MSI MPG Series User manual

MPG Series
Fan
MPG F120 ARGB
User Guide

2
Package Contents
F120 ARGB fan
x2 (for 2 fans package)
x3 (for 3 fans package)
Screw Ø5 8mm
x8 (for 2 fans package)
x12 (for 3 fans package)
Screw #6-32 30mm
x8 (for 2 fans package)
x12 (for 3 fans package)
⚠
Important
If any of the above items are damaged or missing, please contact your retailer.

3
Safety Information
∙Always disconnect the fan from the power source before performing any
maintenance or installation.
∙Be cautious when handling the fan blades. They may have sharp edges that could
cause injury. Handle with care, and avoid touching the blades when the fan is
running.
∙Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing.
∙Do not boot the computer before installation is completed. This could cause
permanent damage to the components as well as injury to the user.
∙Before turning on the computer, ensure that there are no loose screws or metal
components on the motherboard or anywhere within the computer case.
∙Use the provided screws for installation. Do not use screws that are too long, as
they could damage the fan or other components.
∙Ensure that the fan is not obstructed by any objects that could impede airflow.
Proper ventilation is essential for optimal cooling.
∙Monitor your system’s temperatures to prevent overheating. If the fan fails or
becomes noisy, replace it promptly to avoid damage to your components.

4
Installation
The steps to install the fan are as follows:
⚠
Important
Please note that the illustrations below are for reference only. The placement may
vary, depending on the case and actual parts you have.
1. Turn off the main power of the computer and unplug the power cord.
2. Align the fan with the mounting holes on your case or radiator. Secure the fan
using the provided Ø5 8mm screws (for case installation) or #6-32 30mm screws
(for radiator installation). Be careful not to overtighten the screws to avoid
damaging the fan.
Radiator PC Case
Ø5 8mm
screws
#6-32 30mm
screws

5
3. Locate a 4-pin PWM fan header on your motherboard or a fan controller. Connect
the fan’s 4-pin PWM connector to the corresponding header.
4. Locate an ARGB (JRAINBOW) header on your motherboard or an ARGB controller.
Connect the fan’s ARGB connector to the corresponding header. You can daisy-
chain them by connecting the output of one fan to the input of another, ensuring
synchronized lighting effects.
1
1
1
1
JRAINBOW (JARGB)
SYS_FAN (PWM)
SYS_FAN (PWM)
SYS_FAN (PWM)

6
General Information
Copyright and Trademarks Notice
Copyright © Micro-Star Int’l Co., Ltd. All rights reserved.
The MSI logo used is a registered trademark of Micro-Star Int’l Co.,
Ltd. All other marks and names mentioned may be trademarks of
their respective owners. No warranty as to accuracy or completeness is expressed or
implied. MSI reserves the right to make changes to this document without prior notice.
All text, images, illustrations, and other content in this manual are the property of
MSI. No part of this manual may be reproduced, distributed, or used in any form
without the written permission of MSI.
Revision History
∙Version 1.0, 2023/09, First release.
