Motorola Symbol ds9808-r User manual

http://www.motorola.com/ds9808

SYMBOL DS9808-R

DS6708 Poster

BLACK

PANTONE 285

Perforation

DS9808 Poster

POST IN WORK AREAPOST IN WORK AREA

Quick Start Guide

CORD ATTACHMENT/REMOVAL

See Product Reference Guide

for more information

TROUBLESHOOTING

No power to scanner

Check system power;

ensure power supply,

if required, is connected

Incorrect interface cable used

Ensure that correct

interface cable is used

Ensure all cable connections

are secure

Scan appropriate host parameter bar codes Ensure all cable connections are secure

Interface/power cables are loose

Scanner not working

Bar code unreadable

Ensure bar code is not defaced;

try scanning test bar code of same

bar code type

Distance between scanner

and bar code incorrect

Move scanner closer to

or further from bar code

Scanner not programmed

for bar code type

Ensure scanner is programmed

to read type of bar code being

scanned

Scanner not decoding bar code

Scanner not programmed for correct host interface Interface cable is loose

Scanner decoding bar code, but data not transmitting to host

Scanner not programmed for correct host interface

Scan appropriate host parameter bar codes

Scanned data incorrectly displayed on host

SYMBOL DS9808-R PROGRAMMING BAR CODES

1 LED Indicator

2 Scan Window

3 Trigger A

4 Trigger B

5 RFID LED

6 RFID Module

SET DEFAULTS

HID KEYBOARD EMULATION

IBM HAND-HELD USB

ICL RS-232

NIXDORF RS-232 MODE A

NIXDORF RS-232 MODE B

FUJITSU RS-232

OPOS/JPOS

STANDARD RS-232

RS-232 Host Types

Carriage Return/Line Feed

Set Defaults

USB Host Types

SNAPI WITH IMAGING

SNAPI WITHOUT IMAGING

PORT 5B PORT 9B

IBM 46XX Host Types

PORT 17

RFID Same Tag Timeout

DISABLE

2 SECONDS 5 MINUTES

RFID Trigger Modes

CONTINUOUS SINGLE TAG

CONTINUOUS RE-REPORT CONTINUOUS FLUSH

RFID Data Transmission Format

RAW GS1-128

EPC URI

RFID

DS6708 Poster

BLACK

PANTONE 285

http://www.motorola.com/ds9808

PerforationPerforation

SYMBOL DS9808-R

Motorola, Inc.

One Motorola Plaza Holtsville, New York 11742-1300, USA

DS9808 Poster

SYMBOL DS9808-R

Caution

class 2 laser light

when open.

Do not stare

into beam.

Attention : lumière

laser en cas d'ouverture.

Ne pas regarder dans

le faisceau.

Vorsicht

laserlicht klasse 2,

wenn abdeckung geöffnet.

Nicht in den strahl blicken.

DS9808-LR

DS9808-SR

OPTIMUM ARM POSITION AVOID EXTREME WRIST ANGLES

Low/medium/high beep

Power up

Short medium beep

Bar code decoded

4 long low beeps

Transmission error

detected; data is

ignored

Standard Use

Medium/high (two-tone) beep

An RFID tag was

read (if RFID read

beeper is enabled)

High/medium/low/low beeps

Unexpected RFID indication

RFID

Hand-Held Scanning / RFID

High/low beep

Correct programming

sequence performed

Low/high beep

Incorrect

programming

sequence or

“Cancel” bar code

scanned

High/low/high/low beep

Successful

parameter

setting

Parameter Menu Scanning

BEEPER INDICATIONS LED INDICATIONS

Off

Scanner is on and

ready to scan / read,

or no power to scanner

Green

Scanner successfully

decoded bar code

or read RFID tag

Red

Transmission

error

Hands-Free (Presentation) Scanning

Off

No power to

scanner

Off Momentarily

Bar code is

successfully

decoded

Green

Scanner is ready

to scan

Red

Transmission Error

Local Contact:

OPTIMUM DATA CAPTURE

AVOID BENDING AND REACHING

REGULATORY INFORMATION

Ergonomic Recommendations

Caution: In order to avoid or minimize the potential risk of ergonomic injury follow

the recommendations below. Consult with your local Health & Safety Manager to

ensure that you are adhering to your company's safety programs to prevent

employee injury.

• Reduce or eliminate repetitive motion

• Maintain a natural position

• Reduce or eliminate excessive force

• Keep objects that are used frequently within easy reach

• Perform tasks at correct heights

• Reduce or eliminate vibration

• Reduce or eliminate direct pressure

• Provide adjustable workstations

• Provide adequate clearance

• Provide a suitable working environment

• Improve work procedures.

Regulatory Information

The guide applies to Model Numbers DS9808-RUS/RWW

All Motorola devices are designed to be compliant with rules and regulations in

locations they are sold and will be labeled as required.

Any changes or modifications to Motorola equipment, not expressly approved by

Motorola could void the user’s authority to operate the equipment.

Caution

Declared maximum operating temperature: 40oC / 104oF

This guide is available on local languages, translations are available at the

following website: http://www.motorola.com/enterprisemobility/support

Wireless Device Country Approvals

Regulatory markings, subject to certification, are applied to the device signifying

the radio(s) is/are approved for use in the following countries: United States,

Canada and Mexico.

Laser Devices

Complies with 21CFR1040.10 and 1040.11 except for deviations pursuant to

Laser Notice No. 50, dated June 24, 2007.

EN60825-1: 2007

IEC60825-1 (Ed 2.0)

The laser classification is marked on one of the labels on the device.

Class 2 laser scanners use a low power, visible light diode. As with any very bright light source, such as the

sun, the user should avoid staring directly into the light beam. Momentary exposure to a Class 2 laser is not

known to be harmful.

AVOID REACHING

AVOID BENDING

Recommended Usage Guide

AVOID EXTREME

WRIST ANGLES

72-125703-01 Revision A April 2010

Alternate left and right hands

taking breaks and task rotation

recommended

Alternate left and right hands

taking breaks and task rotation

recommended

MOTOROLA and the Stylized M Logo and Symbol and the Symbol logo are registered

in the U.S. Patent and Trademark Office. All other product or service names are the

property of their respective owners.

Motorola reserves the right to make changes to any product to improve reliability, function, or design.

Motorola does not assume any product liability arising out of, or in connection with, the application or

use of any product, circuit, or application described herein. No license is granted, either expressly or by

implication, estoppel, or otherwise under any patent right or patent, covering or relating to any

combination, system, apparatus, machine, material, method, or process in which Motorola products

might be used. An implied license exists only for equipment, circuits, and subsystems contained in

Motorola products. MOTOROLA, the Stylized M Logo and Symbol and the Symbol logo are registered

trademarks of Motorola, Inc. Other product names mentioned in this manual may be trademarks or

registered trademarks of their respective companies and are hereby acknowledged.

Warranty

For the complete Motorola hardware product warranty statement, go to:

http://www.motorola.com/enterprisemobility/warranty

Service Information

If you have a problem using the equipment, contact your facility’s Technical or Systems Support. If there

is a problem with the equipment, they will contact the Motorola Enterprise Mobility Support at:

http://www.motorola.com/enterprisemobility/contactsupport

For the latest version of this guide go to: http://www.motorola.com/enterprisemobility/manuals

Tested to comply

with FCC Standards

FOR HOME OR OFFICE USE

Radio Frequency Interference Requirements

Note: This equipment has been tested and

found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC

rules. These limits are designed to provide

reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

However there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help.

Radio Transmitters (Part 15)

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

Radio Frequency Interference Requirements – Canada

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du

Canada.

Warnings for Use of Wireless Devices

Please observe all warning notices with regard to the usage of wireless devices.

Potentially Hazardous Atmospheres

You are reminded of the need to observe restrictions on the use of radio devices in fuel depots, chemical

plants etc. and areas where the air contains chemicals or particles (such as grain, dust, or metal powders).

Safety in Hospitals

Wireless devices transmit radio frequency energy and may affect medical electrical equipment. Wireless

devices should be switched off wherever you are requested to do so in hospitals, clinics or healthcare

facilitlies. These requests are designed to prevent possible interference with sensitive medical equipment.

Pacemakers

Pacemaker manufacturers recommended that a minimum of 15cm (6 inches) be maintained between a

handheld wireless device and a pacemaker to avoid potential interference with the pacemaker. These recom-

mendations are consistent with independent research and recommendations by Wireless Technology Research.

Persons with Pacemakers:

• Should ALWAYS keep the device more than 15cm (6 inches) from their pacemaker when turned ON.

• Should not carry the device in a breast pocket.

• Should use the ear furthest from the pacemaker to minimise the potential for interference.

• If you have any reason to suspect that interference is taking place, turn OFF your device.

Other Medical Devices

Please consult your physician or the manufacturer of the medical device, to determine if the operation of your

wireless product may interfere with the medical device.

RF Exposure Guidelines

Safety Information

Reducing RF Exposure – Use Properly

Only operate the device in accordance with the instructions supplied.

Handheld Devices

To comply with FCC RF exposure requirements, this device must be operated in the hand with a minimum

separation distance of 23cm or more from a person’s body. Other operating configurations should be avoided.

Power Supply

Use only a Motorola approved power supply output rated at 12 VDC / 3.3 A (center positive connector).

The power supply shall be Listed to UL/CSA 60950-1; and certified to IEC60950-1 and EN60950-1

with SELV outputs.

Use of alternative power supply will invalidate any approval given to this device and may be dangerous.

Radio Transmitters

This device complies with RSS 210 of Industry & Science Canada. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference and (2) this device

must accept any interference received, including interference that may cause undesired operation.

Label Marking: The Term "IC:" before the radio certification only signifies that Industry Canada

technical specifications were met.

XXXXXXXX

LASER LIGHT- DO NOT STARE INTO BEAM .

CLASS 2 LASER PRODUCT.

LASERLICHT - NICHT IN DEN

STRAHL BLICKEN. LASER KLASSE 2.

LUMIÈRE LASER - NE PAS REGARDER DANS LE FAISCEAU.

APPAREIL À LASER DE CLASSE 2 630-680nm, 1mW

SEE PRODUCT GUIDE FOR

PATENT/RADIO INFO

P/N: DS9808RXXXXXXXXXX

MODEL: DS9808RWW

IC:109AN-DS9808RWW

S/N: XXXXXXXXXXXXX

SN BAR CODE

MOTOROLA INC. HOLTSVILLE, N.Y. 11742

MFD:XXXXXXX MADE IN XXXXXX XXXX

5.0Vdc 1.5A

Hands-Free Scanning Hand-Held Scanning Hands-Free RFID

Trigger A Hand-Held RFID

Trigger B

Other manuals for Symbol DS9808-R

Other Motorola Video Game Controllers manuals

Motorola

Motorola Gamepad Moto Mod User manual

Motorola Symbol DS9808-R User manual

Popular Video Game Controllers manuals by other brands
