MTD RGBV3100E User manual

Issued 10/03
ENGINE PARTS - MODEL RGBV3100E
2-CYCLE PETROL MULCHING BLOWER VACUUM
PPN- 41ASGBVG037
34
1238
10
12
34
5
7
6
11
13
14 15
44
45
19
46
21
16
18 17
20
25
26 27 28
29 31
32
33
46
34
35
24
36
37
43
38
40
39
42
23
30
22
9
Item Part No. Description
1791-182059 Air Cleaner/Muffler Cover Assembly
(includes 2 & 34)
2791-180350B Air Cleaner Filter
3791-180351 Carburetor Mounting Screw Assembly
4791-180226 Wavey Washer
6791-182070 Choke Knob and Screw
5753-04418 Choke Lever Assembly (includes 5)
7753-04419 Choke Plate Assembly (includes 6)
8753-04106 Carburetor Assembly W/Limiter Caps
(includes 9 & 20)
9791-610675 Carburetor Gasket
10 791-181860 Carb Mount Screw
11 791-683974 Primer and Hose Assembly
12 753-1196 Carb Mount Assembly (includes 10 & 14)
13 791-684451 Reed Assembly
14 753-1208 Carburetor Mount Gasket
15 791-182775 Crank Case Service Assembly
(includes 10 & 23)
16 791-612134 Rear Mounting Pad
17 753-04310 Fuel Tank Assembly (includes 18-20)
18 753-182400 Fuel Cap Assembly
19 791-181086 Fuel Return Line
20 791-682039 Fuel Line Assembly
21 791-145308 Front Mounting Pad
22 791-153520 Shroud Assembly
23 791-181861 Shroud Screw
24 791-182401 Shroud Extension (includes 34)
25 791-182736 Flywheel Assembly
26 791-181525 Spacer
27 753-04232 Recoil Pulley Assembly
28 791-613102 Recoil Spring
Item Part No. Description
29 791-611061 Rope Guide
30 791-180930 Pulley Retainer Assembly
31 791-181079 Pull Handle
32 791-613103 Rope
33 791-181862 Housing Screw
34 791-181345 Cover Screw
35 791-181931 Starter Housing Assembly (includes 28-34)
36 791-182402 Wire Lead Assembly
37 791-182081 Module Assembly
38 791-147095 Spark Plug
39 791-182066 Muffler Assembly (includes 40-42)
40 753-04159 Exhaust Gasket
41 791-182066 Spark Arrestor
42 791-147575 Muffler Mounting Bolt Assembly
43 753-04323 Cylinder Assembly (includes 45 & 46)
44 753-04367 Piston and Rod Assembly
45 753-1197 Cylinder Gasket
46 791-182723 Cylinder Bolt
47 791-181524 Crankshaft Extension
*753-04134 Engine Gasket Kit
*753-04113 O.E.M. Carburetor Repair Kit (Zama)
*791-180091 Gasket Diaphragm Repair Kit (Zama)
*753-1209 Piston Ring
*753-04156 Short Block Assembly
(includes 10, 15, 23, 38, 42 - 45)
*Items Not Shown
41

Issued 10/03
HOUSING PARTS - MODEL RGBV3100E
2-CYCLE PETROL MULCHING BLOWER VACUUM
PPN- 41ASGBVG037
Item Part No. Description
1753-04138 Engine Cover Assembly (includes 24)
2791-181345 Cover Screw
3791-182419 Throttle Control Assembly (includes 4-7)
4791-182420 Upper Throttle Control Plate
5791-182728 Throttle Control Lever
6791-182422 Lower Throttle Control Plate
7791-182423 Screw, Plastic
8791-182405 Rocker Switch Assembly
9753-04140 Left Side Liner
10 753-04139 Right Side Liner
11 753-04483 Engine Mounting Plate (includes 12 & 13)
12 791-182409 Washer
13 791-181903 Screw
14 791-182410 Mode Control Flapper
15 791-182411 Mode Control Lever (includes 2)
Item Part No. Description
16 791-147353 Impeller Blade
17 791-182412 Washer
18 791-182413 Lock Washer
19 791-182414 Bolt
20 791-182415 Blower/Vac Tube Assembly (includes 2)
21 791-182417 Vacumm Bag Adapter
22 791-182424 Mounting Plate Hardware
23 791-182425 Blower/Vac Tube Mounting Hardware
24 791-181482 Screw
25 791-00049 Throttle Cable
*791-612930 Cable Tie
*791-182416 Vacuum Bag Assembly
(includes 21, Vacuum Bag & Cable Tie)
*791-682075B Shoulder Harness
*Items Not Shown
1
4
8
5
6
25
3
7
9
13
17 18 19
16
14
11
12
10
23 15
23
22
3
24
24
2
24
24
1
24
21
24
23
23
22
20
