1. Remove back and side panels. Discard rear panel.
2. Remove screws from the rear channel. Remove
the bushing from channel and remove channel
from rear of lower cabinet. Discard channel.
3. Remove screws from electrical panel and utility box.
Remove ground screw and disconnect power cord
from unit harness. Remove cord and strain relief from
utility box. Remove utility box from unit. Discard box.
4. Drill out rivets on cord hanger. Save cord hanger
for reinstallation.
5. Remove screws from gas/water inlet fitting
bracket. Disconnect gas/water lines from
regulators on side of unit. Take electrical panel
loose from unit and hang down to gain access
to drain lines.
6. Remove screws from straps on drain lines.
7. Loosen clamp on drain pan drain, break oetiker
on ice bowl drain and remove drain line from
both fittings.
Multiplex
2100 Future Drive
Sellersburg, IN 47172
Phone: 844-724-2273
Fax: 920-683-7592
08/28/2018
9295083
Page 1 of 4
BIC Manual Fill Drain Installation
Applicable to MA-8-2, MA-8-2BF, MA-8-2AF
8. Remove bolts from cup holder mounting
brackets and remove cup holders.
9. Remove caps and hanger brackets from front
and top of blender chambers
10. Remove plastic cover from both blend chambers.
11. Remove bolts from blend chamber frame. Lift
up and slide blend chamber forward to access
drain clamp.
12. Remove clamp and drain hose from both blend
chambers. Remove drain hose from unit. Save
squeeze clamps from blend chambers. Discard old
drain hose. And gas/water inlet fitting bracket.
13. Route new drain lines from rear of unit to blend
chambers and center drain. Drain lines should
be installed underneath the wire harness to
avoid high spots in drain. Align notches on drain
lines with splines on blender drains and install
with squeeze clamps. Tighten clamp on center
drain hose and install drain line to ice bowl with
oetiker clamp provided in install kit.
14. Slide blend chambers back into position and
install bolts to frame.
15. Reinstall plastic blender covers.
16. Reinstall hanger brackets and caps to top of
blend chambers.
17. Reinstall cup dispenser.
Multiplex
2100 Future Drive
Sellersburg, IN 47172
Phone: 844-724-2273
Fax: 920-683-7592
08/28/2018
9295083
Page 2 of 4
BIC Manual Fill Drain Installation
Applicable to MA-8-2, MA-8-2BF, MA-8-2AF
18. Hang electrical panel back in position and
secure with screw.
19. Replace channel on base cabinet. Place utility
box on cabinet next to channel.
20. Place tab on right side of utility box behind
frame and install screw.
21. Install screws inside back of utility box on left
and right sides.
22. Secure drain lines to fittings with oetiker clamps
provided in install kit.
23. Route power cord through side of box and
bushing in tab at rear of box. Reconnect wires
and reinstall ground screw.
24. Secure power cord to box with strain relief.
Multiplex
2100 Future Drive
Sellersburg, IN 47172
Phone: 844-724-2273
Fax: 920-683-7592
08/28/2018
9295083
Page 3 of 4
BIC Manual Fill Drain Installation
Applicable to MA-8-2, MA-8-2BF, MA-8-2AF
25. Route gas/water supply lines through top
bushing. Connect lines to barbs on inlet fittings
and crimp with supplied oetikers.
26. Install utility box cover with screws provided in
install kit.
27. Align cord hanger with side and top of serial
tag. Mark holes and drill pilot. Secure to cabinet
with self drilling/tapping screws provided in
install kit.
28. Reinstall side panels and new back panel.
Multiplex
2100 Future Drive
Sellersburg, IN 47172
Phone: 844-724-2273
Fax: 920-683-7592
08/28/2018
9295083
Page 4 of 4
BIC Manual Fill Drain Installation
Applicable to MA-8-2, MA-8-2BF, MA-8-2AF
