Muddy MGB6000 User manual

WARNING! This product is not reproof. The fabric will burn if
it comes into contact with an open ame or fuel source. Keep
product away from direct ame. Failure to follow this warning
may result in serious injury or death!
WARNING! This product is for hunting purposes only! It is not to
be used as a camping tent or for any other function. Failure to
follow this warning may result in serious injury or death!
WARNING! Do not use devices that produce fumes inside of blind.
Vapors and fumes could result in carbon monoxide poisoning,
serious injury, or death!
WARNING! Do not allow children or adults to use lighted candles,
matches, or other sources of re near this product. Failure to
follow this warning may result in serious injury or death!
WARNING! Do not allow the material to cover your face. This may
result in serious injury, suocation, or death!
WARNING! Do not allow children to use this product without
direct adult supervision. Failure to follow this warning may result
in serious injury or death!
WARNING!
Read all instructions and safety warnings and follow them
thoroughly. Failure to follow these instructions may
result in serious injury or death!
TIPS FOR INCREASING PRODUCT LONGEVITY
Always store your blind in a cool dry place and make sure that your
blind is completely dry and clean before storing in carrying bag. Never
leave your blind outside for any longer than needed. This material may
fade after long periods of time in direct sunlight.
HARDWARE LIST
Part # Description Qty
UP77-0156 [A] 5mm X 1'' Hex Bolt 75
UP77-0173 [B] 5mm x 1 1/4'' Hex Bolt 12
UP77-0157 [C] 5mm x 1 1/2'' Hex Bolt 2
UP77-0097 5mm Nylock Nut 89
UP77-0002 Nylon Washer 1
Part # Description Qty
UP15-0096 End Frame Base - Male Piece 2
UP15-0097 End Frame Base - Female Piece 2
UP15-0098 End Frame Hoop 8
UP15-0099 Side Support 8
UP15-0100 End Support - Male Piece 4
UP15-0101 End Support - Female Piece 4
UP15-0102 Waterfowl Door 1
UP15-0103 Waterfowl Door Extension 1
UP15-0104 Waterfowl Door Latch 1
UP15-0105 Cross Support 4
UP15-0372 Lower Cross Support 8
UP15-0106 Anchor Stakes 4
UP15-0107 Blind Cover 1
UP15-0108 Window Cover 6
UP15-0109 Peek Window Cover 3
UP15-0110 Side Window Bungee - 48'' 4
UP15-0111 End Window Bungee - 30'' 2
UP15-0112 End Window Bungee - 60'' 2
PARTS LIST
Note: Hardware is not listed for pre-assembled
Waterfowl Door Hinges.
Bale Blind
Model MGB6000
January 2018. Published by Premier Outdoor Equipment, LLC., Windom, Minnesota © 2018 Premier Outdoor Equipment, LLC. All rights reserved.
PO Box 454 • Windom, MN 56101 • [phone] • www.GoMuddy.com
Check to make sure you have all the required parts and hardware. If
you nd damaged or missing parts in a newly purchased product,
please return this product to the retailer for replacement.
Please read and follow all instructions and warnings. Failure to follow these instructions may result in serious injury or death!

2
WARNING! DO NOT over tighten the hardware. Over tightening can lead to structural damage and may negatively affect the
performance of your blind. Failure to follow these instructions may result in serious injury or death!
NOTE: All Steps require that you temporarily nger tighten all nuts and bolts until instructed to tighten. This will ensure proper alignment during assembly.
Most parts of this model are manufactured to be universal in use, so there may be some parts containing holes that will not be used for assembly. To
minimize confusion in the assembly process, please read these instructions in entirety before beginning.
ATTENTION!! WHEN YOU SEE A“ WARNING!” BE SURE TO HEED THE MESSAGE!
THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!!
STEP 1. Attach the (2) end frame base male pieces to the (2) end
frame base female pieces using (2) 5mm x 1’’ hex bolts [A] and (2)
5mm nylock nuts. Note: Only one shown here.
READ THIS MANUAL IN ITS ENTIRETY PRIOR TO USING THIS PRODUCT.
End Frame Male Piece
End Frame Female Piece
A
End Frame Hoop
End Frame Hoop
End Frame Hoop
End Frame Hoop
End Frame Base
STEP 2. Complete each end frame by
connecting (4) end frame hoops to each
assembled end frame base. Note: Only
one shown here.

3
ATTENTION!! WHEN YOU SEE A“ WARNING!” BE SURE TO HEED THE MESSAGE!
THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!!
READ THIS MANUAL IN ITS ENTIRETY PRIOR TO USING THIS PRODUCT.
STEP 3. Using (16) 5mm x 1’’hex bolts [A] and (16) 5mm nylock nuts, attach (4) side supports to the outside of the assembled end
frames in the illustrated locations. NOTE: For proper assembly the assembled end frames MUST mirror each other.
End Frame
End Frame
Side Support
Side Support
Side Support
Side Support
A
A
A
A
A
A
AA
A
A
A
A
AA
A
A

4
ATTENTION!! WHEN YOU SEE A“ WARNING!” BE SURE TO HEED THE MESSAGE!
THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!!
READ THIS MANUAL IN ITS ENTIRETY PRIOR TO USING THIS PRODUCT.
STEP 4. Next, attach the (4) remaining side supports to the outside of the assembled end frames in the illustrated locations using
(16) 5mm x 1’’ hex bolts [A] and (16) 5mm nylock nuts to secure.
End Frame
End Frame
Side Support
Side Support
Side Support
Side Support
AA
AA
AA
A
A
A
A
AA
AA
A
A

5
A
A
End Frame
End Frame
Waterfowl
Door
A
A
C
Waterfowl
Door Extension
Waterfowl Door
C
ATTENTION!! WHEN YOU SEE A“ WARNING!” BE SURE TO HEED THE MESSAGE!
THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!!
READ THIS MANUAL IN ITS ENTIRETY PRIOR TO USING THIS PRODUCT.
STEP 5. Connect the waterfowl door extension to the pre-assembled waterfowl door using (2) 5mm x 1 1/2’’ hex bolts [C] and (2)
5mm nylock nuts.
STEP 6. Using (4) 5mm x 1’’hex bolts [A] and
(4) 5mm nylock nuts, attach the assembled
waterfowl door to the outside of the assembled
end frames in the illustrated locations.

6
A
A
Side Supports
A
A
A
A
A
A
A
A
A
A
Cross Supports
ATTENTION!! WHEN YOU SEE A“ WARNING!” BE SURE TO HEED THE MESSAGE!
THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!!
READ THIS MANUAL IN ITS ENTIRETY PRIOR TO USING THIS PRODUCT.
A
End Frame
B
B
B
A
A
B
BB
End Frame
End Support
Male Piece
End Support
Male Pieces
End Support
Male Piece
End Support
Female Piece
End Support
Female Piece
End Support
Female Pieces
B
B
A
STEP 7. Attach the (4) end support male pieces to the (4) end support female pieces using (4) 5mm x 1’’hex bolts [A] and (4) 5mm nylock nuts.
STEP 8. Next, secure the assembled end supports to the illustrated locations on the end frames using (8) 5mm x 1 1/4’’ hex bolts [B] and
(8) 5mm nylock nuts.
STEP 9. Using (12) 5mm
x 1’’ hex bolts [A] and (12)
5mm nylock nuts, attach
the cross supports to the
outer holes on the top
three side supports.

7
Cross Support
Assembly Holes
B
B
B
B
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
Lower
Cross
Supports
Lower
Cross
Supports
Side
Supports
Waterfowl
Door
Ground
Cross Support
Assembly Holes
B
B
B
B
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
Lower
Cross
Supports
Lower
Cross
Supports
Side
Supports
A
Side
Support
Waterfowl Door
Latch
ATTENTION!! WHEN YOU SEE A“ WARNING!” BE SURE TO HEED THE MESSAGE!
THE INFORMATION CONTAINED IN THESE MESSAGES CAN SAVE YOUR LIFE!!
READ THIS MANUAL IN ITS ENTIRETY PRIOR TO USING THIS PRODUCT.
STEP 12. Using (1) 5mm x 1’’hex bolt [A], (1) nylon
washer and (1) 5mm nylock nut attach the waterfowl
door latch to the center hole on the side support
above the waterfowl door.
STEP 10. Attach (4) lower cross supports to the remaining cross support assembly holes using (4) 5mm x 1 1/4’’ hex bolts [B] and
(4) 5mm nylock nuts to secure. Then, nish connecting these (4) lower cross supports to the side supports using (8) 5mm x 1’’
hex bolts [A] and (8) 5mm nylock nuts.
STEP 11. Secure the reaming the lower cross supports to the outer holes on the three side supports below the waterfowl door
using (12) 5mm x 1’’ hex bolts [A] and (12) 5mm nylock nuts.
STEP 13. SECURELY TIGHTEN ALL NUTS AND
BOLTS AT THIS TIME.
STEP 14. Ensuring the zippered corners are open,
carefully pull the fabric cover over the assembled
frame noting the waterfowl door opening is on the
same side as the waterfowl door. Align and secure
the fabric cover on the assembled frame using inner
ties and zippered corners.
Anchoring the bale blind: (4)
anchor stakes are included to
secure your bale blind to the
ground. The (4) anchor stakes are
to be placed in the corners of the
interior of the blind as illustrated.
Anchor
STEP 15. Secure
the pre-assembled
windows between the
fabric cover and the
assembled frame using
bungee hooks.
