MUZEN MW-P6I Operational manual

胶装
小王子贴贴音响多语言说明书
80x75mm(成品尺寸)
封面、封底157g,内页80g铜板纸

M
Product user manual
MUZEN DISCO PORTABLE BLUETOOTH SPEAKER
[e-mail]
www.muzenaudio.com

Packing List
Operating Instructions for Host
No. Packing List
Functional guides
It is recommended to carry out the charge for 2h before the first use.
Host × 1
Micro USB Charging cable × 1
Lanyard × 1
User manual × 1
Product certificate × 1
1
2
3
4
5

①
③ ⑥ ④ ⑤ ② ⑨
①蓝牙指示灯
① Bluetooth indicator:
Bluetooth name: MUZEN DISCO
Indicator flashing: The Bluetooth can be connected
Indicator ON: The Bluetooth has been connected
② Power switch:
Power on: Move the slide switch backwards
Power off: Move the slide switch forwards
③ Volume knob:
Volume up: Turn the knob clockwise
Volume down: Turn the knob counterclockwise
Pause/Play: Short press
④ Last Track Button
Last track: Short press
⑤ Next button: Next Track Button
Next track: Short press
Next: Press the button once
Reset the Bluetooth: Long press the last track button and next track button
at the same time for 3s
⑦ Speaker: For music playback. (**Note: Fragile part. Please do not press it hard
⑧ Lanyard loop: For lanyard installation.
⑨ Charging port: For device charge.

Product Features
Hardware Parameters
Warnings/Cautions
① Bluetooth indicator:
Bluetooth name: MUZEN DISCO
Indicator flashing: The Bluetooth can be connected
Indicator ON: The Bluetooth has been connected
② Power switch:
Power on: Move the slide switch backwards
Power off: Move the slide switch forwards
③ Volume knob:
Volume up: Turn the knob clockwise
Volume down: Turn the knob counterclockwise
Pause/Play: Short press
④ Last Track Button
Last track: Short press
⑤ Next button: Next Track Button
Next track: Short press
Next: Press the button once
Reset the Bluetooth: Long press the last track button and next track button
at the same time for 3s
⑦ Speaker: For music playback. (**Note: Fragile part. Please do not press it hard
Music playing anytime and anywhere
The shell of MUZEN DISCO is made of hard metal to achieve stable sound quality in
a palm-like volume and explosive sound effects with a small body, to bring you a
surprising music experiences.
Convenient controls with a retro feel
Adhere to the experiences of MUZEN knob controls and fast Bluetooth connection
to provide you with the auditory feast from music with a simple operation.
Product model: MW-P6I
Product dimension: 86mm (L) × 33mm (W) × 57mm (H)
Bluetooth version: V 4.2
Loudspeaker: φ33mm, 4Ω/3W
Amplifier power: 3W*2
Signal-to-noise ratio: ≥ 70dB
System frequency response: 110Hz-20KHz
MIC use distance: ≤ 0.05m (**Note: under the quiet surrounding environment)
Battery: 800mAh /3.7V
Charging port: Micro USB
Charging voltage: DC 5V 500mA
1.Please use this product in a dry environment.
⑧ Lanyard loop: For lanyard installation.
⑨ Charging port: For device charge.
2.It is not allowed to place this product near any fire source or expose it to any fire source.
3.The product is not waterproof, which must be noticed during use and storage.
4.This product shall be used at an ambient temperature of 0-45℃ and it is recommended not
to use it beyond this temperature range.
5.Do not modify, repair or dismantle this product without authorization.

1.Please use this product in a dry environment.
Consult the dealer or an experienced radio/TV technician for help. Any changes or
modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate this equipment.
SIMPLIFIED EU DECLARATION OF CONFORMITY
Hereby, Shenzhen Airsmart Technology Co., Ltd. Declares that the radio equipment type
MW-Q1I is in compliance with DIRECTIVE 2014/53/EU. The declaration of conformity may be
consulted at our website, accessible form: www.muzenaudio.com
This product can be used across EU member states
For your safety, please read the following instructions carefully and comply with them:
1. The manufacturer reserves the right to modify or adjust the specifications and details of
the product without notifying users.
2. Please use the product in a dry environment wherever possible.
3. The product should not be placed near or in contact with exposed sources of
fire.
4. This product can be used normally with the ambient temperature of 0‒45°C. Do not use it
outside of this range.
5. Do not modify, repair or dismantle this product without authorization, otherwise, no after
sales services available.
Important Notes
6. Note that if the battery is not replaced properly, it may explode. If necessary, please visit a
professional service center.
After replacing the battery, the product will not be covered by the warranty.
2.It is not allowed to place this product near any fire source or expose it to any fire source.
3.The product is not waterproof, which must be noticed during use and storage.
4.This product shall be used at an ambient temperature of 0-45℃ and it is recommended not
to use it beyond this temperature range.
5.Do not modify, repair or dismantle this product without authorization.

Shenzhen Airsmart Technology Co., Ltd
Manufacturer: Shenzhen Airsmart Technology Co., Ltd
Address: Unit 616, Ant's Union Start-up Accelerator, No.9 Keji Road, Science and
Technology Park, Nanshan District, Shenzhen, China
Email: [email protected]
Website: www.muzenaudio.com
