MTM FLEX HEIGHT ADJUSTABLE TABLE BASE User manual

MTM FLEX HEIGHT ADJUSTABLE
TABLE BASE ASSEMBLY
INSTRUCTIONS.
© all rights reserved 2016

STEP 1: VERIFY ALL COMPONENTS ARE
COMPLETE.
© all rights reserved 2016

STEP 2: ASSEMBLE TOP FRAME USING (8)
M10X25 SET SCREWS.
© all rights reserved 2016

STEP 3: ATTACH EACH LEGS TO TOP FRAME USING
(6) M6X15 MACHINE SCREWS FOR EACH LEGS.
© all rights reserved 2016

STEP 4: ATTACH FEET TO LEGS USING (4)
M6X15 MACHINE SCREWS FOR EACH FOOT.
© all rights reserved 2016

STEP 5: ATTACH ASSEMBLED BASE TO
WORKSURFACE USING (12) WOOD SCREWS.
© all rights reserved 2016

STEP 6: PLUG IN ALL ELECTRICAL WIRES INTO CONTROL BOX
AND SECURE USING ZIP TIES. ENSURE THAT WIRES ARE NOT
EASILY PULLED OUT OF CONTROL BOX.
© all rights reserved 2016

STEP 7: INITIALIZATION PROCEDURE
1. PRESS AND HOLD UP AND DOWN ARROWS >3 SECONDS.
LEGS BEGIN TO MOVE DOWN AT HALF SPEED.
2. KEEP PRESSING UP & DOWN ARROWS.
LEGS MOVE DOWN TO LOWEST POSITION AND REBOUND 2-
5MM AND THEN STOP.
3. OK! READY TO USE TABLE.
