AVR 140 REAR-PANEL CONNECTIONS
NOTE: To assist in making the correct connections for
multichannel input, output and speaker connections, all
connection jacks and terminals are color-coded in
conformance with the latest CEA®standards as follows:
Front Left: White
Front Right: Red
Center: Green
Surround Left: Blue
Surround Right: Gray
Surround Back Left: Brown
Surround Back Right: Tan
Subwoofer: Purple
Digital Audio: Orange
Composite Video: Yellow
Component Video “Y”: Green
Component Video “Pr”: Red
Component Video “Pb”: Blue
¡FM Antenna Jack
™CD Audio Inputs
£Tape Outputs
¢Tape Inputs
∞Subwoofer Output
§Front Speaker Outputs
¶Surround Back Speaker Outputs
•Surround Speaker Outputs
ªCenter Speaker Outputs
‚Component Video Monitor Outputs
⁄Component Video 1 Inputs
¤Component Video 2 Inputs
‹AC Power Cord
›Switched AC Accessory Outlet
fiUnswitched AC Accessory Outlet
flOptical Digital Audio Output
‡Coaxial Digital Audio Output
°S-Video Monitor Output
·Coaxial Digital Audio Inputs
aDVD S-Video Input
bDMP Connector
cVideo 1 S-Video Input
dOptical Digital Audio Inputs
eVideo 1 S-Video Output
fVideo 2 S-Video Input
g6/8-Channel Direct Inputs
hVideo Monitor Output
iDVD Audio/Video Inputs
jVideo 1 Audio/Video Inputs
kVideo 1 Audio/Video Outputs
UVideo 2 Audio/Video Inputs
VAM Antenna Terminals
