Motorola Roadster pro Installation instructions

en
motorola roadster pro
Bluetooth
car speakerphone
®
let’s get started

1en Here’s what you get
Here’s what you get
check it out
Be safe. Be awesome. Make and receive calls or play music
from your phone using the Motorola Roadster Pro while safely
keeping your hands on the steering wheel.
•Connect with two phones at the same time.
•Hear a caller’s name and use your voice to answer or ignore
calls.
•Let voice prompts guide you in making connections,
checking battery level, and more.
Go ahead, check it out:
Hi. Meet your speakerphone . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . 2
Give it some juice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Where to put it. . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . 4
Ready? Turn it on (or off) . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . 5
Connect it and go . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . 6
Stream some music. . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . 9
Calls, how to make them. . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . 10
What do the lights mean?. . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . 12
Make some changes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Problems?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . 14
Get what you need . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Safety, Regulatory, & Legal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Caution: Before using your device, please read the safety,
regulatory and legal information at the back of this guide.

2Here’s what you get en
Hi. Meet your speakerphone
take a good look
Call
Volume Buttons
(on back)
Mute Play, Pause, Next Voice Recognition
Power Switch
Status Light
Micro USB
Charging Port

3en Give it some juice
Give it some juice
charge it up
You can use your speakerphone unplugged or plugged into
the charger.
Note: Your battery is designed to last the life of the product. It
should only be removed by a recycling facility. Any attempt to
remove or replace your battery may damage the product and
void your warranty.
Tip: Later while you’re using your speakerphone, you can hear
what the battery level is by pushing the Volume Up and
Volume Down buttons as the same time.
Status Light
Red (0-30% charge)
Yellow (30-95% charge)
Green (greater than 95% charge)

4Where to put it en
Where to put it
move over, garage door opener
Important: Before installing or using your product, check the
local laws regarding mounting and use of equipment.
For safe installation:
•Do not put your product in a location that obstructs the
driver's vision or interferes with the operation of the
vehicle.
•Do not cover an airbag.
Slide onto carvisor.

5en Ready? Turn it on (or off)
Ready? Turn it on (or off)
power up
•On:the speakerphone automatically turns off when you
move your phone away from the car. Through motion
detection, the speakerphone automatically turns back on
when you open or close the car door.
• Off: the speakerphone is off. The automatic on/off feature
is also disabled.
OnO

6Connect it and go en
Connect it and go
set up Bluetooth®
Turn off any Bluetooth devices previously paired with your
speakerphone. Then:
11
Turn on Bluetooth on your device.
13
Go to the Bluetooth menu on your device,
and enter passcode 0000 if prompted.
2
Turn on the car speakerphone. After the blue light comes
on and you hear, “ready to pair,” follow the voice prompts
to pair and connect with the device.
4
When the device and car speakerphone
connect, you’ll hear “pairing complete”.

7en Connect it and go
Note: If you are prompted by your phone to grant phonebook
access, touch OK on your phone.
Tip: After you pair the first time, when you turn on your
speakerphone and your phone’s Bluetooth feature, they
connect automatically.
Second device?
Do you use two phones, or a tablet and a phone? Integrated
multipoint technology can pair them both.
1Use “Connect it and go” on page 6 to pair the second
device. Your speakerphone remains in pairing mode for
five minutes after turning on.
2After you pair them, just turn on both devices to connect
them.
More tips for using two phones:
• With two phones connected, not on a call: Press to use
voice recognition on the first phone. Double-press it to use
voice recognition on the second phone.
• With two phones connected, one call on hold: Press to
go to the call on the first phone. Double-press it to go to the
call on the second phone.

8Connect it and go en
Test your connection
1Make sure your speakerphone is turned on.
2On your phone, dial a phone number and press the
Call/Send key.
When you successfully connect for calls, you hear ringing on
the speakerphone’s speaker.

9en Stream some music
Stream some music
play music from your phone
Note: This feature is phone dependent.
To hear music on your speakerphone, connect by Bluetooth,
start playing music on your phone, and then:
•To play/pause the song you’re playing on your phone on
your speakerphone, press .
•To advance to the next song, double press until you hear
a tone.
While a call is active, music pauses. When the call ends, music
resumes playing.
Note: You need to play music on your phone before you can
hear and control it with your speakerphone. Also, the volume
setting on your phone may change the volume on your
speakerphone.

10 Calls, how to make them en
Calls, how to make them
it’s good to talk
Note: Some features are phone/network dependent.
Tip: When you’re connected to two phones, use the voice
prompts on the phone you want for features like voice dial and
redial.
To…
answer a call Say “answer” when prompted or press .
reject a call Say “ignore” when prompted or press and
hold a volume button until you hear a tone.
voice dial a
call Press . When you hear a tone, follow the prompts to make a call.
redial the last
number
dialed
Press .
mute or
unmute a call Press . The speakerphone says, “Mute on” or “Mute off”. When mute is on, there
will be a red light on .
answer a
second call Press . The first call is put on hold.
end a call Press .

11en Calls, how to make them
More about calls
Note: Using a mobile device or accessory while driving may
cause distraction and may be illegal. Always obey the laws and
drive safely.
Voice commands
Answer or ignore calls using your voice—just say “answer” or
“ignore”.
Note: This feature does not work for second incoming calls.
Hear a caller’s name
If your phone knows your caller’s name, then you hear “call
from [name]” on an incoming call.
Note: This feature doesn't work when you’re on a call and you
receive a second call.
Voice recognition
Press to activate your phone's voice recognition (on
phones that support this feature) to call a contact in your
phonebook. If you have another voice controlled app on your
phone (like MY MOTOSPEAK™), your phone may ask what
you want to do the first time you press .

12 What do the lights mean? en
What do the lights mean?
figure out the flashes and blinks
If status light is… your speakerphone is…
flashing blue powering on, searching for
devices
solid blue device connected
flashing red slowly low battery
solid red charging (battery 0-30%)
solid yellow charging (battery 30-95%)
solid green charging (battery greater
than 95%)

13en Make some changes
Make some changes
adjust these settings
Press and hold the Call button while turning on your
speakerphone to adjust these settings:
•Factory default reset
Caution: This action erases all pairing information stored in
your speakerphone.
•Voice interface
•Caller ID alert
•Multipoint connections (for two phones)
•Wideband speech
•Voice answer
Note: The speakerphone will automatically turn back on after
you exit the settings menu.

14 Problems? en
Problems?
we have solutions
Why won’t my speakerphone pair with a new device?
Turn the speakerphone off and on. Then follow the steps in
“Connect it and go” on page 6. (You have 5 minutes to pair a
new device. If you need longer, you have to turn the
speakerphone off and on again.)
My speakerphone worked before, but now it's not working!
Make sure your phone is on and the Bluetooth feature is
turned on in your phone. If the Bluetooth feature was turned
off or was turned on only temporarily, you may need to restart
the Bluetooth feature and pair your phone and headset again.
(See “Connect it and go” on page 6.)
My speakerphone and phone won’t automatically
reconnect. What happened?
Perform a factory default reset by going to the settings menu
(see “Make some changes” on page 13). Then use “Connect
it and go” on page 6.

15en Get what you need
Get what you need
help, guides, and a lot of details
•Answers:Visit www.motorola.com/support or contact the
Motorola Customer Support Center: 1-800-331-6456
(United States), 1-888-390-6456 (TTY/TDD United States for
hearing impaired), or 1-800-461-4575 (Canada).
• Bluetooth: If you have questions or need assistance,
contact us at 1-877-MOTOBLU, or visit
www.motorola.com/bluetoothsupport or
www.motorola.com/bluetoothconnect.
•News:Get the latest news, apps, tips & tricks, videos and
so much more—join us on:
Yo uTu be™ www.youtube.com/motorola
Facebook™ www.facebook.com/motorola
Twitter www.twitter.com/motomobile
Google+™ www.google.com/+

16 Safety, Regulatory, & Legal en
Safety, Regulatory, & Legal
Battery Use & Safety
Warning: Your product contains a battery which should only be removed by a Motorola approved
service center or recycler.
• Don’t try to remove or replace the battery yourself. Attempting to remove or replace the
battery may damage the battery and may cause burning and injury.
• Don’t try to take apart or fix your product. Attempting to take apart or fix your product may
damage the battery and may cause burning and injury.
• Don’t crush, bend, or expose your product to heat or liquid. This may damage the battery and
may cause burning and injury.
Battery Charging
Battery Charging
Notes for charging your product’s battery:
• During charging, keep your product and charger near room temperature for efficient battery
charging.
• New batteries are not fully charged.
• New batteries or batteries stored for a long time may take more time to charge.
• Motorolabatteries and chargingsystems have circuitry that protects thebattery from damage
from overcharging.
Third Party Accessories
Using third party accessories, including but not limited to batteries, chargers, headsets, covers,
cases, screen protectors, and memory cards, may impact your product’s performance. Using a
non-Motorola battery or charger may present a risk of fire, explosion, leakage, or other hazard.
Motorola’s warranty doesn’t cover damage to the product caused by non-Motorola batteries
and/or chargers. For a list of Motorola accessories, visit
www.motorola.com/us/consumers/Accessories/accessories,en_US,sc.ht
ml (in English only).
Driving Precautions
Responsible andsafe driving is your primary responsibility when driving a vehicle. Making callsor
using applications while driving may cause distraction, and may be prohibited or restricted in
certain areas—always obey local laws and regulations for the use of mobile devices and
accessories in the vehicle.
While driving, ALWAYS:
• Keep your eyes on the road.
• Use a handsfree device if available or required by law in your area.
• Enter destination information into a navigation device before driving.

17en Safety, Regulatory, & Legal
• Use voice activated features (such as voice dial) and speaking features (such as audible
directions), if available.
• Concentrate on driving, and stop using the mobile device if you can’t concentrate.
Pull over safely before using your mobile device to send messages, surf the web, or use other
applications.
Remember to follow the “Responsible Driving” tips at www.motorola.com/callsmart
(in English only).
Caution About High Volume Usage
Warning: Exposure to loud noise from any source for extended periods of time may
affect your hearing. The louder the volume sound level, the less time is required
before your hearing could be affected. To protect your hearing:
• Limit the amount of time you use headsets or headphones at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness in your ears,
ringing in your ears, or muffled speech, you should stop listening to the device through your
headset or headphones and have your hearing checked.
Children
Children
Keep your product and its accessories away from small children. These products are not toys
and may be hazardous to small children. For example, a choking hazard may exist for small,
detachable parts.
Use & Care
Use & Care
To care for your Motorola product, please observe the following:
liquids
Don’t expose your product to water, rain, extreme humidity, sweat, or other liquids.
drying
Don’t try to dry your product using a microwave oven, conventional oven, or dryer.
extreme heat or cold
Avoid temperatures below -10°C (14°F) or above 60°C (140°F). For battery
powered accessories, do not recharge your accessory in temperatures below 0°C
(32°F) or above 45°C (113°F).

18 Safety, Regulatory, & Legal en
dust and dirt
Don’t expose your product to dust, dirt, sand, food, or similar materials.
cleaning
To clean your product, use only a dry soft cloth. Don’t use alcohol or other cleaning
solutions.
shock and vibration
Don’t drop your product or expose it to strong vibration.
protection
To help protect your product, always make sure that all connector and
compartment covers are closed and secure, and avoid carrying it with hard objects
such as keys or coins.
Symbol Key
Your battery, charger, accessory product, user’s guide, or packaging may contain symbols,
defined as follows:
Symbol Definition
Important safety information follows.
Do not dispose of your product or battery in a fire.
Your product or battery may require recycling in
accordance with local laws. Contact your local
regulatory authorities for more information.
Don’t dispose of your product or battery with your
household waste. See “Disposal & Recycling” for
more information.
For indoor use only.
032374o
032376o
032375o

19en Safety, Regulatory, & Legal
European Union Directives Conformance
Statement
EU Conformance
The following CE compliance information is applicable to Motorola products that carry one of the
following CE marks:
Hereby, Motorola declares that this product is in compliance with:
• The essential requirements and other relevant provisions of Directive 1999/5/EC
• All other relevant EU Directives
For products that support Wi-Fi 802.11a (as defined in your product information): This device is
restricted to indoor use when operating in the 5.15 to 5.25 GHz (802.11a) Wi-Fi frequency band.
The following gives an example of a typical Product Approval Number:
You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC (to R&TTE
Directive) at www.motorola.com/rtte (in English only). To find your DoC, enter the Product
Approval Number from your product’s label in the “Search” bar on the website.
FCC Notice to Users
FCC Notice
The following statement applies to all products that bear the FCC logo and/or FCC ID on the
product label.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. See 47 CFR Sec. 15.105(b). These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
0168
Product
Approval
Number
