MTD RGBV3100 User manual

Issued 11/02
ENGINE PARTS - MODEL RGBV3100
2-CYCLE GAS MULCHING BLOWER VACUUM
PPN- 41ASGBPG734
34
12
38
10
12
34
5
7
6
11
13
14 15
43
44
19
45
21
16
18 17
20
25
26 27 28
29 31
32
33
46
34
35
24
36
37
42
38
39
40
41
23
30
22
9
Item Part No. Description
1753-04105 Air Cleaner/Muffler Cover Assembly
(includes 2 & 34)
2791-180350B Air Cleaner Filter
3791-180351 Carburetor Mounting Screw
4791-180226 Wavey Washer
5791-182061 Choke Lever Assembly (includes 6)
6791-182070 Choke Knob and Screw
7791-182060 Choke Lever and Plate (includes 5)
8753-04255 Carburetor Assembly (includes 9 & 20)
9791-610675 Carburetor Gasket
10 791-181860 Carb Mount Screw
11 791-181558 Primer and Hose Assembly
12 753-1196 Carb Mount Assembly (includes 10 & 14)
13 791-684451 Reed Assembly
14 753-1208 Carburetor Mount Gasket
15 753-04328 Crank Case Service Assembly
(includes 10 & 23)
16 791-612134 Rear Mounting Pad
17 753-04310 Fuel Tank Assembly (includes 18-20)
18 791-182438 Fuel Cap Assembly
19 791-181168 Fuel Return Line
20 791-682039 Fuel Line Assembly
21 791-145308 Front Mounting Pad
22 791-153520 Shroud Assembly
23 791-181861 Shroud Screw
24 791-182401 Shroud Extension (includes 34)
25 791-182736 Flywheel Assembly
26 791-181525 Spacer
27 753-04232 Recoil Pulley Assembly
28 791-613102 Recoil Spring
Item Part No. Description
29 791-611061 Rope Guide
30 791-180930 Pulley Retainer Assembly
31 791-181079 Pull Handle
32 791-613103 Rope
33 791-181862 Housing Screw
34 791-181345 Cover Screw
35 791-181931 Starter Housing Assembly (includes 28-34)
36 791-182402 Wire Lead Assembly
37 753-04109 Module Assembly
38 791-147095 Spark Plug
39 791-182065 Exhaust Gasket
40 753-04110 Muffler Assembly (includes 39, 41 & 47-50)
41 791-147575 Muffler Mounting Bolts
42 753-04111 Cylinder Assembly (includes 44 & 45)
43 753-1207 Piston and Rod Assembly
44 753-04182 Cylinder Gasket
45 791-182723 Cylinder Bolt
46 791-181524 Crankshaft Extension
47 753-04121 Spark Arrestor
48 753-04122 Spark Arrestor Plate
49 753-04123 Spark Arrestor Hood
50 753-04124 Spark Arrestor Screws
*791-182067 Engine Gasket Kit
*791-181069 O.E.M. Carburetor Repair Kit (Zama)
*791-180091 Gasket Diaphragm Repair Kit (Zama)
*753-1209 Piston Ring
*753-04181 Short Block Assembly
(includes 10, 15, 23, 38, 42 - 45)
*Items Not Shown
48
49
50
47

Issued 11/02
HOUSING PARTS - MODEL RGBV3100
2-CYCLE GAS MULCHING BLOWER VACUUM
PPN- 41ASGBPG734
Item Part No. Description
1753-04138 Engine Cover Assembly (includes 2)
2791-181345 Cover Screw
3791-182419 Throttle Control Assembly (includes 4-8)
4791-182420 Upper Throttle Control Plate
5791-00048 Throttle Control Lever
6791-182422 Lower Throttle Control Plate
7791-182423 Screw, Plastic
8791-182405 Rocker Switch Assembly
9753-04140 Left Side Liner
10 753-04139 Right Side Liner
11 791-182408 Engine Mounting Plate (includes 12 & 13)
12 791-182409 Washer
13 791-181903 Screw
14 791-182410 Mode Control Flapper
15 791-182411 Mode Control Lever (includes 24)
Item Part No. Description
16 791-147353 Impeller Blade
17 791-182412 Washer
18 791-182413 Lock Washer
19 791-182414 Bolt
20 791-182415 Blower/Vac Tube Assembly (includes 2)
21 791-182417 Vacumm Bag Adapter
22 791-182424 Mounting Plate Hardware
23 791-182425 Blower/Vac Tube Mounting Hardware
24 791-181482 Screw
25 791-00049 Throttle Cable
*791-612930 Cable Tie
*753-04143 Vacuum Bag Assembly
(includes 21, Vacuum Bag & Cable Tie)
*753-04325 Patio Head
*Items Not Shown
1
4
8
5
6
25
3
7
9
13
17 18 19
16
14
11
12
10
23 15
23
22
24
2
2
1
21
2
23
23
22
2
24
20
20
2
