Mueller MLR010018N User manual

MANUAL MLR010018N | MLR010551N | MLR010552N | MLR010553N
5 SPEED 250 W TURBO
  

2 | IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions
should always be followed including the following:
READ ALL INSTRUCTIONS thoroughly before use and
save for future reference.
–This appliance is intended for household only.
–Do not use the Hand Mixer for anything other than its
intended purpose.
–This appliance is not intended for use by any individual
(including children) with reduced physical, sensory, or mental
capabilities, or lack of experience or knowledge, without
proper supervision and instruction from an adult or individual
responsible for their safety and care.
–Children should not use or play with this appliance. Keep the
appliance and its cord out of reach of children.
–To protect against the risk of electrical shock, do not put cord,
plug or Hand Mixer body in water or other liquid.
–Turn the appliance OFF and then unplug it from the wall outlet
when not in use. To unplug, grasp the plug and pull from the
outlet. Never pull from the Power Cord.
–Turn the appliance OFF before cleaning and before putting on
or taking off parts.
–Avoid contact with moving parts. Keep your hands, hair, and
clothing, as well as spatulas and other utensils, away from
Beaters during operation to reduce the risk of injury to persons
and/or damage to the Hand Mixer.
–Remove Beaters from Hand Mixer before washing.
–Do not leave Hand Mixer unattended while it is operating.
–Do not let cord hang over the edge of the table or counter or
touch hot surfaces, including the stove.
–Do not operate any appliance with a damaged supply cord or
plug or after the appliance malfunctions or has been dropped
or damaged in any manner. Contact Mueller Customer Service
immediately.
–The use of attachments not recommended or sold by the
appliance manufacturer for use with this model may cause fire,
electric shock, or injury.
–Do not use outdoors.
–Do not place on or near a hot gas or electric burner
or in a heated oven.
IMPORTANT SAFETY
INSTRUCTIONS

OVERVIEW OF PARTS | 3
OVERVIEW OF PARTS
Speed
Selector Turbo Button Handle Cover Eject Button
Openings for
Attachments
Storage Box Beater
Power Plug
with Power
Cord
Left
Dough
Hook
Right
Dough
Hook
Collar
Disk
Attachments
ELECTRICAL SHOCK HAZARD
This product is provided with a polarized
plug (one blade is wider than the other)
to reduce the risk of electric shock. The
plug fits only one way into a polarized
outlet. Do not modify the plug in any
way or use an adapter to circumvent
this safety feature. If the plug does not fit fully into the
outlet, reverse the plug. Do not apply excessive pressure
or force the plug into the outlet. If it still does not fit,
consult a certified electrician.
Other Consumer Safety Information

4 | USING THE HAND MIXER
USING THE HAND MIXER
NOTE: Attachments should be
used as a set (two Beaters or
two Dough Hooks). Do not mix
different attachments.
5
min
5
min
1Prior to first use, remove
the accessories from the
Storage Box and wash the
attachments thoroughly.
2Before assembling the Hand
Mixer, ensure the Power Cord
is unplugged from the power
outlet, and the Speed Selector
is at the “0” setting.
3Add attachments to the
Hand Mixer.
Attaching Beaters: Insert one
Beater into any of the Openings.
Push until it clicks into place. Repeat
this step to insert the other Beater.
Attaching Dough Hooks:
While facing the Openings for the
Attachments, insert the Dough Hook
with the collar disc into the right-side
opening. Push until it clicks into
place. Insert the other Dough Hook
into the left-side opening. Push until
it clicks into place.
4Ensure the Hand Mixer is set to
the “O” setting, then plug into
an appropriate outlet.
5There are 5 speed settings.
The appliance will start working
when you slide the Speed Selector
to your desired setting. The power
will increase by 10% from setting
1 to 5. Press and hold the “Turbo”
button to maximize power (same
as setting 5). The “Turbo” button
does not function when set to “0”.

USING THE HAND MIXER | 5
NOTE: When kneading yeast
dough, we suggest first
setting the Speed Selector at
a low speed, then gradually
increasing the speed until the
desired result is obtained.
WARNING!
Do not place any
objects such as
knives, metal spoons,
forks, and so on into
the bowl when operating.
CAUTION!
The “Eject” button can be
pressed down only when the
Speed Selector is on the “0”
setting. Also, make sure the
Power Cord is unplugged
from the power outlet before
removing the accessories.
5
min
5
min
5
min
*Scrapers not included
6Maximum operation time per mixing
should not exceed 5 minutes.
Allow at least 20 minutes rest time
between the two mixing cycles.
7When mixing is completed, slide
the Speed Selector to the “0”
position then unplug the cord
from the power outlet.
8If necessary, you can scrape the
excess food particles from the
Beaters or Dough Hooks with
a rubber or wooden spatula with
the power off.
9To remove the accessories from
your Hand Mixer, first unplug it.
Next, hold the Beaters / Dough
Hooks with one hand and press
the “Ejector” button firmly down
with the other hand. Pull the
accessories down and out.

6 | USEFUL TIPS
–Unless otherwise stated in your recipe, allow refrigerated ingredients
(butter, eggs) to reach room temperature prior to mixing.
This allows them to thoroughly combine.
–For best results when whipping cream, use cold heavy cream.
Do not allow the cream to reach room temperature.
–For best results, use heavy cold cream, straight from the refrigerator,
for making whipped cream.
–Do not over-beat. Be careful that you only mix/blend mixtures until
recommended in your recipe. Fold into dry ingredients only until
just combined.
–When whipping egg whites, plastic mixing bowls are not recommended.
For best results, the mixing bowl and Beaters must be completely clean
and free from any fat or oil. Traces of grease or oil on the attachments or
bowl will prevent the egg whites from increasing in volume during mixing.
–Changes in temperature and the texture and temperature of the
ingredient will affect the required mixing time and end results.
–Always start mixing at a lower speed. Gradually increase to the
recommended speed, as stated in the recipe.
–Clean Hand Mixer and
attachments after every use.
–Unplug the appliance and wait
for it to completely cool down
before cleaning.
–To clean Hand Mixer, wipe the
outside with a damp cloth, then
dry with a soft/dry cloth.
–Wipe any excess food particles
from the Power Cord.
–Always remove accessories from
Hand Mixer before cleaning.
–Wash the Beaters and the Dough
Hooks in warm soapy water and
wipe dry. The accessories can
be washed in the dishwasher.
Speed Selection
1
Slow speed to help prevent ingredients from splashing out of the
bowl. Use to combine wet/dry ingredients (such as flour, milk, eggs).
Use to stir in nuts, chocolate chips, shredded cheese, onions, olives,
and other chunky ingredients.
2
Start with 1, then move to this medium speed to stir thicker
ingredients and heavy mixtures. Use to combine batters, gelatin,
cookie dough, light cream cheese spreads, and to mash potatoes.
3
Start with 1, then move to this medium speed use for combining
heavier mixtures, such as heavy cream cheese mixtures
or mashing squash.
4
Start with 1, then move to this medium-high speed to blend
ingredients. Use for butter and sugar or to mix muffins, quick
breads, cake batters, and frostings.
5
Start with 2, then move to this high-speed setting for whipping
mixtures. Use to beat egg whites, meringue mixtures, whip heavy
cream, and mousse mixtures.
Pressing this convenient button jumps directly
to the highest speed (5).
CLEANING AND MAINTENANCE
USEFUL TIPS
TURBO

TROUBLESHOOTING | 7
Problem Possible Cause Solution
The motor does
not start.
The Power Plug is not
connected to the
wall outlet.
Connect the Power
Plug to a suitable
wall outlet.
The Hand Mixer is not
switched on.
Set the speed control
to 1–5 speed setting.
The motor
works very
slowly.
Too many ingredients
in the bowl.
Remove some food
and restart.
The speed control
is set to low speed.
Set the speed control
to a higher speed.
This product is warranted to be free from defects in material and workmanship
under normal use and service for one year from the date of the original
purchase with the receipt. The manufacturer’s obligation shall be limited to
repairing or replacing any part of the product that is defective. Such warranty
shall not apply to damages resulting from accidents, abuse, or misuse.
TROUBLESHOOTING
IMPORTANT!
Allow the unit to dry fully after
cleaning before using it again.
1YEAR LIMITED WARRANTY
SPECIFICATIONS
CAUTION!
Do not immerse Hand Mixer
in water or any other liquid.
Model
Number Voltage Power Material of Hand Mixer Body
Material of
Attachments
MM 505 120 V~
60 Hz 250 W Plastic with SUS decoration
Chrome-plated
steel
Dimensions with
the Storage Box
(H × W × L)
Dimensions
without the
Storage Box
(H × W × L)
Weight without
the Storage Box
and Attachments
Total
Weight
8 × 3.5 × 3.7 in
(20.5 cm × 9.4 cm ×
20.3 cm)
4.8 × 3.5 × 3.7 in
(12.3 cm × 9.4 cm
× 20.3 cm)
2 lb
(0.9 kg)
2.53 lb
(1.15 kg)

37 E 18TH STREET
NEW YORK, NY 10003
UNITED STATES
MUELLERDIRECT.COM
[e-mail]
888-632-9981
SKU:
MLR010018N
MLR010551N
MLR010552N
MLR010553N MADE IN CHINA
  
5 SPEED 250 W TURBO
  
