3) CM: Camera Mode
LED Status
Blue STOP/READY Mode:
Status just after boot up or completion of recording, or stop/still in playback.
White
VIEW Mode:
The imager is outputting image signal while the last recording image data is kept in
the memory.
Magenta
ARM Mode:
The imager is outputting image signal that is being recorded (overwritten) to the
memory.
Red
REC Mode:
The imager is outputting image signal that is being recorded to the memory after
detecting the trigger signal.
Off Power off or booting up.
4) PW: Power
LED Status
Green Power is on and the camera is in normal state.
Red
Power is on but the camera is in abnormal state.
(in case of malfunctioned, power failure (over/low voltage), over
temperature on the sensor)
Off Power is off.
5) MB: Memory Backup
It indicates amount of the battery and backup status by combination of color and on/blinking/off.
Battery Amount
LED Amount
Red Short
Orange Intermediate
Green Full
Note: Please supply the power to the camera if the LED turns to Red from Orange during the
memory backup otherwise the image data in the memory will be lost.
Backup Status
LED Backup Status
On Backup by an external power supply.
Blinking Backup by the built-in battery.
Off Backup is not activated.
Note: Memory backup is not activated if there is no data in the memory.
