MUNBYN IPDA087 Quick start guide

Munbyn,
More choice for your growing business
IPDA087 Android barcode scanner
Easy Setup Guide
Version 1.00 Version 1.00

1.0 1.0 Product OverviewProduct Overview 01
………………………………………………
02
…………………………………………………………
03
……………………………………………
03
…………………………………………………………
04
……………………………………………………
04
…………………………………………………
04
………………………………………………………………………
05
………………………………………………………………………
06
…………………………………
07
……………………………………………
10
……………………………………………
11
…………………………………………………
11
…………………………………………………
12
…………………………………………………
13
……………………………………………………………
13
…………………………………………………………………
15
……………………………………………………………
15
……………………………………………………………………
15
……………………………………………………………………
15
……………………………………………………………………
16
………………………………………………
18
…………………………………………………………………………
20
………………………………………………………………
21
………………………………………………………………
06
……………………………
2.0 Packing Open and Installation
3.0 Operation
2.1 What’s in the Box
3.1 Barcode Scan（Data capture）
2.2 Install the SIM or Micro SD
2.3 Using Battery
2.4 Charging the Device
2.5 Scanning
2.6 Screenshot
2.7 Download (User Manual & SDK)
2.4.1 Battery Usage Tips
3.1.1 Scan App Settings
3.1.2 Barcode Settings
3.2 Network & Connect
3.3 Reset Options
3.4 Testing Tool
3.5 Technical Specifications
3.6 FAQ
3.7 Cautions
3.8 Contact Us
3.2.1 Wi-Fi
3.2.2Mobile Networks
3.2.3Bluetooth
3.4.1 Network Test
3.4.2GPS Test
3.4.3NFC Test
IPDA087 Android Barcode Scanner Easy Setup Guide Page 1 of 21Version 1.00
①
②
③
SIM/SD
Card Slot
Figure 1- 1 Product overview
Scanner
Scan Auxiliary Light
Charge Port
Camera
Figure 1 - 2 Device layout
③
④ ⑦
⑤ ⑥

2.0 Packing Open and Installation
IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 3 of 21
IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 2 of 21
Figure 2- 1 SIM card slot
Key Function
1Power Key
2Function Key
3SCAN Key
4Menu Key
5Home Key
6Enter Key
7
Located on the left side, press to
ON/OFF device.
Located on the left side, its function
can be defined by software.
The scanning button is located on
both sides.
Display the main menu.
Touch it back to the main screen.
Press to confirm the current selection.
Return to the last step to setup.Back Key
What's in the Box?2.1
Install the SIM or Micro SD2.2
When you receive the package, open and check the packing list in
the package.
Place the SIM card or Micro SD Card into the tray as shown. The
take card pin is in the package as it is showing in [2.1 Unpack].
Using Battery2.3
The IPDA087 uses a non-removable battery, after receiving it you
can turn it on directly and use it, if you can't turn it on please use
the original power cable in the package to charge it for 30
minutes, and then it will work normally.
Do not leave the battery unused for a long time, no matter if it
is in the device or inventory.
The lifespan of a Li-ion battery is around 2 to 3 years, the battery
capacity will be lower after circularly charged about 300 times.
(One full battery charge period means completely charged and
completely discharged.)
If a battery is stored or otherwise unused for an extended period,
be sure to follow the storage instructions in this document.
If the IPDA087 fails to power on or charge, this indicates that
there is usually a problem with the battery. As the IPDA087 is not
removable from the battery, we do not recommend that you
carry out repairs personally, please contact our team of
professional technical engineers (refer to section 5.0)
Store the battery at temperatures between 5 °C and 20 °C (41°F
and 68°F).
While charging, the device and the charger may become hot
and stop charging. This usually does not affect the device’s
Tips:
User Manual
Lanyard
Tempered Film Set
(Including tempered film,
screen wiper, and dust-proof
sticker)
Handheld
Terminal Device
Silicone Sleeve
Plug
Take the Card Pin
USB Cable
Handle Silicone
Sleeve
Table 2 - 1 Packing list

IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 5 of 21IPDA087 Android Barcode Scanner Easy Setup Guide Version 1.00 Page 4 of 21
Figure 2- 3 Status bar
Scanning2.5
Charging the Device2.4
Battery Usage Tips:2.4.1
lifespan or performance and is in the device’s normal range of
operation. For more solutions to battery woes, refer to
Troubleshooting.
To read barcodes, a scanning-enabled application is required. The
device contains the Keyboardemulator application. The function of
the app is to allow the user to enable the scan processor, decode
the barcode data, and display the barcode content, outputting the
Screenshot2.6
Capture an image of your screen. Your device will automatically
create a Screenshots album in the Photos app.
barcode to the corresponding open app.
The charger type is GME10D-050200FGu, output voltage/current
is 5V DC/2A. The plug is considered as a disconnect device of the
adapter.
Connect the device to the cable. The device turns on and starts
charging. The charge/notification LED is blue when charging
and changes to a steady green when fully charged.
Do not use the battery in direct sunlight or in smoky and dusty
environments.
Ensure that an application is open on the IPDA087 and that a
text field is in the cursor.
Operation path: Scroll down the status bar > select the
Screenshot function (if not on the first-page swipe right to go to
the second page) >tap Screenshot
Do not strike, squeeze or step on the battery, nor throw it into
liquid or fire.
If the battery is deformed or damaged, replace it immediately.
Any product warranty is only valid if batteries are supplied by
MUNBYN.
Charging time should not exceed 24 hours. Over-charging or
over-discharging may damage the battery.
If the product is not being used for an extended period, whether
in storage or otherwise, make sure to recharge the battery at
least every 6 months.
The standard battery charges from fully depleted to 90% in
approximately seven hours and from fully depleted to 100% in
approximately three hours. In many cases, 90% provides a
significant charge for everyday use. Depending on usage, a
100% charge lasts approximately 14 hours.
Tips:
Figure 2- 2 The red LED red aiming dot turns on to assist in aiming
Place the top scanning head squarely on the barcode and press
the scan button.

IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 7 of 21
IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 6 of 21
3.0 Operation
Download (User Manual & SDK)2.7 This field represents your scan head model, tick 2D if 2D, 1D if
1D, and H for the ultra far custom model (not required to be
selected)
You can download this manual and the SDK for our models with
the links below:
This section provides information on using the various scanning
options and scanning barcode data.
KeyboardEmulator app is an internal software application to
test barcode-scanning. Meanwhile, it can be used in some basic
business scenarios depending on the customer’s choice. Please
review this chapter for more information and details.
Please ensure that it is switched on before use.
User Manual & SDK: http://u.pc.cd/zBK7
The 2D scan head can scan barcodes and QR codes, the 1D can
scan barcodes, this is related to the configuration you have
purchased and not to the app settings.
If you are unable to use the scan gun keys after receipt, please follow
the below steps:
After finishing the above steps, then you can use Scan Key/Pistol
to trigger barcode-scanning.
Operation video: http://u.pc.cd/U1V
Note:
Figure 3 - 3 KeyboardEmulator AppSettings
Figure 3- 1 Turning on the scan switch
Figure 3- 2 Setting key values
When Enable Scanner is turning off, the following functions can be setup:
Barcode Scan（Data capture）3.1
Scan App Settings3.1.1
A
A：
Select the Barcode type that corresponds to your device.
a：
Turning on the Enable Scanner.
c：
Tap the input box, then press Scan Key/Pistol, and the key code
will appear automatically.
b：
This area means your key settings, the default key value for the
scan side button is 139 and the scan gun button key value is 293
B：
B

IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 9 of 21
IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 8 of 21
If you release the scan key, then scanning
would stop.
If you encounter a situation where the barcode is not output in
the app, please select the keyboard output mode as a priority,
which will solve the problem.
Tips:
Figure 3- 4 Scanning output mode
Figure 3 - 5 Scan default suffix
Figure 3 - 6 Scan data format settings
Operation video: http://u.pc.cd/MUDctalK
Release key off scan :
If scanned successfully, there will be a sound as a
reminder.
Success Sound :
If failed to scan, there will be a sound as a
reminder.
Failure Sound :
If scanned successfully, there will be a vibration as a
reminder.
Vibrate :
It will remove the group separator from
barcodes.
Remove group separator :
This is to block scan key-value, can leave it if it’s not
necessary.
Block scan key :
Open the pistol auxiliary light.
Scan Auxiliary Light :
On this mode, repeated barcodes will not
show when scanning.
Barcode Not Repeat :
The data will show up in the place with
the cursor simultaneously.
Scan content on cursor :
Read-out data will be saved in the clipboard, and can
be pasted directly to anywhere with the cursor.
Clipboard :
It is the method that uses the broadcast
mechanism of Android to transfer data to the
customer’s program.
Broadcast Receiver :
The data will show up together in the input box
with the cursor.
Keyboard input :
Tick this checkbox, and the output will be word-wrapping
automatically.
Enter :
The read-out data will be added with the tab character “\t”
suffix. when data is acquired in Excel, the cursor will move to
the next cell automatically.
TAB :

IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 11 of 21
IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 10 of 21
The prefixing numbers or letters will be added to the front
of the output.
Figure 3- 7 Factory scan settings
Operation video: http://u.pc.cd/Xi0rtalK
If the IPDA087 does not produce light when the scan button
is pressed or if other scan data is scanned after the setting,
you can click on Factory data reset.
Note:
Figure 3 - 8 Scan default suffix
Barcode Settings3.1.2
Wi-Fi3.2.1
Prefix：
e.g. : If you input ‘ABC’, and the original barcode is ‘12345’,
then the final output will be as ‘ABC12345’.
e.g. : If you input ‘ABC’, and the original barcode is ‘12345’,
then the final output will be as ‘12345ABC’.
The suffixing numbers or letters will be added to the front
of the output.
Suffix :
Input the number of characters you want to remove from the front.
Remove the front number of characters :
Input the number of characters you want to remove from the back.
By clicking ‘Factory Data Reset’, the KeyboardEmulator app will
reset to the original status.
We’ve integrated some common Barcode settings in this section.
Under this section, you will find ‘Base setting’ and some common
barcodes of 1D and 2D. Some Settings need to be turned on
manually.
This section provides manage connections between your device
and a variety of networks and other devices.
You can connect your device to a Wi-Fi network to access the
Internet without using your mobile data.
Remove the back number of characters :
It will be filtered out the data you input.
Filter data:
Network & Connect3.2
Figure 3 - 9 Turn on Wi-Fi

IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 13 of 21
IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 12 of 21
From Settings, tap Network & Internet --> Wi-Fi, and then tap
to turn on Wi-Fi and scan for available networks.
Mobile Networks3.2.2
1.
From Settings, tap Network & Internet --> Wi-Fi, and then tap
to turn on Wi-Fi and scan for available networks.
1.
From Settings, tap Network & Internet --> Mobile networks.
1.
Tap Add network at the bottom of the list.
2.
Enter information about the Wi-Fi network:
Network name : Type the exact name of the network.
3.
Tap Save.
WiFi fault operation: http://u.pc.cd/LPt
4.
Tap a network, and enter a password if required.
2.
Tap Connect.
3.
From Settings, tap Connected device --> Bluetooth, and
then tap to turn on Bluetooth.
You can rename a paired device to make it easier to recognize.
Reset network settings and app preferences. You can also reset
your device to its factory defaults.
1.
From Settings, tap Connected device --> Bluetooth, and
then tap to turn on Bluetooth.
1.
Tap a device and follow the prompts to connect.
2.
Tap Device name to enter a new name, and then tap RENAME.
2.
If the Wi-Fi network you want is not listed after a scan, you can still
connect to it by entering the information manually. Ask the Wi-Fi
network administrator for the name and password before you
begin.
Connect to a Hidden Wi-Fi Network
Rename a paired device
Use Mobile Networks to configure your device's ability to connect
to mobile networks and use mobile data. Insert a SIM card
before using it, Options may vary by carrier.
Bluetooth3.2.3
You can pair your device to other Bluetooth-enabled devices. Once
a pairing is created, the devices remember each other and can
exchange information without having to enter the passkey again.
Reset Options3.3
Data roaming : Enable data roaming usage.
Preferred networks : Select the priority of sim cards or network
type.
Preferred network type : Choose preferred Network type.
Access Point Names : Choose or add APNs, which have the
network settings your device needs to connect to your
provider.
Network operators : Choose available and preferred networks.
Security : Select a security option from the list, and enter the
password if required.
View more : Define other advanced options, such as IP and
Proxy settings.
Figure 3 - 10 Turn on Bluetooth
Figure 3 - 11 Reset Options

IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 15 of 21
IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 14 of 21
From Settings, tap System --> Reset options. The following
options are available:
1. Network test3.4.1
GPS test3.4.2
From the App Center app, tap Network.
From the App Center app, tap GPS to access GPS information.
NFC test3.4.3
From the App Center app, tap NFC to read or write ID/IC card, or
write and reader block.
Tap to test Wi-Fi or Mobile signal by requirement.
Reset Wi-Fi, mobile & Bluetooth: You can reset Wi-Fi, mobile
data, and Bluetooth settings with Reset network settings.
Reset app preferences : You can reset all app preferences
settings and will not lose any app data.
Erase all data (factory reset) : You can reset your device to
factory defaults, erasing all data from your device.
Figure 3 - 13 Network test interface
Figure 3 - 14 GPS test interface
Figure 3 - 15 NFC test interface
Figure 3 - 12 App center test list
Testing Tool3.4
This action permanently erases ALL data from the device,
including Google or other account settings, system and
application data and settings, downloaded applications, as well as
your music, photos, videos, and other files.
App Center is an internal software application to test the function
of each module of the device (If you encounter any fault problems
during use, you can use this app to check).

IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 17 of 21
IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 16 of 21
Product parameters
Dimensions 164.2mm*80.0mm*24.3mm
Weight 654g
Audio Speaker, 2 microphones
Sensor Gravity sensor, Light Sensor, Proximity Sensor
Camera 13 MP Autofocus with flash
Key 4 front keys, 1 power key, 2 scan keys,
1 multifunctional key
Performance Parameter
CPU Cortex-A53 2.3 GHz Octa-core
Expand Memory Micro SD port (Max up to 128G)
RAM+ROM
OS Android 11; GMS, FOTA, Soti MobiControl,
SafeUEM
WLAN IEEE802.11 a/b/g/n/ac, 2.4G/5G dual-band,
internal antenna
4G: B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28A
/B28B/B34/B38/B39/B40/B41
Data Communication
3G: WCDMA: B1/B2/B4/B5/B8
CDMA2000 EVDO: BC0
TD-SCDMA: A/F
WWAN(America)
2G: 850/900/1800/1900MHz
SDK Development Android SDK Language: Java, Tool: Android
Studio/Eclipse
Input Mode Standard Stylus, Handwriting, touching input
Battery Capacity
Rechargeable Li-polymer Battery 8000mAh
Standby time > 500 hours
Battery Capacity
Working time > 12 hours
(depending on user environment)
Charging time: 3~4 hours
(with standard adaptor and USB cable)
Expand Port 1 slot for SIM card, 1 slot for SIM or TF card
Communication
Interface USB 2.0 Type-C, OTG
Display Screen 5.2'' IPS FHD 1920x1080P with Corning
Gorilla Glass, multi-touch panel
More Functional Module Tests3.4.4
From the AppCenter app, tap About, tap to select functions.
Figure 3 - 16 Test function selection
Technical Specifications3.5
3GB+32GB；4GB + 64GB (optional)

IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 19 of 21
IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 18 of 21
GNSS GPS/AGPS, GLONASS, BeiDou, internal antenna
Bluetooth Bluetooth 5.0
2D Imager Scanner Zebra: SE4710 / SE4750SR
Barcode Scanner (Optional)
Problem Cause Solution
UPC/EAN, Code128, Code39, Code93, Code11,
Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5,
Codabar, MSI, RSS, etc
FAQ3.6
1D Symbologies
PDF417, MicroPDF417, Composite, RSS, TLC-39,
Datamatrix, QR code, Micro QR code, Aztec,
MaxiCode, Postal Codes: US PostNet,
US Planet,UK Postal, Australian Postal,
Japan Postal, Dutch Postal (KIX), etc
2D Symbologies
Can’t scan the code
Can’t scan the code
Wrong scanning
distance or angle.
Place the device
within the proper
scanning range
or angle.
Wrong barcode
process mode.
Switch the input mode
to the Keyboard input
mode in the
KeyboardEmulator
application.
Scan keycode
is incorrect.
Set the Scan keycode
in KeyboardEmulator.
Refer to the
KeyboardEmulator
application.
Wrong Scan setting.
Reset the
KeyboardEmulator
application and enable
the Scanner again.
The device does
not boot up
The power button
was not pressed.
Hold the Power Key
until the screen
lights up.
The device cannot
be charged
The battery or device
is faulty.
Connect with the USB
cable and check the
device’s LED light. If the
LED lights up,
the Battery is faulty,
otherwise is the
device’s problem.
After turning off the
Code11 check digit
in the
KeyboardEmulation
app, the scan still
shows
Error in operation
Open
KeyboardEmulation
app >check digit
verification disable
+ transmit check digit
disable >
add parameters > 52, 2
The battery is not
charged. Charge the device.
System crash. Perform a reset.
The scanner can’t
read the barcode.
Enable the type of
barcode being
scanned in the
KeyboardEmulator.
Refer to the
KeyboardEmulator
pplication.

IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 21 of 21
IPDA087 Android Barcode Scanner Easy Setup Guide
Version 1.00 Page 20 of 21
Strictly observe the following instructions while install and
connect the device. Connect to stable power socket, try to avoid
charging it together with high-power machines like
air-conditioner.
Please try not to use the device during the thunderstorm in
case of lightening stroke, and power off as well as cut off its
connection to host machine.
This is an electrical product. Do be sure not let anything like a
pin, thumbtack, wire or water slip into the device, or short circuit
will be caused to destroy the device.
Be sure no heavy pressure on device or place anything on it.
Prevent fierce vibration, strike or beat.
Ensure a good working condition, never use it in humid, high
temperature, sun burn, dustiness or frost environment, never
get close to strong electromagnetic field, never use device
under flammable and explosive conditions.
Avoid plugging or swap any part or peripherals when power is
on, or it may cause inner hardware damage. Shutoff device
before cut power.
This device is integrated with Lithium battery, change our
original battery if needed. Other types of battery may cause
damage to the device. Contact our distributor or us when you
need to change battery.
Cut off power and stop operation if device break down. DO NOT
disassemble the device yourself.
Avoid sleet, solar exposure, mechanical shock or extrusion. Be
careful when delivering.
The device should be kept in original package, and temperature
of warehouse should be －20℃～60℃, relative humidity should
be 5%～95%. No noxious gas, flammable, explosive or mordant
chemicals are allowed to be together, ensure no mechanical
shock, impact or high magnetic.
Scan the QR code for Whatsapp online chat
If you meet any problem during using the IPDA087,
please contact us
Cautions3.7 Contact US3.8
[email protected]
（24-7online support）
[phone]
live:munbyn www.munbyn.com
（How-to videos，warranty detalis）
