MSI S270 User manual

GeneralIntroductionsChapter 1
GettingStarted
Chapter 2
Customizing thisNotebook
Chapter 3
BIOSsetup
Chapter 4
Prefeace
G52-N1013X1

II
NotebookPreface
RegulationsInformation
FCC-BRadioFrequencyInterference Statement
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClass B
digital device, pursuant topart15oftheFCCrules.Theselimitsaredesigned
toprovidereasonableprotection againstharmful interferenceinaresidential
installation.Thisequipmentgenerates,usesand can radiateradio frequency
energyand,ifnotinstalled andused inaccordancewiththeinstructions,may
causeharmful interferencetoradiocommunications.However,thereisno
guarantee thatinterferencewillnotoccurinaparticularinstallation.Ifthis
equipmentdoescauseharmful interferencetoradioortelevisionreception,
whichcanbedetermined byturningtheequipmentoffand on,theuseris
encouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing
measures:
wReorientorrelocatethereceivingantenna.
wIncreasetheseparation between theequipmentandreceiver.
wConnecttheequipmentintoan outleton acircuitdifferentfromthatto
whichthereceiverisconnected.
wConsultthedealeroran experienced radioTVtechnicianforhelp.
NOTE
1.Thechangesormodificationsnotexpresslyapproved bytheparty
responsibleforcompliancecouldvoid theusersauthoritytooperatethe
equipment.
2.Shield interfacecablesand ACpowercord,ifanymustbeused inorder
tocomplywiththeemissionlimits.

III
NotebookPreface
FCC Conditions
Thisdevicecomplieswithpart 15oftheFCC Rules.Operation issubjecttothe
followingtwoconditions:
1.Thisdevicemaynotcauseharmful interference.
2.Thisdevicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesired operation.
MS
-
10
1
3
M
icro
-
StarInternational

IV
NotebookPreface
SafetyGuidelineforUsing LithiumBattery
(Danish)ADVARSEL!Lithiumbatteri--- Eksplosionsfarevedfejlagtig
hndtering.Udskiftningm kunskemed batteriafsame
fabrikatog type.
Levédetbrugtebatteritilbagetilleverandøren.
(Deutsch)VORSICHT:Explosionsgefahrbei unsachgemäßemAustauschder
Batterie.Ersatznurdurchdenselben odereinenvomHerstellerempfohlenen
gleich-wertigenTyp.EntsorgunggebrauchterBatterien nachAngaben des
Herstellers.
(English)CAUTION:Dangerofexplosion ifbatteryisincorrectlyreplaced.
Replaceonlywiththesameorequivalenttyperecommendedbythe equipment
manufacturer.Discardused batteriesaccordingtomanufacturer’sinstructions.
(Finnish)VAROITUS:Paristovoiräjähtää
,josseon virheellisestiasennettu.
Vaihdaparistoainoastaan valmistajan suosittelemaan tyyppiin.Hävitäkäytetty
paristovalmistajan ohjeidenmukaisesti.
(French)ATTENTION:II yadangerd’ex;losion s’ilyaremplacementincorrect
delabatterie.Remplaceruniquementavecunebatteriedu memetypeou d’un
type équivalentrecommandéparleconstructeur.Mettreaurebut lesbatteries
usagesconformémentauxinstructionsdufabricant.
(Norwegian)ADVARSEL:Eksplosjonsfareved feilaktig skifteavbatteri.Benytt
samebatteritypeellerentilsvarendetypeanbefaltavappara
tfabrikanten.
BruktebatterierkasseresI henholdtil fabrikantensinstruksjoner.
(Swedish)VARNING:Explosionsfaravidfelaktigtbatteribyte.Använd samma
batteritypelleren ekvivalenttypsomrekommenderasavapparattillverkaren.
Kasseraanvänt batterienligtfabrikantensinstruction.

V
NotebookPreface
CautiononUsingModem
1.Neverinstalltelephonewiringduringalightningstorm.
2.Neverinstalltelephonejacksinwetlocationsunless thejackisspecifically
designedforwet locations.
3.Nevertouchuninsulated telephonewiresorterminalsunless thetelephone
linehasbeendisconnected atthenetworkinterface.
4.Usecaution when installingormodifying telephonelines.
5.Avoidusing thetelephonefunction (otherthan acordless type)during an
electrical storm.Theremaybearemoteriskofelectricshockfrom
lightning.
6.Donot usethetelephonefunction toreportagasleakinthevicinityof the
leak.
CD-ROMDrive Notice
CAUTION:Thisappliancecontainsalasersystemandisclassified asa
CLASS 1LASERPRODUCT.”Tousethismodel properly,readthe
instruction manual carefullyandkeepthismanualforyourfuturereference.
Incaseofanytroublewiththismodel,pleasecontactyournearest
“AUTHORIZEDservicestation.”Topreventdirectexposuretothe laser
beam, donot trytoopentheenclosure.

VI
NotebookPreface
SafetyInstructions
1.Read thesafetyinstructionscarefullyandthoroughly.
2.SavethisUserGuideforpossibleuselater.
3.Keep thisequipmentawayfromhumidityandhightemperature.
4.Laythisequipmenton astablesurfacebeforesettingitup.
5.Theopeningson theenclosureareusedforairconvection andtoprevent
theequipment fromoverheating.Donotcovertheopenings.
6.Makesurethatthepowervoltageiswithin itssafetyrangeandhasbeen
adjusted properlytothevalueof100~240Vbeforeconnectingthe
equipment tothepowerinlet.
7.Placethepowercordin awaythatpeopleareunlikelytostep on it.Do
notplaceanythingon thepowercord.
8.Alwaysunplugthepowercordbeforeinsertinganyadd-on cardormodule.
9.All cautionsandwarningsontheequipment should benoted.
10.Ifanyofthefollowingsituationsarises,gettheequipmentcheckedbya
servicepersonnel:
wThe powercordorplugisdamaged.
wLiquidhaspenetrated intotheequipment.
wThe equipmenthasbeenexposed tomoisture.
wTheequipmenthasnotworked well oryou can notgetitwork
accordingtoUser’sManual.
wThe equipment wasdroppedanddamaged.
wThe equipmenthasobvioussignsofbreakage.

VII
NotebookPreface
11.Neverpouranyliquid intotheopeningthat could damagetheequipmentor
causeanelectrical shock.
12.Donotleavetheequipmentin an unconditioned environmentwitha
storagetemperatureof60OC(140OF)orabove,whichmaydamagethe
equipment.
13.Topreventexplosioncaused byimproperbatteryreplacement, usethe
sameorequivalenttypeofbatteryrecommendedbythemanufactureronly.

VIII
NotebookPreface
Trademarks
All trademarksarethepropertiesoftheirrespectiveowners.
wMicrosoftisaregisteredtrademarkofMicrosoftCorporation.
Windows®98/ME,2000/XPareregistered trademarksofMicrosoft
Corporation.
wAMI®isaregistered trademarkofAmerican MegatrendsInc.
wPCMCIAandCardBusareregistered trademarksofthePersonal
NotebookMemoryCardInternationalAssociation.
ReleaseHistory
Version Revision Note Date
1.0 First Release May2005

IX
NotebookPreface
CopyrightNotice
Thematerial inthisguideistheintellectual propertyofMICRO-STAR
INTERNATIONAL.Wetakeeverycareinthepreparation of thisdocument, but
noguarantee isgiven astothecorrectness ofitscontents.Ourproductsare
undercontinual improvementand wereservetherighttomakechangeswithout
notice.
PleasenotethatthesettingdiagramsorvaluesinthisguideareFORYOUR
REFERENCEONLY.Themodel you boughtmaybeslightlydifferentfromthe
illustrationsanddescriptionsinthisguide.Ifyouarenotsureaboutthese
information, suchastheNotebook specificationandequipment, pleaseask your
local vendorforhelp.
Technical Support
VisittheMSI websiteforFAQ,technical guide,driverandsoftwareupdates,and
otherinformation: http://www.msi.com.tw/.
Contact ourtechnical staff at: [e-mail].

X
NotebookPreface
Preface
RegulationsInformation.....................................................................................II
FCC-B RadioFrequencyInterferenceStatement........................................II
FCC Conditions.............................................................................................II
SafetyGuidelineforUsing LithiumBattery....................................................III
Caution on Using Modem..................................................................................IV
CD-ROMDriveNotice..........................................................................................V
SafetyInstructions.............................................................................................VI
Trademarks........................................................................................................VIII
ReleaseHistory.................................................................................................VIII
CopyrightNotice.................................................................................................IX
TechnicalSupport...............................................................................................IX
Introductions
HowtoUseThisManual..................................................................................1-2
Unpacking..........................................................................................................1-4
GettingStarted
Specification......................................................................................................2-2
ProductView.....................................................................................................2-6
TableofContent

XI
NotebookPreface
Top-open View............................................................................................2-6
FrontView...................................................................................................2-8
Right-sideView.........................................................................................2-10
Left-sideView...........................................................................................2-12
RearView.................................................................................................2-13
BottomView..............................................................................................2-14
PowerManagement........................................................................................2-16
ACAdapter................................................................................................2-16
BatteryPack.............................................................................................2-17
Using theBatteryPack.............................................................................2-20
BasicOperations............................................................................................2-22
SafetyandComfortTips...........................................................................2-22
HaveaGoodWorkHabit.........................................................................2-23
KnowingtheKeyboard.............................................................................2-24
KnowingtheTouchpad.............................................................................2-29
About HardDiskDrive..............................................................................2-33
Using theOptical Storage........................................................................2-34
Customizing thisNotebook
ConnectingtheExternal Devices...................................................................3-2
ConnectingthePeripheralDevices...........................................................3-3
ConnectingtheCommunication Devices...................................................3-6
PCCardInstallation..........................................................................................3-7
Installing thePCcard.................................................................................3-7

XII
NotebookPreface
Removing thePCcard...............................................................................3-8
SafelyRemoveHardware.................................................................................3-9
BIOSSetup
AboutBIOSSetup.............................................................................................4-2
WhentoUseBIOSSetup..........................................................................4-2
HowtoRun BIOSSetup.............................................................................4-2
ControlKeys...............................................................................................4-3
BIOSSetupMenu..............................................................................................4-4
Main menu..................................................................................................4-5
Advanced menu..........................................................................................4-7
Securitymenu.............................................................................................4-9
Bootmenu.................................................................................................4-11
Exitmenu..................................................................................................4-12

GeneralIntroductionsChapter 1
GettingStarted
Chapter 2
Customizing thisNotebook
Chapter 3
BIOSsetup
Chapter 4
Prefeace

1-2
NotebookGeneralIntroductions
Congratulationsonbecominganewuserofthisnotebook,thefinelydesigned
notebook.Thisbrand-newexquisitenotebookwillgiveyouadelightfuland
professional experienceinusingnotebook.Weareproudtotellourusersthat
thisnotebookisthoroughlytested and certified byourreputation for
unsurpasseddependabilityandcustomersatisfaction.
HowtoUseThisManual
ThisUser’sManualprovidesinstructionsandillustrationsonhowtooperatethis
notebook.It isrecommendedtoread thismanual carefullybeforeusingthis
notebook.
Chapter1,GeneralIntroductions, includesthedescriptionsofallthe
accessoriesofthisnotebook.It isrecommended tocheckoutthatifyou have
all theaccessoriesincluded when you open thepackingbox.Ifanyitemis
damagedormissing,pleasecontactthevendorwhereyoupurchased this
notebook.
Chapter2,GettingStarted, providesthespecification ofthisnotebook,and
introducesthefunction buttons,quicklaunchbuttons,connectors,LEDsand
externalsof thisnotebook.Also,thischapterinstructsthecorrectprocedureof
installing oruninstallingthebatterypack,andthebriefideason howtousethis
notebook.
Chapter3,Customizing thisNotebook, givesinstructionsnotonlyin

1-3
NotebookGeneralIntroductions
connectingthemouse,keyboard,webcam,printer,externalmonitor,IEEE1394
devices,andcommunication devices,butalsoininstallingand removing thePC
card.
Chapter4,BIOSsetup, providesinformationon BIOSSetupprogramand
allowsyoutoconfigurethesystemforoptimumuse.

1-4
NotebookGeneralIntroductions
Unpacking
First,unpacktheshippingcarton and checkallitemscarefully.If anyitem
containedisdamagedormissing, pleasecontactyourlocaldealerimmediately.
Also,keep theboxand packingmaterialsincaseyou needtoshiptheunitin the
future.
The packageshouldcontainthefollowingitems:
wNotebook
wUser’sManual orQuickStart Guide
wSoftwareCDcontaining thedriversandutilities
wHigh-capacityLi-ion batterypack
wACadapterandpowercord
wPhonecable/Phonejack (optional)
wNotebookcarrybag (optional)
Theseaccessorieslistedabove maychangewithoutnotice.

GeneralIntroductionsChapter 1
GettingStarted
Chapter 2
Customizing thisNotebook
Chapter 3
BIOSsetup
Chapter 4
Prefeace

2-2
NotebookGettingStarted
Specification
Physical Characteristic
Dimension 303mm(L)x225mm(D)x26-28mm(H)
Weight 1.8kg
CPU
ProcessorType MobileAMDK8
Support ProcessorMobileAMDAthlon 64/Sempronprocessor
L2 Cache 512KB/128KB
Core Chips
NorthBridge ATi®RS480M
SouthBridge ATi®SB400
Memory
Technology DDR 333
Memory DDR SO-DIMMX2slots
128/256/512/1024MBDDR SDRAM
Maximum 2GB(1024MBDDR SO-DIMMX2)
Power
ACAdapter 65W, 19 Volt
BatteryTypeI8cells(Li-lon)(4400mAh)
4cells(Li-lon)(2200mAh)
BatteryTypeI Life Batterymark1.5Hr/3Hr(4cells/8cells)
BatteryTypeI LifeInStand
byMode
S3:1.5days(2200mHA)/3days(4400mHA)
S4,S5:15days(2200mHA)/30days(4400mHA)

2-3
NotebookGettingStarted
Storage
HDD formfactor 9.5mm(H),40/80GB
IDEController UltraDMAATA-100
Optical Device DVD-ROM/COMBO/ DVDdual
I/OPort
Monitor(VGA) 15 pinMini D-Subx1
USB x3(USBversion 2.0),alwayssupplyPower
(S0~S5)
HeadphoneOut x1
IEEE1394 x1
Mic-in x1
Lin-in x1
RJ11 x1
RJ45 x1
CommunicationPort
56KFax/MODEM
MDC (AC’97)
I/F ---AC97 S/WModem
Controller--- AC97 Embedded
WakeonRing --- Supporton S3
PTTApproval---Yes(FCC/CTR21/JATE)
LAN PHY---Realtek8101L
WakeonLAN--- SupportonS3/S4/S5state
LANBoot---Yes
Wfm2.0support
Wireless LAN IEEE 802.11b/g

2-4
NotebookGettingStarted
PCMCIA
Controller RICOHR5C593
MMC/SD/MS3inonecardreaderx1
Slot TypeII x1
CardBus Support
Display
LCD Type 12.1”WXGA
Brightness Brightness controlled byK/Bhot-keys
Video
Controller RS480M
VRAM SharedSystemMemory
LCD 1280 x800WXGA
CRT Support 800x600,max,32bit color
1024x768,max,32bit color
1280x800,max,32bit color
DisplayDetect SystemautodetectLCD orCRT:
1.DisplaytoCRT-onlyifLCDlidisclosed;
2.DisplaytoLCD -onlyifnoCRT
detected;
3.Displaycan scan CRT&LCD
simultaneouslyifbotharedetectedand
activate.
Audio
SoundController SB400
SoundCodecchip RealtekALC655
Internal Speaker 2Speakerswithhousing(AMP:TITPA0202)
