Mr. Coffee BVMC-JWX3-073 User manual

Instruction Manual | 用户手册
5 CUP PROGRAMMABLE COFFEE MAKER
5杯可编程咖啡机
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
使用产品前先阅读此用户手册并妥善保管
MODEL/型 号
MODEL/型 号 BVMC-JWX3-073
BVMC-JWX3-073
BVMC-JWX3-073_14ECM1.indd 1 20/11/14 5:26 PM

1
IMPORTANT SAFEGUARDS
To reduce the risk of fire, electric shock and/or injury to persons,
basic safety precautions should always be followed when using
electrical appliances, including the following:
1. READ ALL INSTRUCTIONS BEFORE USING THE COFFEE MAKER.
2. Check if the voltage indicated on the appliance corresponding
to the local mains voltage before you connect the appliance. For
Mainland China, standard electrical outlet is 220V~50Hz.
3. DO NOT touch the coffee maker’s hot surfaces. Use handles or knobs.
4. To protect against electric shock, DO NOT immerse the power
cord, power plug or coffee maker in water or in any other liquid.
5. Turn the coffee maker off and unplug the power cord from the
power source when the coffee maker and clock are not in use
and before cleaning. Allow the coffee maker parts to cool before
putting on or taking off parts and before cleaning the appliance.
6. DO NOT operate any appliance with a damaged power cord or
power plug, or operate it after the appliance malfunctions, or has
been damaged in any manner. Take this appliance only to the nearest
Authorized Service Center for examination, repair or adjustment.
7. The use of accessory attachments other than those recommended by
the manufacturer may cause hazards or injuries.
8. DO NOT use the coffee maker outdoors.
9. DO NOT let the power cord hang over edge of table or counter,
or allow it to come into contact with hot surfaces.
10.DO NOT place this coffee maker on or near a hot gas stove or
electric burner or in a heated oven.
11.To disconnect the coffee maker, turn it off, then remove the
power plug from the power supply.
12.Place the appliance on a hard, flat level surface to avoid
interruption of airflow underneath the coffee maker.
13.This coffee maker is designed for household use only.
14.DO NOT use appliance for other than intended use.
15. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be
supervised to ensure that they DO NOT play with the appliance.
BVMC-JWX3-073_14ECM1.indd 1 20/11/14 5:26 PM

2
16. This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
17. Close supervision is necessary when any appliance is used by
or near children, or incapacitated individuals.
18. This appliance is not intended to be operated by means of an
external timer or separate remote-control system
19. This appliance is intended to be used in household and similar
applications such as: staff kitchen areas in shops, offices and
other working environments, farm houses, by clients in hotels,
motels and other residential type environments, bed and
breakfast type environments.
DECANTER USE AND CARE
Follow the instructions below to reduce or eliminate the chance of
breaking the glass decanter:
• This decanter is designed for use with your Mr. Coffee®coffee maker
and therefore must never be used on a range top or in any oven,
including a microwave oven.
• Do not set a hot decanter on a wet or cold surface.
• Do not use a cracked decanter or a decanter having a loose or
weakened handle.
• Do not clean the decanter with abrasive cleaners, steel wool pads or
other abrasive materials.
• Discard the decanter immediately if it is ever boiled dry.
• Protect the decanter from sharp blows, scratches or rough handling.
NOTE: Scalding may occur if the lid is removed during brewing cycles.
WARNING! To reduce the risk of fire or electric shock, do not
remove any service covers. There are no user serviceable parts
inside the coffee maker. Only authorized personnel should repair
the coffee maker. Please read ALL of the instructions in this
manual carefully before you begin to use this appliance.
Proper care and maintenance will ensure a long life and a
trouble-free operation for this appliance. Please save these
instructions and refer to them for cleaning and care tips.
BVMC-JWX3-073_14ECM1.indd 2 20/11/14 5:26 PM

3
DESCRIPTION OF THE APPLIANCE
1. Brew Basket Lid
2. Shower Head
3. Water Reservoir
4. Water Window
5. Pause ‘n Serve
6. Warming Plate
7. Decanter
8. Removable Filter Basket
9. Removable Permanent
Filter
8
76
2
3
4
5
1
9
BVMC-JWX3-073_14ECM1.indd 3 20/11/14 5:26 PM

4
COFFEE MAKER FEATURES AND BENEFITS
Your new Mr. Coffee®coffee maker has been designed to make coffee. It has the
following features:
• Brewing Capacity – 5 Cups glass decanter.
• Removable Filter Basket – The filter basket lifts out for fast and easy
cleaning and filling.
• Pause ‘n Serve – Can’t wait for the coffee to finish brewing? The Pause ‘n
Serve feature allows you up to 30 seconds to pour a cup of coffee while the
coffee maker is still brewing. Carefully remove the decanter and the Pause ’n
Serve feature will be automatically activated, temporarily stopping the flow of
coffee into the decanter.
• Water Window – Show amount of water in the reservoir for accurate filling.
• Non-Stick Warming Plate – This feature allows you to keep your coffee hot
after brewing. The non-stick attribute prevents the decanter from sticking to
the surface of the warming plate.
• Cord Storage – Safely stores excess cord to keep your countertop neat.
•On/Off Indicator Light - Lets you know when your coffee maker is “on”.
• One-Hour Auto Shut-Off – Keeps your coffee hot for one hour, then
automatically shuts off.
a. Clock Display
b. On/Off Indicator Light
c. Off Button
d. Minute Button
e. Hour Button
f. Set Delay Button
g. Delay Brew Button
h. Brew Now Button
g
a
c
b
d
e
f
h
BVMC-JWX3-073_14ECM1.indd 4 20/11/14 5:26 PM

5
• Programmable Controls:
– Clock – The clock serves as a handy kitchen clock and allows you to set
the Delay Brew feature.
– Delay Brew – Would you like to wake up to a fresh pot of coffee? The timer
allows you to preset when you would like the coffee maker to automatically
begin brewing your coffee, up to 24 hours in advance.
NOTE: If you have selected any of the operating functions, the coffee maker will
act upon the last operation selected if the power is restored within 10 seconds
after a power outage.
BEFORE USING YOUR COFFEE MAKER FOR THE FIRST TIME
Make sure your first cup of coffee is as good as can be by cleaning your
Mr. Coffee®coffee maker before its first use. Just follow these simple steps:
1. Wash the decanter, decanter lid and the filter basket in a mixture of mild
detergent and water. Rinse each thoroughly (please refer to the Description
of the Appliance).
2. Replace all the parts and close the lid. Then, run a brew cycle with water
only, without adding coffee and coffee filter.
3. When brewing is complete, turn your coffee maker off, discard the water in
the decanter and rinse the decanter, decanter lid, and filter basket.
Your coffee maker is now ready to brew coffee. Enjoy it !
BVMC-JWX3-073_14ECM1.indd 5 20/11/14 5:26 PM

6
To Set the Clock:
1. Plug the power cord into a standard electrical outlet.The clock
will flash on the control panel to indicate that the time has not
been set yet.
2. Press and hold the hour “ ” or minute “ ” buttons until
you reach the current time. The AM or PM indicator will light
along the left side of the display (Figure 1).
The clock is now set!
NOTE: Pressing any button before setting the clock will cause the
clock to start keeping time from 12:00 a.m. You must set the clock
if you want to use the Delay Brew feature.
To Set the Delay Brew Time:
While the display is in the clock mode, simply press and hold the
set delay “ ” button (Figure 2) and, set the brew time by
pressing the hour “ ” or minute “ ” buttons. The AM or
PM indicator will light at the clock display (Figure 3).
Within 35 seconds the display will change to the current time.
The Delay Brew Time is now set!
NOTE: To activate the delay brew cycle, see the Brewing Coffee
Later section.
To check the programmed time, press & hold the set delay
“ ” button. The display will show the time you have programmed the coffee
to brew. If you press the set delay “ ” button again or wait a few seconds, the
display will switch back.
SETTING THE CLOCK AND DELAY BREW TIME
Figure 1
Figure 2
Figure 3
BVMC-JWX3-073_14ECM1.indd 6 20/11/14 5:26 PM

7
PREPARING FOR USE
A. Selecting and Measuring Ground Coffee
For best results, use a level tablespoon for ground coffee measurement.
Make sure you use medium grind coffee for a perfect brew.
Suggested Coffee Measurement Chart
To Brew Ground Coffee
5 Cups 6 tbsp.
2 Cups 3 tbsp.
1 level tablespoon (tbsp) = 5 gr./0.17 oz.
1 cup = 5 fl. oz. (148 mL) of brewed coffee
Use more or less coffee to suit your taste.
B. Adding Water and Ground Coffee
1. Open the brew basket lid. For your convenience, you can lift out the
removable filter basket.
2. Place a 4 cup paper basket-style filter (not included) or the included
permanent filter into the brew basket.
NOTE: If using paper filters, it is important that the sides of the filter fit flush
against the side of the filter basket. If filter collapse occurs, dampen the
filter before placing in the filter basket and adding ground coffee and water.
3. Add the desired amount of coffee and gently shake to level the coffee. See
the Suggested Coffee Measurement Chart.
4. Be sure the removable filter basket is properly centered and all the way
down in the brew basket and close the lid.
5. Fill the decanter with cold, fresh water to the desired capacity (1 cup equals
148ml) For easy and accurate filling, the water markings on the glass
decanter and on the dual water windows show the amount of water needed
to make the corresponding desired number of cups. Do not fill past the
“MAX line” or water will flow out of the overfill hole in the back of the coffee
maker. The amount of coffee brewed will always be slightly less than the
amount of water poured in the water reservoir. This is due to the minimum
absorption of water by the coffee grounds.
6. Lift the reservoir lid and pour the water into the water reservoir. Close the lid
and place the empty decanter onto the warmer plate.
NOTE: Make sure the decanter is fully placed on the warming plate or the water
and the grounds will overflow from the filter basket. An overflow may cause
personal injury or damage to property.
CAUTION! To reduce the risk of damaging the decanter and/or the risk of
personal injury, do not add cold water to the decanter if the decanter is already
hot. Allow the decanter to cool before using.
BVMC-JWX3-073_14ECM1.indd 7 20/11/14 5:26 PM

8
1. After completing the steps in the Adding Water and Coffee
section and with the glass decanter and the filter basket
securely in place, turn the coffee maker on by pressing
the Brew Now button “冲煮”once (Figure 4). Your
coffee maker will keep your coffee hot for one hour, then
automatically shut off.
2. To turn the coffee maker off, push the OFF “O/关”
button so the power indicator light is no longer illuminated
(Figure 5). While the coffee is brewing, the Pause ’n
Serve feature allows you to sneak a cup of coffee from
the decanter. REPLACE THE DECANTER ON THE
WARMING PLATE WITHIN 30 SECONDS TO PREVENT
OVERFLOW AND POSSIBLE INJURY.
CAUTION: If the brew basket overflows or fails to empty
into the decanter, do not open the brew basket. Turn off the coffee maker.
Unplug the coffee maker and wait for the contents to cool before handling.
3. After the used coffee grounds have cooled, carefully remove the filter
basket and discard them.
NOTE: The brew basket lid is hot after brewing. Always allow the coffee maker
to cool down before cleaning.
4. Make sure the decanter is empty before starting to brew coffee.
5. Be sure to turn your coffee maker off when no longer using it.
BREWING COFFEE NOW
Figure 5
Figure 4
BVMC-JWX3-073_14ECM1.indd 8 20/11/14 5:26 PM

9
1. You must first set the time for when you would like the
coffee maker to begin brewing your coffee as described in
Setting the Clock and the Delay Brew Timer section.
2. Prepare your coffee maker as described in Adding Water
and Ground Coffee section.
3. To activate the delay brew function and program your
coffee maker to brew coffee at a later time, press the
DELAY BREW “ 启动/取消” button (Figure 6). The
delay indicator will appear on the digital display. The coffee maker is now
set to automatically brew coffee at the pre-set time.
4. At the pre-set time, the delay indicator will go off, indicating the brewing has
started.
5. The coffee maker warmer plate will keep your coffee hot for 1 hour and
then automatically turn off.
As a safety feature, your coffee maker will NOT start again automatically the
next day. If you want your coffee to brew at the same time the following day,
simply add a new filter, coffee and water and set delay brew, by repeating Steps
2-4 above.
NOTE: If the decanter is not in place then the coffee maker will not brew.
To cancel delay brew:
Press the OFF “O/关” button , the Delay indicator will disappear.
BREWING COFFEE LATER
Daily Cleaning
Always unplug the coffee maker and allow it to cool before cleaning. Remove
the filter basket, permanent filter, decanter and decanter lid and wash them in a
solution of hot water and mild liquid soap.
Unplug unit before cleaning. After unit is cool, wipe exterior with a soft, damp
cloth, and then dry with a soft towel.
Never use abrasive cleansers, steel wool pads or other abrasive materials.
Dishwasher top rack safe parts: glass decanter and lid, filter basket and
permanent filter.
CAUTION! Never immerse the coffee maker itself in water, in any other liquid or
place in the dishwasher.
CLEANING AND MAINTAINING
Figure 6
BVMC-JWX3-073_14ECM1.indd 9 20/11/14 5:26 PM
