WMF coffee machines planning information 1200 S
http://www.wmf-kaffeemaschinen.de/fachplaner
WMF Group GmbH | Eberhardstraße 35 | 73312 Geislingen (Steige)
Optional: vending unit
Coin Checker 105 mm
Optional feet
100 mm
Optional: pipe for grounds
disposal
70 x 120 x 250 mm
(extension with second pipe
possible)
(incl. Hose nozzle)
Only with fixed water
connection
Optional: cut-out for under
machine cooler milk hose
Optional: cut-out for
grounds through counter
Optional: cut-out 60x80
for lines and hoses (water,
waste water, power)
On site
On site
Length 1m
(Angle valve)
Optional: cut-out for under
machine cooler milk hose
and grounds through counter
Card reader and coin
changer height 500 mm
Coin Checker height 502
mm

µ
WMF coffee machines planning information 1200 S
Conditions for usage and installation
Any necessary on-site preparatory work for electricity, water and drainage connections at the customer‘s premises
is to be arranged by the machine owner / operator. The work must be carried out
by authorised installation technicians in compliance with general, country-specific and local regulations. The
WMF service engineers may only connect the coffee machine to existing prepared
connection points. WMF Service is neither authorised nor responsible for carrying out any on-site installation
work prior to connection.
Dimensions
and empty
weight
Width
Height
Depth
Clearance heights
Weight
324 mm
682 mm
553 mm
59- 169 mm
Approx. 33 - 38 kg (depending on the model)
Water supply
Water supply line
Inlet temperature
Water drain tube
(optional)
3/8 inch hose connector with mains tap, and filter, on site. At least 0.2
MPa (2 bar) flow pressure at 2 l/min (standard). Maximum 0.6 MPa (6
bar).
Maximum 35 °C.
Tube a minimum of DN 19, minimum downward slope
of 2 cm/m
For use at
altitude above
NN
< 2000 m
Electrical data
Nominal power
rating
2.0 –3.4 kW
Power supply
220–240 V 50 / 60 Hz (1 / N / PE)
Degree of
protection
IP X0
Protection Class
I
Installation
Clearance
For operating, service and safety reasons the machine should be installed with a clearance of
not less than 50 mm at the back and sides from the building or non-WMF components.
A minimum working space of 800 mm in front of the coffee machine and 200mm above the
hoppers is recommended.
The height of the installation surface above the floor is at least 850 mm. If the coffee
machine connections are to be run downwards through the counter, please make space
for the lines, which can reduce the usable space below the machine. If the coffee machine is
operated with a water filter the additional space under the machine depending on the filter
size has to be considered. For further information see filter instructions.
Installation
surface /
water spray
The device must be placed and leveled on a horizontal, sturdy, water-resistant, and heatproof
base. The device must not be cleaned using a water jet. The device must be installed where it
is protected against water spray. The device must not be located on a surface that is sprayed
or cleaned with a water hose, steam jets, steam cleaner, or similar devices.
http://www.wmf-kaffeemaschinen.de/fachplaner
WMF Group GmbH | Eberhardstraße 35 | 73312 Geislingen (Steige)

µ
WMF coffee machines planning information 1200 S
Electrical
connection
These specifications for the electrical connection and the standards quoted apply for
connecting the coffee machine in EU countries. It may be necessary to also observe additional
country-specific regulations. Outside the EU countries acceptance of the standards quoted is
to be checked by the legal entity or natural person who wishes to use the coffee machine. The
local power supply must be constructed according to the currently valid IEC 364 (DIN VDE
0100). To improve safety, the device should be fitted with an FI 30 mA earth leakage current
circuit breaker complying with EN 61008. (Type B residual current circuit breakers provide
reliable tripping even if the fault current is smooth. This ensures a high level of safety.) Near
the device or about 30 cm below the counter top there should be a shockproof socket as a
single-phase connection installed locally on the rear or side wall of the counter substructure
or a country-specific single-phase socket. If the mains cable for this device is damaged then it
must be replaced by our service personnel or a similarly qualified person, in order to prevent
hazards.
Important advice regarding accounting systems:
In case of operation with a card reader an additional and separately fuse-protected
shockproof socket must be installed onsite if necessary depending on type of card reader. The
supplier of the card reader is to be asked for the required fuse protection. In order to prevent
possibly occurring disturbances of our screened data lines by potential equalization currents
between the units, an additional potential equalization according to VDE 0800-2 should be
provided for units connected to an accounting system.
Water supply
and drainage
The water supply must be located close to the machine (max. distance 800 mm). An anytime
easily accessible and sufficiently dimensioned water tap (preferably ball tap) as well as a dirt
filter with mesh size 0,080 mm must be installed below the counter in the water supply. If the
coffee machine is connected to a drain connection, a siphon must be installed in the drain
pipe. (Fit hose connection in funnel with hose ring mount.) For connection from below
through the counter a cut-out must be made in the hatched area according to drawing (see
top view). For drinking water with carbonate hardness above 5°dKH (carbonate hardness), a
WMF water filter should be fitted upstream.
Miscellaneous
Ambient
temperature
+5 °C to maximum +35 °C
(empty the water system in case of frost)
Maximum humidity
80 % relative humidity without condensation. Do not use device
outdoors.
Heat dissipation
0.05 kWh/h standby mode
12.045 kWh/h maximum use
Continuous sound
pressure level (Lpa)
< 70 dB(A)
For more information as the instruction manual , safety data sheets and certificates , see:
http://www.servicecenter.wmf.de/
All information refers to coffee machines/ equipment as standard version. Individual solutions can differ from the
standard version.
