MTX Thunder 1501D Quick start guide

RCA Input
AMPLIFIER
CAR STEREO
(SOURCE UNIT)
REQUIRED INSTALLATION
TOOLS:
For installation options go to mtx.com
Adjustable Wrench • Crimpers • Screw Driver
Amplifier Input Connections
Utility Knife
Power Drill
Part #: NDM229
Remote/Power Antenna
Turn-On Wire
Phase Switch

AMPLIFIER
Amplifier Output Connections
For installation options go to mtx.com
Minimum Wire Size:
Power: 1/0 AWG. Ground: 1/0 AWG.
Disconnect
Battery Negative (-) Cable
Prior to Installing Amplifier
Grommet
Remove Paint
from Metal
Connect to Car Stereo
Remote/Power Antenna
Turn-On Wire
Ground To Metal Of Vehicle
CAUTION: This amplifier may draw in excess of 150 Amps of current.
Upgrading the vehicle’s factory battery and alternator may be required.
(For specific details, contact your local authorized MTX dealer, or call 1-800-CALL-MTX.)
