Multplx J-PLUG SPLITTER 2 User manual

SPLITTER 2
security.multplx.com 1
TO INSTALL: SPLITTER 2
1. Loop cable around the product.
3. Connect the power and alarm cable. 4.Attach the Pendant to the cable
and close the Pendant with the J-Plug
logo facing you.
Pendant J-Plug Splitter 2
5.Using the Tetrakey screw clockwise to
secure the Pendant.
2a. Using the Tetrakey rotate anti-clockwise
to release the Pendant.
b. Lift and open the Pendant.
a
b
TO INSTALL: SPLITTER PUCK
1a. Use the Drilling Template to mark out the
mounting hole (1) along with the
power cable slot (2).
b. Carefully drill and cut-out the marked
mounting points.
When using adhesive only
drill power cable slot (2)
1
12
2a. Slide the power cable into the power cable
cut-out slot and align the Splitter Puck
over the mounting holes.
b. Screw in the two M5 Screws (not included).
a
b
3. Connect the Standard, Boost or Boost plus
power cable to Splitter Puck connection.
On connection there will be a red LED
followed by a ‘beep’.
LED

SPLITTER 2
security.multplx.com 2
TO INSTALL: AUDIO LOCK
1. Insert Audio Lock into the 3.5 audio socket.
6. Using the Tetrakey screw clockwise to
secure the Pendant.
2. Using Tetrakey apply pressure while
turning clockwise slowly, until the
Audio Lock is secured in the audio socket.
3. Plug in connector to your device and it will
automatically alarm and charge.
a
b
5. Attach the Pendant to the cable
and close the Pendant.
4a. Using the Tetrakey rotate anti-clockwise
to release the Pendant.
b. Lift and open the Pendant.
a
b
