PRO MIC I/O
Vaddio PRO MIC I/O - Document Number 342-0569 Rev A Page 4 of 16
OVERVIEW:
The PRO MIC I/O expands the available echo canceling microphone
device that can be used with the EasyUSB solution. The PRO MIC
I/O expands the installation flexibility by providing an interface device
that connects to quality 3rd party, professional microphones. Now
room designs can use custom mic configuration options using
boundary, button, or gooseneck mics with the EasyUSB Mixer/Amp
solution. Use the EasyUSB Mixer/Amp to transform your PC into a
meeting room using Unified Communication soft-clients such as
Skype, Microsoft Lync, Jabber, Polycom, Vidyo, and others.
The USB tools within the EasyUSB solution include:
EasyUSB Mixer/Amp:
This device is an integrated audio mixer that emulates a single microphone and speaker to the PC. It
includes a 2x20 Watt amplifier and line level audio input and output for connection to other AV equipment
within the room. Up to two EasyMic devices interface directly to the EasyUSB Mixer/Amp using a standard
Cat-5 cable.
EasyUSB PRO MIC I/O:
The PRO MIC I/O is a four channel echo cancelling, microphone input device that connects to the EasyUSB
Mixer/Amp. It includes front panel level controls of the microphone preamp allowing installer to gain match
with an attached 3rd party microphone. Each mic channel offers 48 VDC phantom power (on/off) with dip
switch settings to enable high pass and low pass filters. The PRO MIC I/O connects to the EasyUSB
Mixer/Amp with single home run of Cat-5 cable.
EasyMic MicPOD:
The EasyMic MicPOD is an attractive echo canceling table microphone with 360 degree audio coverage
pattern. The user control buttons such as Mute and Volume are incorporated on top of the device. The
EasyMic MicPOD connects to the EasyUSB Mixer/Amp with single home run of Cat-5 cable providing audio,
control, and power.
EasyMic Ceiling MicPOD:
The Ceiling MicPOD is an Echo Canceling Ceiling microphone array with 360 degree audio pick-up pattern. It
includes a plenum rated electronics module with an adjustable 36” (0.914m) plenum drop cable to a small 2.5”
(63.5mm) diameter Trio 3 mic head. The Ceiling MicPODs are offered in both black and white versions.
EasyTalk Sound Bar:
The Easy Talk Sound Bar is a high definition, 40” long, low profile sound bar loudspeaker. The sound bar
includes installation options for table stand or wall mounting below a LCD display.
EasyTalk Ceiling Speakers:
The EasyTalk speakers are full range Bose DS16 ceiling speakers with tile support braces and plenum rated
back cans - Sold in pairs.
The EasyTalk USB solutions are intended for up to medium size conference
rooms (20’ x 30’) with typically 2 to 20 participants. In addition, the EasyTalk
USB solution can be paired with the Vaddio ClearVIEW™ HD-USB PTZ
Camera to implement a complete AV conferencing solution for the PC or
MAC. These products are offered in pre-configured room bundles for
common conferencing applications or create a unique, custom solution by
purchasing each appliance individually.
Intended Use:
Before operating the device, please read the entire manual thoroughly. The system was designed, built and
tested for use indoors, and with the provided power supply and cabling. The use of a power supply other than the
unit provided or outdoor operation has not been tested and could damage the device and/or create a potentially
unsafe operating condition.
EasyMic MicPODs, EasyUSB
Mixer/Amp and
PRO MIC I/O
HD-USB PTZ
Camera
