DESCRIPTION
GEM-RECV-XP8 receiver Is the hardwired interface to
Napco'sWireless-Ready,.
XP-Serles and GEM-P800 Con-
trol
Panels. The wireless system comprises an XP-400: -
XP-600 or GEM-P800 panel, at least one GEM-RECV-XP8
receiver and one or more companion transmitters. The
transmitters may be wireless smoke detectors, space-
protection devices, window/door sensors, orotherdevices
that report
zone status and supervision information to the
receiver withoutthe use of wires.
THE GEM-RECV-XPB RECEIVER
The GEM-RECV-XPB wUI accommodate up to 8wireless
transmitters, 4
GEM-SMK wireless smoke detectors, and 4
GEM-KEYF Key-Fob transmitters. The receiver is con-
nected to the keypad 3-wlre bus. The receiver monitors
each transmitter, updatingtransmltterstatus as reports are
received, and conveysthis information to thecontrol panel.
Also monitored is the elapsed timesincethelastreportfrom
each transmitter. If no report
Is received within a
programmed
time, the panel wDI issue aSupervisoryFailure
system trouble.
COMPATIBLE TRANSMITTERS
Any ofthe following Napea wireless transmitters may be
used with the GEM-RECV-XP8 receiver.
• GEM-TRANS2 Window/Door Sensor. This super-
vised, two-point transmitter provides an Internal mag-
netic reed switch and/or terminals for one or two
external normally-closed devices.
• GEM- TRANS4Window/Door Sensor. As above, but 4
points.
• GEM-PIR. Dual-element passive infrared sensor. -
•
GEM-DT. Dual-technology PIA/microwave sensor.
• GEM-SMKSmokeDetector.Supervisedsmokedetec-
tor.
• GEM-KEYF Key Fob Transmitter. Keychaln/pendant
remote arming or emergencytransmitter.
• GEM-GB. Glass-break sensor.
SPECIFICATIONS, GEM-RECV-XP8 Receiver
Operating
Temperature: ooc to 49"C
Storage Temperature: -20°Cto +85°C
Power Requirements: 12Vdc, SOmA (supplied by panel)
'Mreleu Ready .. Ia a trademark of Napco Security Systems, Inc.
IINSTALLATION INSTRUCTIONSI
GEM-RECV-XPS
Wireless Receiver for
XP-Series and GEM-PSOO
Control Panels
WI848A 10/96
Antenna: t/4-wave (4)
Dimenslo. ns: 6" x 3511" x 1112" (HxWxD, less mountingtabs)
ORDERING INFORMATION
Note: Batteries are induded with all transmitters.
GEM-RECV-XP8 8-Polnt Receiver/Interlace with four
GEM-DT
GEM-GB
GEM-KEYF
GEM-PIR
GEM-SMK
GEM-TRANS2
GEM-TRANS4
DL123A
antennas
Dual-technology PIRJMicrowave sensor
Glass-Break Detector
Hand-Held
Key Fob Pendant/Keychain
Panic Button
Passive Infrared Transmitter
Supervised Smoke Detector
2-Point Window/DoorTransmitter
4-Polnt Window/DoorTransmitter
Replacement Lithium Battery for GEM-
TRANS2, GEM-PIR (2) and GEM-
GB (2) (bulk packed)
INSTALLATION
Designing the System
In planning the layout of the system, give careful con-
sideration to the location of the receiver. Regardless of
wherethe control
panel Is mounted, the receiver should be
centrallylocated Within thepremises, that Is, approximately
equally distant from
all transmitters. Choose a location as
high above ground level as practical (attic Installations are
not recommended), keeping In mind that metal objects may
adversely affect reception Draw a layout of the system,
Identifying all proposed transmitterlocations and anticipated
receiver location Also Include notations Indicating construc-
tion materials
In use. Although wood and wallboard con-
struction wUI have little effect upon signal strength at the
receiver, concrete or brick can reduce signal strength by
up to 35%, while steel-reinforced concreteor metal lath and
plaster can reduce transmitter strength as much as 90%.
In installationswhere distanttransmitters pose reception
problems, two receivers (maximum)
may be used. The
panelwill respond toreceiverwiththestrongersignal. Both
receivers areconnected tothe panel's3-wlre bus, butthey
must
be addressed differentlysothattheycanbeIdentified
bythe control panel. This Is accomplished bythe placement
of jumper JP1 atthe lower-left comer of the board. Refer to

the Wiring Diagram for jumper configuration.
·Note: Each receiver leaves the factory internally con-
figured as #1 .Therefore, ifonlyone receiver is being used,
address assignment
is not required.
Mounting and Wiring the Receiver
Allowing at least 9" at the top and 6" at the bottomforthe
antennas, mountthe receiver using
two screws suitablefor
the surface through the
two mounting holes in the rear
cover (see Wiring Diagram). Using3-conductorcable, wire
the receiver to the control panel in accordance with the
following table.
. GEM-RECV-XP8 XP-SERIES/GEM-PSOO CONTROL PANEL
' 1
(+)
9 (REMOTE POWER +)
2 (-)
10 (REMOTE POWER -)
3 (DATA)
11 (GREEN)
Table 1. GEM-RECV-XPS terminal connections to the panel.
GETTING UP AND RUNNING
Referring
to the installation and programming instruction
manuals for the control panel, enter
• the programming block number of the zone to which
the transmitter will be mapped,
• the?-digit RF ID Number (6 -digitcode:1-digitchecksum
number) printed on the transmitter.After the lastdigit
is
entered, the keypad will beep.
• the wireless point number.
Note: When programming the
RF ID Number at the
keypad, press
(*][1] for "A"
press [*1[2] for "B"
press [*][3] for "C"
press [*](4]for "D"
press (*]{5] for " E"
press [*][6] for "F".
Press (ON/OFF] to save. Press NEXT to continue.
i
Key Fob Transmitters. Referring to the programming in-
structions for the control panel, enter the following:
• an assigned Key Fob Transmitter number (1 -4);
• the ?-digit hexadecimal RF ID number printed on the
transmitter (enter
all numbers and/or letters, including
leading zeros,
if any);
• Aux. 1 options (see programming worksheets)
CHECKING TRANSMITTERS
.The transmitter will send a report whenever it
is tripped.
It will also send a supervisory transmission about once
every hour. If the receiver does not receive a report within
a programmed time, an
RF Supervisory Failure will be
indicated at the keypad.
Signal Strength. The signal strength of any transmitter
can be determined in the Fault-Find mode, as follows.
(a) Press (*] [7] to enter the Fault-Find mode.
(b) The keypad will give a visual and audible indication of
signal strength as shown in Table 2.
Note: After the audible indication times out, a ZONE LED
will light to indicate the zone to which the transmitter is
mapped.
2
VISUAL AUDIBLE SIGNAL
(ZONE LEOs) (KEYPAD TONE) STRENGTH
NONE 1
V4-SEC. BEEP
30R LESS
ZONE 1 ON
1 1-SEC. BEEP 4
ZONES 1 &20N
2 1-SEC. BEEPS 5
ZONES 1- 30N
31-SEC: BEEPS 6-7
ZONES 1-4 ON 4 1-SEC. BEEPS
8-10
Table 2. Keypad Indications of signal strength.
WIRELESS SYSTEM TROUBLES
A system trouble will cause the yellow
..; SYSTEM LED to
come on and the keypad
to sound a double-beep, which
will repeat everyten seconds. Wireless system troublesare
shewn in Table 3. To identify the system trouble,
(a) Pressthe [v] Button;the yellowvSYSTEM LED will flash
(with keypad sounder) and one
or more Zone LEOs will
come on.
(b) Countthe number of vSYSTEM LED flashes (orbeeps).
(c) Note the ZONE LED(s) that are on.
(d) Find the condition from Table 3.
v'SVSTEM LED ZONE LED(s) SYSTEM TROUBLE
(#FLASHES) ON CONDITION
·-·· .
2 3 Receiver tamper or data failure.
2 4 Receiver jam.
3
H)
Transmitter low battery on
zone(
s) indicated.
4 1-6 Transmitter superyisory failure on
zone(s) indicated.
5
1-4 Low battery, smoke detector 1-4.
6
1-4 Supervisory failure, smoke detec-
tor 1-
4.
7 1-6 Wireless tamper; GEM--DT Self-
test failure.
Table 3. Wireless System
Troubles
Note: Ifa low-battery condition is indicated and all trans-
mitters were installed at the same time, it is recommended
that
all transmitterbatteries be replaced to avoid callbacks.
RECEIVER LED INDICATIONS
Red LED (DS1)
Functions of the red LED are shown in Table 4 below.
RED LED RECEIVER CONDITION
-
OFF No power.
ON
Powered, but not communicating with panel.
FLASHING Powered and communicating with the panel.
Table 4. Red LED Indications.
Green LED (DS2)
The green
LED will flash while receiving a transmission
having a strength
of 4 or greater, indicating a signal of
sufficient strength. Caution: A
green LED display with no
transmitters in operation is a sign of high ambient rf inter-
ference.
If the green LED remains lit continuously, relocate
the receiver.

MOUNTING HOLE (2) - --->H
rr TAMPER
Ur SWITCH
ADDRESS JUMPER ---- ---1~~i--------------~
ONLY REQUIRED IF MORE
THAN ONE GEM-RECV-XP8 IS USED .
(IF NO JUMPERS INSTALLED.
DEFAULTS
TO "1''.)
RECEIVER NO . CONFIG .
2
TO
3-WIRE
KEYPAD
BUS
2 3
ANTENNA
(4)-f
GREEN
LED
DSl
0
GEM-RECV-XP8
WIRING DIAGRAM
r.-~.t ... V No ' ......,No' o''i'<VY ,...,.,.... '•V oW•W•W.Y..- .-~·,. vM"h Vo'O ...... ~.y_,.,. , . , •~•.-.-.• ... -.• ... ... •, -. v.- ... •,·,v,-.·,f,,,_.,.,..,,.,._.,._,,,vhv~v.-.v,-.•.-,•,v.-,•,.,• ,._.,. , ., ., ._.,.i'>'•',.....i"Ho ' "N.-No'N,•,• ...• .v, ·,v,-.•.!' oV _.,,,,,,...,,,_.,,,,•,y,-.v,-.v,.,..-, .., • .,.. , ,.h.,. ,V.Vo' ........... ' o"•'•'•'• '•'•'V•"•'V• ' '_.,..,,...,,,., v,• , v ,-.•,,-. .,. .._ . , .,,,,. , .._.,. , ,,.l'o'. ',"o'' -'•' '.- ,, . _.~
~ '
~ Caution: This equipment generates and uses radio-frequency energy. If not installed using conventional installation practices for rf devices, it ~
~ may cause interference to radio and television reception. It has been type tested and found to comply with the limits for a Class B computing ~
~ device in accordance with the specifications in Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against ~
~~ such interference.However, there isnoguaranteethatinterferencewillnotoccurin aparticularinstallation. If it hasbeenfoundtocause Interference ~
to radio or television reception, which can be determined by removing and reapplying ac and battery power to the equipment, the Installer is ~
I encouraged
to try to correct the Interference by one or more of the following measures: reorient the receiving antenna; connect the power ~
transformerto a differentoutleteo that the control panel andradio or television receiver are on differentbranchcircuits; relocatethe control panel ~
, with respect to the radio or television receiver. ~
< l
l .. Y.Y ... YAV A O, •,._ ...............,...WAY'N<.ilo'VN..... •.• .-,• .y , ,y,-. y_.,, , ... ._._., .... _.,y,o,y,•,y,y .. ,V ..... •................., .. . .......V ... '"•''"" ' '•V"•'.... o',• lo .. Y o'• '•'•'o" .. ...... ... I.' ... Y ..........,............. ... V. ,...........,, ... ..,,,,_.,,, ......._.,._._.,, ... ,, , ,., ... _... _. .. ,, ..............., ................. ... ...... , .. _.,,,,.,o,.,._,_..._,,.,,,_.,y,•,, o, ,,_. , ~, ......,.....,_.,,.,.,,,_. ... ,_.,y..,,,_.,,,• ,•o.'J ... \Yo\'' ...........' ...... ' o' ... '.'·V•'•V......,;1
3

NAPCO LIMITED WARRANTY
NAPCO SECURITY SYSTEMS, INC. (NAPCO) war-
rants Its products
to be free from manufacturing
defects in materials and workmanship for thirty-six
monthsfollowingthedate of manufacture. NAPCO will,
within said period, at its option, repair
or replace any
product failing
to operate correctly without charge to
the original purchaser or user.
This warranty shall not apply to any equipment,
or
any part thereof, which has been repaired by others,
improperly installed, improperlyused,abused,altered,
damaged, subjected
to acts of God, or on which any
serial numbershave beenaltered, defaced orremoved.
Seller will not be responsible for any dismantling or
reinstallation charges.
THERE ARE NO WARRANTIES, EXPRESS OR IM-
PLIED, WHICH EXTEND BEYOND THE DESCRIPTION
ON THE FACE HEREOF. THERE IS NO EXPRESS OR
IMPLIED WARRANTY OF MERCHANTABILITY OR A
WARRANTY OF FITNESS FOR A PAR-TICULAR PUR-
POSE. ADDITIONALLY, THIS WARRANTY IS IN LIEU
OF ALL OTHER OBLIGATIONS OR LIABILITIES ON
THE PART OF NAPCO.
Any action for breach of warranty, including but not
limitedtoanyimpliedwarrantyof merchantability, must
be brought within the six months following the end of
the warranty period.
IN NO CASE SHALL NAPCO BE
LIABLE TO ANYONE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS OR
ANY OTHER WARRANTY , EXPRESS OR IMPLIED,
EVEN IF THE LOSS OR DAMAGE IS CAUSED BY THE
SELLER'S OWN NEGLIGENCE OR FAULT.
or to assume for it, any other warranty or liability
concerning its product$._
In no event shall NAPCO be liable for an amount in
excessofNAPCO'soriginal selling priceoftheproduct,
for any loss or damage, whether direct, indirect, in-
cidental, consequential,or otherwise arising out ofany
failure ofthe product. Seller'swarranty,
as hereinabove
set forth, shall not be enlarged, diminished
or affected
by and no obligation or liability shall arise
or grow out
of Seller's rendering of technical advice
or service in
connection with Buyer's order of the goods furnished
hereunder.
NAPCO RECOMMENDS THAT THE ENTIRE SYS-
TEM BE COMPLET EL Y TESTED WEEKLY.
Warning: Despite frequent testing, and due to, but
not limited to, any or
all of the following; criminal
tampering, electrical
or communications disruption, it
is possibleforthe system tofail toperformasexpected.
NAPCO does not represent that the product/system
may not
be compromised or circumvented; orthat the
product or system will prevent any personal injury
or
property loss by burglary, robbery, fire or otherwise;
nor that the product or system will
in all cases provide
adequate warning or protection. A properly installed
and maintained alarm mayonly reduce risk ofburglary,
robbery, fire or otherwise but it
is not insurance or a
guarantee that these events will not occur. CONSE-
QUENTLY, SELLER SHALL HAVE NO LIABILITY FOR
ANY PERSONAL INJURY, PROPERTY DAMAGE, OR
OTHER LOSS BASED ON A CLAIM THE PRODUCT
FAILED
TO GIVE WARNING. Therefore, the installer
i) In case of defect, contact the security professional should in turn advise the consumer totake any and all
·_,:._f_,:_:_,· whdo intstalled ~nd tmh aintains yt outrhsecuodrity stystemt . bin precautions for his or her safety including, but not
· or er o exerc1se e warran y, e pr uc mus e limited to,fleeing the premises and calling police orfire
returned by the security professional, shipping costs department, in order to mitigate the possibilities of
:;
/1
\\
I
prepaid and insured to NAP CO. After repair orreplace- harm and/or damage.
ment, NAPCO assumes the cost of returning products
i:i
~ ~h~~~=~~~~~Y~~~ih~~~=:ll i~~~: n~r~~~;~t~~~ u~~:~ sa~~~~7t~~ :~!r~snf~:i~~e~r ~;~~~~~!~~ a~~o~~~ ~~ II
~ · d b th · 1 • t 11 d · 1 liability for any loss or damage including incidental or ili
ili repa1re y o ers, Impropery ms a e , Improper y
:; ~s~, a~used, ~t~edtl damag~d, :~:cted to ah~c~ ~~~!e~u:~~~~r:~~~=~at~l~s~~~~~ :~~:
1
0
~~~~~ ~.r_t_:
, _ !~:. a~~ 's~~i:la~~~b~rs ·h::e o~=~ns ~ltered: ~e~;c:d ~~r loss or damage. l:
.. removed. NAPCO will not be responsible for any dis- Some states do not allow limitations on how long an
\f: mantling, reassembly or reinstallation charges. implied warranty lasts or do not allow the exclusion or )\
~ ~ Thiswarrantycontains the entirewarranty.ltisthe limitation of incidental or consequential damages, or
''' sole warranty and any prior agreements or repre- differentiate in their treatment of limitations of liability
~ sentations, whether oral or written, are either for ordinary or gross negligence, so the above limita-
~ merged herein or are expressly cancelled. NAPCO tions or exclusions maynotapplytoyou.ThisWarranty
if: neither assumes, nor authorizes any other person gives you specific legal rights and you may also have
Ipurporting to act on its behalf to modify, to change, other rights which vary from state to state.
*:·:- : ·~:·:·:>:~·:>Y. • :•X • > : .O: · :•:-:-:<•:•X•:> :.O:.;:·:-:~:<:•!·: -=--·:O:.::·:O: • > : ·:·~!- ! •!O:•~!O::{>:.O:•!•:.o:-:-:•:•:-:•:> : •:•:·:• :-:<•:<-:•!·!O:•:O: • :•:. : •:-:.-:•:-:O:•>:•! •!•: •:·:<•XO:•!•:-:·:·X•!•!•:·X•!•!·!•:O:·:•:>:<·»:·:·:·:>:•:•:.:•: • :.:·:•:<•:•;.:.:•:·:<•:·:•:•:·:•!•:•: .. .-:.:•!·:•:•:·:•:·:·:•:·:·:•:-:•:•:<·!·:-:-;.;-:-;.:.:: · :•:•:-:•: · :"..->:-:.;..:,.;.;.;. ;. ;.:•:«-:•: .... :.:<:•! •!•!·! •!•:-:·:•:•:(•XO:•X•!•:·;.;.:.,;v:...:~:...: . : • :-:;;·:-:-:•:-X · :•:.:-:._,:-:.; • >:<·:.:«-:-:·:·:•:·:·:•:·:.:•:·:<·!•!< • !•:if:
