Motospeed SYNOPSIS CK62 User manual

中文
尺寸:290X100X40MM
重量:468g
寿命:50,000,000times(次)
电流:200mA
电压：3.7V
数量:61键，采用双色键帽技术
English
Size: 290X100X40MM
Weight: 468g
Lifetime: 50,000,000times
Current: 200mA
Voltage: 3.7V
Quantity: 61 keys, two-color keycap
USER MANUAl
WWW.MOTOSPEED.CC
WWW.MOTOSPEED.CN
BORN FOR THE GAME
Ck62
SYNOPSIS
GAMING KEYBOARD
GAMING KEYBOARD
Español
Tamaño: 290X100X40MM
Peso: 468g
Vida útil: 50,000,000 veces (veces)
Corriente: 200mA
Voltaje: 3.7V
Cantidad: 61teclas, tecla de dos colores
Türk dili
Boyut: 290X100X40MM
Ağırlık: 468g
Ömür boyu: 50,000,000 kez (kez)
Akım: 200mA
Gerilim: 3.7V
Miktar: 61 tuş, iki renkli tuş takımı
Português
Tamanho: 290X100X40MM
Peso: 468g
Tempo de vida: 50.000.000 vezes (vezes)
Corrente: 200mA
Tensão: 3.7 v
Quantidade: 61 teclas, keycap de duas cores
Українська
Розмір: 290X100X40MM
Вага: 468г
Термін служби: 50 000 000 разів (разів)
Струм: 200мА
Напруга: 3.7V
Кількість: 61 ключі, двокольоровий keycap
Ελληνικά
Μέγεθος: 290X100X40MM
Βάρος: 468g
Διάρκεια ζωής: 50.000.000 φορές (φορές)
Τρέχουσα: 200mA
Τάση: 3.7V
Ποσότητα: 61 πλήκτρα, δύο κεφαλές
Deutsch
Größe: 290X100X40MM
Gewicht: 468 g
Lebensdauer: 50.000.000 mal (mal)
Strom: 200mA
Spannung: 3,7 V
Anzahl: 61 Tasten, zweifarbige Tastenkappe
Polski
Rozmiar: 290X100X40MM mm
Ciężar: 468g
Żywotność: 50 000 000 razy (razy)
Natężenie prądu: 200 mA
Napięcie: 3,7V
Ilość: 61 klucze, dwukolorowe nasadki
Wired mode feature overview:
1. USB Full Speed 2.0, support up to 1000Hz true reporting rate
2. USB cable mode supports full key without punch
3. Support for Windows systems, Android systems, Mac systems, and other general purpose system devices
4. Support the potentiometer knob to adjust the volume and brightness: the factory default is the volume adjustment, when the
knob switch is pressed, the brightness is adjusted (individual mode)
5. Wired mode switching: Press the FN+Tab button (3-5 seconds) at the same time,Caps the indicator light below the button
flashes yellow 3 times.Light green again, switch wired mode successfully.
Note: When using wired mode, please turn off the Bluetooth power switch on the back to protect the battery.
Bluetooth mode feature overview:
1.Bluetooth is Broadcom BCM20730 Bluetooth 3.0; Bluetooth mode supports full-key no-rush.
2.Support for Windows systems, Android systems, Mac systems, and other general purpose system devices.
3.Bluetooth mode switching: Press the FN+Tab button (3-5 seconds) at the same time,Caps the indicator light below the button
flashes purple 3 times,Bright blue again, switch Bluetooth mode successfully.
4.How Bluetooth matches:
Step 1: open the Bluetooth power switch on the back
Step 2: short press FN+E/R/T and any one of these three buttons.
Step 3: long press FN+Q (3-5 seconds) for Bluetooth pairing ,Caps The indicator below the button flashes blue.
 If the code is successful, the blue light is off. If the code is unsuccessful for 3 minutes, it will automatically exit and the
keyboard will sleep.Need to re-pair, press FN+Q again (3-5 seconds)
5.Support one pair of three Bluetooth devices:
When the FN+E R T button is pressed shortly to switch the device, the corresponding purple light flashes 3 times to indicate that
the switch is successful.After the Bluetooth keyboard is connected to the device, it will not operate for 10 seconds, automatically
turn off the backlight, and enter the sleep mode after 10 minutes.Click any button to wake up the original state.
System Requirements:
Windows XP /Vista/win7/Win8/
Win10/Mac/Android
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12
PS PB
PU PDINS
DEL
HOME
END
12 3 4 G1 G2 G3 G4 G5 G6
1 2

Light effect mode switching sequence:
Start-up status after power on, enter from both sides of keyboard orderly and colorful, rotate to the middle, by the center
of the keyboard to spread around the end quickly at last.
●Factory default for "normally on model"
The keyboard whole backlight normally on, brightness is subject to previously regulated memory parameters.
Press FN+Right ctrl combination key, switching random colorful and 8 single colors, total 9 kinds of colors available.
Support FN+O/P 5 level speed adjustment,Support FN+ U/I 5 level brightness adjustment.
●Press FN+ into “ Press and on”
The backlight turned off, by default, one backlight color is lit up when press one button every time, and extinguished
after releasing the button.
Press FN+Right ctrl combination key, switching random colorful and 8 single colors, total 9 kinds of colors available.
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “ Press and off”
The keyboard whole backlight normally on, brightness/color/speed is subject to previously regulated memory parameters.
Via FN+Right ctrl combination key, switching random colorful and 8 single colors, total 9 kinds of colors available.
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “Stars-twinkle”
Keyboard backlight like starry of night, multicolored and blink.
Via FN+Right ctrl combination key, switching random colorful and 8 single colors, total 9 kinds of colors available.
Support FN+O/P 5 level speed adjustment,FN+U/I 5 level brightness adjustment.
●Press FN+ again into “Raindrop”
Keyboard backlight like raindrops stick slip window, particolored, sometimes fast, sometimes slow.
Via FN+Right ctrl combination key, switching random colorful and 8 single colors, total 9 kinds of colors available.
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “colorful Neon”
The keyboard whole backlight like colorful alternation by color, brightness and changing speed is subject to previously
USER MANUAl
WWW.MOTOSPEED.CC
WWW.MOTOSPEED.CN
BORN FOR THE GAME
Ck62
SYNOPSIS
GAMING KEYBOARD
GAMING KEYBOARD
regulated memory parameters.
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “Breathing mode”
The keyboard whole backlight simulate breathing rhythm, shows curve changesfrom destroy to the highest brightness.
brightness, color and breath rhythm speed subject to previously regulated memory parameters.
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “Neon mode”
The keyboard whole backlight is single color and alternate by color, brightness and changing speed is subject to
previously regulated memory parameters.
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “Colorful Spring Inrush”
Keyboard backlight in center for mouth of spring, flow from inside to outside or outside to inside, like spring to inrush by
colorful.
Via FN + right ctrl combination key, switching random colorful and 8 single colors,total 9 kinds of colors available.
Via FN + right alt combination key, can adjust medial-lateral directionof optical wave flowing .
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “Rainbow mode”
Keyboard each row backlight one kind of color, like a ribbon 7 colors hopping automatically .
Via FN + right ctrl combination key, switching random colorful and 8 single colors,total 9 kinds of colors available.
Via FN + right alt combination key, can adjust up-down direction of optical wave flowing .
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “Never-ending”
Keyboard backlight flows from right to left or from left to right.
Via FN + right ctrl combination key, switching random colorful and 8 single colors,total 9 kinds of colors available.
Via FN + right alt combination key, can adjust left-right direction of optical wave flowing.
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “ Rotate Mode”
Keyboard backlight like wheel spinning.
Via FN + right alt combination key, switching random colorful and 8 single colors,total 9 kinds of colors available.
Via FN + right alt combination key, can adjust left-right direction of optical wave flowing.
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
34

●Press FN+ again into “Flash-away mode 1”
Light-off, by default, the row lights up one color backlight when press a key every time, shoot in trailing manner from
both sides.
Via FN+Right ctrl combination key, switching random colorful and 8 single colors, total 9 kinds of colors available.
Support FN+O/P 5 level speed adjustment,FN+U/I 5 level brightness adjustment.
Press FN+ again into “Flash-away mode 2”
Backlight turn off, by default, after touch off buttons, the backlight such as stone in the calm surface, up waves, trailing
extinguished slowly, restore calm eventually.
Via FN+Right ctrl combination key, switching random colorful and 8 single colors, total 9 kinds of colors available.
Support FN+O/P 5 level speed adjustment,FN+U/I 5 level brightness adjustment.
●Press FN+ again into“Ripples-shining”
Centered on the pressed button, volatility spread a layer colorful wave, sparkling and fade away.
Via FN+Right ctrl combination key, switching random colorful and 8 single colors, total 9 kinds of colors available.
Support FN+O/P 5 level speed adjustment,FN+U/I 5 level brightness adjustment.
●Press FN+ again into “marquee mode 1”
The backlight LED lights one by one from left to right, trailing and moved out.
Via FN + right ctrl combination key, switching random colorful and 8 single colors,total 9 kinds of colors available.
Via FN + right alt combination key, can adjust up-down direction of marquee.
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “Sine-wave”
Keyboard background is LED inactive state, a colorful light wave in the form of sine curve fluctuates up and down, trailing
out gradually. The faster of speed, the longer of tail.
Via FN+Right ctrl combination key, switching random colorful and 8 single colors, total 9 kinds of colors available.
Support FN+O/P 5 level speed adjustment,FN+U/I 5 level brightness adjustment.
●Press FN+ again into “Wave mode”
Keyboard backlight flows from lower-left corner to upper right corner or from the upper rightcorner to the lower-left
corner.
Via FN + right ctrl combination key, switching random colorful and 8 single colors,total 9 kinds of colors available.
Via FN + right alt combination key, can adjust flow direction of light wave.optical wave flowing .
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “Wave mode”
Keyboard backlight flows from lower-left corner to upper right corner or from the upper rightcorner to the lower-left
corner.
Via FN + right ctrl combination key, switching random colorful and 8 single colors,total 9 kinds of colors available.
Via FN + right alt combination key, can adjust flow direction of light wave.optical wave flowing .
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “marquee mode 2”
The backlight LED lights by row from left to right or right to left, trailing and moved out, across in turn, alternate by left
right.
Via FN + right ctrl combination key, switching random colorful and 8 single colors,total 9 kinds of colors available.
Via FN + right alt combination key, can adjust flow direction of light wave.
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “Sine-wave”
Keyboard background is LED inactive state, a colorful light wave in the form of sine curve fluctuates up and down, trailing
out gradually. The faster of speed, the longer of tail.
Via FN+Right ctrl combination key, switching random colorful and 8 single colors, total 9 kinds of colors available.
Support FN+ O/P 5 level speed adjustment,FN+U/I 5 level brightness adjustment.
●Press FN+ again into “Wave mode”
Keyboard backlight flows from lower-left corner to upper right corner or from the upper right corner to the lower-left
corner.
Via FN + right ctrl combination key, switching random colorful and 8 single colors,total 9 kinds of colors available.
Via FN + right alt combination key, can adjust flow direction of light wave.optical wave flowing .
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “marquee mode 2”
The backlight LED lights by row from left to right or right to left, trailing and moved out, acrossin turn, alternate by left
right.
Via FN + right ctrl combination key, switching random colorful and 8 single colors,total 9 kinds of colors available.
Via FN + right alt combination key, can adjust flow direction of light wave.
Support FN+O/P 5 level speed adjustment, FN+U/I 5 level brightness adjustment.
●Press FN+ again into “ No light mode”
The overall backlight of the keyboard is always bright, and the brightness is based on the previously adjusted memory
parameters.
Press + right to switch between colorful and 8 monochrome, a total of 9 colors can be adjusted.
Support + five levels of brightness adjustment.
USER MANUAl
WWW.MOTOSPEED.CC
WWW.MOTOSPEED.CN
BORN FOR THE GAME
Ck62
SYNOPSIS
GAMING KEYBOARD
GAMING KEYBOARD
Keyboard doesn’t work and troubleshooting:
1. Check whether the USB cable is connected to the computer properly.
2. Check whether the Bluetooth device is connected to the device.
3.Try to connect the keyboard to other USB port of the computer.
4.Try to restart the computer.
5. If it still doesn't work, try to connect the keyboard to other computers
34
