Murphy M2 User manual

00-02-0674
04-15-10
Section 50
M2Wireless
GatewayandRemotes
InstallationManual

In order to consistently bring you the highest quality, full featured products, we reserve the right to change our
specifications and designs at any time. The latest version of this manual can be found at www.fwmurphy.com.
Please read the following information before installing.
BEFORE BEGINNING INSTALLATION OF THIS MURPHY
PRODUCT:
Read and follow all installation instructions.
Please contact FW MURPHY immediately if you have any
questions.

Table of Contents
M2 Gateway and Wireless Remotes........................................................................................1
Before you begin…. .....................................................................................................1
Tools and Equipment needed ......................................................................................2
Installation Checklist.................................................................................................................3
Installing the M2 Wireless Gateway and Antenna.................................................................4
Mounting the Gateway .................................................................................................4
Power...........................................................................................................................4
Antenna Mounting........................................................................................................4
PC Cabling and Software..........................................................................................................6
USB-COMi Setup.........................................................................................................6
PC to Gateway Connection..........................................................................................8
Download MODBUS configuration software.................................................................9
Gateway Operation..................................................................................................................10
Program the Network Address...................................................................................10
Gateway Power Up –No Remotes Added Yet...........................................................11
Gateway Power Up –Remotes Already Added..........................................................11
Gateway Power Up - Power Input is Less Than 6.1 Volts, Greater Than 5.0 Volts....12
How to Ensure the Gateway is Powered Up ..............................................................12
Prepare Gateway for Learn Operation .......................................................................12
How to Reset Heartbeat Counters .............................................................................13
How to Reset the Gateway to Factory Defaults..........................................................13
How to Verify the Gateway is Reset to Factory Defaults............................................13
Installing Remote Units...........................................................................................................14
Learn Operation .......................................................................................................................16
How to Remove a Remote from the Network.............................................................17
How to Install a Battery in the Remote.......................................................................18
MODBUS Register Access.........................................................................................19
How to Program the Remote Configuration Registers ...............................................20
General Operation: Discrete Remote –ONE CHANNEL ...........................................21
How to Configure a Discrete Remote –ONE CHANNEL...........................................22

General Operation: Thermocouple Remote –ONE CHANNEL..................................23
How to Configure a Thermocouple Remote –ONE CHANNEL .................................25
Sensor Event Retry Counter ......................................................................................26
Deep Sleep ................................................................................................................27
LED Functionality......................................................................................................30
FCC Compliance & Warnings.................................................................................................31
FCC Compliance........................................................................................................31
Warnings....................................................................................................................32

Section 50 00-02-0674
04-16-10 - 1 -
M2 Gateway and Wireless Remotes
The following quick connect diagram provides an overview of the M2 Wireless components
and how they are connected.
Before you begin….
Survey the location site and determine the best location for the antenna and remote units. For
optimal performance, the remote units should be placed in clear line of site, or unobstructed
view to the antenna. To improve line-of-site between remote and Gateway, use an appropriate
length of conduit to elevate the remote above the sensor.

Section 50 00-02-0674
04-16-10 - 2 -
Tools and Equipment needed
PC, including cable to connect to RS485. RS232/RS485 adapters can be purchased from
accessioproducts.com and baterunner.com. Recommended RS485 USB converter is a USB-
Comi.
MODBUS configuration software is required for initial setup and activation. Listed below are
two options that may be downloaded from the following sites:
Murphy MConfig Software (www.fwmurphy.com/support/software.htm)
Modbus Interface (www.calta.com)
Wire cutter, stripper
Screw driver
Conduit, if needed to improve line-of-site between remote and Gateway
Teflon tape

Section 50 00-02-0674
04-16-10 - 3 -
Installation Checklist
Use the checklist below as a guideline for installing and activating the M2 Wireless
components.
Site Survey - determine the best location for the antenna and remote units. (See
Before you begin….page 1)
Gather tools and equipment needed. (See Tools and Equipment needed, page 2)
IMPORTANT! Shut down engine before installing M2 components.
Install the M2 Wireless Gateway and Antenna
Mounting the Gateway (page 4)
Power (page 4)
Antenna Mounting (page 4)
Prepare Laptop for communication
USB-COMi Setup (page 6)
PC to Gateway Connection (page 7)
Download MODBUS configuration software (page 8)
Gateway Activation
Connect laptop PC cable to RS-485 connection on Gateway.
Launch MODBUS program on laptop.
Gateway Power Up –No Remotes Added Yet (page 10)
Program the Network Address (page 9)
Install Remote Units
Installing Remote Units (page 13)
Remote Activation
How to Ensure the Gateway is Powered Up (page 11)
Prepare Gateway for Learn (page 11)
Learn Operation (page 15)
How to Reset Heartbeat Counters (page 11)

Section 50 00-02-0674
04-16-10 - 4 -
Installing the M2 Wireless Gateway and Antenna
Mounting the Gateway
Mount the M2 Gateway on a DIN rail inside the
panel enclosure.
The M2 Gateway can be mounted vertically or
horizontally on a standard DIN rail. Two clamp-
type feet along the bottom of the Gateway attach
to the DIN rail.
NOTE: Rail stops are recommended to
prevent sliding.
Power
Power up the Gateway by attaching a power cable to the GND/BAT terminals and connecting
to a battery or power supply. Voltage must be between 8-32 volts DC.
Antenna Mounting
1. Mount the antenna bracket to the top of the panel, or
other structure, no more than 12 feet away from the
Gateway.
2. Attach the antenna coax cable to the Primary
Antenna connection on the Gateway. Feed cable
down and outside of the panel through a free
conduit hole. It is recommended that the coax cable
be run separately from other cabling and kept away
from noise sources such as the “G-Lead, cell
modem cabling, antenna, etc.
3. Attach the coax cable to the antenna through the mounting bracket, locking the antenna
into place.

Section 50 00-02-0674
04-16-10 - 5 -
GATEWAY RF Antenna Connection
Attach grounding plane in a horizontal position to a solid metal surface as shown.
Base of antenna should be 3‟6” to 5‟6” above ground.
Antenna should have clear line of sight to remotes for optimal performance.

Section 50 00-02-0674
04-16-10 - 6 -
PC Cabling and Software
A laptop is required to communicate MODBUS commands to the M2 Gateway. A USB-COMi
port should be configured for connecting to the Gateway, and MODBUS program should be
installed in order to activate the M2 Gateway and Wireless Remotes.
USB-COMi Setup
1. Open the USB-COMi USB to EIA-485 converter. Orient the converter and locate the
jumper block.
2. Remove all jumpers and then reinstall a jumper at positions 1-2, 5-6, 7-8, 11-12, 15-16,
and 19-20. Positions 3-4, 9-10, 13-14, and 17-18 do not have a jumper. Place excess
jumpers onto one pin of positions 3-4 and 9-10 so they hang off to one side for storage.
This configures the unit as terminated and transmit data echo suppression mode.
3. Reassemble the USB-COMi.
4. Locate the USB cable supplied with the USB-COMi. Connect the small end of the USB
cable into the USB-COMi and install the large end of the USB cable into the computer.
Do not connect USB-COMi into a USB Gateway or erratic behavior can result.
5. When Windows notifies you that “Found New hardware”, insert the driver CD supplied
with the USB-COMi into the computer. If the driver install does not start automatically,
select “Search for the best driver for my device” on the computer and then click “Next”.
Click on “Specify a location” and select your CD-ROM. Driver should now install on
computer.
6. “Found New Hardware” will appear again and this time it will install a USB serial port.
7. Right click on “My Computer”, click on “Proprieties”, click on the “Hardware” tab, and
then click on “Device Manager”.
8. Click on “Ports (COM & LPT)”. You should now see an entry for USB Serial Port
(COMX) where X represents the port number.

Section 50 00-02-0674
04-16-10 - 7 -
9. Double Click on USB Serial Port and a window will open that lets you set the COM port
properties. Click on “Port Settings” and then set “Bits per second” to 115200 but leave
“Data bits” set to 8, “Parity” to None, “Stop bits” to 1, and “Flow control” to None. Click
on OK to save changes.
10.Close the device and properties windows.

Section 50 00-02-0674
04-16-10 - 8 -
PC to Gateway Connection
Once the USB-COMi USB to EIA-485 converter has been installed and configured on the PC,
use the following guidelines to connect the PC to the Gateway.
Connect Pin 1 on USB-COMi to Gateway RS-485-B terminal
Connect Pin 2 on USB-COMi to Gateway RS-485-A terminal

Section 50 00-02-0674
04-16-10 - 9 -
Download MODBUS configuration software
Connect to the internet and download a MODBUS application from one of the following sites:
Murphy MConfig Software (www.fwmurphy.com/support/software.htm)
“Mdbus”Interface (www.calta.com)
Follow the example below to set up the MODBUS configuration.

Section 50 00-02-0674
04-16-10 - 10 -
Gateway Operation
Refer to the diagram below when following the procedures outlined in this section.
IMPORTANT:
When no remotes have been added to the system, the Form-C relay
output will be in an alarm condition and the heartbeat LED will flash
slowly.
The Form-C relay output will be connected between „COM & NO‟.
The LED will change state every 2 seconds.
After the first remote has been added to the system, the heartbeat LED
will flash more quickly.
Program the Network Address
Ensure the Gateway is powered up.
To enable MODBUS writes, send a value of 4660 to MODBUS address 40053.

Section 50 00-02-0674
04-16-10 - 11 -
Set the network address by sending a unique value to MODBUS address 40051. Enter
this unique value on the „M2 Wireless Setup Sheet‟ included with this manual.
Verify that the value was programmed via the MODBUS map.
IMPORTANT!
Network address must be programmed before Learn Mode can be
enabled.
It is important to maintain a list of network addresses at location so that
two Gateways are not each programmed with the same address.
Each Gateway must have a unique address between 1 - 255.
Gateway Power Up –No Remotes Added Yet
Turn the power to the Gateway off.
Leave power off for at least 10 seconds.
Turn power to the Gateway back on.
The „Heartbeat‟ LED will start flashing slowly approximately every 2 seconds.
All of the „Output‟ LED‟s will be off and the „Form C‟output will be connected between
„COM & NO‟.
If there is MODBUS communication with the Gateway, then the MODBUS LED‟s will be
flashing; otherwise they will be off.
Gateway Power Up –Remotes Already Added
Turn the power to the Gateway off.
Leave power off for at least 10 seconds.
Turn power to the Gateway back on.
The „Heartbeat‟ LED will start flashing on a periodic basis.
All of the „Output‟ LED‟s will be off for at least 90 seconds.
If there is MODBUS communication with the Gateway, then the MODBUS LED‟s will be
flashing; otherwise they will be off.
The „Form C‟ output will be connected between „COM‟ & „NO‟ until all Remotes have
reported in.

Section 50 00-02-0674
04-16-10 - 12 -
As soon as all Remotes report in subsequent to Gateway power up, the „Form C” output
will be connected between „COM‟ & „NC‟.
In the event all Remotes do not report in within 90 seconds, the „Output‟ LED(s)
corresponding to the Remote(s) that have not reported in will be illuminated and the
„Form C‟ output will not change state.
Gateway Power Up - Power Input is Less Than 6.1 Volts but Greater Than 5.0
Volts
The „Heartbeat‟ & „Misc‟ LED‟s are on and do not go off.
When the power input is greater than or equal to 6.1 volts, the „Misc‟ LED will go off and
the „Heartbeat‟ LED will start flashing on a periodic basis.
How to Ensure the Gateway is Powered Up
Measure the voltage across the BAT/GND terminals of the power connection inputs.
The voltage across the BAT/GND terminals must be between 8-32 VDC.
The „Heartbeat‟ LED will flash.
Prepare Gateway for Learn Operation
1. Ensure the Gateway is powered up.
2. If necessary, Reset the Gateway to Factory Defaults –this is required if the Gateway is
used at a new location. (See How to Reset the Gateway to Factory Defaults, page
13).
3. Verify the Network address has been programmed into the Gateway. (See page 10).
IMPORTANT!
When no remotes have been added to the system, the Form-C relay
output will be In an alarm condition and the heartbeat LED will flash.
The Form-C relay output will be connected between „COM & NO‟.
The LED will change state every 2 seconds.
After the first remote has been added to the system, the heartbeat LED
will flash every 2 seconds (approx).
4. Program the Network Address (page 10).

Section 50 00-02-0674
04-16-10 - 13 -
5. Press and hold the PROGRAM button on the Gateway until the COP (MISC) LED
flashes three times, then release.
6. The COP (MISC) LED should begin flashing rapidly indicating that the Gateway has
entered „learn mode‟ and is waiting for a remote to initiate the learn operation.
7. If the Gateway does not detect a remote initiating the learn operation within 30 seconds,
it will time out and return to normal operation. Subsequent to timing out, the COP
(MISC) LED will turn off and the „Heartbeat‟ LED will begin flashing again.
How to Reset Heartbeat Counters
1. Insure the Gateway is powered up.
2. On the Gateway, write a value of 4660 to MODBUS address 40053.
3. On the Gateway, write a value of 165 to MODBUS address 40098
4. On the Gateway, write a value of 161 to MODBUS address 40098
5. On the Gateway, write a value of 163 to MODBUS address 40098
How to Reset the Gateway to Factory Defaults
Program Button Method
Press and hold the „Program‟ button until the COP (MISC) LED flashes at least ten
times and release.
Turn off Gateway power.
Wait at least 10 seconds.
Turn Gateway power back on.
Verify that the Gateway has been reset to factory defaults
How to Verify the Gateway is Reset to Factory Defaults
MODBUS address 51 is zero indicating that the Network Address has been reset.
MODBUS address 8 is zero indicating that no remotes have been added to the network.
The „HEARTBEAT‟LED will toggle slowly. It will change state every 2 seconds.
The „Form C‟ output will be connected between „COM & NO.‟

Section 50 00-02-0674
04-16-10 - 14 -
Installing Remote Units
Read MODBUS address 40016. This will contain the remote ID of the next remote you will be
adding to the network. Label the next remote to be added with the value contained in address
40016. This is done to create a reference between the remote and the MODBUS map.
NOTE: The first 8 remote units correspond to Gateway LEDs 1 through 8.
Additional remotes will use LED 8 to display sensor events.
When a sensor event occurs, a heartbeat is missed, or the remote‟s
battery is low, the Gateway will light up the appropriate LED 1 through 8.
1. Loosen the 4 screws and remove the lid to the remote
enclosure. Take out the PC board and place it onto the
lid. Set aside for later.
2. Place 2 wraps of Teflon tape in a clockwise fashion
around threaded connection as shown.
3. Run sensor wires into the remote case, leaving a few
inches of extra wire outside of the case.
4. Attach the remote case to the sensor or conduit, leaving
the case opening face up.
5. Snap the battery into place on the back side of the pc board,
aligning the +/- as indicated below.
NOTE: Use only Tadiran TL-5903-S 3.6 volt Lithium batteries.(See
How to Install a Battery in the Remote.)
6. Replace the PC board into the casing, battery side down.

Section 50 00-02-0674
04-16-10 - 15 -
7. Trim wires and strip ends approximately 9/32 inch
minimum.
8. Place wire ends in slot and screw down until snug.
NOTE: Make sure wire connects directly to
the J301 terminal without looping the wire
inside casing.
9. Rotate the remote unit clockwise to 90° vertical
position.
10.Repeat steps 1-9 for each additional remote unit. Do
not replace lid until the remote has been activated
and is recognized by the Gateway.
NOTE: The sensor resistance must be less than 25K Ohm. If the sensor
is greater than 25K Ohm, excessive current will reduce battery life.
11.Follow the instructions for “Remote Activation”. Ensure the signal is recognized by the
Gateway before replacing the lid in the next step.
12.Replace the lid. Hand tighten all 4 screws, then tighten-to-snug in a cross pattern to
ensure even seating, as illustrated below.
IMPORTANT! In order to meet NEMA 4 requirements, ensure all 4
screws are used to hold the lid in place.

Section 50 00-02-0674
04-16-10 - 16 -
Learn Operation
NOTE: After performing the Learn Operation, you will want to reset the
heartbeat counters so that accurate statistics can be recorded. Use the
PC to send a command to the Gateway to Reset Heartbeat Counters (see
page 13). This will clear any LED fault lights on the Gateway as well.
NOTE: The remote and Gateway must be a minimum of 2 feet apart at all
times. If the units are placed closer than 2 feet apart, either unit may
experience temporary loss of RF functionality. If this occurs, simply
remove power for at least 30 seconds. Subsequent to powering back up,
verify functionality
NOTE: Fifteen remotes can be added to the network.
NOTE: In the event a remote has been deleted from the network,
subsequently adding a new remote will fill in the next available remote
location. For instance, if remote #3 was removed from a network of eight
remotes, then a new remote will be added as remote #3.
1. Verify the Network Address has been programmed on the Gateway (see page 10).
2. Prepare the Gateway for the Learn Operation (see page 11).
