Mytee Hot Turbo 240-120 Assembly instructions

Instructions for
240-120 Mytee Hot Turbo™
Please read before use.
Model #
Serial #
Form # ADM-240-120
4-09

BACK
PRESSURE BYPASS
INLET/OUTLET
FRONT
1. Inlet QD-Hooks to extractor
2. Pressure bypass-hooks in-line to vacuum hose
3. Hot water outlet
4. 20 amp power cord
4
3
1
2
Hook bypass up to your vacuum hose so that excess pressure will
be brought back to recovery tank.
SWITCHES
Unit can be run with 1, 2, 3, or 4 heater switches on. Each switch
controls 600 watts of the heater (5 amps).
Hook inlet hose to your extractor, hook outlet to your cleaning tool
or hose.
To Wand To Extractor

Dear Customer:
Congratulations on the purchase of your new 240-120 Mytee Hot Turbo™. As you
are already aware, the scene of the equipment world is becoming more high tech,
and we at Mytee Products Inc. strive to keep you on the cutting edge with superior
quality and technology.
Keep in mind that the 240-120 Mytee Hot Turbo™ is an electric appliance, so neglect
or abuse will cause unnecessary damage and void the warranty. However with sim-
ple maintenance the 240-120 will give quality performance for many years to come.
If warranty questions arise, please consult your user manual or get in touch with
your distributor. If you have questions about maintenance, replacing parts or
ordering parts, please call an authorized Mytee Products Inc. Service Center.
To see an updated list, visit our website at www.mytee.com
Before you begin using, please read your manual thoroughly.
Sincerely,
Mytee Customer Care Dept.
Grounding Instructions
This machine must be grounded. If it should malfunction or breakdown, grounding
provides a path of least resistance for electrical shock. This machine is equipped
with a cord having an equipment-grounding conductor and grounding plug. The plug
must be plugged into an appropriate outlet that is properly installed in accordance
with all local code and ordinances. Do not remove ground pin; if missing, replace
plug before use.
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualied electrician or service person if you are in doubt
as to whether the outlet is properly grounded. Do not modify the plug provided with
the machine. If it will not t the outlet, have a proper outlet installed by a qualied
electrician.
This appliance is for use on a nominal 120-volt circuit, and has a grounding plug
that looks like the plug illustrated in Figure 1 below. A temporary adapter illustrated
in Figures 2 and 3 may be used~to connect this plug to a 2-pole receptacle as
shown in Figure 2 if a properly grounded outlet is not available. The temporary
adapter should be used only until a properly grounded outlet (Figure 1) can be
installed by a qualied electrician. The green colored rigid ear, tab or the like
extending from the adapter must be connected to a permanent ground such as a
properly grounded outlet box cover. Whenever the adapter is used, it must be held
in place by a metal screw. Grounding adapters are not approved for use in Canada.
Replace the plug if the grounding pin is damaged or broken.
The Green (or GreenYellow) wire in the cord is the grounding wire. When replacing
a plug, this wire must be attached to the grounding pin only.
DO NOT use extension cords.
Please Note for America use only
Parts and Service
Repairs, when required, should be performed by Mytee service personnel or Mytee
authorized Service Center using Mytee original replacement parts and accessories.
Call Mytee for repair parts or service. Please specify the Model and Serial Number
when discussing your machine.
Name Plate
The Model and Serial Number of your machine are shown on the Nameplate on the
back panel of the machine. This information is needed when ordering repair parts
for the machine. Use the space provided on the front cover to note the Model and
Serial Number of your machine for future reference.
Unpacking the Machine
When the machine is delivered, carefully inspect the shipping carton and the
machine for damage. If damage is evident, save the shipping carton so that it can
be inspected by the carrier that delivered it. Contact the carrier immediately to le a
freight damage claim.
Caution and Warnings
Symbols
Mytee uses the symbols below to signal potentially dangerous conditions. Always
read this information carefully and take the necessary steps to protect personnel
and property.
Is used to warn of immediate hazards that will cause severe personal injury or death.
Is used to call attention to a situation that could cause severe personal injury.
Is used to call attention to a situation that could cause minor personal injury or
damage to the machine or other property. When using an electrical appliance, basic
precautions should always be followed, including the following: Read all instructions
before using this machine. This product is intended for commercial use only.
To reduce the risk of re, electrical shock, or injury:
1. Read all instructions before using equipment.
2. Use only as described in this manual. Use only manufacturer’s recommended attachments.
3. Always unplug power cord from electrical outlet before attempting any adjustments
or repairs.
4. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
5. Do not pull or carry by cord. Do not close a door on cord or pull cord around sharp
edges or corners.
6. Do not run appliance over cord. Keep cord away from heated surfaces.
7. Do not use with damaged cord or plug. If cord is damaged, repair immediately.
8. Do not use outdoors or on wet surfaces and or standing water.
9. Always unplug or disconnect the appliance from power supply when not in use.
10. Do not allow to be used as a toy. Close attention is necessary when used by or
near children.
11. Do not use in areas where ammable or combustible material may be present.
12. Do not leave the unit exposed to harsh weather elements. Temperatures below
freezing may damage components and void warranty.
13. Use only the appropriate handles to move and lift unit. Do not use any other parts
of this machine for this purpose.
14. Keep hair, loose clothing, ngers, and all parts of the body away from all
openings and moving parts.
15. Use extra care when cleaning on stairs.
16. To reduce the risk of re or electric shock, do not use this machine with a solid-
state speed control device.
17. The voltage and frequency indicated on the name plate must correspond to the
wall receptacle supply voltage.
18. When cleaning and servicing the machine, local or national regulations may apply
to the safe disposal of liquids which may contain: chemicals, grease, oil, acid, alka-
lines, or other dangerous liquids.
19. Do not leave operating unattended.
Operating Instructions
1. All switches in OFF position on both the extractor and Mytee Hot Turbo™.
2. Fill extractor with preferred solution.
3. Connect male quick disconnect of Mytee Hot Turbo™ to the female quick discon-
nect of the extractor.
4. Connect male quick disconnect of the solution hose assembly to the female quick
disconnect of the Mytee Hot Turbo™.
5. Turn pump to ON position.
6. Engage trigger to dispense solution throughout extractor and Mytee Hot Turbo™
until the water ow is sufcient.
7. Turn Mytee Hot Turbo™ switches to the on position (please keep in mind that each
switch pulls approximately 5 amps).
8. Please allow for a 5-10 minute Preheat cycle to obtain maximum heat
9. In the event of dramatic heat loss allow Mytee Hot Turbo™ to Reheat for
1-3 minutes.
10. Temperatures may vary depending on Pump (pressure and GPM) and Jets
(quantity and orice size).
Figure 1
Grounding Pin
Grounded Outlet
Grounded Outlet Box
Adapter
Tab for Grounding
Screw
Metal
Screw
Figure 2 Figure 3

After Use
1. Unplug.
2. Inspect hose and replace if damaged.
3. Inspect power cord and replace if damaged.
4. Store the machine in a clean, dry place.
Maintenance Schedule
Maintenance item Daily Once a week
Clean and inspect Hoses and Fittings.
Check power supply cable.
Clean machine with all purpose cleaner and cloth.
Flush solution system with Mytee system maintainer.
x
x
x
x
Trouble Shooting
There is no power.
1. Plug machine in proper outlet.
2. Check circuit breaker; reset circuit breaker, other items should not run on the
same circuit as machine. Outlet must be a 20-amp circuit.
Water does not ow through unit.
1. Snap quick disconnects rmly together.
2. Check your solution tank; may be empty.
3. Jets clogged, remove jet and ush clean.
4. Filters clogged, remove lters and rinse clean with water.
5. Heater is blocked; ush out with Mytee’s system maintainer.
Heater does not work properly.
1. If sensor mounted on the heater has popped, reset sensor by pushing in button.
2. Heating element may need to be replaced.
FAQs
Q: How much does the 240-120 weigh and what are the shipping dimensions?
A: 25 Pounds - Box dimensions are 14” x 14” x 14”. Must ship motor freight.
Q: Where do I plug the machine in?
A: The 240-120 requires a 20A grounded circuit. Please note: GFI outlets may trip
before the breaker setting.
Q: What is the proper pre heat cycle for the 240-120?
A: Turn pump on and prime pump through the solution hose and the heater. Then
turn the heater to the on position. Let the heater sit idle for 8-10 minutes. Spray tool
until you feel the hot water from the jet. Let heater sit idle for an additional 3-5
minutes. This will insure the water in the heater and hoses will be at the hottest point
to start cleaning.
Q: Is there anything I can do to increase the expected life of my heater?
A: You should run a System Maintainer through the system to keep the hoses and
heater clean and free of debris.
Warranty
MYTEE LIFETIME LIMITED WARRANTY POLICY
Mytee Products, Inc. endeavors to provide high quality products and product support
to its customers and therefore backs up all of its new products purchased from Mytee
Products Inc. (“Mytee”) or any authorized Mytee distributor/service center with this
lifetime limited warranty. This limited warranty begins on the date of the customer’s
purchase and is valid and available to the original purchaser with proof of purchase,
and is not transferable. Mytee’s products are for commercial use only and are not
intended for personal, family or household uses.
HOUSING LIMITED LIFETIME WARRANTY: Mytee warrants for life that its rotation-
ally-molded housings will be free from manufacturing defects. This warranty covers
the cost of replacement or repair only and does not cover shipping or labor costs.
WEAR PARTS 90-DAY LIMITED WARRANTY: Mytee will replace all wear parts for
90 days from the date of original purchase. “Wear parts” are items which wear out
as a result of usage or the passage of time and are consumed despite attempts to
maintain them, such as gaskets, wheels, brass, cords, wires, electrical terminals,
hoses, switches, thermostats, plastisol parts, lters, bearings, brushes, solenoids, o-
rings, bulbs, heating elements, castors, or other parts deemed wear items in Mytee’s
sole discretion. This warranty covers the cost of replacement only and does not cover
shipping or labor costs.
PUMP, VACUUM MOTOR AND HEATER TWO-YEAR LIMITED WARRANTY: Mytee
warrants that pumps, vacuum and oor machine motors, and heaters will be free
from manufacturing defects, defects in workmanship, and defects in material for two
(2) years from the date of original purchase. This warranty does not apply and is void
if the pump, vacuum motor, or heater has worn brush motors, water damage, chemi-
cal build-up, chemical damage, or evidence of abuse, neglect or tampering. This
warranty covers the cost of replacement or repair only and does not cover shipping
or labor costs.
HOWEVER, OTHER THAN SET FORTH HEREIN, MYTEE GIVES NO WARRANTY,
EXPRESS OR IMPLIED, AS TO DESCRIPTION, QUALITY, MERCHANTABILITY,
FITNESS FOR ANY PARTICULAR PURPOSE, PRODUCTIVENESS, INFRINGE-
MENT, OR OTHER MATTER, OF ANY GOODS WHICH MYTEE SHALL SUPPLY.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION
ON THE FACE HEREOF. MYTEE SHALL IN NO WAY BE RESPONSIBLE FOR THE
PROPER USE AND APPLICATION OF THE GOODS. MYTEE NEITHER ASSUMES
NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR MYTEE ANY OTHER
LIABILITY IN CONNECTION WITH THE SALE OF MYTEE’S GOODS. THIS LIM-
ITED WARRANTY POLICY MAY BE CHANGED OR WITHDRAWN BY MYTEE AT
ANY TIME WITHOUT NOTICE.
LIMITATION OF DAMAGES: THE REMEDY OF REPLACEMENT OR REPAIR
OF ANY DEFECTIVE GOODS SHALL BE THE EXCLUSIVE REMEDY UNDER
ANY WARRANTY MADE BY MYTEE, WHETHER EXPRESS OR IMPLIED. IN NO
EVENT SHALL MYTEE BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES, PROPERTY DAMAGES, OR PERSONAL INJURIES.
All limited warranties are void for, and Mytee does not warrant in any way, any prod-
uct that evidences misapplication, improper installation, abuse, lack of maintenance,
negligence in use or care, abnormal use, alteration of design, modication, use of
incompatible or corrosive chemicals, use in a rental service, and/or servicing, installa-
tion of parts, or repairs by anyone other than Mytee or a Mytee authorized distributor
or service center. Mytee may make changes in products it manufactures and markets
at any time; these changes are made without obligation to change, retrot, or up-
grade any product previously sold or manufactured.
Mytee has no obligation to honor the limited warranties set forth herein unless the
original purchaser, promptly upon discovering the warranty claim and prior to continu-
ing to use the product, contacts Mytee or a Mytee authorized distributor or service
center to describe the claim and to receive and follow instructions for documenting
and resolving the claim. In addition, the purchaser must provide the product to which
the claim applies to Mytee or a Mytee authorized distributor or service center for a
thorough inspection. In addition, the purchaser must provide/return the product intact,
unmodied, with all of its original parts.
If any provision or portion of this limited warranty policy is found to be unenforceable,
then the remaining provisions and portions shall remain valid and enforceable.
If any provision or portion of this limited warranty policy is found to be limited by law,
then that provision or portion shall be construed to make it effective within the
bounds of law. For example, if there are legal limitations on the duration of warran-
ties, the warranties made herein shall be construed to have the minimum duration
required by law, or, if there are legal limitations of exclusion of remedies, the exclu-
sions made herein shall be construed to apply to the fullest extent possible without
violating the law.
The validity, construction and performance of this warranty policy shall be governed
by the laws of the State of California, without respect to conicts of laws principles.
The exclusive jurisdiction of any legal action arising from or related to this warranty
policy shall be in the State of California and no legal action shall be commenced
elsewhere.
Return Material Authorization Procedure
It is the responsibility of any Authorized Service Center (ASC) or Distributor with
written authorization to ensure the Customers equipment is repaired as soon as
possible. Only Mytee Products Inc. or it’s authorized dealers with written authoriza-
tion, service centers, and agents may make warranty repairs on these products. All
others do so at their own risk and expense.
The Distributor must follow Mytee Products, Inc. standard RMA procedure:
1. When a repair falls within the Warranty time period for a piece of equipment, the
Distributor will ll out a RMA/Warranty claim form. This form will act as a repair order
to replace any defective parts.
2. All defective parts must be returned to Mytee Products, Inc. with the RMA/claim
form for evaluation at the customer’s expense. This shipping is non-refundable. All
warranty claims are subject to an evaluation by Mytee Products, Inc. to determine if
warranty will be approved. Any credit for repair and/or parts will only be issued upon
evaluation and approval from Mytee Products, Inc.
3. When Warranty is approved, the Distributor’s account will be credited for the
replacement part(s). Mytee Products, Inc. will ship the warranted replacement part(s)
to the Distributor prepaid. If Warranty is denied the Distributor’s account will not be
credited for any parts sent for this claim.
