X5‑80
SW
Extendable
hand/
twist‑tiller
SW 24V Variable No 36.3 kgf
(80 lbf)
152.4 cm
(60 in.)
X5‑105
FW
Foot pedal/
cable steer FW 36 V Variable No 47.6 kgf (105 lbf)
114.3 cm
(45 in.)
X5‑105
FW
Foot pedal/
cable steer FW 36 V Variable Yes 47.6 kgf (105 lbf)
114.3 cm
(45 in.)
PRODUCT OVERVIEW
eng 7

Model Control Type Volts
Speeds
Forward/
Reverse
Sonar Peak
Thrust
Shaft
Length
X5‑105
FW
Foot pedal/
cable steer FW 36 V Variable No 47.6 kgf (105 lbf)
127.0 cm
(50 in.)
X5‑105
FW
Foot pedal/
cable steer FW 36 V Variable Yes 47.6 kgf (105 lbf)
127.0 cm
(50 in.)
X5‑105
FW
Foot pedal/
cable steer FW 36 V Variable No 47.6 kgf (105 lbf)
152.4 cm
(60 in.)
X5‑105
FW
Foot pedal/
cable steer FW 36 V Variable Yes 47.6 kgf (105 lbf)
152.4 cm
(60 in.)
X5‑105
SW
Extendable
hand/
twist‑tiller
SW 36 V Variable No 47.6 kgf
(105 lbf)
127.0 cm
(50 in.)
X5‑105
SW
Extendable
hand/
twist‑tiller
SW 36 V Variable No 47.6 kgf
(105 lbf)
152.4 cm
(60 in.)
PRODUCT OVERVIEW
8 eng

Wiring and Battery Information
! WARNING
An operating or charging battery produces gas that can ignite and explode,
spraying out sulfuric acid, which can cause severe burns. Ventilate the area
around the battery and wear protective equipment when handling or servicing
batteries.
! WARNING
Performing service or maintenance without first disconnecting the battery can
cause product damage, personal injury, or death due to fire, explosion,
electrical shock, or unexpected motor starting. Always disconnect the battery
cables from the battery before maintaining, servicing, installing, or removing
motor components.
Recommended Practice and Procedures
IMPORTANT: Unplug the trolling motor after each use and when charging the
battery.
• Do not use the main engine battery to power the trolling motor. Use a
dedicated trolling motor battery or battery bank.
• Ensure that the batteries are enclosed and secured within a battery box to
prevent accidental shorting of the battery terminals.
• Route the trolling motor wires on the opposite side of the boat from other
boat wiring.
• Connect boat accessories directly to the main engine battery.
• Do not charge the trolling motor batteries while the trolling motor is in the
deployed (down) position.
Battery Recommendations
• Use 12‑volt, deep cycle marine batteries. The number of batteries
required varies according to the model of your trolling motor. Refer to
Battery Connection.
• As a general rule, deep cycle batteries with a higher amp‑hour rating or
reserve capacity rating will provide longer run times and better
performance.
• Install a manual reset circuit breaker in line with the trolling motor positive
leads within 1.8 m (6 ft) of the batteries. These can be purchased from
your local MotorGuide retailer or from www.motorguide.com.
• Do not extend the included 10‑gauge battery cables more than 1.8 m (6 ft)
for a total of 3 m (10 ft). If longer battery cables are required, MotorGuide
offers accessory 8 mm² (8‑gauge) battery cables.
• Use nylock nuts to secure the battery cables to their terminals. Using wing
nuts to secure the battery cables can cause loose connections.
WIRING AND BATTERY INFORMATION
eng 9

• Do not power any depth sounders or fish finders from the trolling motor
battery. Connecting electronic equipment to the trolling motor batteries
can cause electrical interference. Any depth sounders or fish finders must
be powered from the engine starting or accessory battery.
Recommended MotorGuide Accessory Description
8‑gauge battery cable and terminals with 50‑amp manual reset circuit breaker
50‑amp manual reset circuit breaker
60‑amp manual reset circuit breaker
Battery Precautions
! WARNING
An operating or charging battery produces gas that can ignite and explode,
spraying out sulfuric acid, which can cause severe burns. Ventilate the area
around the battery and wear protective equipment when handling or servicing
batteries.
When charging batteries, an explosive gas mixture forms in each cell. Part of
this gas escapes through holes in the vent plugs and may form an explosive
atmosphere around the battery if ventilation is poor. This explosive gas may
remain in or around the battery for several hours after it has been charged.
Sparks or flames can ignite this gas and cause an internal explosion, which
may shatter the battery.
The following precautions should be observed to prevent an explosion:
1. Keep flames away and do not smoke near batteries being charged or
which have been charged recently.
2. Do not disconnect the battery cables while the trolling motor is operating,
because a spark usually occurs at the point where a live circuit is broken.
Always use care to prevent reverse polarization when connecting or
disconnecting cable clamps on chargers. Poor connections are a common
cause of electrical arcs, which cause explosions.
3. Do not reverse the polarity of battery terminal to cable connections.
Wire and Cable Routing
• Route the trolling motor wires on the opposite side of the boat from other
boat wiring.
• The trolling motor should be connected to its own dedicated battery.
• Sensitive electronics, such as depth finders, should be connected to a
separate battery.
• Marine engines should have their own dedicated starting battery.
• All batteries should have a common ground.
WIRING AND BATTERY INFORMATION
10 eng

Wire Color Code Abbreviations
Wire Color Abbreviations
BLK Black BLU Blue
BRN Brown GRY or GRA Gray
GRN Green ORN or ORG Orange
PNK Pink PPL or PUR Purple
RED Red TAN Tan
WHT White YEL Yellow
LT or LIT Light DK or DRK Dark
Battery Connection
! WARNING
Before working around electrical system components, disconnect the battery
cables from the battery to prevent injury or damage to the electrical system
due to an accidental short circuit.
! CAUTION
Disconnecting or connecting the battery cables in the incorrect order can
cause injury from electrical shock or can damage the electrical system.
Always disconnect the negative (‑) battery cable first and connect it last.
NOTICE
Failure to operate the trolling motor within the recommended voltage
specifications can cause product damage. Do not exceed the maximum
supply voltage.
IMPORTANT: Refer to the decal on the head of the trolling motor to determine
the voltage requirements of your trolling motor.
12-VOLT BATTERY CONNECTION
1. Starting with the negative (–) lead, disconnect the battery cables from the
engine starting or accessory battery.
2. Install a 50‑amp (good) or 60‑amp (best) manual reset circuit breaker in
line with the trolling motor power cable positive (+) lead and the trolling
motor battery positive (+) terminal.
3. Connect the positive (+) trolling motor lead to the positive (+) trolling
motor battery terminal.
4. Connect the negative (–) trolling motor lead to the negative (–) trolling
motor battery terminal.
5. Connect a common ground bond from the trolling motor battery negative
(–) terminal to the engine starting battery negative (–) terminal.
WIRING AND BATTERY INFORMATION
eng 11

6. Starting with the positive (+) lead, reconnect the battery cables to the
engine starting or accessory battery.
a - Power cables to trolling motor
b - Manual reset circuit breaker
c - Trolling motor battery
d - Engine starting or accessory battery
e - Power cables to engine
f - Common ground bond
24-VOLT BATTERY CONNECTION
1. Starting with the negative (–) lead, disconnect the battery cables from the
engine starting or accessory battery.
2. Install a 50‑amp (good) or 60‑amp (best) manual reset circuit breaker in
line with the trolling motor power cable positive (+) lead and the trolling
motor battery B positive (+) terminal.
3. Connect the positive (+) trolling motor lead to the positive (+) terminal on
trolling motor battery B.
4. Connect a jumper wire (reference gray) between the negative (–) terminal
on battery B to the positive (+) terminal on battery A.
IMPORTANT: The jumper wire should be the same wire gauge as the
negative (–) and positive (+) power cables.
5. Connect the trolling motor negative (–) lead to the negative (–) terminal on
battery A.
RED
BLACK
REDRED
a
b
c
e
f
d
45086
BLACK
WIRING AND BATTERY INFORMATION
12 eng

6. Starting with the positive (+) lead, reconnect the battery cables to the
engine starting or accessory battery.
24-volt battery connection
a - Power cables to trolling motor
b - Manual reset circuit breaker
c - Jumper wire (not supplied)
d - Negative (–) battery terminal
36-VOLT BATTERY CONNECTION
1. Starting with the negative (–) lead, disconnect the battery cables from the
engine starting or accessory battery.
2. Install a 50‑amp (good) or 60‑amp (best) manual reset circuit breaker in
line with the trolling motor power cable positive (+) lead and the trolling
motor battery C positive (+) terminal.
3. Connect the positive (+) trolling motor lead to the positive (+) terminal on
trolling motor battery C.
4. Connect a jumper wire (reference gray) between the negative (–) terminal
on battery C to the positive (+) terminal on battery B.
IMPORTANT: The jumper wire should be the same wire gauge as the
negative (–) and positive (+) power cables.
5. Connect a jumper wire (reference gray) between the negative (–) terminal
on battery B to the positive (+) terminal on battery A.
6. Connect the trolling motor negative (–) lead to the negative (–) terminal on
battery A.
RED
BLACK
a
b
c
d
37824
GRAY
c
Battery A
Battery B
WIRING AND BATTERY INFORMATION
eng 13

7. Starting with the positive (+) lead, reconnect the battery cables to the
engine starting or accessory battery.
36-volt battery connection
a - Power cables to trolling motor
b - Manual reset circuit breaker
c - Jumper wire (not supplied)
d - Negative (–) battery terminal
RED
BLK
37825
GRY
c
Battery B
Battery C
Battery A
GRY
c
a
b
c
d
WIRING AND BATTERY INFORMATION
14 eng
