Moyerdiebel 301HT User manual

OPTIONS & ACCESSORIES
70°F/39°C rise booster
CST- Combination sink/table
Machine on right P/N 403561
CST- Combination sink/table
Machine on left P/N 403562
Flat bottom dishrack P/N 101273
Peg dishrack P/N 101285
6" Stand P/N 0712393
17RS – 17" Stand P/N 0708757
Three phase machine available
STANDARD FEATURES
• ENERGYSTAR®Qualified
• NEW Counterbalanced doors. Minimizes wear and
tear on door supports.
• NEW Top-mounted detergent and rinse-aid prime switches.
• Rinse-sentryfeature.Ensures proper 180°F/82°C final
rinse temperature.
• Standard liquid detergent & rinse-aid
dispensing pumps.
• Stainlesssteeltopandsidepanels.
• Washtankheatermaintainswaterat
required temperature.
• Standardpumpeddrain,flexiblefillanddrainlinesand
standard line strainer for total ease of installation.
• Low.74USgal.(0.62impgal/2.9L)waterusageperrack.
• 150secondcycletime.20racksperhourcapacity.
• 13"[330mm]dooropeningaccommodates
cafeteriatrays.
• Energyefficient–only20or30Amp.breakerrequired
for 40°F/22°C rise.
• Completewithtwo20"x20"[508mmx508mm]
racks(onepegandoneflatbottom).
• Pressureregulatingvalve(PRV).
301HT
UndercounterHighTemperature
Dishwashing Machine
withBuilt-inBoosterHeater
301HT UNDERCOUNTER
MD033PrintedinU.S.A.
Moyer Diebel – USA
P.O.Box4183,Winston-Salem,NC27115Tel:336/661-1992Fax:336/661-1979800/228-8350www.moyerdiebel.com
Moyer Diebel Ltd. – Canada
2674NorthServiceRd.,JordanStation,Ontario,CanadaL0R1S0Tel:800/263-5798Fax:905/562-4618
[email protected]
SPECIFIER STATEMENT
SpecifiedunitwillbeMoyerDiebel301HTundercounterhigh
temperature dishwashing machine with built-in booster.
Featuresincludemaximum13"dooropeningclearance,
standardliquiddetergent&rinse-aiddispensingpumps,topand
sidepanels.Unitwillhavestandardpumpeddrainandrinse-
sentryfeaturetoensureproper180°Ffinalrinsetemperature.
Optionally,ifrequired,unitwillbesupplied
in 208-240/60/3 voltage.
1yr.partsandlaborwarranty.
Project
Item No.
Quantity
NEW!

Warning: Plumbing and electrical connections should
bemadebyqualifiedpersonnelwhowillobserveallthe
applicableplumbing,sanitaryandsafetycodes.
Dimensionsshownininchesand[millimeters]
(1M)3/08
SPECIFICATIONS
Capacity
NSF Racks per hr. 20
MotorHorsepower
 Wash 1
WaterConsumption
 Gal.perhr.(max.use)
 USgal.(imp.gal/liters) 14.8(12.3/56)
Gal. per rack
  USgal.(imp.gal/liters) .74(.62/2.9)
Temperatures°F/C
 Wash(minimum) 150/66
 Rinse(minimum) 180/82
Heating
 Tankheat,electric(kW) 2
Electric booster
  (kWrequiredfor40°F/22°Crise) 4
  (kWrequiredfor70°F/39°Crise) 6
TimeCycleinSeconds
 Wash 120
Rinse 15
Dwell 15
Total 150
301HT
UndercounterHighTemperature
Dishwashing Machine
withBuilt-inBoosterHeater
DuetoanongoingvalueanalysisprogramatMoyerDiebel,specificationsinthiscatalogaresubjecttochangewithoutnotice.
*Optionalvoltage–pleasespecifywhenordering
Utilities
1Electrical
208-240/60/1or(optional3phase);hardwiringrequired(seeboxesbelow)
2HotWater
140°F/60°CMin.,connectionfor40°F/22°Crisebooster.
110°F/43°CMin.,connectionfor70°F/39°Crisebooster.
6ft.long1/2"I.D.flexiblefillhosewith3/4"NPT.
Flowpressure:18-22psi(124-152kPa),PRVsupplied
3DrainConnection
6ft.long,3/4"I.D.flexiblehose.
Max.drainflow:8USgpm;30lpm;7imp.gpm
   Minimum Maximum
 Elec. Rated Supply Overcurrent
 Specs. Amps Circuit Protective
   Ampacity Device
208/60/1 28 40 40
230/60/1 31 40 40
*208/60/3 19 25 25
*230/60/3 20 25 25
301HTwith70°FRise Electric Booster
   Minimum Maximum
 Elec. Rated Supply Overcurrent
 Specs. Amps Circuit Protective
 Ampacity Device
208/60/1 21 30 30
230/60/1 22 30 30
*208/60/3 14 20 20
*230/60/3 15 20 20
301HTwith40°FRiseElectric Booster
Plan ViewFront View Side View
13" [330]
Clearance
14" [356]
38-5/8"
[981] 17-5/8"
[448]
1
32
1
6" [152]
23-7/8" [606]
23
23-5/8"
[600]
3-3/4" [95]
30" [762]
33-5/8" [851]
2" [51]
14-5/8" [371]
9-1/2" [241]
32
1
1
Uncrated Crated
Height 33-1/2"[851] 39-1/2"[1003]
Width 23-5/8"[600] 25"[635]
Depth 23-7/8"[606] 25-1/2"[647]
ShipWt. lbs/kg 148/67 165/75
* Front leveling feet provided.
