Mr. Coffee BVMC-DR5-073 User manual

Instruction Manual | 用户手册
4 CUP COFFEE MAKER
4杯咖啡机
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
使用产品前先阅读此用户手册并妥善保管
MODELS/型 号 BVMC-DR5-073
MODELS/型 号 BVMC-DR5-073
BVMC-DR5-073_14ECM1.indd 1 21/11/14 8:44 AM

1
IMPORTANT SAFEGUARDS
To reduce the risk of fire, electric shock and/or injury to
persons, basic safety precautions should always be followed
when using electrical appliances, including the following:
1. READ ALL INSTRUCTIONS BEFORE USING THE
COFFEE MAKER.
2. Check if the voltage indicated on the appliance corresponding
to the local mains voltage before you connect the appliance.
For Mainland China, standard electrical outlet is 220V~50Hz.
3. DO NOT touch the coffee maker’s hot surfaces. Use
handles or knobs.
4. To protect against electric shock, DO NOT immerse the
power cord, power plug or coffee maker in water or in any
other liquid.
5. Turn the coffee maker off and unplug the power cord from
the power source when the coffee maker are not in use
and before cleaning. Allow the coffee maker parts to cool
before putting on or taking off parts and before cleaning the
appliance.
6. DO NOT operate any appliance with a damaged power
cord or power plug, or operate it after the appliance
malfunctions, or has been damaged in any manner. Take
this appliance only to the nearest Authorized Service Center
for examination, repair or adjustment.
7. The use of accessory attachments other than those recommended
by the manufacturer may cause hazards or injuries.
8. DO NOT use the coffee maker outdoors.
9. DO NOT let the power cord hang over edge of table or
counter, or allow it to come into contact with hot surfaces.
10.DO NOT place this coffee maker on or near a hot gas stove
or electric burner or in a heated oven.
11.To disconnect the coffee maker, turn it off, then remove the
power plug from the power supply.
12.Place the appliance on a hard, flat level surface to avoid
interruption of airflow underneath the coffee maker.
13.This coffee maker is designed for household use only.
14.DO NOT use appliance for other than intended use.
BVMC-DR5-073_14ECM1.indd 1 21/11/14 8:44 AM

2
15. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their
safety. Children should be supervised to ensure that they
DO NOT play with the appliance.
16. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be
made by children without supervision.
17. Close supervision is necessary when any appliance is used
by or near children, or incapacitated individuals.
18. This appliance is not intended to be operated by means of
an external timer or separate remote-control system
19. This appliance is intended to be used in household and
similar applications such as: staff kitchen areas in shops,
offices and other working environments, farm houses,
by clients in hotels, motels and other residential type
environments, bed and breakfast type environments.
DECANTER USE AND CARE
Follow the instructions below to reduce or eliminate the chance of
breaking the glass decanter:
• Thisdecanterwasdesignedforuseonlywithyour
Mr. Coffee
®
coffee maker and therefore must never be used on a
range top or in any oven, including a microwave oven.
• DO NOT set a hot decanter on a wet or cold surface.
• DO NOT use a cracked decanter or a decanter having a loose or
weakened handle.
• DO NOT clean the decanter with abrasive cleaners, steel wool
pads or other abrasive materials.
• Discardthedecanterimmediatelyifitiseverboileddry.
• Protectthedecanterfromsharpblows,scratchesorrough
handling.
NOTE: Scalding may occur if the lid is removed during brewing cycles.
WARNING! To reduce the risk of fire or electric shock,
do not remove any service covers. There are no user
BVMC-DR5-073_14ECM1.indd 2 21/11/14 8:44 AM

3
DESCRIPTION OF THE APPLIANCE
serviceable parts inside the coffee maker. Only authorized
personnel should repair the coffee maker. Please read ALL
of the instructions in this manual carefully before you begin
to use this appliance.
Proper care and maintenance will ensure a long life and a
trouble-free operation for this appliance. Please save these
instructions and refer to them for cleaning and care tips.
1. Dual Water Windows
2. Water Reservoir
3. Coffee Maker Lid
4. Pause ’n Serve
5. Cord Storage
6. Warming Plate
7. On/Off Switch/Indicator Light
8. Glass Decanter
9. Removable Filter Basket
10. Shower Head
11. Removable Permanent Filter
1
2
3
4
5
6
7
8
9
10
11
BVMC-DR5-073_14ECM1.indd 3 21/11/14 8:44 AM

4
COFFEE MAKER FEATURES AND BENEFITS
Your new Mr. Coffee®coffee maker has the following features:
• Brewing Capacity – 4 Cups – glass decanter.
• Removable Filter Basket – The filter basket pulls out for fast and easy
cleaning and filling.
• Pause ‘n Serve – Can’t wait for the coffee to finish brewing? The Pause ‘n
Serve feature allows you up to 30 seconds to pour a cup of coffee while the
coffee maker is still brewing. Carefully remove the decanter and the Pause ’n
Serve feature will be automatically activated, temporarily stopping the flow of
coffee into the decanter.
• Dual Water Windows – Show amount of water in the reservoir for accurate filling.
• Non-Stick Warming Plate – Allows you to keep your coffee hot after brewing.
The non-stick attribute prevents the decanter from sticking to the surface of
the warming plate.
• Cord Storage – Safely stores excess cord to keep your countertop neat.
• On/Off Indicator Light – Lets you know when your coffee maker is “on”.
MakesureyourrstcupofcoffeeisasgoodascanbebycleaningyourMr.Coffee®
coffeemakerbeforeitsrstuse.Justfollowthesesimplesteps:
1. Washthedecanter,decanterlidandthelterbasketinamixtureofmilddetergent
and water. Rinse each thoroughly (please refer to the Description of the Appliance).
2. Replace all the parts and close the lid. Then, run a brew cycle with water only,
withoutaddingcoffeeandcoffeelter.
3. When brewing is complete, turn your coffee maker off, discard the water in the
decanterandrinsethedecanter,decanterandlterbasket.
Your coffee maker is now ready to use. Enjoy it!
BEFORE USING YOUR COFFEE MAKER FOR THE FIRST TIME
BVMC-DR5-073_14ECM1.indd 4 21/11/14 8:44 AM

5
PREPARING FOR USE
Selecting and Measuring Ground Coffee
For best results, use a level tablespoon for ground coffee measurement.Make
sure you use medium grind coffee for a perfect brew.
A. Suggested Coffee Measurement Chart
To Brew Ground Coffee
4 Cups 3 tbsp.
2 Cups 1.5 tbsp.
1 level tablespoon (tbsp) = 5 gr./0.17 oz.
1 cup = 5 fl. oz. (148 mL) of brewed coffee
Use more or less coffee to suit your taste.
B. Adding Water and Ground Coffee
1. Lift and open the coffee maker lid. For your
convenience, you can lift out the removable filter
basket.
2. Place a 4 cup paper basket-style filter (not included)
or the included permanent filter into the brew basket.
(see Figure 1).
NOTE: If using paper filters, it is important that the
sides of the filter fit flush against the side of the filter
basket. If filter collapse occurs, dampen the filter
before placing in the filter basket and adding ground
coffee and water.
3. Add the desired amount of coffee and gently shake to level the coffee. See
the Suggested Coffee Measurement Chart.
4. Be sure the filter basket is properly centered and all the way down in the
filter basket.
5. Fill the decanter with cold, fresh water to the desired capacity (1 cup equals
148 mL). For easy and accurate filling, the water markings on the decanter
and on the dual water windows show the amount of water needed to make
the corresponding desired number of cups. Do not fill past the “MAX line” or
water will flow out of the overfill hole in the back of the water reservoir.
NOTE: The amount of coffee brewed will always be slightly less than the amount
of water poured in the water reservoir. This is due to the minimum absorption of
water by the coffee grounds.
6. Pour the water into the water reservoir. Close the lid and place the empty
decanter onto the warming plate.
Figure 1
BVMC-DR5-073_14ECM1.indd 5 21/11/14 8:44 AM

6
CAUTION: To reduce the risk of damaging the decanter and/or the risk of
personal injury, do not add cold water to the decanter if the decanter is already
hot. Allow the decanter to cool before using. Do not place the decanter in the
dishwasher.
1. Press the ON/OFF Switch on the control panel so the green indicator light
illuminates. The light indicates that the coffee maker is on and that the brew
cycle will begin. To turn off the coffee maker, push the switch so the light is
no longer illuminated.
2. While the coffee is brewing, the Pause ’n Serve feature allows you to sneak
a cup of coffee from the decanter. REPLACE THE DECANTER ON THE
WARMING PLATE WITHIN 30 SECONDS TO PREVENT OVERFLOW AND
POSSIBLEINJURY.
CAUTION: If the brew basket overflows or fails to empty into the decanter,
do not open the brew basket. Turn off the coffee maker. Unplug the coffee
maker and wait for the contents to cool before handling.
3. After the used coffee grounds have cooled, carefully discard them.
4. Make sure the decanter is empty before starting to brew coffee.
5. Be sure to turn your coffee maker off when no longer using it.
BREWING COFFEE NOW
NOTE: Make sure the decanter is fully placed on the warming plate or the water
and the grounds will overflow from the filter basket. An overflow may cause
personal injury or damage to property.
Daily Cleaning
Always unplug the coffee maker and allow it to cool before cleaning.
Remove the filter basket, permanent filter, decanter and decanter lid and wash
them in a solution of hot water and mild liquid soap.
Never use abrasive cleansers, steel wool pads or other abrasive materials.
Dishwasher top rack safe parts: glass decanter and lid, filter basket and
permanent filter.
CAUTION! Never immerse the coffee maker itself in water, in any other liquid or
place in the dishwasher.
Regular Cleaning and Maintenance
Decalcifying your Mr. Coffee®coffee maker minerals (calcium/limestone) found
in water will leave deposits in your coffee maker and affect its performance. It’s
recommended that you regularly remove these deposits using vinegar.
CLEANING AND MAINTAINING
BVMC-DR5-073_14ECM1.indd 6 21/11/14 8:44 AM

7
1. Prepare a solution using at least 4 cups of undiluted white household
vinegar may be used to clean.
2. Pour the vinegar into the water reservoir.
3. Place an empty 4 cup basket-style paper filter or the permanent filter that
came with the unit into the filter basket and close the coffee maker lid.
4. Place the empty decanter back in the unit, centered on the warming plate.
5. Brew three cups of cleaning solution through the coffee maker.
6. Turn the coffee maker off and let stand for 30 minutes.
7. Run the remainder of the cleaning solution through the coffee maker.
8. Discard the cleaning solution and rinse the decanter thoroughly with clean
water.
9. Fill the water reservoir with clean, fresh water.
10. Place the empty decanter back on the coffee maker, centered on the
warming plate.
11. Remove and discard the paper filter used during the cleaning cycle. If the
permanent was used during cleaning, remove it and rinse it thoroughly
before replacing it in the filter basket.
12. Begin brewing and allow the full brew cycle to complete.
13. Repeat steps 9 through 12 one more time.
Your coffee maker is now clean and ready to brew the next pot of delicious, hot
coffee!
Suggested Decalcifying Interval
Type of Water Cleaning Frequency
Soft Water Every 80 Brew Cycles
Hard Water Every 40 Brew Cycles
Coffee Filters – Basket-style paper filers can be found at most grocery stores
and other retailers. If you need to replace the permanent filter, please contact
the Consumer Service number as printed on the back of this manual.
Cleaning the Decanter
Hard water can leave a whitish stain inside the decanter, and coffee may then
turn this stain brown.
To remove decanter stains:
1. Fill the decanter with a solution of equal parts water and vinegar and let the
solution stand in it for approximately 20 minutes.
2. Discard the solution, then wash and rinse the decanter.
DO NOT use harsh abrasive cleaners that may scratch the decanter.
BVMC-DR5-073_14ECM1.indd 7 21/11/14 8:44 AM

8
Your coffee maker has been carefully designed to give you many years of trouble-
free service. In the unlikely event that your new coffee maker does not operate
satisfactorily, please review the following potential problems and try the steps
recommended BEFORE you call or take it to an Authorized Service Center.
PROBLEM POSSIBLE CAUSE SOLUTION
The power ON light does
not light up
•Theapplianceisunplugged.
•There’sapoweroutage.
•Plugunitin.
•Waitforpowertoberestored.
The coffee is not brewing •Theapplianceisunplugged.
•There’sapoweroutage.
•Thewaterreservoirisempty.
•Thelterbasketisnotproperly
inserted.
•Thedecanterisnotplacedall
the way on the warming plate.
•Plugunitin.
•Waitforpowertoberestored.
•Checkthewaterwindowsand
llwaterreservoir.
•Insertlterbasketcorrectly.
•Placedecantercorrectlyon
warming plate.
The coffee maker only
brews water
•Therearenocoffeegroundsin
thelterbasket.
•Addthedesiredamountof
coffeetothelter.
The coffee maker brews
slowly
•Thecoffeemakerneeds
cleaning.
•Cleancoffeemakeras
described in “cleaning and
maintaining” section.
The filter basket overflows •Thelterbasketisnotproperly
inserted.
•Thedecanterisnotplacedall
the way on the platform.
•Toomanycoffeegroundswere
placeinthelter.
•Thedecanterwasremoved
from the platform for more than
30 seconds.
•Insertlterbasketcorrectly.
•Placedecantercorrectlyon
platform.
•Removelteranddiscard
ground.Ifusingpaperlter,
replace it. If using permanent
lter,rinseit.Beginbrewing
process again.
•Turnoffandunplugtheunit.
Allow it to cool. Wipe up spill.
Do not set the hot decanter
back on the warming plate or it
might crack.
The coffee is not hot •Thereisapoweroutage. •Waitforpowertoberestored.
The coffee tastes bad •Coffeegroundsotherthanfor
an automatic drip coffee maker
was used.
•Thegroundcoffee-to-water
ratio was unbalanced.
•Thecoffeemakerneeds
cleaning.
•Usecoffeegrounds
recommended for automatic
drip coffee makers.
•Usecorrectgroundcoffee-to-
water ratio.
•Cleancoffeemakeras
described in “Maintaining your
coffee maker” section.
The grounds are in the coffee •Thelterisnotproperlyseated
in the basket.
•Theltercollapsed.
•Seatlterproperlywithinthe
lterbasket.
•Removelterandreplace.
TROUBLESHOOTING YOUR COFFEE MAKER
BVMC-DR5-073_14ECM1.indd 8 21/11/14 8:44 AM

9
重要安全措施
使用电气产品时，应该遵守基本的安全保护措施，降低火灾风
险，触电和/或人身伤害。基本的安全保护措施包含以下内容：
1. 使用咖啡机前，请阅读所有的操作说明。
2. 检查咖啡机上标示的电压，看其是否符合当地的市电
电压，然后再连接咖啡机。国内的标准电气插座规格为
220V~50Hz。
3. 切勿触摸咖啡机的灼热表面。使用手柄或按钮。
4. 为了防止触电，切勿将电源线，插头或咖啡机置于水中或其它液
体中。
5. 当不使用咖啡机时，以及清洁咖啡机之前，请关闭咖啡机的
电源开关，并从电源插座上拔掉电源线。让咖啡机的零件冷
却，然后于清洁咖啡机之前，安装或者取下零件。
6. 在电源线或电源插头损坏时或者在咖啡机出现故障或由于其
它原因而已经损坏之后，切勿操作咖啡机。将咖啡机寄送到
最近的授权的电器服务中心，进行检查、维修或调整。
7. 使用非厂商推荐的零配件可能会造成危害或人身伤害。
8. 切勿于室外使用咖啡机。
9. 切勿让电源线伸出桌子或工作台面的边缘之外或让其接触灼热
表面。
10. 切勿将咖啡机置于热气体或电炉的上方或旁边，或者将咖啡机置
入灼热的烤箱中。
11. 如果要切断电源，请将控制开关调到关闭位置，然后再从壁插座
上拔下电源插头。
12. 为了避免中断咖啡机底部的气流，请将其放置在硬质、平整的表
面上。
13. 此咖啡机仅适合家庭使用。
14. 切勿将本产品用于其预定之外的用途。
15. 本产品不适合那些体能差、敏感度或智力较弱者，或者缺乏使用
经验和不了解本产品的人士（包括小孩）使用，除非已有负责安
全的人员监管他们或者告知他们本产品的使用方法。需对小孩进
行监管，确保他们不会玩弄本产品。
BVMC-DR5-073_14ECM1.indd 9 21/11/14 8:44 AM
