Owner’s Manual
C565BEE
Compact Disc Player
SAVE THESE INSTRUCTIONS FOR LATER USE.
FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE
AUDIO EQUIPMENT.
1 Read instructions - All the safety and operating instructions should be
read before the product is operated.
2 Retain instructions - The safety and operating instructions should be
retained for future reference.
3 Heed Warnings - All warnings on the product and in the operating
instructions should be adhered to.
4 Follow Instructions - All operating and use instructions should be
followed.
5 Cleaning - Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
6 Attachments - Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
7 Water and Moisture - Do not use this product near water-for example,
near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet
basement; or near a swimming pool; and the like.
8 Accessories - Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing serious injury to
a child or adult, and serious damage to the product. Use only with a
cart, stand, tripod, bracket, or table recommended by the manufacturer,
or sold with the product. Any mounting of the product should follow
the manufacturer’s instructions, and should use a mounting accessory
recommended by the manufacturer.
9 A product and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces may
cause the product and cart combination to overturn.
10 Ventilation - Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the product and to
protect it from overheating, and these openings must not be blocked
or covered. The openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface. This product should
not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s instructions have
been adhered to.
11 Power Sources - This product should be operated only from the type
of power source indicated on the marking label. If you are not sure of
the type of power supply to your home, consult your product dealer or
local power company.
The primary method of isolating the amplier from the mains supply
is to disconnect the mains plug. Ensure that the mains plug remains
accessible at all times. Unplug the AC power cord from the AC outlet if
the unit will not be used for several months or more.
12 Grounding or Polarization - This product may be equipped with a
polarized alternating-current line plug (a plug having one blade wider
than the other). This plug will t into the power outlet only one way.
This is a safety feature. If you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug should still fail to t, contact
your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
13 Power - Cord Protection - Power-supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the product.
14 Outdoor Antenna Grounding - If an outside antenna or cable system
is connected to the product, be sure the antenna or cable system is
grounded so as to provide some protection against voltage surges
and built-up static charges. Article 810 of the National Electrical Code,
ANSI/NFPA 70, provides information with regard to proper grounding
of the mast and supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding conductors, location
of antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer’s attention to Section
820-40 of the NEC which provides guidelines for proper grounding and, in
particular, species that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
15 Lightning - For added protection for this product during a lightning
storm, or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the antenna or
cable system. This will prevent damage to the product due to lightning
and power-line surges.
16 Power Lines - An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or power circuits,
or where it can fall into such power lines or circuits. When installing an
outside antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them might be
fatal.
17 Overloading - Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a risk of re or
electric shock.
18 Object and Liquid Entry - Never push objects of any kind into this
product through openings as they may touch dangerous voltage points
or short-out parts that could result in a re or electric shock. Never spill
liquid of any kind on the product.
WARNING: THE APPARATUS SHOULD NOT BE EXPOSED TO
DRIPPING OR SPLASHING, AND OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHOULD NOT BE PLACED ON THE APPARATUS.
AS WITH ANY ELECTRONIC PRODUCTS, USE CARE NOT TO SPILL
LIQUIDS INTO ANY PART OF THE SYSTEM. LIQUIDS CAN CAUSE A
FAILURE AND/OR A FIRE HAZARD.
IMPORTANT SAFETY INSTRUCTIONS
2
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ
19 Damage Requiring Service - Unplug this product from the wall outlet
and refer servicing to qualied service personnel under the following
conditions:
a) When the power-supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions as an improper adjustment of other controls
may result in damage and will often require extensive work by a
qualied technician to restore the product to its normal operation.
e) If the product has been dropped or damaged in any way.
f) when the product exhibits a distinct change in performance-this
indicates a need for service.
20 Replacement Parts - When replacement parts are required, be
sure the service technician has used replacement parts specified
by the manufacturer or have the same characteristics as the
original part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
21 Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
22 Wall or Ceiling Mounting - The product should be mounted to a wall
or ceiling only as recommended by the manufacturer.
23 Heat - The product should be situated away from heat sources such as
radiators, heat registers, stoves or other products (including ampliers)
that produce heat.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
CAUTION
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
CAUTION
The C 545BEE employs a Laser System. To ensure proper use of this product,
please read this owner’s manual carefully and retain for future reference.
Should the unit require maintenance, contact an authorized service
location. Use of controls, adjustments or the performance of procedures
other than those specied may result in exposure to laser radiation. To
prevent direct exposure to laser beam, do not try to open the enclosure.
Visible laser radiation when the enclosure is opened.
DO NOT STARE INTO BEAM.
FCC NOTICE
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try
to correct the interference by one or more of the following measures
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING
Changes or modications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
INDUSTRY CANADA REQUIREMENT
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN
AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER
TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE”
WITHIN THE PRODUCT’S ENCLOSURE THAT MAYBE OF
SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC
SHOCK TO PERSONS.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS
INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT
OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN
THE LITERATURE ACCOMPANYING THE APPLIANCE.
The equipment draws its nominal non-operational power from the AC
outlet with its POWER switch in the STANDBY position.
The socket-outlet shall be installed near the apparatus and shall be easily
accessible.
TO COMPLETELY DISCONNECT THIS APPARATUS FROM THE AC
MAINS, DISCONNECT THE POWER SUPPLY CORD PLUG FROM THE
AC RECEPTACLE.
THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN
READILY ACCESSIBLE.
CAUTION
Changes or modications to this equipment not expressly approved by
NAD Electronics for compliance could void the user’s authority to operate
this equipment.
CAUTION REGARDING PLACEMENT
To maintain proper ventilation, be sure to leave a space around the unit
(from the largest outer dimensions including projections) that is equal to or
greater than shown below.
Left and Right Panels: 10 cm
Rear Panel: 10 cm
Top Panel: 50 cm
IMPORTANT SAFETY INSTRUCTIONS
3
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ
INFORMATION ABOUT COLLECTION AND DISPOSAL OF
WASTE BATTERIES DIRECTIVE 2006/66/EC OF THE EUROPEAN
PARLIAMENT AND THE COUNCIL OF EUROPEAN UNION FOR
EUROPEAN CUSTOMERS ONLY
Batteries bearing any of these symbols indicate
that they should be treated as“separate
collection”and not as municipal waste. It is
encouraged that necessary measures are
implemented to maximize the separate
collection of waste batteries and to minimize the
disposal of batteries as mixed municipal waste.
End-users are exhorted not to dispose waste
batteries as unsorted municipal waste. In order
to achieve a high level of recycling waste batteries, discard waste batteries
separately and properly through an accessible collection point in your
vicinity. For more information about collection and recycling of waste
batteries, please contact your local municipality, your waste disposal service
or the point of sale where you purchased the items.
By ensuring compliance and conformance to proper disposal of waste
batteries, potential hazardous eects on human health is prevented and
the negative impact of batteries and waste batteries on the environment
is minimized, thus contributing to the protection, preservation and quality
improvement of the environment.
NOTES ON ENVIRONMENTAL PROTECTION
At the end of its useful life, this product must not be disposed
of with regular household waste but must be returned to a
collection point for the recycling of electrical and electronic
equipment. The symbol on the product, user’s manual and
packaging, point this out.
The materials can be reused in accordance with their markings. Through
re-use, recycling of raw materials or other forms of recycling of old
products, you are making an important contribution to the protection of
our environment. Your local administrative oce can advise you of the
responsible waste disposal point.
WARNING!
Batteries (battery pack or batteries installed) must not be exposed to
excessive heat such as sunshine, re or the like.
NOTE: THE C 565BEE IS NOT AN AUTO VOLTAGE CD PLAYER.
CONNECT ONLY TO THE PRESCRIBED AC OUTLET, I.E., 120V 60HZ
OR 230V 50HZ.
RECORD YOUR MODEL NUMBER NOW, WHILE YOU CAN SEE IT
The model and serial number of your new C 565BEE are located on the
back of the cabinet. For your future convenience, we suggest that you
record these numbers here:
Model no. : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Serial no. : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IMPORTANT SAFETY INSTRUCTIONS
NAD is a trademark of NAD Electronics International, a division of Lenbrook Industries Limited
Copyright 2009, NAD Electronics International, a division of Lenbrook Industries Limited
4
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ
INTRODUCTION
TABLE OF CONTENTS
THANK YOU FOR CHOOSING NAD.
The C 565BEE CD Player is a technologically advanced and highly capable
product — yet we have invested great eort in making it simple and easy
to use. We have been careful to ensure that the C 565BEE is as musically
transparent and spatially accurate as possible, incorporating much of what
we’ve learned from a quarter-century’s experience designing audio, video
and home-theater components. As with all our products, NAD’s “Music First”
design philosophy guided the C 565BEE’s design in such a way that it can
condently promise you state-of-the-art audiophile-quality music listening
for years to come.
We encourage you to take a few minutes now to read right through this
manual. Investing a little time here at the outset might save you a good
deal of time later, and is by far the best way to ensure that you make the
most of your investment in the C 565BEE.
One more thing: We urge you to register your C 565BEE ownership on the
NAD Worldwide Web site:
http://NADelectronics.com/warranty
For warranty information contact your local distributor.
IMPORTANT SAFETY INSTRUCTIONS .........................2
INTRODUCTION
GETTING STARTED ...............................................6
UNPACKING AND SETUP .............................................6
QUICK START .........................................................6
IDENTIFICATION OF CONTROLS
FRONT PANEL....................................................7
REAR PANEL .....................................................9
CD 9 REMOTE CONTROL.........................................10
OPERATION
USING THE C 565BEE – CD MODE ................................11
CDR AND CDRW AUDIO DISCS ................................... 11
PLAYING MP3/WMA FILES .......................................... 11
PROGRAMMING .................................................... 11
USING THE C 565BEE – USB AND OPTICAL INPUT MODE ..........12
USB MODE ......................................................... 12
OPTICAL INPUT MODE ............................................. 12
USING THE C 565BEE – CD 9 REMOTE CONTROL ..................13
NUMERIC KEY PAD ................................................. 13
RPTAB............................................................. 13
DIM ................................................................ 13
PROGRAM AND CLEAR ............................................. 13
FILTER.............................................................. 13
REFERENCE
TROUBLESHOOTING ............................................14
NOTES ON DISCS................................................14
SPECIFICATIONS ................................................15
5
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ
INTRODUCTION
GETTING STARTED
UNPACKING AND SETUP
WHAT’S IN THE BOX
Packed with your C 565BEE you will nd:
• An audio cable connector
• The CD 9 remote control with two AA batteries
• A detachable AC power cord
• This owner’s manual (This owner’s manual version in CD-ROM).
SAVE THE PACKAGING
Please save the box and all of the packaging in which your C 565BEE
arrived. Should you move or otherwise need to transport your C 565BEE,
this is by far the safest container in which to do so. We’ve seen too many
otherwise perfect components damaged in transit for lack of a proper
shipping carton, so please: Save that box!
CHOOSING A LOCATION
Choose a location that is well ventilated (with at least several inches to
both sides and behind), and that will provide a clear line of sight, within
23 feet/7 meters, between the C 565BEE’s front panel and your primary
listening/viewing position. This will ensure reliable infrared remote control
communications. The C 565BEE generates a modest amount of heat, but
nothing that should trouble adjacent components. It is perfectly possible to
stack the C 565BEE on top of other components.
NOTE ON INSTALLATION
IMPORTANT! Install the C 565BEE Compact Disc player on a level, vibration-
free surface. Severe vibration or operation in a tilted position may cause
the player to mis-track. The player may be stacked with other stereo
components, as long as there is adequate ventilation around it. If the
C 565BEE is placed in close proximity to a radio tuner (AM or FM), a VCR or
a television set, the operation of its digital circuits may produce static that
would interfere with reception of weak broadcast signals. If this occurs,
move the C 565BEE away from other devices or switch it o when viewing
or listening to broadcasts.
QUICK START
In case you simply cannot wait to experience the performance of your new
NAD C 565BEE, we provide the following“Quick Start” instructions to get
you underway.
Please make all the connections to your C 565BEE with the unit unplugged.
It is also advisable to power down or unplug all associated components
while making or breaking any signal or AC power connections.
PLAY A CD
1 Connect a twin RCA-to-RCA lead from the L (left) and R (right) Line
Output jacks to the corresponding CD inputs on your amplier.
2 Connect the AC cord to the C 565BEE’s AC Mains input and then plug
into an AC outlet. The Standby LED indicator embedded around the
bezel of the STANDBY button will illuminate amber.
3 Press the STANDBY button to turn ON the player. The Standby LED
indicator will turn from amber to blue and illuminate the Vacuum
Fluorescent Display (VFD).
4 Press [STOP/OPEN] to open the disc drawer.
5 Place a CD, label side up, in the tray’s circular recess. Be certain that the
disc is centered within the recess.
6 Press [PLAY/PAUSE/SKIP]. The drawer closes automatically, and the disc
begins to play.
7 At any time you may rotate the [PLAY/PAUSE/SKIP] knob to select
dierent tracks on the disc.
8 Press [PLAY/PAUSE/SKIP] if you want to stop play temporarily while
keeping the pickup at its current position on the disc. Press [PLAY/
PAUSE/SKIP] again when you want to resume playback. Press [STOP/
OPEN] if you want to end play and reset the pickup to the beginning of
the disc.
6
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ
IDENTIFICATION OF CONTROLS
FRONT PANEL
1 STANDBY BUTTON: Press this button to switch ON the C 565BEE. The
Standby LED indicator will turn from amber to blue and illuminate the
Vacuum Fluorescent Display (VFD). Pressing the Standby button again
turns the unit back to standby mode.
The C 565BEE can also be switched ON from standby mode by pressing
[PLAY/PAUSE/SKIP] knob on the front panel. Pressing CD 9’s [ON], [ ] or
[ ] buttons will also wake up the C 565BEE from standby mode.
If the disc tray is open and the Standby button is pressed, the disc tray
will draw close and the C 565BEE goes to standby mode.
NOTE
The C 565BEE will wake up from standby mode at the same SOURCE
setting it was in prior to being switched OFF to standby mode.
2 STANDBY LED: This indicator will light up amber when the C 565BEE
is at standby mode. When the C 565BEE is at ON state, this indicator will
illuminate blue.
3 DISC TRAY: With the disc tray open, insert a CD or other compatible
media disc face down onto the tray. Place the disc in the drawer,
centered in the smaller circular recess, with its label facing UP.
“No Disc” appears on the C 565BEE’s VFD if the disc is placed upside
down or there is no disc loaded.
NOTE
This player is not designed to accommodate neither a “damping disc”
placed on a CD nor two CDs stacked together. It plays audio CDs, but not
discs identied as CD-V, DVD, CD-I, CD-ROM or PHOTO CD. Refer also to
the item “CD-R AND CD-RW AUDIO DISCS” at the “USING THE C 565BEE
– CD MODE” section of the “OPERATION” page.
4 STOP/OPEN: This dual-function button alternates between stopping
playback and opening/closing the disc tray. Press this button to open
and close the disc tray. Pressing this button during disc playback will
cause the C 565BEE to stop playback; press again to open the disc tray.
Press [STOP/OPEN] button once to stop playback and re-set the
pickup to the beginning of the disc. The display reverts to showing
the number of tracks and total playing time on the disc; for WMA/MP3
les, the display will revert to total number of les. If the C 565BEE was
programmed to play a selection of tracks, the program will be retained
in the player’s memory. Pressing [STOP/OPEN] twice at program mode
will delete the program.
Repeat and Random playback mode can be disengaged by pressing
the [STOP/OPEN] button.
5 SOURCE: Toggle this button to select through the following SOURCE
modes - CD, USB and OPTICAL INPUT. A corresponding icon (CD, USB or
OPTICAL) will illuminate in the VFD as the applicable SOURCE is selected
or comes up during selection.
6 SRC (SAMPLE RATE CONVERTER): Sample rate converter (SRC)
enables the conversion of the sampling rate of a data stream from a
specic sampling rate to another sampling rate. By selecting a higher
SRC level, the upsampling of data stream could make, for example, a
“standard” CD to have the enhanced audio clarity, richness and dynamic
range that would normally be associated with SACD or DVD-Audio
discs. Source components (through the front USB port and rear panel
optical input) enjoy the same superb quality converter as the CD signal.
Toggle this button to select desired SRC level - “SRC 96”, “SRC 192” or
“SRC OFF”. The VFD will display these SRC settings during selection and
a corresponding icon “SRC 96” or “SRC 192” will be illuminated in the
VFD when either setting is selected. Select “SRC OFF” to keep the native
sampling rate of the disc or source.
1 2 3 4 5 6 7 8 9 12
1413
10 11
7
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ
7 RANDOM: This button when pressed will engage or disengage
random playback mode. When engaged (a corresponding “RANDOM”
icon is illuminated in the VFD), random playback of tracks or les will
begin by pressing [PLAY/PAUSE/SKIP] from STOP mode or rotating
[PLAY/PAUSE/SKIP] during playback mode. Press [RANDOM] again to
return to normal playback (“RANDOM”icon in the VFD is extinguished).
Random playback mode can also be disengaged by pressing [STOP/
OPEN] button.
The Random playback mode can be used in combination with the
Repeat Play All mode but not with Program playback mode.
8 REPEAT: A particular track or le can be repeatedly played back by
pressing this button. Toggle this button to repeat a track/le, folder, all
tracks or all les. Corresponding icons like REPEAT, REPEAT FOLDER, or
REPEAT ALL will be illuminated in the VFD as the particular repeat mode
is selected. Turn o repeat mode by pressing the REPEAT button until
the REPEAT icon is extinguished in the VFD.
9 DISPLAY: Toggle to display the following disc information during
playback
INFORMATION AUDIO CD CD TEXT MP3/WMA
Elapsed time of the current track -
Remaining time of the current track -
Total playback time of the disc -
Remaining time of the disc -
Song title -
Artist name -
Album name -
File name - -
Elapsed time of the current le - -
File number of the current le with
respect to the total number of les
under the current folder
--
NOTES
• Some information may not be displayed on some discs. Display is
dependent on the disc’s information content.
• If the le has no available information about the song title, artist or
album, the display will show “NO TITLE”, “NO ARTIST” or “NO ALBUM”.
10 SCAN [ ]: Press and hold [ ] for more than 2 seconds
to search up or down a track/le. The SCAN [ ] button causes the
optical pickup to scan backwards through the recording at high speed.
The SCAN [ ] button causes the optical pickup to scan rapidly
forward through the music.
11 USB INPUT: Connect a USB device into this input.
12 PLAY/PAUSE/SKIP: This control knob has three functions – PLAY,
PAUSE and SKIP [ ].
PLAY/PAUSE: Press this knob to toggle between Play and Pause of
a CD or other compatible media disc. Press to start play or resume
play after Pause. The icon “ ” is illuminated in the VFD indicating the
C 565BEE is in playback mode. If the disc tray is open, press this button
to automatically close the tray and start playback if a disc is loaded.
During playback, press this button to stop playback temporarily,
keeping the optical pickup at its current position on the disc. The
icon “ ”is illuminated in the VFD indicating the C 565BEE is in pause
mode. To resume playback at the exact point where it stopped, press
[PLAY/PAUSE/SKIP] again.
SKIP [ ]: Rotate this knob clockwise to SKIP forward a track/
le. Rotate it counterclockwise to SKIP backward to the beginning of the
current track/le or previous track/le.
13 VFD: The Vacuum Fluorescent Display (VFD) provides playback
information, settings and other indicators.
14 REMOTE SENSOR: Point the CD 9 at the remote sensor and press the
buttons. Do not expose the remote sensor of the CD 9 to a strong light
source such as direct sunlight or illumination. If you do so, you may not
be able to operate the C 565BEE with the remote control.
Distance: About 23ft (7m) from the front of the remote sensor.
Angle: About 30o in each direction of the front of the remote sensor.
IDENTIFICATION OF CONTROLS
FRONT PANEL
8
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ
IDENTIFICATION OF CONTROLS
REAR PANEL
1 LINE OUT: Connect to the corresponding analog audio input of an
amplier, receiver or stereo system.
2 RS232: Connect this interface via RS-232 serial cable (not supplied) to
any Windows® compatible PC to allow remote control of the C 565BEE
through NAD’s proprietary PC software or other compatible external
controllers. NAD is a certied partner of AMX and Crestron and fully
supports these external devices. See your NAD audio specialist for more
information.
3 DIGITAL AUDIO IN (OPTICAL): Connect to the optical S/PDIF-
format digital output of sources such as CD or DVD players, and other
compatible components.
4 DIGITAL OUT (COAXIAL, OPTICAL): The digital playback audio
output signal is available at these ports. Connect the optical or coaxial
digital OUT ports to the corresponding S/PDIF digital input of an
amplier, receiver, computer soundcard or other digital processors.
5 +12V TRIGGER IN: This input allows the C 565BEE to be switched
remotely to standby and ON by ancillary equipment, such as an
amplier, preamp, AV processor, etc. The controlling device must be
equipped with a 12 V trigger output to use this feature. Connect this
+12V-trigger input to the remote component’s corresponding +12V DC
output jack using a mono cable with 3.5mm male plug.
WARNING
If the male plug of the mono cable (with or without +12V DC) is
connected to C 565BEE’s +12V TRIGGER IN, the Standby button in the
front panel as well as the corresponding ON/OFF function keys in the
remote control will be disabled. Unplug the mono cable to maintain
normal power ON/OFF function procedures.
6 IR IN: This input is connected to the output of an IR (infrared) repeater
(Xantech or similar) or the IR output of another component to allow
control of the C 565BEE from a remote location.
7 AC MAINS INPUT: The C 565BEE comes supplied with a separate AC
Mains cable. Before connecting the cable to a live wall socket ensure that
it is rmly connected to the C 565BEE’s AC Mains input socket rst. Always
disconnect the AC Mains cable plug from the live wall socket rst, before
disconnecting the cable from the C 565BEE’s Mains input socket.
ATTENTION!
Please make all the connections to your C 565BEE with the unit unplugged. It is also advisable to power down or unplug all associated components while
making or breaking any signal or AC power connections.
2 3 4 5 6 71
9
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ
IDENTIFICATION OF CONTROLS
CD 9 REMOTE CONTROL
BATTERY ASSEMBLY
Press in and lift tab to remove battery cover out
of recess.
Press batteries into opening. Ensure correct
tting is observed.
Replace battery cover by aligning and inserting
the two tabs into the holes. Press battery cover
into place until it “clicks”closed.
ON: Switch ON C 565BEE.
CD: Select CD as the active source.
USB: Select USB as the active source.
OPT: Select optical input as the active source.
SRC: Toggle to select desired SRC mode.
FOLDER [ ] : Select through folder lists.
FILE [ ] : Select through WMA/MP3 les.
ENTER: Select desired folder or WMA/MP3 le.
[ ]: Open or close disc tray.
[ ]: Pause playback temporarily.
0 to 9 NUMBER BUTTONS: Direct-entry of
track or le number.
OFF: Switch OFF C 565BEE.
RAND: Play tracks/les in random mode.
RPT: Repeat track, le or whole disc.
RPT A-B: Setup repeat sequence.
DIM: Reduce, turn o or restore VFD brightness.
FILTER: Select lter number.
SKIP [ ] : Go to next track or le.
SKIP [ ] : Go to beginning of current track/
le or to previous track/le.
SCAN [ ]: Fast reverse/forward search.
[ ]: Start playback.
[ ]: Stop playback.
DISP: Show playback time and other display
information.
PROG: Enter or exit program mode.
CLEAR: Delete programmed track/le.
10
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ
CD-R AND CD-RW AUDIO DISCS
The C 565BEE can play back CD-R or CD-RW audio discs that have been
recorded on a computer or CD recorder. The quality of CD-R or CD-RW
audio discs varies widely which may aect playability. Some factors that
aect playability:
• The quality of the disc itself. Generally speaking, CD-R or CD-RW blanks
from well-renowned companies give better results than unbranded
ones.
• The quality of CD-recorder or computer CD re/writer. Some recorders
and writers produce better results than others.
• The CD-R and CD-RW were created with high-speed writing. In general,
the quality of a CD-R or CD-RW is better when produced at a lower
speed against a higher speed on the same recorder or re/writer.
PLAYING MP3/WMA FILES
The C 565BEE can play MP3/WMA formatted recordings on CD-R or CD-RW
discs. You may mix any of the le types on the disc. Using the CD 9 remote
control, one can select through the MP3/WMA folders and les as well as
start playback through the following steps
1 Load the applicable disc.
2 Press [FOLDER ] to select desired folder. Press [ENTER].
3 Press [FILE ] to select desired le number. Press [ENTER] to start
playback.
NOTES
• The le number is recognized per disc, not per folder – that is, the
number assigned to each le corresponds to their sequence in the disc.
• If you want to select le number “119” in a disc where there are 100 or
more MP3/WMA les, press “1” twice and then “9.”
• During disc playback, it is possible to select through the folder or le lists
(using [FOLDER ] or [FILE ] buttons) without interrupting the
current le being played back.
IMPORTANT NOTICE
Customers should note that permission is required in order to download
MP3/WMA les and music from the Internet. NAD ELECTRONICS
INTERNATIONAL has no right to grant such permission. Permission
should always be sought from the copyright owner.
PROGRAMMING
The program function enables you to store your favorite tracks from any
disc in the player memory. When programming a sequence of tracks, the
C 565BEE must be in STOP mode. Using the CD 9 remote control, enter your
desired program sequence through the following steps
1 Press [PROG]. The display indicates“P00 T000”. The “000”in the “T000” keeps
on blinking, meaning that the player is awaiting the rst Program entry.
2 Use the Direct-Entry numeric keypad buttons to enter the rst track
in your planned sequence. Upon entering the track number, the VFD
will briey show the total number and total time of the currently
programmed tracks like “01 3:25”.
3 The display will revert to show “P02 T000,” indicating that the player is
ready for your second program entry. Upon entering the second track,
the VFD will again briey show the total number and total time of the
currently programmed tracks like “02 6:45” – “02”indicates that there are
now a total of two programmed tracks and“6:45”is the total playback
time of both programmed tracks.
4 Repeat steps 2 and 3 to select and store other track numbers in
memory, up to a maximum of 40 entries. If you attempt to program
more than 40 tracks or les,“P-FULL” will be displayed in the VFD.
5 Press [PROG] to end or nalize the program – the VFD will show the last
programmed number and track.
6 Press [ ] to start playback of the rst programmed track. Rotate [PLAY/
PAUSE/SKIP] if you wish to SKIP forward/backward the programmed tracks.
NOTES
• Programming of MP3/WMA les is the same as above procedure except
that there will be no brief display of the total number and total time of
currently programmed les upon entering the desired le number to be
programmed (refer to item 3 above).
• If you want to select le number “119” in a disc where there are 100 or
more MP3/WMA les, press “1” twice and then “9.”
• Pressing [
] key at any time during the programming procedure will
put to a STOP to the sequence and clear all the currently programmed
tracks or les. VFD will revert back to displaying the total number of
tracks and total playback time for audio CD and total number of les for
MP3/WMA.
• Pressing [
] key twice during program playback will result to having
the whole program list deleted.
REVIEW/EDIT PROGRAM LIST
1 Initiate review of your programmed entries by pressing [PROG].
• If you are still in programming mode, press [PROG].
• If during program playback, press [ ] once, then [PROG].
2 The VFD will show the rst Program Number and the corresponding
“blinking” programmed track.
3 To change the programmed track of a particular sequence, use the
Direct-Entry numeric keypad buttons. Press [SKIP ] to move
forward or backward the programmed tracks as well as review the list
and change if so desired.
4 If you want to delete a particular program sequence during program
review, press [CLEAR] key.
5 After nalizing your program changes or completing your review, press
[PROG] again.
PROGRAM PLAYBACK
1 To play the stored program, press [ ] while you are in“PROGRAM”
mode. “PROG” icon will appear in the display, indicating that a stored
program is being played. During Program Play, the SKIP buttons will
access only the tracks in the program list.
2 If you want to play only a portion of a stored program, initiate play and
press SKIP to jump over the programmed tracks that you don’t want to
hear.
STOP OR DELETE PROGRAM
1 To terminate Program play, press [ ] once. The stored track list remains
in memory. If you want to play the program again, simply press [ ].
2 To clear the program memory, perform any of the following steps
• Press [ ] twice during program playback.
• Press [ ] to open the disc tray.
• Switch OFF the C 565BEE by pressing the Standby button.
• Switch to another source other than CD mode by pressing the front
panel’s [SOURCE] button or [USB} / [OPT} source buttons on the
CD 9.
OPERATION
USING THE C 565BEE CD MODE
11
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ
USB MODE
The C 565BEE can play back MP3/WMA les stored in external USB
(Universal Serial Bus) devices. The following are the C 565BEE’s capabilities
with respect to USB device playability.
USB SUPPLEMENTARY INFORMATION
Maximum number of folders supported 128
Maximum le in one folder 511
Maximum le in device 65408
Maximum number of sub-directory 8
Maximum number of bytes supported for Folder/File name 64
Maximum number of bytes supported for ID3 Title/Artist/Album 60
Maximum bit rate supported VBR, 320K
HDD handling capacity (additional power adapter maybe required for
some HDD models) FAT 16/32
USB version supported 1.1
LISTENING TO USB DEVICE
1 Toggle [SOURCE] button to select “USB” mode. If no external USB device
is connected to the front panel’s USB input, “No USB” will be displayed
in the VFD. If there are no applicable MP3/WMA les available in the
external USB, the VFD will show“USB Empty”.
2 Plug-in the external USB device to the USB input – “USB Reading”will be
blinking in the VFD and then the total number of les will displayed.
3 Press [ ] to start playback.
SELECTING DIRECTORIES OR FILES
The following are the steps on how to select a desired directory and MP3 or
WMA le at stop mode.
1 Connect the external USB device to the front panel’s USB input. Toggle
[SOURCE] button to select “USB” mode.
2 Press [FOLDER ] to select desired folder. Press [ENTER].
3 Press [FILE ] to select desired le number.
4 Press [ENTER] to start playback. Toggle CD 9’s [DISP] button to show
information about the current le. Refer also to the item about DISPLAY at
the FRONT PANEL section of the IDENTIFICATION OF CONTROLS page.
NOTE
Do not disconnect the USB ash drive during playback. It may cause
damage to the C 565BEE.
OPTICAL INPUT MODE
The C 565BEE is equipped with an optical digital input. This makes it
possible for other external digital sources to make use of C 565BEE as a top
quality digital-to-analog converter. The C 565BEE accepts audio data only at
this optical input port and can handle up to 192 kHz/24 bit signals.
LISTENING TO OPTICAL INPUT
1 Toggle [SOURCE] button to select “Optical Input” mode. If no source
component is connected at the rear panel OPTICAL DIGITAL AUDIO
IN port or if the source is not supplying a signal, the VFD will display
“UNLOCKED”. If the source supplies a non-valid data such as compressed
format, Dolby Digital or DTS audio signal, the VFD will display “Not
Support”; only audio data is supported.
2 When the C 565BEE detects a valid digital audio input, the VFD will
show the audio format and the current sample rate. Toggle CD 9’s [SRC]
button if you would like to change the sample rate of the input signal.
3 Audio available from the connected external digital source will now be
the active input.
OPERATION
USING THE C 565BEE USB AND OPTICAL INPUT MODE
12
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ
The CD 9 remote control is provided with your C 565BEE Compact Disc Player
to enable you to operate playback functions from the comfort of your chair or
from virtually anywhere in the room. For reliable operation, there should be a
clear line-of-sight path from the remote control to the front of the CD player. If
the player does not respond to remote commands, it may be that this line-of-
sight path is obstructed by clothing, paper or furnishings.
Most of the buttons on the remote control handset have the same eect as the
corresponding buttons on the front panel of the player. In addition, the handset
is equipped with some extra buttons like the following function keys.
NUMERIC KEY PAD
Using the direct-entry numeric keypad (0 to 9) causes the C 565BEE to jump
directly to the beginning of a numbered track and commence play. Thus, to
play Track 5, simply press “5”. To play Track 20, press “2” and “0”.
RPT A-B
To repeat a sequence, implement the following procedures:
1 Press [RPT A-B] at your chosen starting point. “REPEAT A B” is
illuminated in the VFD with “B” blinking.
2 Press [RPT A-B] again at your chosen end point. “REPEAT A B” stay
illuminated. The repeat sequence begins.
3 Press [RPT A-B] again to cancel the sequence.
DIM
Toggle to reduce, turn o and restore VFD brightness.
PROGRAM AND CLEAR
Use [PROG] button to start, review, edit or exit programming mode. In
combination with [PROG] button, the [CLEAR] button allows the deletion of
a programmed track during program review or edit sequence. Refer also to
the item about “PROGRAMMING”at the“USING THE C 565BEE – CD MODE”
section of the “OPERATION” page.
FILTER
The C 565BEE oers ve unique digital ltering options dedicated to the
achievement of a better audio experience. These selectable lters allow
users the exibility to choose key characteristics that aect frequency
response and time domain characteristics.
Before describing these ve digital lters, please take time to read the
following brief denitions of some of the terminologies used in their
descriptions.
• Passband is the range of frequencies or wavelengths that can pass
through a lter without being attenuated.
• A stopband lter rejects frequencies within a band and letting through
frequencies outside it.
• Group delay is the transit time of a signal through a device versus
frequency.
• Rollo is a term used to describe the steepness or slope of the lter
response in the transition region from the passband to the stopband.
• Ripple refers to uctuations in the passband or stopband of a lter’s
frequency magnitude response curve. It is the periodic oscillation in
the passband near the inection point of the lter (the point where the
passband meets the stopband).
The following is a brief description of each lter’s characteristics. The
selection of lter number is basically a matter of personal choice; tailor
the audio conversion by selecting the lter number that will best suit your
desired listening experience.
Filter 1: Slow roll o lter that has low group delay, low ripple and wide
stopband characteristics.
Filter 2: Medium roll o lter that has high group delay, low ripple and
medium stopband characteristics.
Filter 3: Fast roll o lter that has lower group delay and wider stopband
characteristics.
Filter 4: Medium roll o lter that has higher group delay and narrower
stopband characteristics.
Filter 5: Medium roll o lter that has lower group delay and wider
stopband characteristics.
NOTE
The lter eect applies only to the analog output; it is not applicable to
the digital outputs.
OPERATION
USING THE C 565BEE CD 9 REMOTE CONTROL
13
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ
CONDITION POSSIBLE CAUSES POSSIBLE SOLUTIONS
No power. The power cord is disconnected.
•
Plug the power cord into the wall outlet
securely.
•
The power is ON, but the C 565BEE does
not work.
No disc is inserted.
•
Insert a disc.
•
The C 565BEE does not start playback. The disc is loaded upside down.
•
Reload the disc with the label side UP.
•
The disc is too dirty.
•
Clean the disc.
•
No sound. The equipment connected with the audio
cable is not set to receive CD signal output.
•
Select the correct input mode of the audio
receiver so you can listen to the sound from
the C 565BEE.
•
The power of the equipment connected with
the audio cable is turned o.
•
Turn on the equipment connected with the
audio cable.
•
Sound skips. The C 565BEE is subject to vibration or physical
shock from external sources.
•
Change the installation location.
•
VFD shows“UNLOCKED” at Optical Input
mode.
No source component is connected at the rear
panel OPTICAL DIGITAL AUDIO IN port or the
connected source is not supplying a signal.
•
Connect source component at OPTICAL
DIGITAL IN port.
•
Ensure that the connected source is
supplying compatible audio signal via
C 565BEE’s OPTICAL DIGITAL IN.
•
The C 565BEE cannot be switched to
standby mode.
A mono plug is plugged-in at the +12V
TRIGGER IN port of the rear panel.
•
Unplug the mono plug.
•
The remote control does not work properly. The remote control is not pointed at the
remote sensor on the CD player.
•
Point the remote control at the remote
sensor of the CD player.
•
The remote control is too far from the CD
player.
•
Operate the remote control closer to the
CD player.
•
The remote control batteries are dead.
•
Replace the remote control batteries.
•
REFERENCE
TROUBLESHOOTING
NOTES ON DISCS
HANDLING DISCS
Do not touch the playback side of the disc. Hold the disc by the edges so that
ngerprints do not get on the surface. Never stick paper or tape on the disc.
STORING DISCS
After playing, store the disc in its case. Do not expose the disc to direct
sunlight or sources of heat and never leave it in a parked car exposed to
direct sunlight.
CLEANING DISCS
Fingerprints and dust on the disc can cause poor picture quality and sound
distortion. Before playing, clean the disc with a clean cloth. Wipe the disc
from the center out.
Do not use strong solvents such as alcohol, benzine, thinner, commercially
available cleaners, or anti-static spray intended for older vinyl records.
14
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ
GENERAL PARAMETERS
Output level - Analog 2.2 ± 0.1 V
Optical -22.5 ± 3.5 dBm
Coaxial 650 ± 150 mV
Frequency response ± 0.3 dB (ref. 0 dB 20 Hz-1 kHz)
± 0.5 dB (ref. 0 dB 5 kHz-20 kHz)
Total harmonic distortion < 0.01% (ref. 1 kHz)
Signal/Noise ratio 118 dB (A-weighted, ref. 1 kHz)
Channel balance ± 0.5 dB (ref. 0dB 1kHz)
Dynamic range > 95 dB
Channel separation > 90 dB
De-emphasis -3.73 to -5.33 dB (ref. 0dB 5 kHz)
-8.04 to -10.04 dB (ref. 0 dB 16 kHz)
Linearity ± 0.01 dB (ref. 1 kHz at -3 dB)
± 0.02 dB (ref. 1 kHz at -6 dB)
± 0.02 dB (ref. 1 kHz at -10 dB)
± 0.05 dB (ref. 1 kHz at -20 dB)
± 0.15 dB (ref. 1 kHz at -60 dB)
POWER CONSUMPTION
Rated power 18 W (ref. 230V AC 50 Hz; 120V AC 60 Hz)
Standby power < 1 W (230V version only)
< 0.7 W (120V version only)
Idle power < 15 W
DIMENSION AND WEIGHT
Unit Dimensions (W x H x D) 435 x 70 x 285 mm (Net)
435 x 86 x 293 mm (Gross)*
Net weight 5.2 kg
Shipping weight 6.6 kg
* - Gross dimensions include feet, extended buttons and rear panel terminals.
Specications are subject to change without notice. For updated documentation and features, please log onto www.NADelectronics.com for the latest
information about C 565BEE.
REFERENCE
SPECIFICATIONS
15
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ
www.NADelectronics.com
©2009 NAD ELECTRONICS INTERNATIONAL
A DIVISION OF LENBROOK INDUSTRIES LIMITED
All rights reserved. No part of this publication may be reproduced, stored or transmitted in any form without the written permission of NAD Electronics International
C 565BEE Manual 03/09
Safety
Instrudions
CAUTION: PLEASE READ
AND
OBSERVE ALL
WARNINGS
AND
INSTRUCTIONS GIVEN
IN
THIS LEAFLET, THE OWNER'S
MANUAL
FOR
THIS
UNIT
AND
THOSE
MARKED
ON THE
UNIT. RETAIN THIS LEAFLET
FOR
FUTURE REFERENCE.
ThiS
set
has
been
deSigned
and
manufactured to
assure
personal safety However. improper
use
can
result
in
electriC shock
or
fire
hazard.
The
safe-guards Incorporated in this unit will protect you if you
observe the following procedures
for
installation.
use
and servicing. This Unit
is
fully transistorized
and does not contain any parts that can
be
repaired by the
user.
Do
not remove the cabinet cover. or
you
may
be
exposed to dangerous voltages.
Refer
servicing to
Qualified servIce personnel
t.
After unpacking the unit, read the owner's manual carefully, and
follow all the operating and other instructions.
2.
This unit should be operated only from the type of power source
indicated
on
the unit or as indicated
in
the owners manual.
If
you
are not sure of the type
of
power supply
in
your home, consult
your sales person or your local power company. For equipment
designed
to
be
operated on battery power, refer to the operating
instructions.
3.
Do
not expose this unit
to
rain or use near water:- For example,
near abathtub, washbowl, kitchen sink, washing machine,
in
a
wet basement, or near aswimming pool.
4.
To mount the unit on awall or ceiling, follow the recommended
instructions
in
the owner's manual.
5.
Slots and openings
in
the cabinet and
in
the back or bottom pro
vide ventilation to prevent the unit overheating. For safety and to
ensure reliable operation of the equipment, these openings
should not be blocked or covered. They should never be covered
with acloth or other material, and the bottom openings should not
be
blocked
by
placing the unit on abed, sofa, rug or similar sur
face. Never place the equipment
in
afitted unit such as abook
case or cabinet that may impede the flow of air through the
ventilation openings.
6.
To.
prevent overheating, place the unit well away from heat
sources such as radiators, heat registers, stoves and
so
on, and
never place the unit
on
other equipment that produces heat, such
as power amplifiers.
7.
Power-supply cords should be routed so that they are not likely to
be walked
on
or pinched by items placed upon or against them,
paying particular attention
to
cords
at
plugs, convenience
receptacles, and the point where they exit from the appliance.
8.
Do
not overload wall outlets, extension cords, or the power outlets
on the unit, as this can result
in
afire or electric shock.
9.
Precautions should be taken
so
that the grounding or polarization
means of
an
appliance
is
not defeated.
to.An
appliance and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause
the appliance and cart combination to overturn.
EXAMPLE
Of
AN"TENNA
GROUNDING
AS
PER
NATIONAL
ELECTRICAL
CODE
ELECTRIC
SERVICE
EOU1Pl.l[Nl
__
NEC
-
NATlON.AL
EL£CTRIC"L
CODE
ANTENNA
LEAD
IN
WIRE
ANTENNA
DISCHARGE UNlT
(NEC SECTION
810-20)
Q
11.lf
an outside antenna is connected to the equipment, be sure the
antenna system is grounded so as to provide some protection
against voltage surges and built up static charges. Section 810 of
the National Electrical Code, ANSI/NFPA No. 70 -1984 provides
information with respect to proper grounding of the mast and sup-
porting structure, grounding of the lead-in wire to an antenna dis-
charge unit, size of grounding conductors, location of antenna dis-
charge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
a.
Use NO. 10 AWG (5.3 mm') copper,
NO.8
AWG (8.4 mm')
aluminum NO.
17
AWG (1.0 mm') copper-clad steel or bronze
wire, or larger, as aground wire.
b.
Secure antenna lead-in and ground wires to house with stand-off
insulators spaced from 4feet (1.22
m)
to 6feet (1.83 m) apart.
c.
Mount antenna discharge unit as close as possible to where lead-
in
enters house.
d. Use jumper wire not smaller than
NO.6
AWG (1.33 mm') copper,
or the equivalent, when aseparate antenna grounding electrode
is used. See NEC Section 810-21 (J)
12.
An
outside antenna system should not be located near overhead
power lines or electric light or power circuits, or where an accident
may allow the antenna system
to
touch power lines or circuits.
When installing an outside antenna system, take every. precaution
to prevent the possibility of touching apower line or circuits as
such contact can be fatal.
13. For added protection before and during alightning storm, or when
equipment
is
to
be left unattended and not used for along period
of time, unplug the equipment from the wall outlet and disconnect
the antenna. This will prevent damage to equipment that might be
caused
by
power line surges or
by
lightning attracted to the
antenna.
14.lf
an
indoor antenna
is
used (either built-into the set or installed
separately). never allow any part of the antenna to touch the
metal parts of other electrical appliances such as alamp, TV set,
etc.
15.When you want to use the unit with acart or stand, please consult
with your sales person about the proper cart or stand recom-
mended by the manufacturer.
To
use the unit on
an
unstable cart
or stand may result
in
an
injury
to
the person, damage to the unit,
or other dangerous conditions.
16.
Unplug the unit from the wall outlet before cleaning.
Never use benzine. thinner or other solvents for cleaning.
Use only asoft damp cloth.
17. Please take care that objects will not fall into the unit and liquids
are not spilled through the openings into the unit, to prevent
possible shock or fire hazard.
18. Unplug the unit from the wall outlet, and refer servicing
to
qualified service personnel under the following conditions.
a.
If
the power cord or plug
is
damaged.
b.
If
any object or liquid has entered the equipment.
c.
If
the unit has been exposed
to
rain.
d.
If
the unit does not appear to operate normally or exhibits
amarked change
in
performance.
e.
If
the unit has been dropped or the case damaged.
Do not attempt
to
service the equipment except as described in
the owner's manual. All other servicing may require extensive
work by aqualified technician.
19. Upon completion of any servicing or repairs, request the service
shop's assurance that only Factory Authorized Replacement
Parts with the same characteristics as the original parts have
been used, and that routine safety checks have been performed
to guarantee that the equipment
is
in
safe operating condition.
REPLACEMENT WITH UNAUTHORIZED PARTS MAY RESULT
IN
FIRE, ELECTRIC SHOCK, OR OTHER HAZARDS.
NAD
1995-11
PIN:N30301
057+2
Garantie
NAD Electronics of America
et
Lenbrook/NAD Canada garantissent que
la
presente composante est exempte
de
tout vice
de
materiau et
de
fabrication selon les
modalites suivantes :
Composantes
electroniques (preamplificateurs, amplificateurs, amplificateurs integres, syntoniseurs, processeurs
AN
et produits
AN
integres)
Composantes
electromecaniques (platines cassettes, lecteur
de
disques compacts et platines tourne-disques) 2ans, pieces
et
main-d'ceuvre
2ans, pieces
et
main-d'ceuvre
La
presente garantie est valide uniquement dans
Ie
pays
OU
Ie
produit aete achete et n'est pas transferable. Elle est offerte
en
exclusivite a
la
personne ayant effectue
I'achat, aI'origine, chez
un
depositaire agree
de
produits NAD. Seuls les depositaires agrees peuvent
se
presenter
en
cette qualite, et I'acheteur peut verifier la qualite
de depositaire agree
du
marchand
en
communiquant avec NAD/Lenbrook
au
numero suivant :1800263-4641.
Obligation
de NAD:
Si, pendant la duree
de
la garantie, la composante. NAD cesse de fonctionner correctement
en
raison d'un vice
de
fabrication, NAD/Lenbrook, aleur seule discretion,
repareront
ou
remplaceront celle-ci gratuitement.
Pour
une
reparation:
Pour faire reparer
Ie
produit, veuillez I'apporter, avec
la
facture
ou
Ie
coupon de caisse original, avotre depositaire
NAD.
Si
cet etablissement n'est pas
un
centre de
reparation NAD autorise,
il
vous indiquera
ou
se
trouve
Ie
centre
Ie
plus proche. Vous pouvez aussi appeler
au
1800 263-4641 pour connaltre I'emplacement
du
centre
de reparation NAD agree
Ie
plus proche.
Ce
qui
nous
payons:
Nous assumons tous les frais
de
main-d'csuvre et
de
materiaux des articles garantis, mais ne payons pas les frais d'expedition
si
vous devez faire parvenir
Ie
produit a
NAD/Lenbrook
ou
a
un
centre de reparation NAD agree.
Si
les reparations sont couvertes par la garantie, NAD/Lenbrook
ou
Ie
centre de reparation assumeront les frais
de transport pour
Ie
retour
de
votre produit.
Etendue
de la garantie:
La
presente garantie
ne
couvre par les composantes :
1.
endommagees dans
Ie
transport
ou
dans
un
cas
de
force majeure;
2.
soumises aune trop forte charge, utilisees
de
fa90n abusive, mal utilisees
ou
combinees a
un
equipement defectueux
ou
inapproprie
ou
encore utilisees d'une
maniere contraire aux directives donnees dans
Ie
manuel accompagnant
Ie
produit;
3.
reparees par
du
personnel non autorise;
4.
dont
Ie
numero
de
serie aete enleve
ou
altere.
LE
GARANT
NE
POURRA,
EN
AUCUNE CIRCONSTANCE, ETRE TENU RESPONSABLE POUR
LES
DOMMAGES ACCESSOIRES, qu'ils resultent de I'inexecution
d'une garantie explicite
ou
indirecte, d'un delit, d'une negligence
ou
d'une autre cause.
Certains etats et certaines provinces
ne
permettent pas I'exclusion
ou
la
limitation des dommages accessoires;
il
est possible que les limitations et exclusions ci-dessus
ne s'appliquent pas avous.
La
presente garantie vous accorde des droits reconnus par la loi.
II
se pourrait que vous
en
ayez d'autres, qui peuvent varier d'un etat
ou
d'une province aI'autre
ou
d'un pays aI'autre.
IMPORTANT:
La
garantie peut etre differente d'un pays a
un
autre.
Le
distributeur local ataus les details.
AVERTISSEMENT
NE CONFIEZ
PAS
LA REPARATION DU PRODUIT AUNE PERSONNE NON AUTORISEE. LES PIECES NECESSAIRES POUR VEILLER A
CE QUE VOTRE PRODUIT FONCTIONNE COMME AL:ORIGINE NE PEUVENT ETRE OBTENUES QUE
PAR
L:ENTREMISE DES
DEPOSITAIRES ET DES DISTRIBUTEURS AGREES. LA PRESENTE GARANTIE EST NULLE
SI
L:EQUIPEMENT AETE ALTERE OU
SI
DES PIECES INADEQUATES
ONT
ETE UTILISEES.
NAD Electronics of America, 6Merchant Street, Sharon, Massachusetts, 02067 Lenbrook /NAD Canada, 633 Granite Court, Pickering, Ontario L
1W
3K1
Formule
101
Rev. 3/98
Warranty
NAD Electronics of America and Lenbrook/NAD Canada warrants this component to be free from all defects
in
materials and workmanship as follows:
Electronic
components
(preamplifiers, amplifiers, integrated amplifiers, receivers, A/V processors, &integrated
AJV
products)
Electro-mechanical
products
(cassette decks, CD players &changers, turntables) 2years,
parts
&
labor
2years,
parts
&
labor
This warranty is valid only
in
the country of purchase. This warranty
is
non-transferable, and is valid for the first, original purchaser purchasing from
an
Authorized Dealer
of NAD products. Only Authorized Dealers represent themselves as such, and purchasers may confirm the status of Authorized Dealers
by
calling NAD/Lenbrook at 1-
800-263-4641.
What
we
will
do:
Should your NAD component fail to function properly due to amanufacturing defect, NAD/Lenbrook, at its sole discretion, will repair or replace it free of charge during ttie
warranty period.
How
to
obtain
service:
To
obtain warranty service, please bring your unit along with the original invoice or bill of sale to your NAD dealer. If he is not
an
authorized NAD service center he will
direct you to the nearest one or you may call 1-800-263-4641 for the location of the nearest NAD service center.
Note: The NAD warranty requires proof-of-purchase prior to any in-warranty repairs. Always retain your original sales slip.
What
we
will
pay
for:
We
will pay alJlabor and material expenses for covered items, but you must pay any shipping charges if it
is
necessary to ship the product to NAD/Lenbrook or to an
authorized NAD service center. If the repairs are covered by the warranty, NAD/Lenbrook or the service center will pay the return shipping charges.
What
is
not
covered:
This warranty does not cover acomponent which has been:
1.
Damaged
in
transit or by act of God;
2.
Overloaded, abused, misused, or operated with faulty or unsuitable equipment, or contrary to instructions contained
in
the accompanying product manual;
3.
Serviced by unauthorized personnel;
4.
The serial number has been altered or removed.
IN
NO EVENT SHALL THE WARRANTOR BE LIABLE FOR INCIDENTAL, OR CONSEQUENTIAL DAMAGES, whether damages result from breach of express or implied
warranties, tort, negligence, or otherwise.
Some states(provinces) do not allow exclusion or limitation of incidental or consequential damages so the above limitation or exclusion may not apply to you. This
warranty gives you specific legal rights, and you may also have other rights which vary from state(province) to state(province) or between countries.
IMPORTANT: Warranty
in
other countries may
vary.
Contact your local distributor for details.
WARNING
DO NOT ENTRUST ANY REPAIR WORK TO UNAUTHORIZED PERSONS. THE COMPONENTS NECESSARY
TO
MAINTAIN THE
ORIGINAL PERFORMANCE OF THIS PRODUCT ARE AVAILABLE ONLY THROUGH AUTHORIZED DEALERS AND DISTRIBUTORS. THE
WARRANTY WILL
BE
INVALIDATED IF THE EQUIPMENT
IS
TAMPERED WITH
OR
INCORRECT PARTS ARE SUBSTITUTED.
PIN:
3030-1225+1
NAD Electronics of America, 6Merchant Street, Sharon, Massachusells, 02067 Lenbrook /NAD Canada, 633 Granite Court, Pickering, Ontario L1W 3K1
Form
101
Rev.
3/98
Other manuals for C565BEE
2
This manual suits for next models
1
Table of contents
Other NAD CD Player manuals
