FIF-12 USB PROGRAMMING INTERFACE
The FIF-12 is the Interface Unit which allows cloning of channel data to Vertex Standard transceivers, and/or re-writing of the
firmware on some Vertex Standard transceivers, using the USB port of a personal computer.
: Check with your Vertex Standard Dealer for applicable models.
OPERATING SYSTEM REQUIREMENTS
Microsoft® Windows® 2000, Windows® XP (32 bit Ver. only),
Windows® Vista (32 / 64 bit Ver.), or Windows® 7 (32 / 64 bit
Ver.)
PACKING LIST
FIF-12 Interface Unit
USB Cable
CD-ROM (Includes the Driver File and Operating Manual)
OPERATION
Log on to the computer using the “Administrator”
account. If you do not know how to change the account
to “Administrator,” please consult your computer system
administrator.
Install the FIF-12 driver.
When the driver installation is finished, connect the sup-
plied USB Cable between the FIF-12 and your computer,
then connect the appropriate Connection Cable (option) be-
tween the FIF-12 and the transceiver.
Confirm the computer’s communication port which detects
the FIF-12.
Execute the cloning/writing software.
If this is the first time you have executed the programming/
writing software on this computer after installing the FIF-12
USB Interface, check the programming/writing software’s
“CONFIGURE” parameter, to be sure that the communica-
tion port of the programming/writing software matches that
set for the FIF-12. See page 13.
OPTIONS
CT-171 Connection Cable with 8-pin Modular Jack
(for the VX-4500/-4600/-2100/-2200/-4100/-4200/
VX-7100/-7200/, VXR-9000/-7000/-1000
etc.)
CT-105 Connection Cable with 14-pin Universal Connector
(for the VX-800/-537/-5500/-6000 etc.)
CT-106 Connection Cable 4-conductor Mini-phone Jack
(for the VX-450/-230/-350/-410/-420/-160/-180 etc.)
CT-108 Connection Cable with 14-pin Universal Connector
(for the VX-820/-920 etc.)
Connect the Transceiver to this
jack using the appropriate (op-
tional) Connection Cable.
Connect your Computer to this
jack using the supplied USB Cable.
Status Indicator
GREEN: Normal Condition
RED: Uploading/Downloading
ORANGE: Firmware Writing
TYPICAL SETUP FOR THE FIF-12
Personal Computer
Connection Cable CT-106 (not supplied)
USB Cable
VX-450
FIF-12
NOTE
The FIF-12 is designed to be connected directly to
the computer’s USB port. Devices that are made
to convert a USB device to a 9 pin serial port will
not work and/or may damage the FIF-12.
E A J 2 3 X 1 0 0

~ 2 ~
INSTALLATION PROCEDURE FOR THE FIF-12 DRIVER (Microsoft® Windows® 2000)
Note: Please perform this operation after changing user ac-
count to an "Administrator". DO NOT INSTALL ANY HARD-
WARE BEFORE INSTALLING FIF-12 DRIVER.
1. Set the supplied CD into your CD-ROM drive, then Click
the left mouse button on the “setup.exe”.
3. Click the left mouse button on the “Install” button.
4. Click the left mouse button on the “Finish” button.
5. Connect the FIF-12 to the USB port on your computer,
the Driver is recognized automatically.
2. T h e f o l l o w i n g w i n d o w ( I n s t a l l S h i e l d
Wizard) will be open. Click the left mouse button on
“Next >” button.

~ 3 ~
CONFIRMING THE COMPUTER’s COMMUNICATION PORT (Microsoft® Windows® 2000)
1. Click the right mouse button on the “My Computer” icon
on the desktop, then click the left mouse button on the
“Properties” item to open the “System Properties” win-
dow.
2. Click the left mouse button on the “Hardware” Folder,
then click the left mouse button on the “Device Man-
ager” Button to open the “Device Manager” window.
3. Confirm the computer’s communication port which de-
tects the FIF-12.

~ 4 ~
INSTALLATION PROCEDURE FOR THE FIF-12 DRIVER (Microsoft® Windows® XP)
2. T h e f o l l o w i n g w i n d o w ( I n s t a l l S h i e l d
Wizard) will be open. Click the left mouse button on
“Next >” button.
Note: Please perform this operation after changing user ac-
count to an "Administrator". DO NOT INSTALL ANY HARD-
WARE BEFORE INSTALLING FIF-12 DRIVER.
1. Set the supplied CD into your CD-ROM drive, then Click
the left mouse button on the “setup.exe”.
3. Click the left mouse button on the “Install” button.
4. Click the left mouse button on the “Continue Anyway”
button.
5. Click the left mouse button on the “Finish” button.

~ 5 ~
INSTALLATION PROCEDURE FOR THE FIF-12 DRIVER (Microsoft® Windows® XP)
9. The Driver is recognized automatically.
6. Connect the FIF-12 to the USB port on your computer.
7. The following window (Found New Hardware) will be open.
8. The following window (Found New Hardware Wizard) will
be open. Select “Install the software automatically
(Recommended),” then click the left mouse button on
the “Next>” button.
10.Click the left mouse button on the “Continue Anyway”
button.
11.Click the left mouse button on the “Finish” button.
12.Repeat step 7 ~ step 11.

~ 6 ~
CONFIRMING THE COMPUTER’s COMMUNICATION PORT (Microsoft® Windows® XP)
1. Click the left mouse button on the “start” button, then
click the right mouse button on the “My Computer” item.
Click the left mouse button on “Propeties” to open the
“System Properties” window.
2. Click the left mouse button on the “Hardware” Folder,
then click the left mouse button on the “Device Man-
ager” button to open the “Device Manager” window.
3. Confirm the computer’s communication port which de-
tects the FIF-12.

~ 7 ~
Note: Please perform this operation after changing user ac-
count to an "Administrator". DO NOT INSTALL ANY HARD-
WARE BEFORE INSTALLING FIF-12 DRIVER.
1. Set the supplied CD into your CD-ROM drive, then Click
the left mouse button on the “setup.exe”.
2. The following window (User Account Control) will be open.
Click the left mouse button on “Allow”.
INSTALLATION PROCEDURE FOR THE FIF-12 DRIVER (Microsoft® Windows® Vista)
3. The following window (FIF-12 Driver Setup) will be open.
4. T h e f o l l o w i n g w i n d o w ( I n s t a l l S h i e l d
Wizard) will be open. Click the left mouse button on
“Next >” button.
5. Click the left mouse button on the “Install” button.
6. Click the left mouse button on the “Finish” button.

~ 8 ~
INSTALLATION PROCEDURE FOR THE FIF-12 DRIVER (Microsoft® Windows® Vista)
7. Connect the FIF-12 to the USB port on your computer,
the Driver is recognized automatically.

~ 9 ~
CONFIRMING THE COMPUTER’s COMMUNICATION PORT (Microsoft® Windows® Vista)
1. Click the left mouse button on the “start” button, then
click the right mouse button on the “Computer” Item.
Click the left mouse button on “Propeties” to open the
“System Properties” window.
2. Click the left mouse button on the “Device Manager”
Item, to open the “Confirmation” window.
4. Confirm the computer’s communication port which de-
tects the FIF-12.
3. Click the left mouse button on the “Continue” button to
open the “Device Manager” window.

~ 10 ~
Note: Please perform this operation after changing user ac-
count to an "Administrator". DO NOT INSTALL ANY HARD-
WARE BEFORE INSTALLING FIF-12 DRIVER.
1. Set the supplied CD into your CD-ROM drive, then Click
the left mouse button on the “setup.exe”.
2. The following window (User Account Control) will be open.
Click the left mouse button on “Yes” button.
INSTALLATION PROCEDURE FOR THE FIF-12 DRIVER (Microsoft® Windows® 7)
4. T h e f o l l o w i n g w i n d o w ( I n s t a l l S h i e l d
Wizard) will be open. Click the left mouse button on
“Next >” button.
5. Click the left mouse button on the “Install” button.
6. The “Windows Security” window will be open. Click the
left mouse button on “Install this driver software any-
way”.
3. The following window (FIF-12 Driver Setup) will be open.

~ 11 ~
INSTALLATION PROCEDURE FOR THE FIF-12 DRIVER (Microsoft® Windows® 7)
7. Click the left mouse button on the “Finish” button.
8. Connect the FIF-12 to the USB port on your computer,
the Driver is recognized automatically.

~ 12 ~
CONFIRMING THE COMPUTER’s COMMUNICATION PORT (Microsoft® Windows® 7)
1. Click the left mouse button on the “start” button, then
click the right mouse button on the “Computer” Item.
Click the left mouse button on “Properties” to open the
“System Properties” window.
2. Click the left mouse button on the “Device Manager”
Item, to open the “Device Manager” window.
3. Confirm the computer’s communication port which de-
tects the FIF-12.

~ 13 ~
“CONFIGURE” PARAMETER SETTING PROCEDURE (EXAMPLE: “CE115”)
1. Click the left mouse button on the “File” parameter.
2. Click the left mouse button on the “Configure” item to
open the “Configure” window.
3. Select the communication port which is detecting the
FIF-12.
4. Select the Baud Rate for the transceiver’s computer in-
terface circuitry.
5. Click the left mouse button on the “OK” button.
